FCC ID A3LATKM102000
ARTIK-1020
by Samsung Electronics Co Ltd
Grantee Code: A3L Product Code: ATKM102000
Latest application date: 2016-06-21
Device Images
FCC ID Device Details
| FCC ID | A3LATKM102000 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | A3L |
| Product Code | ATKM102000 |
| Applicant Business | Samsung Electronics Co Ltd 🇺🇸 |
| Related Domains |  samsung.com |
| Equipment Class | ARTIK-1020 |
| Test Firm | SGS KOREA CO., Ltd. |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 5180-5240 MHz | Original Equipment | 2016-06-21 |
| 2402-2480 MHz | Original Equipment | 2016-06-21 |
| 2402-2480 MHz | Original Equipment | 2016-06-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-12-18 | PDF 995.4 KB |
| User Manual_antenna | Users Manual | 2016-12-18 | PDF 196.6 KB |
| Internal Photos | Internal Photos | 2016-12-18 | PDF 141.1 KB |
| External Photos | External Photos | 2016-12-18 | PDF 233.9 KB |
| ID Label | ID Label/Location Info | 2016-06-21 | PDF 64.8 KB |
| Test Setup Photos | Test Setup Photos | 2016-12-18 | PDF 418.2 KB |
| Test report_BT Metadata only | Test Report | 2016-06-21 | PDF 2.1 MB |
| Test report_BT_r | Test Report | 2016-06-21 | PDF 2.2 MB |
| Test report_DFS | Test Report | 2016-06-21 | PDF 786.7 KB |
| Test report_LE | Test Report | 2016-06-21 | PDF 1.4 MB |
| Test report_WLAN2.4G | Test Report | 2016-06-21 | PDF 3.7 MB |
| Test report_WLAN5G_1 | Test Report | 2016-06-21 | PDF 5.5 MB |
| Test report_WLAN5G_2 | Test Report | 2016-06-21 | PDF 5.8 MB |
| Test report_Zigbee | Test Report | 2016-06-21 | PDF 1.4 MB |
| Authorization Letter | Cover Letter(s) | 2016-06-21 | PDF 658.6 KB |
| Confidentiality Request | Cover Letter(s) | 2016-06-21 | PDF 614.9 KB |
| Request for Modular | Cover Letter(s) | 2016-06-21 | PDF 78.6 KB |
| Request for Modular Approval | Cover Letter(s) | 2016-06-21 | PDF 78.6 KB |
| Wi-Fi Direct letter | Cover Letter(s) | 2016-06-21 | PDF 199.9 KB |
| MPE Metadata only | RF Exposure Info | 2016-06-21 | PDF 455.7 KB |
| MPE | RF Exposure Info | 2016-06-21 | PDF 669.7 KB |
| MPE_r | RF Exposure Info | 2016-06-21 | PDF 669.7 KB |
| Block Diagram Metadata only | Block Diagram | PDF 81.9 KB | |
| Schematics Metadata only | Schematics | PDF 926.7 KB | |
| Antenna Specification Metadata only | Operational Description | PDF 951.2 KB | |
| Operation Description_WLAN_BT Metadata only | Operational Description | PDF 1.6 MB | |
| Operation Description_Zigbee Metadata only | Operational Description | PDF 1.1 MB | |
| Operational Description Metadata only | Operational Description | PDF 405.1 KB | |
| SOFTWARE SECURITY Metadata only | SDR Software/Security Inf | PDF 103.8 KB |
Application Information
| Application ID | PQc0eHn1mopdLlNL3oylHA== |
|---|---|
| Final Action Date | 2016-06-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0027908797 |
| Model | ATKM102000 |
| Frequency Range | 5180-5240 MHz |
| Equipment Class | NII - Unlicensed National Information Infrastructure TX |
| Device Description | ARTIK-1020 |
| Responsible Party | Jenni Chun, General Manager, j1.chun@samsung.com , 973-808-6375 |
| Test Firm | Jackie Jeon, SGS KOREA CO., Ltd., jackie.jeon@sgs.com  , 82-31-8005-6020 |
| TCB Email | LST.FRE.CertNotice@ul.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 12/18/2016 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Modular approval. Output power listed is conducted. This device supports both 20 MHz, 40MHz and 80MHz bandwidths. Device operates with specific antennas in MIMO configurations as described in this filing. This module may only be installed by the OEM or an OEM integrator. Only antenna(s) documented in this filings may be used with this transmitter. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be collocated or operating in conjunction with any other antenna or transmitter within a host device, except in accordance with FCC multi-transmitter product procedures. OEM integrators, end-users and installers must be provided with antenna installation instructions and transmitter operating conditions for satisfying RF exposure compliance. |
