10041 Mobile Phone Test Setup Photos - FCC ID ZSW-10-041

FCC ID ZSW-10-041

Test Setup

Mobile Phone

by b mobile HK Limited

Document preview loads when visible.

Document Details

FCC IDZSW-10-041
Document ID5406783
Document TypeTest Setup Photos
DescriptionTest Setup
Applicantb mobile HK Limited
Equipment ClassMobile Phone
Product Code10041
Application IDoSt2rJvdrprVTltPqjUTbg==
Application PurposeOriginal Equipment
Application Date2021-08-24
Frequency Range2402-2480 MHz
FRN0021037635
Test FirmShenzhen NTEK Testing Technology Co., Ltd.
Certified ByALEX LI
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date02/20/2022
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2021-08-24
Available2022-02-20
Created2021-08-23
Modified2021-08-23
Pages2
File TypeAdobe Acrobat PDF
File Size317778
File SHA-256da83084a44e7c1fa84ad81fdd9769b70b3109241ce8e9f441fa189c6b3344c8a
PDF Metadata Authorntek202
PDF Metadata ProducerMicrosoft® Office Word 2007 Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 5406783
