M250N Multi-Band GSM/EDGE/UMTS/LTE Phone with... - FCC ID ZNFM250N

FCC ID ZNFM250N

SAR Test Setup Photographs

Multi-Band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN, and NFC

by LG Electronics USA, Inc.

Document preview loads when visible.

Document Details

FCC IDZNFM250N
Document ID3240942
Document TypeTest Setup Photos
DescriptionSAR Test Setup Photographs
Document Title© 2001 PCTEST Engineering Lab
ApplicantLG Electronics USA, Inc.
Equipment ClassMulti-Band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN, and NFC
Product CodeM250N
Application IDpvlObYLlTJVoQV3xuNFZ9w==
Application PurposeOriginal Equipment
Application Date2016-12-28
Frequency Range2402-2480 MHz
FRN0020917688
Test FirmHCT Co., Ltd.
Certified ByKyung-Su Han
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date03/24/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2016-12-27
Available2017-03-24
Created2017-12-20
Modified2017-12-20
Pages15
File TypeAdobe Acrobat PDF
File Size422921
File SHA-25621e9df824bfcb42b53cdc493ed9423a420bcc3f56e79a27e9a4e144c5f3de31d
PDF Metadata Author박근호
PDF Metadata ProducerGPL Ghostscript 9.18 박근호
FCC.gov SourcesFCC.gov 3240942, FCC.gov 3240913
