STSPRS250 Arrival Sensor Teardown... - FCC ID 2AF4S-STS-PRS-250

FCC ID 2AF4S-STS-PRS-250

Internal Photos

Arrival Sensor

by SAM JIN CO., LTD

Document preview loads when visible.

Document Details

FCC ID2AF4S-STS-PRS-250
Document ID2902686
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantSAM JIN CO., LTD
Equipment ClassArrival Sensor
Product CodeSTSPRS250
Application IDMORCKfZVNDIHLM6P+F4CsA==
Application PurposeOriginal Equipment
Application Date2016-02-12
Frequency Range2405-2470 MHz
FRN0024941692
Test FirmKCTL INC
Certified BySang Soo Kim Senior Research Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-02-12
Available2016-02-12
Created2015-11-20
Modified2015-11-20
Pages2
File TypeAdobe Acrobat PDF
File Size387412
File SHA-2569042b59ed6f48c54d61ee7fb3fb30d76b12afbd51c099e75ee10eaa1e0b7bf1b
PDF Metadata Authormaverick
PDF Metadata ProducerMicrosoft® Word 2013 Microsoft® Word 2013
FCC.gov SourcesFCC.gov 2902686
