SS1 Digital Transmission System Teardown... - FCC ID 2AFTLSS1
FCC ID 2AFTLSS1
Internal Photo (Wall Sensor) - updated.pdf
Digital Transmission System
Document preview loads when visible.
Document Details
| FCC ID | 2AFTLSS1 |
|---|---|
| Document ID | 2811687 |
| Document Type | Internal Photos |
| Description | Internal Photo (Wall Sensor) - updated.pdf |
| Applicant | ecoVent Corp. |
| Equipment Class | Digital Transmission System |
| Product Code | SS1 |
| Application ID | /LjAFHSG3eehJG0PfViHJA== |
| Application Purpose | Original Equipment |
| Application Date | 2015-11-13 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0024870743 |
| Test Firm | BUREAU VERITAS CONSUMER PRODUCTS SERVICES, INC. |
| Certified By | Christopher Reynolds EMC Supervisor |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Short-Term Confidentiality Date | 05/11/2016 |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Submitted | 2015-11-13 |
| Available | 2016-05-11 |
| Created | 2015-09-24 |
| Modified | 2015-09-24 |
| Pages | 5 |
| File Type | Adobe Acrobat PDF |
| File Size | 867109 |
| File SHA-256 | ed0df9a7e126359a65316736fe813a5cb593d42414442d2e34e2d77e5df87cfe |
| PDF Metadata Author | Win7Image |
| PDF Metadata Producer | Microsoft® Word 2010 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 2811687 |
