ZS820915AL3 Data Gateway Label Diagram - FCC ID ZSSZS820915AL3
FCC ID ZSSZS820915AL3
Label and location
Data Gateway
Document preview loads when visible.
Document Details
| FCC ID | ZSSZS820915AL3 |
|---|---|
| Document ID | 4533538 |
| Document Type | ID Label/Location Info |
| Description | Label and location |
| Document Title | Lable Location Infox |
| Applicant | Gutermann Technology GmbH |
| Equipment Class | Data Gateway |
| Product Code | ZS820915AL3 |
| Application ID | FNIUioLOPkKsJyJM/P3Whw== |
| Application Purpose | Original Equipment |
| Application Date | 2019-11-29 |
| FRN | 0021035092 |
| Test Firm | PHOENIX TESTLAB GmbH |
| Certified By | Erwin Glashauser |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2019-11-29 |
| Available | 2019-11-29 |
| Created | 2019-11-04 |
| Modified | 2019-11-04 |
| Pages | 1 |
| File Type | Adobe Acrobat PDF |
| File Size | 172872 |
| File SHA-256 | 84f0b5948ec81ae3d3c2dc7d2ddb6eb70534c2b33e89a6c5a24e343652722b9d |
| PDF Metadata Author | pbbd08 |
| PDF Metadata Producer | Acrobat Distiller 10.0.0 (Windows) pbbd08 |
| FCC.gov Sources | FCC.gov 4533538, FCC.gov 4533571 |
