UN220 Multi-Band CDMA/GSM/EDGE/UMTS/LTE Phone... - FCC ID ZNFUN220

FCC ID ZNFUN220

Internal Photographs

Multi-Band CDMA/GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN

by LG Electronics USA, Inc.

Document preview loads when visible.

Document Details

FCC IDZNFUN220
Document ID3468063
Document TypeInternal Photos
DescriptionInternal Photographs
ApplicantLG Electronics USA, Inc.
Equipment ClassMulti-Band CDMA/GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN
Product CodeUN220
Application IDqKCpRnLj3Xj7289tVEv5EQ==
Application PurposeOriginal Equipment
Application Date2017-07-18
Frequency Range2402-2480 MHz
FRN0020917688
Test FirmPCTEST Engineering Laboratory, Inc.
Certified ByKyung-Su Han
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date11/10/2017
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2017-07-17
Available2017-11-10
Created2017-07-11
Modified2017-07-12
Pages7
File TypeAdobe Acrobat PDF
File Size979029
File SHA-256f708800925103ea9f5cc84084cdeca1f78e518cb589b57084ff577e7f5c8b3c4
PDF Metadata ProducerAcrobat Distiller 17.0 (Windows)
