FCC ID 2ABOSGCPHOTOPRO

FCC ID 2ABOSGCPHOTOPRO Users-Manual, 2ABOS GCPHOTOPRO, 2ABOSGCPH0T0PR0, 2ABOSGCPHOTOPRO, 2ABO5GCPHOTOPRO, 2AB0SGCPH0T0PR0

Sky Phone LLC 4G Smart Phone GCPHOTOPRO

An FCC ID is the product ID assigned by the FCC to identify wireless products in the market. The FCC chooses 3 or 5 character "Grantee" codes to identify the business that created the product. For example, the grantee code for FCC ID: 2ABOSGCPHOTOPRO is 2ABOS. The remaining characters of the FCC ID, GCPHOTOPRO, are often associated with the product model, but they can be random. These letters are chosen by the applicant. In addition to the application, the FCC also publishes internal images, external images, user manuals, and test results for wireless devices. They can be under the "exhibits" tab below.

Purchase on Amazon: 4G Smart Phone

*Please Check Individual Documents for more images

Application: 4G Smart Phone
Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Short Link: fcc.id/2ABOSGCPHOTOPRO
Sources: FCC.gov | FCC.report
Registered By: Sky Phone LLC - 2ABOS (United States)

App #	Purpose	Date	Unique ID
1	Original Equipment	2016-07-22	Jj0+OM0Ndjcphja/lTN12A==
2	Original Equipment	2016-07-22	w2mdiHXT3eU3Wwar/72GYQ==
3	Original Equipment	2016-07-22	AEoVQ43u5Xj3CxEckjKRrQ==
4	Original Equipment	2016-07-22	WZHFRrPxokhfl3/o/yn0Zg==

Operating Frequencies

Colombia Homologation [?]: 2ABOSGCPHOTOPRO

Device operates within approved frequencies overlapping with the following cellular bands: LTE 41,TD 2500 DOWN | LTE 7,2600 UP | UMTS CH 7 UP |

Frequency Range	Power Output	Tolerance	Emission Designator	Rule Parts	Grant Notes	App #
				15B	CC	3.1
704-716 MHz	112 mW	2.5ppm	4M57G7D	27		2.45
704-716 MHz	109 mW	2.5ppm	4M57D7W	27		2.46
704-716 MHz	112 mW	2.5ppm	9M02G7D	27		2.47
704-716 MHz	109 mW	2.5ppm	9M02D7W	27		2.48
824.7-848.3 MHz	118 mW	2.5ppm	1M10D7W	22H		2.3
824.7-848.3 MHz	115 mW	2.5ppm	1M10G7D	22H		2.29
825.5-847.5 MHz	112 mW	2.5ppm	2M69G7D	22H		2.31
825.5-847.5 MHz	121 mW	2.5ppm	2M69D7W	22H		2.32
826.5-846.5 MHz	115 mW	2.5ppm	4M53G7D	22H		2.33
826.5-846.5 MHz	118 mW	2.5ppm	4M55D7W	22H		2.34
829-844 MHz	118 mW	2.5ppm	8M98G7D	22H		2.35
829-844 MHz	121 mW	2.5ppm	8M98D7W	22H		2.36
1.7107-1.7543 GHz	129 mW	2.5ppm	1M10D7W	27		2.2
1.7107-1.7543 GHz	129 mW	2.5ppm	1M10G7D	27		2.19
1.7115-1.7535 GHz	126 mW	2.5ppm	2M68G7D	27		2.21
1.7115-1.7535 GHz	123 mW	2.5ppm	2M69D7W	27		2.22
1.715-1.75 GHz	123 mW	2.5ppm	8M98G7D	27		2.23
1.715-1.75 GHz	129 mW	2.5ppm	8M98D7W	27		2.24
1.7175-1.7475 GHz	126 mW	2.5ppm	13M5G7D	27		2.25
1.7175-1.7475 GHz	126 mW	2.5ppm	13M5D7W	27		2.26
1.72-1.745 GHz	126 mW	2.5ppm	18M0G7D	27		2.27
1.72-1.745 GHz	129 mW	2.5ppm	18M0D7W	27		2.28
1.8502-1.9098 GHz	251 mW	2.5ppm	245KG7W	24E		2.5
1.8507-1.9093 GHz	120 mW	2.5ppm	1M11G7D	24E		2.7
1.8507-1.9093 GHz	123 mW	2.5ppm	1M11D7W	24E		2.8
1.8515-1.9085 GHz	123 mW	2.5ppm	2M69D7W	24E		2.1
1.8515-1.9085 GHz	120 mW	2.5ppm	2M71G7D	24E		2.9
1.8525-1.9075 GHz	126 mW	2.5ppm	4M53G7D	24E		2.11
1.8525-1.9075 GHz	126 mW	2.5ppm	4M55D7W	24E		2.12
1.8528-1.9074 GHz	155 mW	2.5ppm	4M21F9W	24E		2.6
1.855-1.905 GHz	120 mW	2.5ppm	8M94G7D	24E		2.13
1.855-1.905 GHz	126 mW	2.5ppm	8M94D7W	24E		2.14
1.8575-1.9025 GHz	120 mW	2.5ppm	13M5G7D	24E		2.15
1.8575-1.9025 GHz	126 mW	2.5ppm	13M5D7W	24E		2.16
1.86-1.9 GHz	120 mW	2.5ppm	18M0G7D	24E		2.17
1.86-1.9 GHz	120 mW	2.5ppm	18M0D7W	24E		2.18
2.402-2.48 GHz	3 mW			15C	CC	1.1
2.402-2.48 GHz	0.7 mW			15C	CC	4.3
2.412-2.472 GHz	40.4 mW			15C	CC	4.1
2.422-2.462 GHz	39.6 mW			15C	CC	4.2
2.5025-2.5675 GHz	132 mW	2.5ppm	4M55G7D	27		2.37
2.5025-2.5675 GHz	132 mW	2.5ppm	4M55D7W	27		2.38
2.505-2.565 GHz	132 mW	2.5ppm	8M98D7W	27		2.4
2.505-2.565 GHz	135 mW	2.5ppm	8M98G7D	27		2.39
2.5075-2.5625 GHz	132 mW	2.5ppm	13M53G7	27		2.41
2.5075-2.5625 GHz	129 mW	2.5ppm	13M53D7	27		2.42
2.51-2.56 GHz	129 mW	2.5ppm	18M0G7D	27		2.43
2.51-2.56 GHz	126 mW	2.5ppm	18M0D7W	27		2.44

Exhibits

Available Exhibits

App #	Document	Type	Submitted Available
4	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 2016-07-22
4	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (185 kB)	2016-07-22 2016-07-22
4	Test Report	Test Report Adobe Acrobat PDF (932 kB)	2016-07-22 2016-07-22
4	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 2016-07-22
4	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 2016-07-22
4	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 2016-07-22
4	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 2016-07-22
1	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 2016-07-22
1	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (185 kB)	2016-07-22 2016-07-22
1	Test Report	Test Report Adobe Acrobat PDF (981 kB)	2016-07-22 2016-07-22
1	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 2016-07-22
1	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 2016-07-22
1	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 2016-07-22
1	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 2016-07-22
3	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 2016-07-22
3	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (328 kB)	2016-07-22 2016-07-22
3	Test Report	Test Report Adobe Acrobat PDF (315 kB)	2016-07-22 2016-07-22
3	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 2016-07-22
3	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 2016-07-22
3	Extrnal Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 2016-07-22
3	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 2016-07-22
2	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 2016-07-22
2	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (88 kB)	2016-07-22 2016-07-22
2	Test Report	Test Report Adobe Acrobat PDF (3229 kB)	2016-07-22 2016-07-22
2	SAR Test Report	RF Exposure Info Adobe Acrobat PDF (5741 kB)	2016-07-22 2016-07-22
2	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 2016-07-22
2	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 2016-07-22
2	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 2016-07-22
2	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 2016-07-22

APP # 4 (2016-07-22)

App #	Document	Type	Submitted Available
4	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (185 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	Test Report	Test Report Adobe Acrobat PDF (932 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
4	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00

APP # 1 (2016-07-22)

App #	Document	Type	Submitted Available
1	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (185 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	Test Report	Test Report Adobe Acrobat PDF (981 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
1	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00

APP # 3 (2016-07-22)

App #	Document	Type	Submitted Available
3	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (328 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	Test Report	Test Report Adobe Acrobat PDF (315 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	Extrnal Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
3	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00

APP # 2 (2016-07-22)

App #	Document	Type	Submitted Available
2	Users Manual	Users Manual Adobe Acrobat PDF (232 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	Test Setup Photos	Test Setup Photos Adobe Acrobat PDF (88 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	Test Report	Test Report Adobe Acrobat PDF (3229 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	SAR Test Report	RF Exposure Info Adobe Acrobat PDF (5741 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	Internal Photos	Internal Photos Adobe Acrobat PDF (893 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	FCC ID Label	ID Label/Location Info Adobe Acrobat PDF (96 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	External Photos	External Photos Adobe Acrobat PDF (512 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00
2	Confidential Request Letters	Cover Letter(s) Adobe Acrobat PDF (39 kB)	2016-07-22 00:00:00 2016-07-22 00:00:00

APP # 1 (2016-07-22)

App #	Document	Type	Submitted Available
1	Operational Description	Operational Description Adobe Acrobat PDF (35 kB)	2016-07-22 00:00:00 N/A

APP # 2 (2016-07-22)

App #	Document	Type	Submitted Available
2	Operational Description	Operational Description Adobe Acrobat PDF (35 kB)	2016-07-22 00:00:00 N/A

APP # 3 (2016-07-22)

App #	Document	Type	Submitted Available
3	Block Diagram	Block Diagram Adobe Acrobat PDF (11 kB)	2016-07-22 00:00:00 N/A

APP # 1 (2016-07-22)

App #	Document	Type	Submitted Available
1	Block Diagram	Block Diagram Adobe Acrobat PDF (11 kB)	2016-07-22 00:00:00 N/A

APP # 4 (2016-07-22)

App #	Document	Type	Submitted Available
4	Operational Description	Operational Description Adobe Acrobat PDF (35 kB)	2016-07-22 00:00:00 N/A

APP # 2 (2016-07-22)

App #	Document	Type	Submitted Available
2	Turn Up Information	Parts List/Tune Up Info Adobe Acrobat PDF (52 kB)	2016-07-22 00:00:00 N/A

APP # 4 (2016-07-22)

App #	Document	Type	Submitted Available
4	Block Diagram	Block Diagram Adobe Acrobat PDF (11 kB)	2016-07-22 00:00:00 N/A

APP # 1 (2016-07-22)

App #	Document	Type	Submitted Available
1	Schematics	Schematics Adobe Acrobat PDF (307 kB)	2016-07-22 00:00:00 N/A

APP # 2 (2016-07-22)

App #	Document	Type	Submitted Available
2	Parts List	Parts List/Tune Up Info Adobe Acrobat PDF (127 kB)	2016-07-22 00:00:00 N/A
2	Schematics	Schematics Adobe Acrobat PDF (307 kB)	2016-07-22 00:00:00 N/A

APP # 4 (2016-07-22)

App #	Document	Type	Submitted Available
4	Schematics	Schematics Adobe Acrobat PDF (307 kB)	2016-07-22 00:00:00 N/A

Application Forms

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Sky Phone LLC
FCC Registration Number (FRN):	0023252042
Alphanumeric FCC ID:	2ABOSGCPHOTOPRO
Unique Application Identifier:	Jj0+OM0Ndjcphja/lTN12A==
Line one:	1348 Washington Av.
Line two:	Suite 350
City:	Miami Beach
State:	Florida
Country:	United States
Zip Code:	33139

TCB Information

TCB Application Email Address:	bacl.regulatory@baclcorp.com
TCB Scope:	A4: UNII devices & low power transmitters using spread spectrum techniques

FCC ID

Grantee Code:	2ABOS
Product Code:	GCPHOTOPRO

Person at the applicant's address to receive grant or for contact

Name:

Roberto Conrado

Telephone Number:

3055315218

Extension:

Fax Number:	3056736938
Email:	rc@skydevices.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: DSS - Part 15 Spread Spectrum Transmitter
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	4G Smart Phone

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? Yes

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Bay Area Compliance Laboratory Corp. (Shenzhen)

First Name: John

Last Name: Chan

Telephone Number:

08675533320018

Extension:

8016

Fax Number: 08675533320008

E-mail: john.chan@baclcorp.com

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Output power listed is peak conducted

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

WILLFUL FALSE STATEMENTS MADE ON THIS FORM ARE PUNISHABLE BY FINE AND IMPRISONMENT (U.S. CODE, TITLE 18, SECTION 1001), AND/OR REVOCATION OF ANY STATION LICENSE OR CONSTRUCTION PERMIT (U.S. CODE, TITLE 47, SECTION 312(a)(1)), AND/OR FORFEITURE (U.S. CODE, TITLE 47, SECTION 503).

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

The applicant must certify that neither the applicant nor any party to the application is subject to a denial of Federal benefits, that include FCC benefits, pursuant to Section 5301 of the Anti-Drug Abuse Act of 1988, 21 U.S.C. § 862 because of a conviction for possession or distribution of a controlled substance. See 47 CFR 1.2002(b) for the definition of a "party" for these purposes.

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

I certify that I am authorized to sign this application. All of the statements herein and the exhibits attached hereto, are true and correct to the best of my knowledge and belief. In accepting a Grant of Equipment Authorization as a result of the representations made in this application, the applicant is responsible for (1) labeling the equipment with the exact FCC ID specified in this application, (2) compliance statement labeling pursuant to the applicable rules, and (3) compliance of the equipment with the applicable technical rules. If the applicant is not the actual manufacturer of the equipment, appropriate arrangements have been made with the manufacturer to ensure that production units of this equipment will continue to comply with the FCC's technical requirements.

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

If an agent has signed this application on behalf of the applicant, a written letter of authorization which includes information to enable the agent to respond to the above section 5301 (Anti-Drug Abuse) Certification statement has been provided by the applicant. It is understood that the letter of authorization must be submitted to the FCC upon request, and that the FCC reserves the right to contact the applicant directly at any time.

Signature of Authorized Person Filing: Roberto Conrado

Title of authorized signature:

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Sky Phone LLC
FCC Registration Number (FRN):	0023252042
Alphanumeric FCC ID:	2ABOSGCPHOTOPRO
Unique Application Identifier:	w2mdiHXT3eU3Wwar/72GYQ==
Line one:	1348 Washington Av.
Line two:	Suite 350
City:	Miami Beach
State:	Florida
Country:	United States
Zip Code:	33139

TCB Information

TCB Application Email Address:	bacl.regulatory@baclcorp.com
TCB Scope:	B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 & 27

FCC ID

Grantee Code:	2ABOS
Product Code:	GCPHOTOPRO

Person at the applicant's address to receive grant or for contact

Name:

Roberto Conrado

Telephone Number:

3055315218

Extension:

Fax Number:	3056736938
Email:	rc@skydevices.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: PCE - PCS Licensed Transmitter held to ear
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	4G Smart Phone

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? Yes

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Bay Area Compliance Laboratory Corp. (Shenzhen)

First Name: John

Last Name: Chan

Telephone Number:

08675533320018

Extension:

8016

Fax Number: 08675533320008

E-mail: john.chan@baclcorp.com

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Output power listed is ERP for operations below 1 GHz and EIRP for operations above 1 GHz. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2/4, 5/10/15/20 MHz BW modes in Band 7, 1.4/3/5/10 MHz BW modes in Band 5, 5/10 MHz BW modes in Band 17. The antenna(s) used for this transmitter must not be co-located with any other transmitters except in accordance with FCC multi-transmitter product procedures. SAR compliance for body-worn operating conditions is restricted to belt clips, holsters or similar accessories that have no metallic component in the assembly and must provide a minimum separation distance of 10 mm between the device and the body. End-users must be informed of the body-worn operating requirements for satisfying RF exposure compliance. The highest reported SAR values for head, body-worn accessory, product specific, and simultaneous transmission exposure conditions are 1.05 W/kg, 1.12W/kg, 1.28W/kg, and 1.28W/kg, respectively. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

Signature of Authorized Person Filing: Roberto Conrado

Title of authorized signature:

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Sky Phone LLC
FCC Registration Number (FRN):	0023252042
Alphanumeric FCC ID:	2ABOSGCPHOTOPRO
Unique Application Identifier:	AEoVQ43u5Xj3CxEckjKRrQ==
Line one:	1348 Washington Av.
Line two:	Suite 350
City:	Miami Beach
State:	Florida
Country:	United States
Zip Code:	33139

TCB Information

TCB Application Email Address:	bacl.regulatory@baclcorp.com
TCB Scope:	A1: Low Power Transmitters below 1 GHz (except Spread Spectrum), Unintentional Radiators, EAS (Part 11) & Consumer ISM devices

FCC ID

Grantee Code:	2ABOS
Product Code:	GCPHOTOPRO

Person at the applicant's address to receive grant or for contact

Name:

Roberto Conrado

Telephone Number:

3055315218

Extension:

Fax Number:	3056736938
Email:	rc@skydevices.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: JBP - Part 15 Class B Computing Device Peripheral
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	4G Smart Phone

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? Yes

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Bay Area Compliance Laboratory Corp. (Shenzhen)

First Name: John

Last Name: Chan

Telephone Number:

08675533320018

Extension:

8016

Fax Number: 08675533320008

E-mail: john.chan@baclcorp.com

Grant Comments

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

Signature of Authorized Person Filing: Roberto Conrado

Title of authorized signature:

Application for Equipment Authorization FCC Form 731 TCB Version

Applicant Information

Applicant's complete, legal business name:	Sky Phone LLC
FCC Registration Number (FRN):	0023252042
Alphanumeric FCC ID:	2ABOSGCPHOTOPRO
Unique Application Identifier:	WZHFRrPxokhfl3/o/yn0Zg==
Line one:	1348 Washington Av.
Line two:	Suite 350
City:	Miami Beach
State:	Florida
Country:	United States
Zip Code:	33139

TCB Information

TCB Application Email Address:	bacl.regulatory@baclcorp.com
TCB Scope:	A4: UNII devices & low power transmitters using spread spectrum techniques

FCC ID

Grantee Code:	2ABOS
Product Code:	GCPHOTOPRO

Person at the applicant's address to receive grant or for contact

Name:

Roberto Conrado

Telephone Number:

3055315218

Extension:

Fax Number:	3056736938
Email:	rc@skydevices.com

Long-Term Confidentiality

Does this application include a request for confidentiality for any portion(s) of the data contained in this application pursuant to 47 CFR § 0.459 of the Commission Rules?: Yes

Short-Term Confidentiality

Does short-term confidentiality apply to this application?: No

If so, specify the short-term confidentiality release date (MM/DD/YYYY format):
Note: If no date is supplied, the release date will be set to 45 calendar days past the date of grant.

Software Defined/Cognitive Radio

Is this application for software defined/cognitive radio authorization? No

Equipment Class

Equipment Class: DTS - Digital Transmission System
Description of product as it is marketed: (NOTE: This text will appear below the equipment class on the grant):	4G Smart Phone

Related OET KnowledgeDataBase Inquiry

Is there a KDB inquiry associated with this application? No

Modular Equipment

Modular Type: Does not apply

Application Purpose

Application is for: Original Equipment

Composite/Related Equipment

Is the equipment in this application a composite device subject to an additional equipment authorization? Yes

Is the equipment in this application part of a system that operates with, or is marketed with, another device that requires an equipment authorization? No

Test Firm Information

Name of test firm and contact person on file with the FCC:

Firm Name: Bay Area Compliance Laboratory Corp. (Shenzhen)

First Name: John

Last Name: Chan

Telephone Number:

08675533320018

Extension:

8016

Fax Number: 08675533320008

E-mail: john.chan@baclcorp.com

Grant Comments

Enter any text that you would like to appear at the bottom of the Grant of Equipment Authorization:
Output power listed is peak conducted. This device supports 20 MHz and 40 MHz bandwidth modes.

Set the grant of this application to be deferred to a specified date:
No

Equipment Authorization Waiver

Is there an equipment authorization waiver associated with this application? No

If there is an equipment authorization waiver associated with this application, has the associated waiver been approved and all information uploaded?: No

SECTION 5301 (ANTI-DRUG ABUSE) CERTIFICATION:

Does the applicant or authorized agent so certify? Yes

Applicant/Agent Certification:

Authorizing an agent to sign this application, is done solely at the applicant's discretion; however, the applicant remains responsible for all statements in this application.

Signature of Authorized Person Filing: Roberto Conrado

Title of authorized signature:

Applications are submitted for FCC ID and Grant requests. Click an above application to view details

Grants

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bay Area Compliance Laboratory Corp.
1274 Anvilwood Avenue
Sunnyvale, CA 94089

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Sky Phone LLC

1348 Washington Av.

Suite 350

Miami Beach, FL 33139

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Part 15 Class B Computing Device Peripheral
Notes:	4G Smart Phone

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15B	-

CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

Sky Phone LLC
1348 Washington Av. Suite 350
Miami Beach, FL 33139
United States

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Part 15 Class B Computing Device Peripheral
Notes:	4G Smart Phone
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15B	-

CC:	This device is certified pursuant to two different Part 15 rules sections.

Mail To:

EA511472

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bay Area Compliance Laboratory Corp.
1274 Anvilwood Avenue
Sunnyvale, CA 94089

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Sky Phone LLC

1348 Washington Av.

Suite 350

Miami Beach, FL 33139

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	4G Smart Phone

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15C	2402.0 - 2480.0	0.003

Output power listed is peak conducted

CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

Sky Phone LLC
1348 Washington Av. Suite 350
Miami Beach, FL 33139
United States

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Part 15 Spread Spectrum Transmitter
Notes:	4G Smart Phone
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15C	2402.0 - 2480.0	0.003

Output power listed is peak conducted

CC:	This device is certified pursuant to two different Part 15 rules sections.

Mail To:

EA723200

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bay Area Compliance Laboratory Corp.
1274 Anvilwood Avenue
Sunnyvale, CA 94089

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Sky Phone LLC

1348 Washington Av.

Suite 350

Miami Beach, FL 33139

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	PCS Licensed Transmitter held to ear
Notes:	4G Smart Phone

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
	22H	824.2 - 848.8	0.783	2.5 PM	245KGXW
	22H	824.2 - 848.8	0.366	2.5 PM	248KG7W
	22H	826.6 - 846.4	0.11	2.5 PM	4M21F9W
	24E	1850.2 - 1909.8	0.575	2.5 PM	245KGXW
	24E	1850.2 - 1909.8	0.251	2.5 PM	245KG7W
	24E	1852.8 - 1907.4	0.155	2.5 PM	4M21F9W
	24E	1850.7 - 1909.3	0.12	2.5 PM	1M11G7D
	24E	1850.7 - 1909.3	0.123	2.5 PM	1M11D7W
	24E	1851.5 - 1908.5	0.12	2.5 PM	2M71G7D
	24E	1851.5 - 1908.5	0.123	2.5 PM	2M69D7W
	24E	1852.5 - 1907.5	0.126	2.5 PM	4M53G7D
	24E	1852.5 - 1907.5	0.126	2.5 PM	4M55D7W
	24E	1855.0 - 1905.0	0.12	2.5 PM	8M94G7D
	24E	1855.0 - 1905.0	0.126	2.5 PM	8M94D7W
	24E	1857.5 - 1902.5	0.12	2.5 PM	13M5G7D
	24E	1857.5 - 1902.5	0.126	2.5 PM	13M5D7W
	24E	1860.0 - 1900.0	0.12	2.5 PM	18M0G7D
	24E	1860.0 - 1900.0	0.12	2.5 PM	18M0D7W
	27	1710.7 - 1754.3	0.129	2.5 PM	1M10G7D
	27	1710.7 - 1754.3	0.129	2.5 PM	1M10D7W
	27	1711.5 - 1753.5	0.126	2.5 PM	2M68G7D
	27	1711.5 - 1753.5	0.123	2.5 PM	2M69D7W
	27	1715.0 - 1750.0	0.123	2.5 PM	8M98G7D
	27	1715.0 - 1750.0	0.129	2.5 PM	8M98D7W
	27	1717.5 - 1747.5	0.126	2.5 PM	13M5G7D
	27	1717.5 - 1747.5	0.126	2.5 PM	13M5D7W
	27	1720.0 - 1745.0	0.126	2.5 PM	18M0G7D
	27	1720.0 - 1745.0	0.129	2.5 PM	18M0D7W
	22H	824.7 - 848.3	0.115	2.5 PM	1M10G7D
	22H	824.7 - 848.3	0.118	2.5 PM	1M10D7W
	22H	825.5 - 847.5	0.112	2.5 PM	2M69G7D
	22H	825.5 - 847.5	0.121	2.5 PM	2M69D7W
	22H	826.5 - 846.5	0.115	2.5 PM	4M53G7D
	22H	826.5 - 846.5	0.118	2.5 PM	4M55D7W
	22H	829.0 - 844.0	0.118	2.5 PM	8M98G7D
	22H	829.0 - 844.0	0.121	2.5 PM	8M98D7W
	27	2502.5 - 2567.5	0.132	2.5 PM	4M55G7D
	27	2502.5 - 2567.5	0.132	2.5 PM	4M55D7W
	27	2505.0 - 2565.0

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

Sky Phone LLC
1348 Washington Av. Suite 350
Miami Beach, FL 33139
United States

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	PCS Licensed Transmitter held to ear
Notes:	4G Smart Phone
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
	22H	824.2 - 848.8	0.783	2.5 PM	245KGXW
	22H	824.2 - 848.8	0.366	2.5 PM	248KG7W
	22H	826.6 - 846.4	0.11	2.5 PM	4M21F9W
	24E	1850.2 - 1909.8	0.575	2.5 PM	245KGXW
	24E	1850.2 - 1909.8	0.251	2.5 PM	245KG7W
	24E	1852.8 - 1907.4	0.155	2.5 PM	4M21F9W
	24E	1850.7 - 1909.3	0.12	2.5 PM	1M11G7D
	24E	1850.7 - 1909.3	0.123	2.5 PM	1M11D7W
	24E	1851.5 - 1908.5	0.12	2.5 PM	2M71G7D
	24E	1851.5 - 1908.5	0.123	2.5 PM	2M69D7W
	24E	1852.5 - 1907.5	0.126	2.5 PM	4M53G7D
	24E	1852.5 - 1907.5	0.126	2.5 PM	4M55D7W
	24E	1855.0 - 1905.0	0.12	2.5 PM	8M94G7D
	24E	1855.0 - 1905.0	0.126	2.5 PM	8M94D7W
	24E	1857.5 - 1902.5	0.12	2.5 PM	13M5G7D
	24E	1857.5 - 1902.5	0.126	2.5 PM	13M5D7W
	24E	1860.0 - 1900.0	0.12	2.5 PM	18M0G7D
	24E	1860.0 - 1900.0	0.12	2.5 PM	18M0D7W
	27	1710.7 - 1754.3	0.129	2.5 PM	1M10G7D
	27	1710.7 - 1754.3	0.129	2.5 PM	1M10D7W
	27	1711.5 - 1753.5	0.126	2.5 PM	2M68G7D
	27	1711.5 - 1753.5	0.123	2.5 PM	2M69D7W
	27	1715.0 - 1750.0	0.123	2.5 PM	8M98G7D
	27	1715.0 - 1750.0	0.129	2.5 PM	8M98D7W
	27	1717.5 - 1747.5	0.126	2.5 PM	13M5G7D
	27	1717.5 - 1747.5	0.126	2.5 PM	13M5D7W
	27	1720.0 - 1745.0	0.126	2.5 PM	18M0G7D
	27	1720.0 - 1745.0	0.129	2.5 PM	18M0D7W
	22H	824.7 - 848.3	0.115	2.5 PM	1M10G7D
	22H	824.7 - 848.3	0.118	2.5 PM	1M10D7W
	22H	825.5 - 847.5	0.112	2.5 PM	2M69G7D
	22H	825.5 - 847.5	0.121	2.5 PM	2M69D7W
	22H	826.5 - 846.5	0.115	2.5 PM	4M53G7D
	22H	826.5 - 846.5	0.118	2.5 PM	4M55D7W
	22H	829.0 - 844.0	0.118	2.5 PM	8M98G7D
	22H	829.0 - 844.0	0.121	2.5 PM	8M98D7W
	27	2502.5 - 2567.5	0.132	2.5 PM	4M55G7D
	27	2502.5 - 2567.5	0.132	2.5 PM	4M55D7W
	27	2505.0 - 2565.0	0.135	2.5 PM	8M98G7D
	27	2505.0 - 2565.0

TCB	GRANT OF EQUIPMENT AUTHORIZATION	TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

Bay Area Compliance Laboratory Corp.
1274 Anvilwood Avenue
Sunnyvale, CA 94089

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Sky Phone LLC

1348 Washington Av.

Suite 350

Miami Beach, FL 33139

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Digital Transmission System
Notes:	4G Smart Phone

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15C	2412.0 - 2472.0	0.0404
CC	15C	2422.0 - 2462.0	0.0396
CC	15C	2402.0 - 2480.0	0.0007

Output power listed is peak conducted. This device supports 20 MHz and 40 MHz bandwidth modes.

CC:	This device is certified pursuant to two different Part 15 rules sections.

COPY	FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION	COPY
Certification

Sky Phone LLC
1348 Washington Av. Suite 350
Miami Beach, FL 33139
United States

Date of Grant: 07/22/2016

Application Dated: 07/22/2016

Attention: Roberto Conrado

NOT TRANSFERABLE

EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:	2ABOSGCPHOTOPRO

Name of Grantee:	Sky Phone LLC

Equipment Class:	Digital Transmission System
Notes:	4G Smart Phone
Modular Type:	Does not apply

Grant Notes	FCC Rule Parts	Frequency Range (MHZ)	Output Watts	Frequency Tolerance	Emission Designator
CC	15C	2412.0 - 2472.0	0.0404
CC	15C	2422.0 - 2462.0	0.0396
CC	15C	2402.0 - 2480.0	0.0007

Output power listed is peak conducted. This device supports 20 MHz and 40 MHz bandwidth modes.

CC:	This device is certified pursuant to two different Part 15 rules sections.

Mail To:

EA420646

FCC ID 2ABOSGCPHOTOPRO

FCC ID 2ABOSGCPHOTOPRO Users-Manual, 2ABOS GCPHOTOPRO, 2ABOSGCPH0T0PR0, 2ABOSGCPHOTOPRO, 2ABO5GCPHOTOPRO, 2AB0SGCPH0T0PR0

Sky Phone LLC 4G Smart Phone GCPHOTOPRO

Purchase on Amazon: 4G Smart Phone

Operating Frequencies

Exhibits

Available Exhibits

APP # 4 (2016-07-22)

APP # 1 (2016-07-22)

APP # 3 (2016-07-22)

APP # 2 (2016-07-22)

APP # 1 (2016-07-22)

APP # 2 (2016-07-22)

APP # 3 (2016-07-22)

APP # 1 (2016-07-22)

APP # 4 (2016-07-22)

APP # 2 (2016-07-22)

APP # 4 (2016-07-22)

APP # 1 (2016-07-22)

APP # 2 (2016-07-22)

APP # 4 (2016-07-22)

Application Forms

Applications are submitted for FCC ID and Grant requests. Click an above application to view details

Grants

Grants authorize equipment for operation at approved frequencies and sale within the USA. Click an above grant to view details
