FCC ID ZNFX220MB
Smart phone which supports GSM850/900/1800/1900, WCDMA Band 2/4/5, WIFI 2.4G and BT 3.0+EDR/BT 4.0
by LG Electronics USA, Inc.
Grantee Code: ZNF Product Code: X220MB
Latest application date: 2016-03-16
Device Images
FCC ID Device Details
| FCC ID | ZNFX220MB |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | ZNF |
| Product Code | X220MB |
| Applicant Business | LG Electronics USA, Inc. 🇺🇸 |
| Related Domains |  lge.com |
| Equipment Class | Smart phone which supports GSM850/900/1800/1900, WCDMA Band 2/4/5, WIFI 2.4G and BT 3.0+EDR/BT 4.0 |
| Test Firm | SPORTON INTERNATIONAL(KUN SHAN)INC. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-03-16 |
| 2402-2480 MHz | Original Equipment | 2016-03-16 |
| 824.2-848.8 MHz | Original Equipment | 2016-03-16 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| Users Manual | Users Manual | 2016-07-25 | PDF 1 MB |
| Internal Photos | Internal Photos | 2016-07-25 | PDF 3.3 MB |
| External Photos | External Photos | 2016-07-25 | PDF 1.6 MB |
| ID Label | ID Label/Location Info | 2016-03-16 | PDF 1.3 MB |
| Tsup_DSS | Test Setup Photos | 2016-07-25 | PDF 306 KB |
| Tsup_DTS BT4.0 | Test Setup Photos | 2016-07-25 | PDF 305.7 KB |
| Tsup_DTS WLAN 2.4G | Test Setup Photos | 2016-07-25 | PDF 669.9 KB |
| Tsup_JBP | Test Setup Photos | 2016-07-25 | PDF 272.2 KB |
| Tsup_PCE | Test Setup Photos | 2016-07-25 | PDF 400.4 KB |
| Tsup_RFExp | Test Setup Photos | 2016-07-25 | PDF 270.4 KB |
| TestRpt_DSS | Test Report | 2016-03-16 | PDF 2 MB |
| TestRpt_DTS BT4.0 | Test Report | 2016-03-16 | PDF 3.6 MB |
| TestRpt_DTS WLAN 2.4G | Test Report | 2016-03-16 | PDF 4.5 MB |
| TestRpt_JBP | Test Report | 2016-03-16 | PDF 723.3 KB |
| TestRpt_PCE | Test Report | 2016-03-16 | PDF 3 MB |
| Authorization Letter | Cover Letter(s) | 2016-03-16 | PDF 82.9 KB |
| Long-term Confidentiality | Cover Letter(s) | 2016-03-16 | PDF 71.9 KB |
| POA | Cover Letter(s) | 2016-03-16 | PDF 89.1 KB |
| Short-term Confidentiality | Cover Letter(s) | 2016-03-16 | PDF 83.6 KB |
| RFExp_Part 1 | RF Exposure Info | 2016-03-16 | PDF 5.4 MB |
| RFExp_Part 2 | RF Exposure Info | 2016-03-16 | PDF 5.4 MB |
| RFExp_Part 3 | RF Exposure Info | 2016-03-16 | PDF 5.7 MB |
| RFExp_Part 4 | RF Exposure Info | 2016-03-16 | PDF 1.1 MB |
| TestRpt_RFExp_Part 1 | RF Exposure Info | 2016-03-16 | PDF 5.4 MB |
| Block Diagrams Metadata only | Block Diagram | PDF 79.7 KB | |
| Schematics Metadata only | Schematics | PDF 497.3 KB | |
| Main Antenna Metadata only | Operational Description | PDF 723 KB | |
| Operational Description Metadata only | Operational Description | PDF 86.8 KB | |
| WiFi&BT Antenna Metadata only | Operational Description | PDF 797.6 KB | |
| PartsLst Metadata only | Parts List/Tune Up Info | PDF 59.4 KB | |
| TunPro Metadata only | Parts List/Tune Up Info | PDF 68.6 KB | |
| Tune Up Metadata only | Parts List/Tune Up Info | PDF 68.6 KB |
Application Information
| Application ID | z9TEMd8QTKb/wgu5oCImbQ== |
|---|---|
| Final Action Date | 2016-03-16 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0020917688 |
| Model | X220MB |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DSS - Part 15 Spread Spectrum Transmitter |
| Device Description | Smart phone which supports GSM850/900/1800/1900, WCDMA Band 2/4/5, WIFI 2.4G and BT 3.0+EDR/BT 4.0 |
| Responsible Party | Sung Soo Kim, Director, Regulatory and Environmental Affairs, sungsoo.kim@lge.com , 201-266-2215 |
| Test Firm | Alex Chen, SPORTON INTERNATIONAL(KUN SHAN)INC., alex@sporton.com.tw  , 886-3-3273456 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 07/25/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Power output listed is conducted. SAR compliance for body-worn accessory operation is based on a separation distance of 1.0 cm between the unit and the body of the user. Belt clips, holsters and other body-worn accessories may not contain metallic components. End-users must be informed of the body worn operating requirements for satisfying RF exposure compliance. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| z9TEMd8QTKb/wgu5oCImbQ== | 2016-03-16 | Original Equipment |
| TSCE2xYqik0Irniq671Zmg== | 2016-03-16 | Original Equipment |
| 64OVoRe31bner4apM5AsLg== | 2016-03-16 | Original Equipment |
| +vTOBSDCoIk9O/XOuJbXAA== | 2016-03-16 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 824.2-848.8 MHz | 0.9811 | 2.5ppm | 245KGXW | 22H | |
| 826.4-846.6 MHz | 0.1025 | 2.5ppm | 4M15F9W | 22H | |
| 1712.4-1752.6 MHz | 0.1238 | 2.5ppm | 4M16F9W | 27 | |
| 1850.2-1909.8 MHz | 0.6245 | 2.5ppm | 244KGXW | 24E | |
| 1852.4-1907.6 MHz | 0.1281 | 2.5ppm | 4M15F9W | 24E | |
| 2402-2480 MHz | 0.0009 | 15C | CC | ||
| 2402-2480 MHz | 0.0051100 | 15C | CC | ||
| 2412-2462 MHz | 0.2153 | 15C | CC |
Grants
TCB Grant - Application z9TEMd8QTKb/wgu5oCImbQ==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
UL Verification Services Inc. (formerly UL CCS) 47173 Benicia Street Fremont, CA 94538 |
Date of Grant: 03/16/2016 Application Dated: 03/16/2016 |
| LG Electronics USA, Inc. |
| 111 Sylvan Ave |
| North Building |
| Englewood Cliffs, NJ 07632 |
| Attention: Sung Soo Kim , Director, Regulatory and Environmental Affairs |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | ZNFX220MB |
| Name of Grantee: | LG Electronics USA, Inc. |
| Equipment Class: | Part 15 Spread Spectrum Transmitter |
| Notes: | Smart phone which supports GSM850/900/1800/1900, WCDMA Band 2/4/5, WIFI 2.4G and BT 3.0+EDR/BT 4.0 |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2402.0 - 2480.0 | 0.00511 |
| Power output listed is conducted. SAR compliance for body-worn accessory operation is based on a separation distance of 1.0 cm between the unit and the body of the user. Belt clips, holsters and other body-worn accessories may not contain metallic components. End-users must be informed of the body worn operating requirements for satisfying RF exposure compliance. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
