Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Report No: CCISE181114902
Cover Page
FCC REPORT
(Bluetooth)
Applicant:
Interglobe Connection Corp
Address of Applicant:
8228 NW 30th Terrace. Doral, Miami, FL 33122
Equipment Under Test (EUT)
Product Name:
Mobile Phone
Model No.:
EKO Star 5.0 G50
Trade mark:
EKO
FCC ID:
2AC7IEKONG50
Applicable standards:
FCC CFR Title 47 Part 15 Subpart C Section 15.247
Date of sample receipt:
12 Dec., 2018
Date of Test:
12 Dec., to 21 Dec., 2018
Date of report issued:
22 Dec., 2018
Test Result:
PASS *
In the configuration tested, the EUT complied with the standards specified above.
Authorized Signature:
Bruce Zhang
Laboratory Manager
This report details the results of the testing carried out on one sample. The results contained in this test report do not relate to other
samples of the same product and does not permit the use of the CCIS product certification mark. The manufacturer should ensure that all
products in series production are in conformity with the product sample detailed in this report.
This report may only be reproduced and distributed in full. If the product in this report is used in any configuration other than that detailed in
the report, the manufacturer must ensure the new system complies with all relevant standards.
This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or
falsification of the content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law.
Unless otherwise stated the results shown in this test report refer only to the sample(s) tested and such sample(s) are retained for 90 days
only.
Report No: CCISE181114902
Version
Version No.
Date
Description
00
22 Dec., 2018
Original
Tested by:
Date:
22 Dec., 2018
Date:
22 Dec., 2018
Test Engineer
Reviewed by:
Project Engineer
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 2 of 54
Report No: CCISE181114902
Contents
Page
COVER PAGE ....................................................................................................................................................... 1
VERSION ............................................................................................................................................................... 2
CONTENTS ........................................................................................................................................................... 3
TEST SUMMARY .................................................................................................................................................. 4
GENERAL INFORMATION .................................................................................................................................. 5
5.1
5.2
5.3
5.4
5.5
5.6
5.7
5.8
CLIENT INFORMATION ...............................................................................................................................5
GENERAL DESCRIPTION OF E.U.T. ............................................................................................................5
TEST ENVIRONMENT AND TEST MODE .........................................................................................................6
DESCRIPTION OF SUPPORT UNITS .............................................................................................................6
MEASUREMENT UNCERTAINTY...................................................................................................................6
LABORATORY FACILITY .............................................................................................................................6
LABORATORY LOCATION ...........................................................................................................................6
TEST INSTRUMENTS LIST ...........................................................................................................................7
TEST RESULTS AND MEASUREMENT DATA ................................................................................................ 8
6.1
ANTENNA REQUIREMENT...........................................................................................................................8
6.2
CONDUCTED EMISSIONS ...........................................................................................................................9
6.3
CONDUCTED OUTPUT POWER .................................................................................................................12
6.4
20DB OCCUPY BANDWIDTH ....................................................................................................................15
6.5
CARRIER FREQUENCIES SEPARATION ......................................................................................................18
6.6
HOPPING CHANNEL NUMBER...................................................................................................................22
6.7
DWELL TIME ...........................................................................................................................................24
6.8
PSEUDORANDOM FREQUENCY HOPPING SEQUENCE ................................................................................27
6.9
BAND EDGE............................................................................................................................................28
6.9.1 Conducted Emission Method ...........................................................................................................28
6.9.2 Radiated Emission Method ..............................................................................................................32
6.10
SPURIOUS EMISSION...............................................................................................................................45
6.10.1
Conducted Emission Method .......................................................................................................45
6.10.2
Radiated Emission Method ..........................................................................................................48
TEST SETUP PHOTO ........................................................................................................................................ 53
EUT CONSTRUCTIONAL DETAILS................................................................................................................. 54
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 3 of 54
Report No: CCISE181114902
Test Summary
Test Items
Section in CFR 47
Result
Antenna Requirement
15.203 & 15.247 (c)
Pass
AC Power Line Conducted Emission
15.207
Pass
Conducted Peak Output Power
15.247 (b)(1)
Pass
20dB Occupied Bandwidth
15.247 (a)(1)
Pass
Carrier Frequencies Separation
15.247 (a)(1)
Pass
Hopping Channel Number
15.247 (a)(1)
Pass
Dwell Time
15.247 (a)(1)
Pass
Spurious Emission
15.205 & 15.209
Pass
Band Edge
15.247(d)
Pass
Pass: The EUT complies with the essential requirements in the standard.
N/A: Not Applicable.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 4 of 54
Report No: CCISE181114902
General Information
5.1 Client Information
Applicant:
Interglobe Connection Corp
Address:
8228 NW 30th Terrace. Doral, Miami, FL 33122
Manufacturer/ Factory:
INTERGLOBE CONNECTION LTD
Address:
RM 1101 11F SAN TOI BLDG 139 CONNAUGHT RD CENTRAL HK
5.2 General Description of E.U.T.
Product Name:
Mobile Phone
Model No.:
EKO Star 5.0 G50
Operation Frequency:
2402MHz~2480MHz
Transfer rate:
1/2/3 Mbits/s
Number of channel:
79
Modulation type:
GFSK, π/4-DQPSK, 8DPSK
Modulation technology:
FHSS
Antenna Type:
Internal Antenna
Antenna gain:
-2.9 dBi
Power supply:
Rechargeable Li-ion Battery DC3.8V-2000mAh
AC adapter:
Model: Omega LTE Q60
Input: AC100-240V, 50/60Hz, 0.15A
Output: DC 5.0V, 1000mA
Test Sample Condition:
The test samples were provided in good working order with no visible
defects.
Operation Frequency each of channel for GFSK, π/4-DQPSK, 8DPSK
Channel
Frequency
Channel
Frequency
Channel
Frequency
2402MHz
20
2422MHz
40
2442MHz
2403MHz
21
2423MHz
41
2443MHz
2404MHz
22
2424MHz
42
2444MHz
2405MHz
23
2425MHz
43
2445MHz
2406MHz
24
2426MHz
44
2446MHz
2407MHz
25
2427MHz
45
2447MHz
…
…
…
…
…
…
15
2417MHz
35
2437MHz
55
2457MHz
16
2418MHz
36
2438MHz
56
2458MHz
17
2419MHz
37
2439MHz
57
2459MHz
18
2420MHz
38
2440MHz
58
2460MHz
19
2421MHz
39
2441MHz
59
2461MHz
Remark: Channel 0, 39 &78 selected for GFSK, π/4-DQPSK and 8DPSK.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Channel
60
61
62
63
64
65
…
75
76
77
78
Frequency
2462MHz
2463MHz
2464MHz
2465MHz
2466MHz
2467MHz
…
2477MHz
2478MHz
2479MHz
2480MHz
Project No.: CCISE1811149
Page 5 of 54
Report No: CCISE181114902
5.3 Test environment and test mode
Operating Environment:
Temperature:
24.0 C
Humidity:
54 % RH
Atmospheric Pressure:
1010 mbar
Test Modes:
Non-hopping mode:
Keep the EUT in continuous transmitting mode with worst case data rate.
Hopping mode:
Keep the EUT in hopping mode.
Remark
GFSK (1 Mbps) is the worst case mode.
The sample was placed 0.8m (below 1GHz)/1.5m (above 1GHz) above the ground plane of 3m chamber*.
Measurements in both horizontal and vertical polarities were performed. During the test, each emission was
maximized by: having the EUT continuously working with a fresh battery, investigated all operating modes,
rotated about all 3 axis (X, Y & Z) and considered typical configuration to obtain worst position, manipulating
interconnecting cables, rotating the turntable, varying antenna height from 1m to 4m in both horizontal and
vertical polarizations. The emissions worst-case are shown in Test Results of the following pages.
5.4 Description of Support Units
The EUT has been tested as an independent unit.
5.5 Measurement Uncertainty
Parameters
Conducted Emission (9kHz ~ 30MHz)
Radiated Emission (9kHz ~ 30MHz)
Radiated Emission (30MHz ~ 1000MHz)
Radiated Emission (1GHz ~ 18GHz)
Radiated Emission (18GHz ~ 40GHz)
Expanded Uncertainty
±2.22 dB (k=2)
±2.76 dB (k=2)
±4.28 dB (k=2)
±5.72 dB (k=2)
±2.88 dB (k=2)
5.6 Laboratory Facility
The test facility is recognized, certified, or accredited by the following organizations:
 FCC - Registration No.: 727551
Shenzhen Zhongjian Nanfang Testing Co., Ltd. has been accredited as a testing laboratory by FCC
(Federal Communications Commission). The Registration No. is 727551.
 IC - Registration No.: 10106A-1
The 3m Semi-anechoic chamber of Shenzhen Zhongjian Nanfang Testing Co., Ltd. has been
Registered by Certification and Engineering Bureau of Industry Canada for radio equipment testing with
Registration No.: 10106A-1.
 CNAS - Registration No.: CNAS L6048
Shenzhen Zhongjian Nanfang Testing Co., Ltd. is accredited to ISO/IEC 17025:2005 General
Requirements for the Competence of Testing and Calibration laboratories for the competence of
testing. The Registration No. is CNAS L6048.
 A2LA - Registration No.: 4346.01
This laboratory is accredited in accordance with the recognized International Standard ISO/IEC
17025:2005 General requirements for the competence of testing and calibration laboratories. The test
scope can be found as below link: https://portal.a2la.org/scopepdf/4346-01.pdf
5.7 Laboratory Location
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
Address: No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Tel: +86-755-23118282, Fax: +86-755-23116366
Email: info@ccis-cb.com, Website: http://www.ccis-cb.com
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 6 of 54
Report No: CCISE181114902
5.8 Test Instruments list
Radiated Emission:
966
00044
497
916
1805
Cal. Date
(mm-dd-yy)
07-22-2017
03-16-2018
03-16-2018
03-16-2018
06-22-2017
Cal. Due date
(mm-dd-yy)
07-21-2020
03-15-2019
03-15-2019
03-15-2019
06-21-2020
BBHA 9170
BBHA9170582
11-21-2018
11-21-2019
AUDIX
HP
CD
Rohde & Schwarz
Rohde & Schwarz
E3
8447D
PAP-1G18
FSP30
FSP40
2944A09358
11804
101454
100363
Version: 6.110919b
03-07-2018
03-07-2018
03-07-2018
11-21-2018
03-06-2019
03-06-2019
03-06-2019
11-21-2019
Rohde & Schwarz
ZDECL
MICRO-COAX
SUHNER
MWRFTEST
MWRFTEST
ESRP7
Z108-NJ-NJ-81
MFR64639
SUCOFLEX100
MW200
MTS8200
Test Equipment
Manufacturer
Model No.
Serial No.
3m SAC
Loop Antenna
BiConiLog Antenna
Horn Antenna
Horn Antenna
SAEMC
SCHWARZBECK
SCHWARZBECK
SCHWARZBECK
SCHWARZBECK
9m*6m*6m
FMZB1519B
VULB9163
BBHA9120D
BBHA9120D
Horn Antenna
SCHWARZBECK
EMI Test Software
Pre-amplifier
Pre-amplifier
Spectrum analyzer
Spectrum analyzer
EMI Test Receiver
Cable
Cable
Cable
RF Switch Unit
Test Software
101070
1608458
K10742-5
58193/4PE
N/A
03-07-2018
03-07-2018
03-07-2018
03-07-2018
N/A
Version: 2.0.0.0
03-06-2019
03-06-2019
03-06-2019
03-06-2019
N/A
Conducted Emission:
Test Equipment
Manufacturer
Model No.
EMI Test Receiver
Pulse Limiter
LISN
LISN
Cable
EMI Test Software
Rohde & Schwarz
SCHWARZBECK
CHASE
Rohde & Schwarz
HP
AUDIX
ESCI
OSRAM 2306
MN2050D
ESH3-Z5
10503A
E3
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Cal. Date
(mm-dd-yy)
101189
03-07-2018
9731
03-07-2018
1447
03-19-2018
8438621/010
07-21-2018
N/A
03-07-2018
Version: 6.110919b
Serial No.
Cal. Due date
(mm-dd-yy)
03-06-2019
03-06-2019
03-18-2019
07-20-2019
03-06-2019
Project No.: CCISE1811149
Page 7 of 54
Report No: CCISE181114902
Test results and measurement data
6.1 Antenna Requirement
Standard requirement:
FCC Part 15 C Section 15.203 & 247(c)
15.203 requirement:
An intentional radiator shall be designed to ensure that no antenna other than that furnished by the
responsible party shall be used with the device. The use of a permanently attached antenna or of an
antenna that uses a unique coupling to the intentional radiator, the manufacturer may design the unit
so that a broken antenna can be replaced by the user, but the use of a standard antenna jack or
electrical connector is prohibited.
15.247(c) (1)(i) requirement:
(i) Systems operating in the 2400-2483.5 MHz band that is used exclusively for fixed. Point-to-point
operations may employ transmitting antennas with directional gain greater than 6dBi provided the
maximum conducted output power of the intentional radiator is reduced by 1 dB for every 3 dB that the
directional gain of the antenna exceeds 6dBi.
E.U.T Antenna:
The Bluetooth antenna is an Internal antenna which permanently attached, and the best case gain of
the antenna is -2.9 dBi.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 8 of 54
Report No: CCISE181114902
6.2 Conducted Emissions
Test Requirement:
FCC Part 15 C Section 15.207
Test Method:
ANSI C63.10:2013
Test Frequency Range:
150 kHz to 30 MHz
Class / Severity:
Class B
Receiver setup:
RBW=9 kHz, VBW=30 kHz, Sweep time=auto
Frequency range
Limit (dBuV)
(MHz)
Quasi-peak
Average
0.15-0.5
66 to 56*
56 to 46*
0.5-5
56
46
5-30
60
50
* Decreases with the logarithm of the frequency.
Limit:
Class B
Test setup:
Test procedure:
1. The E.U.T and simulators are connected to the main power through a
line impedance stabilization network (L.I.S.N.). This provides a
50ohm/50uH coupling impedance for the measuring equipment.
2. The peripheral devices are also connected to the main power through a
LISN that provides a 50ohm/50uH coupling impedance with 50ohm
termination. (Please refer to the block diagram of the test setup and
photographs).
3. Both sides of A.C. line are checked for maximum conducted
interference. In order to find the maximum emission, the relative
positions of equipment and all of the interface cables must be changed
according to ANSI C63.4: 2014 on conducted measurement.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 9 of 54
Report No: CCISE181114902
Measurement Data:
Product name:
Mobile Phone
Product model:
EKO Star 5.0 G50
Test by:
Carey
Test mode:
BT Tx mode
Test frequency:
150 kHz ~ 30 MHz
Phase:
Line
Test voltage:
AC 120 V/60 Hz
Environment:
Temp: 22.5℃
Huni: 55%
Notes:
1. An initial pre-scan was performed on the line and neutral lines with peak detector.
2. Quasi-Peak and Average measurement were performed at the frequencies with maximized peak emission.
3. Final Level =Receiver Read level + LISN Factor + Cable Loss.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 10 of 54
Report No: CCISE181114902
Product name:
Mobile Phone
Product model:
EKO Star 5.0 G50
Test by:
Carey
Test mode:
BT Tx mode
Test frequency:
150 kHz ~ 30 MHz
Phase:
Neutral
Test voltage:
AC 120 V/60 Hz
Environment:
Temp: 22.5℃
Huni: 55%
Notes:
1. An initial pre-scan was performed on the line and neutral lines with peak detector.
2. Quasi-Peak and Average measurement were performed at the frequencies with maximized peak emission.
3. Final Level =Receiver Read level + LISN Factor + Cable Loss.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 11 of 54
Report No: CCISE181114902
6.3 Conducted Output Power
Test Requirement:
FCC Part 15 C Section 15.247 (b)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
RBW=1MHz, VBW=3MHz, Detector=Peak (If 20dB BW ≤1 MHz)
RBW=3MHz, VBW=10MHz, Detector=Peak (If 20dB BW > 1 MHz and <
3MHz)
For frequency hopping systems operating in the 2400-2483.5 MHz band
employing at least 75 non-overlapping hopping channels: 1 watt. For all
other frequency hopping systems in the 2400-2483.5 MHz band: 0.125
watts.
Receiver setup:
Limit:
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode
Test results:
Pass
Measurement Data:
Test channel
Peak Output Power (dBm)
Limit (dBm)
Result
GFSK mode
Lowest channel
3.93
30.00
Pass
Middle channel
3.16
30.00
Pass
Highest channel
2.27
30.00
Pass
π/4-DQPSK mode
Lowest channel
3.53
21.00
Pass
Middle channel
2.80
21.00
Pass
Highest channel
1.85
21.00
Pass
8DPSK mode
Lowest channel
3.50
21.00
Pass
Middle channel
2.80
21.00
Pass
Highest channel
1.85
21.00
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 12 of 54
Report No: CCISE181114902
Test plot as follows:
Modulation mode: π/4-DQPSK
Modulation mode: GFSK
Ref
16.5 dBm
Offset
* Att
* RBW
1 MHz
* VBW
3 MHz
20 dB
Marker 1 [T1 ]
3.93 dBm
SWT 2.5 ms
2.401840000 GHz
Ref
6.5 dB
10
* Att
20 dB
* RBW
3 MHz
* VBW
10 MHz
3.53 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.401940000 GHz
6.5 dB
10
1 PK
16.5 dBm
Offset
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.402 GHz
Date: 18.DEC.2018
500 kHz/
Span 5 MHz
Center 2.402 GHz
00:50:35
Date: 18.DEC.2018
1 MHz/
00:50:55
Lowest channel
Ref
16.5 dBm
Offset
* Att
* RBW
1 MHz
* VBW
3 MHz
20 dB
Lowest channel
Marker 1 [T1 ]
3.16 dBm
SWT 2.5 ms
2.441100000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
3 MHz
* VBW
10 MHz
2.80 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.440740000 GHz
6.5 dB
10
1 PK
Span 10 MHz
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.441 GHz
Date: 18.DEC.2018
500 kHz/
Span 5 MHz
Center 2.441 GHz
00:50:07
Date: 18.DEC.2018
1 MHz/
00:51:10
Middle channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
1 MHz
* VBW
3 MHz
SWT 2.5 ms
Middle channel
Marker 1 [T1 ]
2.27 dBm
2.480160000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
3 MHz
* VBW
10 MHz
1.85 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.479700000 GHz
6.5 dB
10
1 PK
Span 10 MHz
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.48 GHz
Date: 18.DEC.2018
500 kHz/
00:50:23
Span 5 MHz
Center 2.48 GHz
Date: 18.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
1 MHz/
Span 10 MHz
00:51:25
Highest channel
Project No.: CCISE1811149
Page 13 of 54
Report No: CCISE181114902
Modulation mode: 8DPSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
3 MHz
* VBW
10 MHz
3.50 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.401980000 GHz
Ref
6.5 dB
Offset
10
* Att
20 dB
* RBW
3 MHz
* VBW
10 MHz
2.80 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.440980000 GHz
6.5 dB
10
1 PK
16.5 dBm
MAXH
1 PK
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.402 GHz
Date: 18.DEC.2018
1 MHz/
Span 10 MHz
Center 2.441 GHz
00:52:04
Date: 18.DEC.2018
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
1 MHz/
Span 10 MHz
00:51:52
Middle channel
* RBW
3 MHz
* VBW
10 MHz
1.85 dBm
SWT 2.5 ms
Marker 1 [T1 ]
2.480020000 GHz
6.5 dB
10
1 PK
MAXH
LVL
-10
-20
-30
3DB
-40
AC
-50
-60
-70
-80
Center 2.48 GHz
Date: 18.DEC.2018
1 MHz/
Span 10 MHz
00:51:39
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 14 of 54
Report No: CCISE181114902
6.4 20dB Occupy Bandwidth
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=30 kHz, VBW=100 kHz, detector=Peak
Limit:
NA
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode
Test results:
Pass
Measurement Data:
Test channel
20dB Occupy Bandwidth (kHz)
GFSK
π/4-DQPSK
8DPSK
Lowest
828
1122
1176
Middle
832
1128
1170
Highest
832
1128
1176
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 15 of 54
Report No: CCISE181114902
Test plot as follows:
Modulation mode: π/4-DQPSK
Modulation mode: GFSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.23 dB
SWT 2.5 ms
828.000000000 kHz
6.5 dB
Ref
-16.41 dBm
10
2.401568000 GHz
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-1.99 dB
SWT 5 ms
1.122000000 MHz
6.5 dB
Marker 1 [T1 ]
-18.73 dBm
10
2.401436000 GHz
D1 3.62 dBm
1 PK
16.5 dBm
Offset
Marker 1 [T1 ]
1 PK
MAXH
D1 1.29 dBm
MAXH
LVL
LVL
-10
-10
D2 -16.38 dBm
-20
D2 -18.71 dBm
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.402 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
Center 2.402 GHz
01:06:28
Date: 18.DEC.2018
300 kHz/
01:05:10
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Lowest channel
Delta 1 [T1 ]
-0.15 dB
SWT 2.5 ms
832.000000000 kHz
6.5 dB
Ref
-17.39 dBm
2.440564000 GHz
16.5 dBm
Offset
Marker 1 [T1 ]
10
Span 3 MHz
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.23 dB
SWT 5 ms
1.128000000 MHz
6.5 dB
Marker 1 [T1 ]
-20.88 dBm
10
2.440430000 GHz
D1 2.9 dBm
1 PK
1 PK
MAXH
D1 0.48 dBm
MAXH
LVL
LVL
-10
-10
D2 -17.1 dBm
-20
D2 -19.52 dBm
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.441 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
Center 2.441 GHz
01:07:36
Date: 18.DEC.2018
300 kHz/
01:04:16
Middle channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Middle channel
Delta 1 [T1 ]
-0.63 dB
SWT 2.5 ms
832.000000000 kHz
6.5 dB
16.5 dBm
Offset
-18.11 dBm
2.479568000 GHz
Ref
Marker 1 [T1 ]
10
1 PK
Span 3 MHz
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
SWT 5 ms
-0.37 dB
1.128000000 MHz
6.5 dB
Marker 1 [T1 ]
-21.81 dBm
10
D1 2.02 dBm
2.479430000 GHz
1 PK
MAXH
D1 -0.43 dBm
MAXH
LVL
LVL
-10
-10
D2 -17.98 dBm
-20
-20
-30
-30
3DB
-40
D2 -20.43 dBm
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.48 GHz
Date: 18.DEC.2018
200 kHz/
01:08:24
Span 2 MHz
Center 2.48 GHz
Date: 18.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
300 kHz/
Span 3 MHz
01:02:31
Highest channel
Project No.: CCISE1811149
Page 16 of 54
Report No: CCISE181114902
Modulation mode: 8DPSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
-0.56 dB
SWT 5 ms
1.176000000 MHz
6.5 dB
-19.37 dBm
2.401418000 GHz
16.5 dBm
Offset
Marker 1 [T1 ]
10
1 PK
Ref
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Delta 1 [T1 ]
0.35 dB
SWT 5 ms
1.170000000 MHz
6.5 dB
Marker 1 [T1 ]
-20.02 dBm
10
D1 1.45 dBm
2.440418000 GHz
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
D2 -18.55 dBm
-20
-20
-30
D2 -19.37 dBm
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.402 GHz
Date: 18.DEC.2018
300 kHz/
Span 3 MHz
Center 2.441 GHz
00:54:26
Date: 18.DEC.2018
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
30 kHz
* VBW
100 kHz
Span 3 MHz
00:57:09
Middle channel
-0.83 dB
1.176000000 MHz
6.5 dB
Marker 1 [T1 ]
-21.01 dBm
2.479418000 GHz
300 kHz/
Delta 1 [T1 ]
SWT 5 ms
10
1 PK
D1 0.63 dBm
D1 -0.43 dBm
MAXH
LVL
-10
-20
D2 -20.43 dBm
-30
3DB
-40
AC
-50
-60
-70
-80
Center 2.48 GHz
Date: 18.DEC.2018
300 kHz/
Span 3 MHz
00:58:32
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 17 of 54
Report No: CCISE181114902
6.5 Carrier Frequencies Separation
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=100 kHz, VBW=300 kHz, detector=Peak
Limit:
a)
b)
0.025MHz or the 20dB bandwidth (whichever is greater)
0.025MHz or 2/3 of the 20dB bandwidth (whichever is greater)
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 18 of 54
Report No: CCISE181114902
Measurement Data:
Test channel
Carrier Frequencies Separation
(kHz)
Limit (kHz)
Result
GFSK
Lowest
1000
828.00
Pass
Middle
1000
828.00
Pass
Highest
1000
828.00
Pass
π/4-DQPSK mode
Lowest
1000
748.00
Pass
Middle
1000
748.00
Pass
Highest
1008
748.00
Pass
8DPSK mode
Lowest
1004
780.00
Pass
Middle
1000
780.00
Pass
Highest
1004
780.00
Pass
Note: According to section 6.4
Mode
20dB bandwidth (kHz)
(worse case)
Limit (kHz)
(Carrier Frequencies Separation)
GFSK
828
828.00
π/4-DQPSK
1122
748.00
8DPSK
1170
780.00
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 19 of 54
Report No: CCISE181114902
Test plot as follows:
Modulation mode: π/4-DQPSK
Modulation mode: GFSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
-0.01 dB
SWT 2.5 ms
6.5 dB
1.000000000 MHz
2.401840000 GHz
16.5 dBm
Offset
3.51 dBm
10
1 PK
Ref
Marker 1 [T1 ]
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
-0.01 dB
SWT 2.5 ms
6.5 dB
1.000000000 MHz
Marker 1 [T1 ]
2.57 dBm
10
1 PK
MAXH
2.401840000 GHz
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4025 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
Center 2.4025 GHz
01:10:03
Date: 18.DEC.2018
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
-0.04 dB
1.000000000 MHz
Ref
2.79 dBm
2.440840000 GHz
16.5 dBm
Offset
Marker 1 [T1 ]
10
Span 2 MHz
Lowest channel
Delta 1 [T1 ]
SWT 2.5 ms
6.5 dB
200 kHz/
01:15:01
Lowest channel
1 PK
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
0.01 dB
SWT 2.5 ms
6.5 dB
1.000000000 MHz
Marker 1 [T1 ]
1.75 dBm
10
1 PK
MAXH
2.440844000 GHz
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
Center 2.4415 GHz
01:11:00
Date: 18.DEC.2018
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
6.5 dB
Delta 1 [T1 ]
-0.03 dB
1.000000000 MHz
Ref
2.478840000 GHz
16.5 dBm
Offset
1.94 dBm
10
Span 2 MHz
Middle channel
Marker 1 [T1 ]
200 kHz/
01:13:56
Middle channel
1 PK
MAXH
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
6.5 dB
Delta 1 [T1 ]
-0.16 dB
1.008000000 MHz
Marker 1 [T1 ]
0.98 dBm
10
2.478828000 GHz
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4795 GHz
Date: 18.DEC.2018
200 kHz/
01:11:51
Span 2 MHz
Center 2.4795 GHz
Date: 18.DEC.2018
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
200 kHz/
Span 2 MHz
01:12:51
Highest channel
Project No.: CCISE1811149
Page 20 of 54
Report No: CCISE181114902
Modulation mode: 8DPSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
6.5 dB
Delta 1 [T1 ]
-0.00 dB
1.004000000 MHz
2.56 dBm
2.401836000 GHz
16.5 dBm
Offset
Marker 1 [T1 ]
10
1 PK
Ref
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Delta 1 [T1 ]
-0.02 dB
SWT 2.5 ms
6.5 dB
1.000000000 MHz
Marker 1 [T1 ]
1.80 dBm
10
1 PK
MAXH
2.440840000 GHz
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4025 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
Center 2.4415 GHz
01:16:05
Date: 18.DEC.2018
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 ms
6.5 dB
200 kHz/
Span 2 MHz
01:17:05
Middle channel
Delta 1 [T1 ]
-0.04 dB
1.004000000 MHz
Marker 1 [T1 ]
0.89 dBm
10
2.478836000 GHz
1 PK
MAXH
LVL
-10
-20
-30
3DB
-40
AC
-50
-60
-70
-80
Center 2.4795 GHz
Date: 18.DEC.2018
200 kHz/
Span 2 MHz
01:18:12
Highest channel
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 21 of 54
Report No: CCISE181114902
6.6 Hopping Channel Number
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=100 kHz, VBW=300 kHz, Frequency range=2400MHz-2483.5MHz,
Detector=Peak
Limit:
15 channels
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Hopping mode
Test results:
Pass
Measurement Data:
Mode
GFSK, π/4-DQPSK, 8DPSK
Hopping channel numbers
Limit
Result
79
15
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 22 of 54
Report No: CCISE181114902
Test plot as follows:
π/4-DQPSK
GFSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 10 ms
6.5 dB
-1.19 dB
78.000000000 MHz
Ref
3.42 dBm
2.401900000 GHz
16.5 dBm
Offset
Marker 1 [T1 ]
10
1 PK
Delta 1 [T1 ]
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 10 ms
6.5 dB
1.12 dBm
10
2.402100000 GHz
1 PK
MAXH
-0.23 dB
78.000000000 MHz
Marker 1 [T1 ]
Delta 1 [T1 ]
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
10 MHz/
Span 100 MHz
Center 2.4415 GHz
01:23:55
Date: 18.DEC.2018
10 MHz/
Span 100 MHz
01:22:11
8DPSK
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 10 ms
6.5 dB
-2.59 dB
78.200000000 MHz
Marker 1 [T1 ]
1.96 dBm
10
2.401900000 GHz
1 PK
Delta 1 [T1 ]
MAXH
LVL
-10
-20
-30
3DB
-40
AC
-50
-60
-70
-80
Center 2.4415 GHz
Date: 18.DEC.2018
10 MHz/
Span 100 MHz
01:20:04
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 23 of 54
Report No: CCISE181114902
6.7 Dwell Time
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1)
Test Method:
ANSI C63.10:2013 and KDB DA00-705
Receiver setup:
RBW=1 MHz, VBW=1 MHz, Span=0 Hz, Detector=Peak
Limit:
0.4 Second
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Hopping mode
Test results:
Pass
Measurement Data (Worse case):
Mode
GFSK
π/4-DQPSK
8DPSK
Packet
Dwell time (second)
DH1
0.12864
DH3
0.26784
DH5
0.31232
2-DH1
0.13120
2-DH3
0.26688
2-DH5
0.31573
3-DH1
0.12736
3-DH3
0.26688
3-DH5
0.31147
Limit (second)
Result
0.4
Pass
0.4
Pass
0.4
Pass
Note:
The test period = 0.4 Second/Channel x 79 Channel = 31.6 s
Calculation Formula: Dwell time = Ton time per hop * Hopping numbers * Period
For example:
DH1 time slot=0.420*(1600/ (2*79)) * 31.6=128.64ms
DH3 time slot=1.674*(1600/ (4*79)) * 31.6=267.84ms
DH5 time slot=2.928*(1600/ (6*79)) * 31.6=312.32ms
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 24 of 54
Report No: CCISE181114902
Test plot as follows:
Modulation mode: π/4-DQPSK
Modulation mode: GFSK
RBW 1 MHz
* VBW
Ref
16.5 dBm
Offset
* Att
20 dB
Delta 1 [T1 ]
1 MHz
6.5 dB
RBW 1 MHz
-0.59 dB
SWT 1 ms
* VBW
402.000000 µs
Ref
Offset
Marker 1 [T1 ]
-63.33 dBm
10
404.000000 µs
16.5 dBm
* Att
20 dB
Delta 1 [T1 ]
1 MHz
0.74 dB
SWT 1 ms
410.000000 µs
6.5 dB
Marker 1 [T1 ]
-64.30 dBm
10
274.000000 µs
SGL
1 PK
SGL
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
100 µs/
Center 2.4415 GHz
01:25:39
Date: 18.DEC.2018
100 µs/
01:26:10
DH1
RBW 1 MHz
* VBW
Ref
16.5 dBm
Offset
* Att
20 dB
2-DH1
Delta 1 [T1 ]
1 MHz
6.5 dB
RBW 1 MHz
-1.28 dB
SWT 3 ms
* VBW
1.674000 ms
Ref
Offset
Marker 1 [T1 ]
-60.18 dBm
10
648.000000 µs
16.5 dBm
* Att
20 dB
Delta 1 [T1 ]
1 MHz
SWT 3 ms
6.5 dB
-0.85 dB
1.668000 ms
Marker 1 [T1 ]
-61.06 dBm
10
840.000000 µs
SGL
1 PK
SGL
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
300 µs/
Center 2.4415 GHz
01:27:37
Date: 18.DEC.2018
300 µs/
01:26:47
DH3
RBW 1 MHz
* VBW
Ref
16.5 dBm
Offset
* Att
20 dB
2-DH3
Delta 1 [T1 ]
1 MHz
SWT 4 ms
6.5 dB
RBW 1 MHz
0.48 dB
* VBW
2.928000 ms
Ref
Offset
Marker 1 [T1 ]
-62.45 dBm
10
440.000000 µs
16.5 dBm
* Att
20 dB
Delta 1 [T1 ]
1 MHz
SWT 4 ms
6.5 dB
1.78 dB
2.960000 ms
Marker 1 [T1 ]
-62.10 dBm
10
344.000000 µs
SGL
1 PK
MAXH
SGL
1 PK
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-60
-50
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
400 µs/
01:29:12
Center 2.4415 GHz
Date: 18.DEC.2018
DH5
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
400 µs/
01:29:43
2-DH5
Project No.: CCISE1811149
Page 25 of 54
Report No: CCISE181114902
Modulation mode: 8DPSK
RBW 1 MHz
* VBW
Ref
16.5 dBm
Offset
* Att
20 dB
Delta 1 [T1 ]
1 MHz
SWT 1 ms
6.5 dB
RBW 1 MHz
4.58 dB
* VBW
398.000000 µs
Ref
-65.21 dBm
10
374.000000 µs
16.5 dBm
Offset
Marker 1 [T1 ]
* Att
20 dB
Delta 1 [T1 ]
1 MHz
1.33 dB
SWT 3 ms
6.5 dB
1.668000 ms
Marker 1 [T1 ]
-61.44 dBm
10
642.000000 µs
SGL
1 PK
SGL
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
-80
-80
Center 2.4415 GHz
Date: 18.DEC.2018
100 µs/
Center 2.4415 GHz
01:24:46
Date: 18.DEC.2018
3-DH1
RBW 1 MHz
* VBW
Ref
16.5 dBm
Offset
* Att
20 dB
1 MHz
SWT 4 ms
6.5 dB
300 µs/
01:28:08
3-DH3
Delta 1 [T1 ]
-1.53 dB
2.920000 ms
Marker 1 [T1 ]
-59.69 dBm
10
688.000000 µs
SGL
1 PK
MAXH
LVL
-10
-20
-30
3DB
-40
AC
-50
-60
-70
-80
Center 2.4415 GHz
Date: 18.DEC.2018
400 µs/
01:28:41
3-DH5
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 26 of 54
Report No: CCISE181114902
6.8 Pseudorandom Frequency Hopping Sequence
Test Requirement:
FCC Part 15 C Section 15.247 (a)(1) requirement:
Frequency hopping systems shall have hopping channel carrier frequencies separated by a minimum of
25 kHz or the 20 dB bandwidth of the hopping channel, whichever is greater.
Alternatively. Frequency hopping systems operating in the 2400-2483.5 MHz band may have hopping
channel carrier frequencies that are separated by 25 kHz or two-thirds of the 20 dB bandwidth of the
hopping channel, whichever is greater, provided the systems operate with an output power no greater
than 125 mW. The system shall hop to channel frequencies that are selected at the system hopping rate
from a Pseudorandom ordered list of hopping frequencies. Each frequency must be used equally on the
average by each transmitter. The system receivers shall have input bandwidths that match the hopping
channel bandwidths of their corresponding transmitters and shall shift frequencies in synchronization
with the transmitted signals.
EUT Pseudorandom Frequency Hopping Sequence
The pseudorandom sequence may be generated in a nine-stage shift register whose 5th and 9th stage
outputs are added in a modulo-two addition stage. And the result is fed back to the input of the first
stage. The sequence begins with the first ONE of 9 consecutive ONEs; i.e. the shift register is initialized
with nine ones.
• Number of shift register stages: 9
• Length of pseudo-random sequence: 2 -1 = 511 bits
• Longest sequence of zeros: 8 (non-inverted signal)
An example of Pseudorandom Frequency Hopping Sequence as follow:
Each frequency used equally on the average by each transmitter.
The system receivers have input bandwidths that match the hopping channel bandwidths of their
corresponding transmitters and shift frequencies in synchronization with the transmitted signals.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 27 of 54
Report No: CCISE181114902
6.9 Band Edge
6.9.1 Conducted Emission Method
Test Requirement:
FCC Part 15 C Section 15.247 (d)
Test Method:
ANSI C63.10:2013 and DA00-705
Receiver setup:
RBW=100 kHz, VBW=300 kHz, Detector=Peak
Limit:
In any 100 kHz bandwidth outside the frequency band in which the spread
spectrum intentional radiator is operating, the radio frequency power that
is produced by the intentional radiator shall be at least 20 dB below that in
the 100 kHz bandwidth within the band that contains the highest level of
the desired power, based on either an RF conducted or a radiated
measurement.
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode and hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 28 of 54
Report No: CCISE181114902
Test plot as follows:
GFSK
Lowest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-49.10 dBm
SWT 2.5 ms
2.399932000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-50.46 dBm
SWT 2.5 ms
2.399906000 GHz
6.5 dB
10
D1 3.75 dBm
1 PK
D1 3.43 dBm
1 PK
MAXH
MAXH
LVL
LVL
-10
-10
D2 -16.25 dBm
D2 -16.57 dBm
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
F1
-80
Start 2.39 GHz
Date: 18.DEC.2018
1.3 MHz/
F1
-80
Stop 2.403 GHz
Start 2.39 GHz
01:32:03
Date: 18.DEC.2018
1.3 MHz/
Stop 2.403 GHz
01:33:27
No-hopping mode
Hopping mode
Highest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-52.03 dBm
2.498240000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-52.15 dBm
2.490056000 GHz
6.5 dB
10
1 PK
D1 2.26 dBm
1 PK
MAXH
D1 2.24 dBm
MAXH
LVL
-10
LVL
-10
D2 -17.74 dBm
D2 -17.76 dBm
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
-50
-60
-70
F1
-80
Start 2.478 GHz
Date: 18.DEC.2018
-50
-60
-70
-80
AC
2.2 MHz/
01:44:55
Stop 2.5 GHz
F1
Start 2.478 GHz
Date: 18.DEC.2018
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
01:45:51
Hopping mode
Project No.: CCISE1811149
Page 29 of 54
Report No: CCISE181114902
π/4-DQPSK
Lowest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-48.06 dBm
SWT 2.5 ms
2.399542000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-49.47 dBm
SWT 2.5 ms
2.399568000 GHz
6.5 dB
10
D1 2.75 dBm
1 PK
1 PK
MAXH
D1 2.28 dBm
MAXH
LVL
LVL
-10
-10
D2 -17.25 dBm
D2 -17.72 dBm
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
F1
-80
Start 2.39 GHz
Date: 18.DEC.2018
1.3 MHz/
F1
-80
Stop 2.403 GHz
Start 2.39 GHz
01:34:54
Date: 18.DEC.2018
1.3 MHz/
Stop 2.403 GHz
01:35:50
No-hopping mode
Hopping mode
Highest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-50.96 dBm
SWT 2.5 ms
2.494720000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-52.38 dBm
2.485568000 GHz
6.5 dB
10
1 PK
D1 0.89 dBm
1 PK
MAXH
D1 0.81 dBm
MAXH
LVL
-10
-20
LVL
-10
D2 -19.11 dBm
-20
-30
D2 -19.19 dBm
-30
3DB
-40
3DB
-40
AC
-50
-60
-60
-70
-80
-70
F1
-80
Start 2.478 GHz
Date: 18.DEC.2018
AC
-50
2.2 MHz/
01:44:17
Stop 2.5 GHz
F1
Start 2.478 GHz
Date: 18.DEC.2018
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
01:42:58
Hopping mode
Project No.: CCISE1811149
Page 30 of 54
Report No: CCISE181114902
8DPSK
Lowest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-46.83 dBm
SWT 2.5 ms
2.399490000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
-49.40 dBm
SWT 2.5 ms
2.399542000 GHz
6.5 dB
10
1 PK
D1 2.54 dBm
1 PK
MAXH
D1 2.07 dBm
MAXH
LVL
LVL
-10
-10
D2 -17.46 dBm
D2 -17.93 dBm
-20
-20
-30
-30
3DB
-40
3DB
-40
AC
AC
-50
-50
-60
-60
-70
-70
F1
-80
Start 2.39 GHz
Date: 18.DEC.2018
1.3 MHz/
F1
-80
Stop 2.403 GHz
Start 2.39 GHz
01:37:02
Date: 18.DEC.2018
1.3 MHz/
Stop 2.403 GHz
01:38:23
No-hopping mode
Hopping mode
Highest Channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-52.25 dBm
2.484160000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
Marker 1 [T1 ]
SWT 2.5 ms
-52.19 dBm
2.487548000 GHz
6.5 dB
10
1 PK
D1 0.77 dBm
1 PK
MAXH
D1 0.66 dBm
MAXH
LVL
-10
-20
LVL
-10
D2 -19.23 dBm
-20
-30
D2 -19.34 dBm
-30
3DB
-40
3DB
-40
AC
-50
-60
-60
-70
-80
-70
F1
-80
Start 2.478 GHz
Date: 18.DEC.2018
AC
-50
2.2 MHz/
01:39:16
Stop 2.5 GHz
F1
Start 2.478 GHz
Date: 18.DEC.2018
No-hopping mode
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.2 MHz/
Stop 2.5 GHz
01:40:17
Hopping mode
Project No.: CCISE1811149
Page 31 of 54
Report No: CCISE181114902
6.9.2 Radiated Emission Method
Test Requirement:
FCC Part 15 C Section 15.209 and 15.205
Test Method:
ANSI C63.10: 2013
Test Frequency Range:
2.3GHz to 2.5GHz
Test Distance:
3m
Receiver setup:
Frequency
Detector
RBW
VBW
Remark
Peak
1MHz
3MHz
Peak Value
RMS
1MHz
3MHz
Average Value
Above 1GHz
Limit:
Frequency
Limit (dBuV/m @3m)
Remark
54.00
Average Value
74.00
Peak Value
Above 1GHz
Test setup:
Test Procedure:
1. The EUT was placed on the top of a rotating table 1.5meters above the
ground at a 3 meter camber. The table was rotated 360 degrees to
determine the position of the highest radiation.
2. The EUT was set 3 meters away from the interference-receiving
antenna, which was mounted on the top of a variable-height antenna
tower.
3. The antenna height is varied from one meter to four meters above the
ground to determine the maximum value of the field strength. Both
horizontal and vertical polarizations of the antenna are set to make the
measurement.
4. For each suspected emission, the EUT was arranged to its worst case
and then the antenna was tuned to heights from 1 meter to 4 meters
and the rota table was turned from 0 degrees to 360 degrees to find the
maximum reading.
5. The test-receiver system was set to Peak Detect Function and
Specified Bandwidth with Maximum Hold Mode.
6. If the emission level of the EUT in peak mode was 10dB lower than the
limit specified, then testing could be stopped and the peak values of the
EUT would be reported. Otherwise the emissions that did not have
10dB margin would be re-tested one by one using peak, quasi-peak or
average method as specified and then reported in a data sheet.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode
Test results:
Passed
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 32 of 54
Report No: CCISE181114902
GFSK Mode:
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 33 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 34 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 35 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 36 of 54
Report No: CCISE181114902
π/4-DQPSK mode
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
2DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 37 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
2DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 38 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
2DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 39 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
2DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 40 of 54
Report No: CCISE181114902
8DPSK mode
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
3DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 41 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
3DH1 Tx mode
Test Channel:
Lowest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 42 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
3DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 43 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
3DH1 Tx mode
Test Channel:
Highest channel
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 44 of 54
Report No: CCISE181114902
6.10 Spurious Emission
6.10.1 Conducted Emission Method
Test Requirement:
FCC Part 15 C Section 15.247 (d)
Test Method:
ANSI C63.10:2013 and DA00-705
Limit:
In any 100 kHz bandwidth outside the frequency band in which the spread
spectrum intentional radiator is operating, the radio frequency power that
is produced by the intentional radiator shall be at least 20 dB below that in
the 100 kHz bandwidth within the band that contains the highest level of
the desired power, based on either an RF conducted or a radiated
measurement.
Test setup:
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode
Test results:
Pass
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 45 of 54
Report No: CCISE181114902
Test plot as follows:
π/4-DQPSK
Lowest channel
GFSK
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-43.70 dBm
13.713560000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-43.95 dBm
20.205760000 GHz
6.5 dB
10
D1 3.54 dBm
1 PK
1 PK
MAXH
D1 0.96 dBm
MAXH
LVL
LVL
-10
-10
D2 -16.46 dBm
-20
-20
-30
-30
-40
3DB
D2 -19.04 dBm
-40
-50
-50
-60
-60
-70
-70
-80
-80
Start 30 MHz
Date: 18.DEC.2018
2.497 GHz/
Stop 25 GHz
Start 30 MHz
01:43:45
Date: 18.DEC.2018
2.497 GHz/
30MHz~25GHz
Middle channel
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Stop 25 GHz
01:51:19
30MHz~25GHz
Ref
3DB
Middle channel
Marker 1 [T1 ]
-44.34 dBm
21.304440000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-43.78 dBm
13.663620000 GHz
6.5 dB
10
1 PK
MAXH
1 PK
D1 -0.98 dBm
D1 0.82 dBm
MAXH
LVL
LVL
-10
-10
-20
D2 -19.18 dBm
-20
D2 -20.98 dBm
-30
-30
-40
3DB
-40
-50
-50
-60
-60
-70
-70
-80
-80
Start 30 MHz
Date: 18.DEC.2018
2.497 GHz/
Stop 25 GHz
Start 30 MHz
01:47:34
Date: 18.DEC.2018
2.497 GHz/
30MHz~25GHz
Highest channel
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Stop 25 GHz
01:49:14
30MHz~25GHz
Ref
3DB
Highest channel
Marker 1 [T1 ]
-42.10 dBm
13.663620000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-44.34 dBm
13.763500000 GHz
6.5 dB
10
1 PK
D1 1.73 dBm
1 PK
MAXH
D1 -0.56 dBm
MAXH
LVL
LVL
-10
-20
-10
D2 -18.27 dBm
-20
-30
-40
3DB
-40
-50
-50
-60
-60
-70
-70
-80
3DB
-80
Start 30 MHz
Date: 18.DEC.2018
D2 -20.56 dBm
-30
2.497 GHz/
01:46:19
Stop 25 GHz
Start 30 MHz
Date: 18.DEC.2018
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
2.497 GHz/
Stop 25 GHz
01:49:50
30MHz~25GHz
Project No.: CCISE1811149
Page 46 of 54
Report No: CCISE181114902
8DPSK
Lowest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Middle channel
Marker 1 [T1 ]
-44.67 dBm
13.663620000 GHz
Ref
6.5 dB
16.5 dBm
Offset
10
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-44.65 dBm
13.663620000 GHz
6.5 dB
10
1 PK
D1 1.29 dBm
1 PK
MAXH
D1 1.6 dBm
MAXH
LVL
LVL
-10
-10
D2 -18.71 dBm
-20
-20
-30
D2 -18.4 dBm
-30
-40
3DB
-40
-50
-50
-60
-60
-70
-70
-80
3DB
-80
Start 30 MHz
Date: 18.DEC.2018
2.497 GHz/
Stop 25 GHz
Start 30 MHz
01:52:02
Date: 18.DEC.2018
30MHz~25GHz
2.497 GHz/
Stop 25 GHz
01:53:14
30MHz~25GHz
Highest channel
Ref
16.5 dBm
Offset
* Att
20 dB
* RBW
100 kHz
* VBW
300 kHz
SWT 2.5 s
Marker 1 [T1 ]
-44.54 dBm
15.111880000 GHz
6.5 dB
10
1 PK
D1 0.52 dBm
MAXH
LVL
-10
-20
D2 -19.48 dBm
-30
-40
3DB
-50
-60
-70
-80
Start 30 MHz
Date: 18.DEC.2018
2.497 GHz/
Stop 25 GHz
01:54:02
30MHz~25GHz
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 47 of 54
Report No: CCISE181114902
6.10.2 Radiated Emission Method
Test Requirement:
FCC Part 15 C Section 15.209
Test Method:
ANSI C63.10: 2013
Test Frequency Range:
9 kHz to 25 GHz
Test Distance:
3m
Receiver setup:
Frequency
Detector
RBW
VBW
Remark
30MHz-1GHz
Quasi-peak
120kHz
300kHz
Quasi-peak Value
Peak
1MHz
3MHz
Peak Value
RMS
1MHz
3MHz
Average Value
Above 1GHz
Limit:
Frequency
Limit (dBuV/m @3m)
Remark
30MHz-88MHz
40.0
Quasi-peak Value
88MHz-216MHz
43.5
Quasi-peak Value
216MHz-960MHz
46.0
Quasi-peak Value
960MHz-1GHz
54.0
Quasi-peak Value
54.0
Average Value
74.0
Peak Value
Above 1GHz
Test setup:
Below 1GHz
Above 1GHz
Test Procedure:
1. The EUT was placed on the top of a rotating table 0.8m(below 1GHz)
/1.5m(above 1GHz) above the ground at a 3 meter chamber. The table
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 48 of 54
Report No: CCISE181114902
2.
3.
4.
5.
6.
was rotated 360 degrees to determine the position of the highest
radiation.
The EUT was set 3 meters away from the interference-receiving
antenna, which was mounted on the top of a variable-height antenna
tower.
The antenna height is varied from one meter to four meters above the
ground to determine the maximum value of the field strength. Both
horizontal and vertical polarizations of the antenna are set to make the
measurement.
For each suspected emission, the EUT was arranged to its worst case
and then the antenna was tuned to heights from 1 meter to 4 meters
and the rota table was turned from 0 degrees to 360 degrees to find the
maximum reading.
The test-receiver system was set to Peak Detect Function and
Specified Bandwidth with Maximum Hold Mode.
If the emission level of the EUT in peak mode was 10dB lower than the
limit specified, then testing could be stopped and the peak values of the
EUT would be reported. Otherwise the emissions that did not have
10dB margin would be re-tested one by one using peak, quasi-peak or
average method as specified and then reported in a data sheet.
Test Instruments:
Refer to section 5.8 for details
Test mode:
Non-hopping mode
Test results:
Pass
Remark:
1. Pre-scan all kind of the place mode (X-axis, Y-axis, Z-axis), and found
the Y-axis is the worst case.
2. 9 kHz to 30 MHz is noise floor, so only shows the data of above
30MHz in this report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 49 of 54
Report No: CCISE181114902
Measurement Data (worst case):
Below 1GHz:
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
BT Tx mode
Test Frequency:
30 MHz ~ 1 GHz
Polarization:
Vertical
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 50 of 54
Report No: CCISE181114902
Product Name:
Mobile Phone
Product Model:
EKO Star 5.0 G50
Test By:
Carey
Test mode:
BT Tx mode
Test Frequency:
30 MHz ~ 1 GHz
Polarization:
Horizontal
Test Voltage:
AC 120/60Hz
Environment:
Temp: 24℃
Huni: 57%
Remark:
1. Final Level = Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 51 of 54
Report No: CCISE181114902
Above 1GHz:
Test channel: Lowest channel
Detector: Peak Value
Frequency
(MHz)
Read
Level
(dBuV)
4804
4804
47.16
47.43
Antenna
Factor
(dB/m)
30.85
30.85
Read
Level
(dBuV)
37.11
37.48
Antenna
Factor
(dB/m)
30.85
30.85
Frequency
(MHz)
4804.00
4804.00
Frequency
(MHz)
4882.00
4882.00
Frequency
(MHz)
4882.00
4882.00
Frequency
(MHz)
4960.00
4960.00
Frequency
(MHz)
4960.00
4960.00
Read
Level
(dBuV)
45.79
45.06
Antenna
Factor
(dB/m)
31.20
31.20
Read
Level
(dBuV)
35.31
35.86
Antenna
Factor
(dB/m)
31.20
31.20
Read
Level
(dBuV)
47.19
46.42
Antenna
Factor
(dB/m)
31.63
31.63
Read
Level
(dBuV)
37.22
36.87
Antenna
Factor
(dB/m)
31.63
31.63
Cable
Loss
(dB)
Preamp
Factor
(dB)
Level
(dBuV/m)
6.80
41.81
43.00
6.80
41.81
43.27
Detector: Average Value
Cable
Preamp
Level
Loss
Factor
(dBuV/m)
(dB)
(dB)
6.80
41.81
32.95
6.80
41.81
33.32
Test channel: Middle channel
Detector: Peak Value
Cable
Preamp
Level
Loss
Factor
(dBuV/m)
(dB)
(dB)
6.86
41.84
42.01
6.86
41.84
41.28
Detector: Average Value
Cable
Preamp
Level
Loss
Factor
(dBuV/m)
(dB)
(dB)
6.86
41.84
31.53
6.86
41.84
32.08
Test channel: Highest channel
Detector: Peak Value
Cable
Preamp
Level
Loss
Factor
(dBuV/m)
(dB)
(dB)
6.91
41.87
43.86
6.91
41.87
43.09
Detector: Average Value
Cable
Preamp
Level
Loss
Factor
(dBuV/m)
(dB)
(dB)
6.91
41.87
33.89
6.91
41.87
33.54
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
74.00
74.00
-31.00
-30.73
Vertical
Horizontal
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
54.00
54.00
-21.05
-20.68
Vertical
Horizontal
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
74.00
74.00
-31.99
-32.72
Vertical
Horizontal
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
54.00
54.00
-22.47
-21.92
Vertical
Horizontal
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
74.00
74.00
-30.14
-30.91
Vertical
Horizontal
Limit Line
(dBuV/m)
Over
Limit (dB)
Polarization
54.00
54.00
-20.11
-20.46
Vertical
Horizontal
Remark:
1. Final Level =Receiver Read level + Antenna Factor + Cable Loss – Preamplifier Factor.
2. The emission levels of other frequencies are very lower than the limit and not show in test report.
Shenzhen Zhongjian Nanfang Testing Co., Ltd.
No. B-C, 1/F., Building 2, Laodong No.2 Industrial Park, Xixiang Road,
Bao’an District, Shenzhen, Guangdong, China
Telephone: +86 (0) 755 23118282 Fax: +86 (0) 755 23116366
Project No.: CCISE1811149
Page 52 of 54
Download: EKONG50 Mobile Phone Test Report 1 Interglobe Connection Corp
Mirror Download [FCC.gov]EKONG50 Mobile Phone Test Report 1 Interglobe Connection Corp
Document ID4184571
Application ID2GFtMCQkSyJiYHIHnuqkUQ==
Document DescriptionTest report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize250.26kB (3128304 bits)
Date Submitted2019-02-28 00:00:00
Date Available2019-02-28 00:00:00
Creation Date2019-02-21 16:06:39
Producing SoftwareMicrosoft® Word 2010
Document Lastmod2019-02-21 16:07:47
Document TitleTest Report 1
Document CreatorMicrosoft® Word 2010
Document Author: 张永岗

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : 张永岗
Create Date                     : 2019:02:21 16:06:39+08:00
Modify Date                     : 2019:02:21 16:07:47+08:00
Language                        : zh-CN
XMP Toolkit                     : Adobe XMP Core 4.2.1-c041 52.342996, 2008/05/07-20:48:00
Format                          : application/pdf
Creator                         : 张永岗
Title                           : 1
Creator Tool                    : Microsoft® Word 2010
Metadata Date                   : 2019:02:21 16:07:47+08:00
Producer                        : Microsoft® Word 2010
Document ID                     : uuid:a7da7cc1-237c-46b4-a682-9b261a7804c3
Instance ID                     : uuid:5453e448-acba-498c-b282-9c562b3018fe
Page Count                      : 52
