FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
REVISION HISTORY
The revision history for this document is shown in table.
Report No.
Issue Date
Information About Changes
HCT-EM-1801-FC001
January 03, 2018
Initial Release
Reissue of Report No. HCT-E-1711-F005
Changed the additional model name
HCT-EM-1801-FC001-R1
January 05, 2018
Added Additional Model Name
F-TP22-03 (Rev.00)
2 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
TABLE OF CONTENTS
PAGE
1. GENERAL INFORMATION .......................................................................................................... 4
1.1 Description of EUT .................................................................................................................... 4
1.2 Related Submittal(s) / Grant(s) .................................................................................................. 5
1.3 Test Facility ................................................................................................................................ 5
1.4 Calibration of Measuring Instrument ......................................................................................... 5
1.5 Tested System Details ................................................................................................................ 6
1.6 Cable Description ....................................................................................................................... 7
1.7 Noise Suppression Parts on Cable. (I/O Cable) ......................................................................... 7
2. MEASUREMENT UNCERTAINTY .............................................................................................. 8
3. DESCRIPTION OF TEST ............................................................................................................... 9
3.1 Measurement of Conducted Emission ........................................................................................ 9
3.2 Measurement of Radiated Measurements ................................................................................ 10
4. PRELIMINARY TEST .................................................................................................................. 12
4.1 Conducted Emission Test ......................................................................................................... 12
4. 2 Radiated Emission Test ........................................................................................................... 12
5. CONDUCTED AND RADIATED EMISSION TEST SUMMARY ............................................. 13
5.1 Conducted Emission Test ......................................................................................................... 13
5.2 Radiated Emission Test ............................................................................................................ 20
6. LIST OF TEST EQUIPMENT....................................................................................................... 22
7. CONCLUSION .............................................................................................................................. 23
APPENDIX A_TEST SETUP PHOTOGRAPHS ............................................................................. 24
F-TP22-03 (Rev.00)
3 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
1. GENERAL INFORMATION
1.1 Description of EUT
Its basic purpose is used for communications.
FCC ID
ZNFX210APM
Model
LM-X210APM
Additional Model
LMX210APM, X210APM, LM-X210CM, LMX210CM, X210CM,
LM-X210CMR, LMX210CMR, X210CMR
EUT Type
GSM/WCDMA/LTE phone with Bluetooth and WLAN
TX Frequency
824.20 MHz to 848.80 MHz (GSM 850)
1 850.20 MHz to 1 909.80 MHz (GSM 1 900)
1 852.4 MHz to 1 907.6 MHz (WCDMA B2)
1712.4 MHz to 1752.6 MHz (WCDMA B4)
826.40 MHz to 846.60 MHz (WCDMA B5)
1 850 MHz to 1 910 MHz (LTE B2)
1 710 MHz to 1 755 MHz (LTE B4)
824 MHz to 849 MHz (LTE B5)
699 MHz to 716 MHz (LTE B12)
2 402 MHz to 2 480 MHz (Bluetooth)
2 412 MHz to 2 462 MHz (WiFi 2.4 GHz)
RX Frequency
869.20 MHz to 893.80 MHz (GSM 850)
1 930.20 MHz to 1 989.80 MHz (GSM 1 900)
1 932.4 MHz to 1 987.6 MHz (WCDMA B2)
2 112.4 MHz to 2 152.6 MHz (WCDMA B4)
871.40 MHz to 891.60 MHz (WCDMA B5)
1 930 MHz to 1 990 MHz (LTE B2)
2 110 MHz to 2 155 MHz (LTE B4)
869 MHz to 894 MHz (LTE B5)
729 MHz to 746 MHz (LTE B12)
2 402 MHz to 2 480 MHz (Bluetooth)
2 412 MHz to 2 462 MHz (WiFi 2.4 GHz)
F-TP22-03 (Rev.00)
4 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
1.2 Related Submittal(s) / Grant(s)
Original submittal only.
1.3 Test Facility
Test site is located at 74, SEOICHEON-RO, 578BEON-GIL, MAJANG-MYEON, ICHEON-SI,
GYEONGGI-DO, SOUTH KOREA. Those measurement facilities are constructed in conformance with
the requirements of ANSI C63.4-2014.
Measurement Facilities
Registration Number
Radiated Field strength measurement facility
3 m Semi Anechoic chamber
Radiated Field strength measurement facility
10 m Semi Anechoic chamber
90661 (July 07, 2015)
1.4 Calibration of Measuring Instrument
The measuring equipment, which was utilized in performing the tests documented herein, has
been calibrated in accordance with the manufacturers recommendations for utilizing calibration
equipments, which is traceable to recognized national standards.
Espectially, all antenna for measurement is calibrated in accordance with the requirements of C63.5 (Versi
on : 2006).
F-TP22-03 (Rev.00)
5 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
1.5 Tested System Details
All equipment descriptions used in the tested system (including inserted cards) are:
Device Type
Model Name
Serial Number
Manufacturer
FCC ID / DoC
EUT
LM-X210APM
LG
ZNFX210APM
Data cable
EAD62377922
KSD
Data cable
EAD62377927
Earphone
EAB64168751
I-Sound
Notebook PC
ProBook6560b
5CB2053MXF
HP
DoC
Notebook PC
adaptor
Series PPP009L-E
LITE-On
Technology
RJ45 cable
Gateway
TL-WR747N
TP-LINK
Gateway adaptor
T120150-2H1
TP-LINK
02031069
Radio shack
FSUGMZE3
SanDisk
Serial mouse
Micro SD card
F-TP22-03 (Rev.00)
Serial 2 button
mouse
SanDisk Extreme
32 GB SD Card
Ningbo
6 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
1.6 Cable Description
Power Cord
Shielded (Y/N)
I/O Cable Shielded
(Y/N)
(P,D)1.0
Earphone
N/A
(D)1.2
RJ 45
N/A
(D)1.6
Serial (Mouse)
N/A
(D)1.8
DC in
N/A
(P)1.8
DC in
N/A
(P)1.8
Product Name
EUT
Notebook PC
Gateway
Port
Micro USB
Length (m)
* The marked “(D)” means the data cable and “(P)” means the power cable.
1.7 Noise Suppression Parts on Cable. (I/O Cable)
Ferrite Bead
(Y/N)
Location
Metal Hood
(Y/N)
Micro USB
N/A
Both End
Earphone
N/A
EUT End
RJ 45
N/A
N/A
Serial (Mouse)
N/A
Notebook PC
End
Product Name
EUT
Notebook PC
F-TP22-03 (Rev.00)
Port
7 / 24
Location
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
2. MEASUREMENT UNCERTAINTY
The measurement uncertainties shown below were calculated in accordance with the requirements
of ANSI C63.4-2014.
All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a 95 %
level of confidence. The measurement data shown herein meets or exceeds the UCISPR measurement
uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly to specified limits to
determine compliance.
Parameter
Expanded Uncertainty (dB)
Conducted Emission (0.15 MHz to 30 MHz)
1.82 dB (k = 2)
Radiated Emissions (30 MHz to 1 GHz)
5.20 dB (k = 2)
Radiated Emissions (1 GHz to 18 GHz)
5.24 dB (k = 2)
Radiated Emissions (18 GHz to 40 GHz)
5.40 dB (k = 2)
F-TP22-03 (Rev.00)
8 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
3. DESCRIPTION OF TEST
3.1 Measurement of Conducted Emission
The test procedure was in accordance with ANSI C63.4-2014, Clause 7.3
a. The EUT was placed 0.4 meters from the conducting wall of the shielded room with EUT being
connected to the power mains through a line impedance stabilization network (LISN).
If the EUT is connected to the PC through USB, the AC power-line adapter of the PC is directly
connected to a line impedance stabilization network (LISN).
Other support units were connected to the power mains through another LISN. The two LISNs provide
50 Ohm/ 50uH of coupling impedance for the measuring instrument.
b. Both conducted lines are measured in Quasi-Peak and Average mode, including the worst-case
data points for each tested configuration.
c. The frequency range from 150 kHz to 30 MHz was searched.
[ Conducted Emission Limits ]
Frequency
(MHz)
0.15 to 0.5
Resolution Bandwidth
(kHz)
Quasi-Peak
(dB(μV))
Average
(dB(μV))
66 to 56*
56 to 46*
0.5 to 5
56
46
5 to 30
60
50
*Decreases with the logarithm of the frequency.
F-TP22-03 (Rev.00)
9 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
3.2 Measurement of Radiated Emission
The test procedure was in accordance with ANSI C63.4-2014, Clause 8.3
a. The EUT was placed on the top of a turn table 0.8 meters above the ground at a semi-anechoic chamber.
The table was rotated 360 degrees to determine the position of the highest radiation.
b. The EUT was set 3 m away from the interference-receiving antenna, which was mounted on
the top of a variable-height antenna tower.
c. The antenna height is varied from 1 m to 4 m above the ground to determine the maximum
value of the field strength. Both horizontal and vertical polarizations of the antenna are set to
make the measurement.
d. For each suspected emission, the EUT was arranged to its worst case and then the antenna
was tuned to heights from 1 m to 4 m and the turn table was turned from 0 degrees to 360
degrees to find the maximum reading.
e. The test-receiver system was set to Quasi-Peak detect function and specified bandwidth with
maximum hold mode when the test frequency is below 1 GHz.
f. The test-receiver system was set to Peak and Average detect function and specified
bandwidth with maximum hold mode when the test frequency is above 1 GHz.
g. Place the measurement antenna away from each area of the EUT determined to be a source of
emissions at the specified measurement distance, while keeping the measurement antenna aimed
at the source of emissions at each frequency of significant emissions, with polarization oriented
for maximum response.(1 GHz to 40 GHz)
[ Radiated Emission Limits ]
Frequency
(MHz)
30 to 88
Antenna Distance
(m)
Field Strength
(μV/m)
100
Quasi-Peak
(dB(μV)/m)
40.0
88 to 216
150
43.5
216 to 960
200
46.0
Above 960
Frequency
(MHz)
Above 1 000
Antenna Distance
(m)
500
Peak
(dB(μV)/m)
74
54.0
Average
(dB(μV)/m)
54
F-TP22-03 (Rev.00)
10 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
3.2.1 Frequency Range of Radiated Measurements
An unintentional radiator, including a digital device, the spectrum shall be investigated from the lowest
radio frequency signal generated or used in the device, without going below the lowest frequency for
which a Radiated Emission limit is specified, up to the frequency shown in the following table
Highest frequency generated or used in the device
or on which the device operates or tunes
(MHz)
Below 1.705
Upper frequency of measurement range
(MHz)
30
1.705 to 108
1 000
108 to 500
2 000
500 to 1 000
5 000
5th harmonic of the highest frequency
or 40 ㎓, whichever is lower
Above 1 000
3.3 Configuration of Tested System
Gateway
Adaptor
Notebook
PC
EUT
Earphone
Notebook PC
adaptor
Serial Mouse
Non-Conductive Table
Power Line: 120 VAC, 60 Hz
F-TP22-03 (Rev.00)
11 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
4. PRELIMINARY TEST
4.1 Conducted Emission Test
It was tested Data Communication mode, after connecting all peripheral devices.
Operation Mode:
Data Communication mode
4. 2 Radiated Emission Test
It was tested Data Communication mode, after connecting all peripheral devices.
Operation Mode:
F-TP22-03 (Rev.00)
Data Communication mode
12 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
5. CONDUCTED AND RADIATED EMISSION TEST SUMMARY
5.1 Conducted Emission Test
The test results of conducted emission at mains ports provide the following information:
Rule Part / Standard
FCC PART 15 Subpart B Class B
Detector
Quasi-Peak, CISPR-Average
Bandwidth
9 kHz (6 dB)
Operation Mode
Data Communication mode
Worst Data Cable
KSD
Kind of Test Site
Shielded Room
Temperature
21.5 °C
Relative Humidity
47.2 %
Test Date
November 07, 2017
- Calculation Formula:
1. Conductor L1 = Hot, Conductor N = Neutral
2. Corr. = LISN Factor + Cable Loss
3. QuasiPeak or CAverage= Receiver Reading + Corr.
4. Margin = Limit – QuasiPeak or CAverage
F-TP22-03 (Rev.00)
13 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
Figure 1: Conducted Emission, AC Main Port, Data Communication Mode, Line (L1)
FCC CLASS B
90
80
70
60
Level in dBμ
50
40
30
20
10
-10
150k
300
400 500
800 1M
2M
3M
4M 5M 6
8 10M
20M
30M
Frequency in Hz
FCC CLASS B_QP
Preview Result 2-AVG
F-TP22-03 (Rev.00)
FCC CLASS B_ AV
Final Result 1-QPK
14 / 24
Preview Result 1-PK+
Final Result 2-CAV
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
QuasiPeak Final Result, Line (L1)
Frequency
(MHz)
QuasiPeak
(dBuV)
Bandwidth
(kHz)
Line
Corr.
(dB)
Margin
(dB)
Limit
(dBuV)
0.182000
43.7
9.000
L1
9.6
20.7
64.4
0.188000
44.4
9.000
L1
9.6
19.7
64.1
0.194000
44.5
9.000
L1
9.6
19.3
63.9
0.198000
44.3
9.000
L1
9.6
19.4
63.7
0.274000
39.0
9.000
L1
9.6
21.9
61.0
0.328000
37.4
9.000
L1
9.6
22.1
59.5
3.214000
37.4
9.000
L1
9.8
18.6
56.0
3.488000
37.5
9.000
L1
9.8
18.5
56.0
3.688000
37.0
9.000
L1
9.8
19.0
56.0
3.720000
36.7
9.000
L1
9.8
19.3
56.0
3.770000
35.6
9.000
L1
9.8
20.4
56.0
3.830000
36.7
9.000
L1
9.8
19.3
56.0
9.402000
32.6
9.000
L1
10.1
27.4
60.0
9.458000
32.5
9.000
L1
10.1
27.5
60.0
9.462000
32.2
9.000
L1
10.1
27.8
60.0
11.900000
33.5
9.000
L1
10.1
26.5
60.0
11.904000
33.1
9.000
L1
10.1
26.9
60.0
12.268000
32.8
9.000
L1
10.1
27.2
60.0
F-TP22-03 (Rev.00)
15 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
CAverage Final Result, Line (L1)
Frequency
(MHz)
CAverage
(dBuV)
Bandwidth
(kHz)
Line
Corr.
(dB)
Margin
(dB)
Limit
(dBuV)
0.150000
20.3
9.000
L1
9.6
35.7
56.0
0.158000
19.6
9.000
L1
9.6
36.0
55.6
0.190000
33.1
9.000
L1
9.6
21.0
54.0
0.198000
32.3
9.000
L1
9.6
21.4
53.7
0.316000
24.4
9.000
L1
9.6
25.4
49.8
0.328000
23.9
9.000
L1
9.6
25.6
49.5
3.214000
27.6
9.000
L1
9.8
18.4
46.0
3.688000
27.0
9.000
L1
9.8
19.0
46.0
3.720000
28.1
9.000
L1
9.8
17.9
46.0
3.770000
27.1
9.000
L1
9.8
18.9
46.0
3.796000
26.9
9.000
L1
9.8
19.1
46.0
3.830000
26.8
9.000
L1
9.8
19.2
46.0
9.336000
23.2
9.000
L1
10.1
26.8
50.0
9.402000
24.0
9.000
L1
10.1
26.0
50.0
9.458000
23.9
9.000
L1
10.1
26.1
50.0
9.462000
23.9
9.000
L1
10.1
26.1
50.0
11.900000
26.7
9.000
L1
10.1
23.3
50.0
14.716000
24.3
9.000
L1
10.2
25.7
50.0
F-TP22-03 (Rev.00)
16 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
Figure 2: Conducted Emission, AC Main Port, Data Communication Mode, Line (N)
FCC CLASS B
90
80
70
60
Level in dBμ
50
40
30
20
10
-10
150k
300
400 500
800 1M
2M
3M
4M 5M 6
8 10M
20M
30M
Frequency in Hz
FCC CLASS B_QP
Preview Result 2-AVG
F-TP22-03 (Rev.00)
FCC CLASS B_ AV
Final Result 1-QPK
17 / 24
Preview Result 1-PK+
Final Result 2-CAV
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
QuasiPeak Final Result, Line (N)
Frequency
(MHz)
QuasiPeak
(dBuV)
Bandwidth
(kHz)
Line
Corr.
(dB)
Margin
(dB)
Limit
(dBuV)
0.190000
45.6
9.000
9.6
18.4
64.0
0.206000
43.5
9.000
9.6
19.9
63.4
0.248000
41.8
9.000
9.6
20.0
61.8
0.260000
41.3
9.000
9.6
20.1
61.4
0.268000
41.1
9.000
9.6
20.1
61.2
0.304000
38.2
9.000
9.6
21.9
60.1
4.040000
33.9
9.000
9.8
22.1
56.0
4.120000
35.3
9.000
9.8
20.7
56.0
4.150000
34.5
9.000
9.8
21.5
56.0
4.186000
34.6
9.000
9.8
21.4
56.0
4.192000
35.1
9.000
9.8
20.9
56.0
4.302000
34.0
9.000
9.8
22.0
56.0
5.134000
33.7
9.000
9.9
26.3
60.0
5.162000
33.5
9.000
9.9
26.5
60.0
5.272000
33.3
9.000
9.9
26.7
60.0
5.350000
31.5
9.000
9.9
28.5
60.0
9.040000
28.4
9.000
10.0
31.6
60.0
9.238000
30.7
9.000
10.0
29.3
60.0
F-TP22-03 (Rev.00)
18 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
CAverage Final Result, Line (N)
Frequency
(MHz)
CAverage
(dBuV)
Bandwidth
(kHz)
Line
Corr.
(dB)
Margin
(dB)
Limit
(dBuV)
0.150000
20.8
9.000
9.6
35.2
56.0
0.190000
33.5
9.000
9.6
20.5
54.0
0.200000
32.3
9.000
9.6
21.4
53.6
0.248000
28.3
9.000
9.6
23.5
51.8
0.258000
27.5
9.000
9.6
24.0
51.5
0.268000
26.8
9.000
9.6
24.4
51.2
3.996000
26.5
9.000
9.8
19.5
46.0
4.040000
25.0
9.000
9.8
21.0
46.0
4.120000
27.5
9.000
9.8
18.5
46.0
4.186000
25.6
9.000
9.8
20.4
46.0
4.224000
25.7
9.000
9.8
20.3
46.0
4.302000
25.5
9.000
9.8
20.5
46.0
5.188000
24.6
9.000
9.9
25.4
50.0
5.272000
23.5
9.000
9.9
26.5
50.0
5.350000
22.2
9.000
9.9
27.8
50.0
9.040000
19.3
9.000
10.0
30.7
50.0
9.238000
21.5
9.000
10.0
28.5
50.0
9.412000
21.9
9.000
10.1
28.1
50.0
F-TP22-03 (Rev.00)
19 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
5.2 Radiated Emission Test
The test results of radiated emission provide the following information:
-For Measurement Below 1 GHz
Rule Part / Standard
FCC PART 15 Subpart B Class B
Detector
Quasi-Peak
Bandwidth
120 kHz (6 dB)
Operation Mode
Data Communication mode
Worst Data Cable
KSD
Kind of Test Site
3 m semi anechoic chamber
Temperature
22.7 °C
Relative Humidity
50.7 %
Test Date
November 02, 2017
Frequency
(MHz)
Quasi Peak
(dBμV/m)
Antenna
Height
(cm)
POL.
(H/V)
Azimuth
(deg)
Corr.
(dB)
Margin
(dB)
Limit
(dBμV/m)
30.781166
30.9
100.0
292.0
21.8
9.1
40.0
54.189600
31.4
100.0
132.0
23.2
8.6
40.0
84.614400
32.3
400.0
278.0
18.2
7.7
40.0
125.007200
33.5
100.0
258.0
21.5
10.0
43.5
265.612800
34.2
125.0
129.0
22.8
11.8
46.0
600.019200
40.6
115.0
1.0
31.3
5.4
46.0
- Calculation Formula:
1. POL. H = Horizontal, POL. V = Vertical
2. QuasiPeak = Reading (Receiver Reading) + Corr.
3. Corr. (Correction Factor) = Antenna Factor + Cable Loss
4. Margin = Limit - QuasiPeak
F-TP22-03 (Rev.00)
20 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
-For Measurement Above 1 GHz
Rule Part / Standard
FCC PART 15 Subpart B Class B
Detector
Peak mode: Peak (RBW: 1 MHz, VBW: 3 MHz)
CISPR-Average mode: Peak (RBW: 1 MHz, VBW: 10 Hz)
Highest Operating Frequency
2 480 MHz
Upper Frequency
1 GHz to 12.4 GHz
Operation Mode
Data Communication mode
Worst Data Cable
KSD
Kind of Test Site
3 m semi anechoic chamber
Temperature
22.4 °C
Relative Humidity
50.5 %
Test Date
November 03, 2017
Frequency
(MHz)
Peak
(dBμV/m)
Antenna
Height
(cm)
POL.
(H/V)
Azimuth
(deg)
Corr.
(dB)
Margin
(dB)
Limit
(dBμV/m)
1400.020000
46.3
291.7
178.0
-12.9
27.7
74.0
1499.010000
46.7
322.5
0.0
-12.6
27.3
74.0
1986.820000
48.4
111.5
51.0
-11.8
25.6
74.0
2590.920000
52.3
290.6
62.0
-9.5
21.7
74.0
4486.765000
43.3
99.8
0.0
-5.4
30.7
74.0
5994.480000
48.2
349.7
49.0
-2.2
25.8
74.0
Frequency
(MHz)
CAverage
(dBμV/m)
Antenna
Height
(cm)
POL.
(H/V)
Azimuth
(deg)
Corr.
(dB)
Margin
(dB)
Limit
(dBμV/m)
1400.020000
44.5
291.7
178.0
-12.9
9.5
54.0
1499.010000
40.5
322.5
0.0
-12.6
13.5
54.0
1986.820000
32.8
111.5
51.0
-11.8
21.2
54.0
2590.920000
33.2
290.6
62.0
-9.5
20.8
54.0
4486.765000
28.5
99.8
0.0
-5.4
25.5
54.0
5994.480000
33.6
349.7
49.0
-2.2
20.4
54.0
- Calculation Formula:
1. POL. H = Horizontal, POL. V = Vertical
2. Peak or CAverage = Reading (Receiver Reading) + Corr.
3. Corr. (Correction Factor) = Antenna Factor+ Cable Loss –Amplifier Gain
4. Margin = Limit - Peak or CAverage
F-TP22-03 (Rev.00)
21 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
6. LIST OF TEST EQUIPMENT
Type
Calibration
Cycle
Manufacturer
Model Name
Serial Number
CAL Date
Rohde & Schwarz
Rohde & Schwarz
Rohde & Schwarz
Rohde & Schwarz
Rohde & Schwarz
Rohde & Schwarz
ESCI
ESCI
ESH3-Z5
ENV216
ENV216
EMC32 VER8.54.0
100584
100033
100282
100073
100073
1 year
1 year
1 year
1 year
1 year
06.20.2017
06.27.2017
05.22.2017
12.23.2016
07.18.2017
ESU40
VULB 9168
MA240
HD 100
1060-2M
CO2000
ESU26
MA4000-EP
DT3000-3T
EMC32 VER8.40.0
100524
760
240/520
100/637
100241
MA4000/283
DT3000/69
1 year
2 year
N/A
N/A
N/A
N/A
1 year
N/A
N/A
08.16.2017
04.06.2017
08.16.2017
ESU40
MA4000-XP-ET
100524
CO 3000/870/
35990515/L
24348
21873
19660
296
BBHA9170124
100/637
21691
240/520
1300
100241
DT3000/69
1 year
N/A
08.16.2017
N/A
N/A
N/A
1 year
1 year
1 year
2 year
2 year
N/A
1 year
N/A
2 year
1 year
N/A
06.01.2017
01.19.2017
07.11.2017
10.12.2016
04.25.2017
06.28.2017
06.30.2017
08.16.2017
Conducted Emission
EMI Test Receiver
EMI Test Receiver
LISN
LISN
LISN
Software
Radiated Emission
-For measurement below 1 GHz
EMI Test Receiver
Trilog Antenna
Antenna master
Antenna master controller
Turn Table
Turn Table controller
EMI Test Receiver
Antenna master
Turn Table
Software
Rohde & Schwarz
Schwarzbeck
HD GmbH
HD GmbH
INNCO Systems
INNCO Systems
Rohde & Schwarz
INNCO Systems
INNCO Systems
Rohde & Schwarz
-For measurement above 1 GHz
EMI Test Receiver
Antenna master
Rohde & Schwarz
INNCO Systems
Antenna master controller INNCO Systems
CO 3000
Turn Table
Turn Table controller
Power Amplifier
Power Amplifier
Power Amplifier
Horn Antenna
Horn Antenna
Antenna master controller
Power Amplifier
Antenna master
Horn Antenna
EMI Test Receiver
Turn Table
Software
1060-2M
CO2000
CBLU5183530
CBL18265035
CBL26405040
BBHA 9120D
BBHA 9170
HD 100
CBLU1183540
MA240
BBHA 9120D
ESU26
DT3000-3T
EMC32 VER8.40.0
F-TP22-03 (Rev.00)
INNCO Systems
INNCO Systems
CERNEX
CERNEX
CERNEX
Schwarzbeck
Schwarzbeck
HD GmbH
CERNEX
HD GmbH
Schwarzbeck
Rohde & Schwarz
INNCO Systems
Rohde & Schwarz
22 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
7. CONCLUSION
The data collected shows that the EUT Type: GSM/WCDMA/LTE phone with Bluetooth and
WLAN, Model: LM-X210APM, FCC ID: ZNFX210APM complies with §15.107 and §15.109 of
the FCC rules.
F-TP22-03 (Rev.00)
23 / 24
HCT CO.,LTD.
FCC ID: ZNFX210APM
Report No.: HCT-EM-1801-FC001-R1
APPENDIX A. TEST SETUP PHOTOGRAPHS
Please refer to Appendix A
F-TP22-03 (Rev.00)
24 / 24
HCT CO.,LTD.
Download: X210APM Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN Test Report 1 LG Electronics MobileComm USA, Inc.
Mirror Download [FCC.gov]X210APM Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth and WLAN Test Report 1 LG Electronics MobileComm USA, Inc.
Document ID3712390
Application IDbiFlgjNAZmqz//+4sg5umw==
Document DescriptionTest Report 1
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize65.08kB (813461 bits)
Date Submitted2018-01-12 00:00:00
Date Available2018-01-12 00:00:00
Creation Date2018-01-05 15:35:03
Producing SoftwareAcrobat Distiller 11.0 (Windows)
Document Lastmod2018-01-05 16:56:50
Document TitleTest Report 1
Document CreatorPScript5.dll Version 5.2.2
Document Author: HCT-1524

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : HCT-1524
Create Date                     : 2018:01:05 15:35:03+09:00
Modify Date                     : 2018:01:05 16:56:50+09:00
Has XFA                         : No
XMP Toolkit                     : Adobe XMP Core 5.4-c006 80.159825, 2016/09/16-03:31:08
Creator Tool                    : PScript5.dll Version 5.2.2
Metadata Date                   : 2018:01:05 16:56:50+09:00
Producer                        : Acrobat Distiller 11.0 (Windows)
Format                          : application/pdf
Title                           : Microsoft Word - HCT-EM-1801-FC001_LG Electronics_LM-X210APM_EMI FCC Certifiction original
Creator                         : HCT-1524
Document ID                     : uuid:ed1858b1-7491-4e9b-99d9-c578b2eba887
Instance ID                     : uuid:37169aac-30ef-4f1b-94da-23a7031398d5
Page Count                      : 24
