14 Wireless Module User Manual - FCC ID ZVA14
FCC ID ZVA14
User Manual
Wireless Module
Document preview loads when visible.
Document Details
| FCC ID | ZVA14 |
|---|---|
| Document ID | 4212532 |
| Document Type | Users Manual |
| Description | User Manual |
| Document Title | IA9Q5_S83D-E Module datasheet with Application note V0.2 |
| Applicant | Tonly Technology Co., Ltd. |
| Equipment Class | Wireless Module |
| Product Code | 14 |
| Application ID | oP4WuWX2EgBYDR3REO1QHg== |
| Application Purpose | Original Equipment |
| Application Date | 2019-04-03 |
| Frequency Range | 5743-5838 MHz |
| FRN | 0020517298 |
| Test Firm | Bureau Veritas Shenzhen Co., Ltd. Dongguan Branch |
| Certified By | Weirun Peng |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2019-03-25 |
| Available | 2019-04-03 |
| Created | 2017-08-22 |
| Modified | 2017-08-29 |
| Pages | 21 |
| File Type | Adobe Acrobat PDF |
| File Size | 1074628 |
| File SHA-256 | 2fe42df0d5afe9a6a87aba846a511f213f6da5b0b1aafe0094d2aaffa1ace09e |
| PDF Metadata Author | jimmy.liu |
| PDF Metadata Creator | PDFCreator Version 1.5.0 |
| PDF Metadata Producer | GPL Ghostscript 9.05 |
| FCC.gov Sources | FCC.gov 4212532 |
