FCC ID ZNFX220DSH
Mobile phone
by LG Electronics USA, Inc.
Grantee Code: ZNF Product Code: X220DSH
Latest application date: 2016-03-16
Device Images
FCC ID Device Details
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 824.2-848.8 MHz | Original Equipment | 2016-03-16 |
| 2402-2480 MHz | Original Equipment | 2016-03-16 |
| 2402-2480 MHz | Original Equipment | 2016-03-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| LG-X220dsh_User Guide | Users Manual | 2016-05-10 | PDF 1 MB |
| LG-X220dsh_InPho | Internal Photos | 2016-05-10 | PDF 3.4 MB |
| LG-X220dsh_ExPho | External Photos | 2016-05-10 | PDF 1.6 MB |
| LG-X220dsh_FCC ID Label form and label location | ID Label/Location Info | 2016-03-16 | PDF 1.3 MB |
| LG-X220dsh_Tsup_JBP | Test Setup Photos | 2016-05-10 | PDF 385 KB |
| LG-X220dsh_Tsup_PCE | Test Setup Photos | 2016-05-10 | PDF 371.2 KB |
| LG-X220dsh_Tsup_RFExp | Test Setup Photos | 2016-05-10 | PDF 271.9 KB |
| LG-X220g_Tsup_DSS | Test Setup Photos | 2016-05-10 | PDF 305.5 KB |
| LG-X220g_Tsup_DTS_BT4.0 | Test Setup Photos | 2016-05-10 | PDF 306.8 KB |
| LG-X220g_Tsup_DTS_WLAN2.4G | Test Setup Photos | 2016-05-10 | PDF 645.3 KB |
| LG-X220dsh_TestRpt_JBP | Test Report | 2016-03-16 | PDF 1.2 MB |
| LG-X220g_TestRpt_DSS | Test Report | 2016-03-16 | PDF 5.2 MB |
| LG-X220g_TestRpt_DTS_BT4.0 | Test Report | 2016-03-16 | PDF 2.4 MB |
| LG-X220g_TestRpt_DTS_WLAN2.4G | Test Report | 2016-03-16 | PDF 5.2 MB |
| LG-X220g_TestRpt_JBP | Test Report | 2016-03-16 | PDF 649 KB |
| LG-X220g_TestRpt_PCE | Test Report | 2016-03-16 | PDF 4.4 MB |
| LG_LG-X220dsh_Report_PCE | Test Report | 2016-03-16 | PDF 1.1 MB |
| LG-X220dsh_cvrltr_variation attestation | Attestation Statements | 2016-03-16 | PDF 81.9 KB |
| LG-X220dsh_cvrltr_Long-term Confidentiality_WWAN function | Cover Letter(s) | 2016-03-16 | PDF 89.7 KB |
| LG-X220dsh_cvrltr_POA | Cover Letter(s) | 2016-03-16 | PDF 89 KB |
| LG-X220dsh_cvrltr_Short-term Confidentiality | Cover Letter(s) | 2016-03-16 | PDF 83.3 KB |
| LG-X220dsh_TestRpt_RFExp Part 1 | RF Exposure Info | 2016-03-16 | PDF 5.5 MB |
| LG-X220dsh_TestRpt_RFExp Part 2 | RF Exposure Info | 2016-03-16 | PDF 5.7 MB |
| LG-X220dsh_TestRpt_RFExp Part 3 | RF Exposure Info | 2016-03-16 | PDF 4.3 MB |
| LG-X220g_TestRpt_RFExp_Appendix C_Part 1 | RF Exposure Info | 2016-03-16 | PDF 4.2 MB |
| LG-X220g_TestRpt_RFExp_Appendix C_Part 2 | RF Exposure Info | 2016-03-16 | PDF 4.5 MB |
| LG-X220g_TestRpt_RFExp_Report & Appendix A,B | RF Exposure Info | 2016-03-16 | PDF 3 MB |
| LG-X220dsh_BlckDia Metadata only | Block Diagram | PDF 101.5 KB | |
| LG-X220dsh_SchemDia Metadata only | Schematics | PDF 495.3 KB | |
| LG-X220dsh GPS-WiFi&BT Antenna Specification Metadata only | Operational Description | PDF 791.6 KB | |
| LG-X220dsh Main Antenna Specification Metadata only | Operational Description | PDF 716.4 KB | |
| LG-X220dsh_OpDes Rev. 01 Metadata only | Operational Description | PDF 85.6 KB | |
| Product Equality Declaration (PED)_X220dsh vs X220g Metadata only | Operational Description | PDF 625.7 KB | |
| LG-X220dsh_PartsLst Metadata only | Parts List/Tune Up Info | PDF 53.1 KB | |
| LG-X220dsh_TunPro Metadata only | Parts List/Tune Up Info | PDF 74 KB |
Application Information
| Application ID | icKkTOfnmYjWRAKJB4NUGQ== |
|---|---|
| Final Action Date | 2016-03-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020917688 |
| Model | X220DSH |
| Frequency Range | 824.2-848.8 MHz |
| Equipment Class | PCE - PCS Licensed Transmitter held to ear |
| Device Description | Mobile phone |
| Responsible Party | Sung Soo Kim, Director, Regulatory and Environmental Affairs, sungsoo.kim@lge.com  , 201-266-2215 |
| Test Firm | Alex Chen, SPORTON INTERNATIONAL(KUN SHAN)INC., alex@sporton.com.tw  , 886-3-3273456 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 05/10/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is ERP for bands below 1 GHz and EIRP for bands above 1 GHz. SAR compliance for body-worn accessory operation is based on a separation distance of 1 cm between the unit and the body of the user. Belt clips, holsters and other body-worn accessories may not contain metallic components. End-users must be informed of the body worn operating requirements for satisfying RF exposure compliance. The highest reported SAR for head, body-worn accessory, product specific (hotspot), and simultaneous transmission exposure conditions are 0.86W/kg, 0.79W/kg, 0.79W/kg and 1.22W/kg respectively. This device also contains functions that are not operational in U.S. territories. |
