Report Number: 1708FS18
SAR Exclusion Evaluation Report
Applicant
: Nuheara Limited
Product Type
: IQbuds
Trade Name
: NUHEARA
Model Number
: NU317
Date of Received
: Aug. 02, 2017
Test Period
: Aug. 15, 2017
Date of Issued
: Aug. 21, 2017
Issue by
Approved By
:
Tested By
(Mark Duan)
:
(Sky Chou)
A Test Lab Techno Corp.
No. 140-1, Changan Street, Bade District,
Taoyuan City 33465, Taiwan (R.O.C)
Tel:+886-3-2710188 / Fax:+886-3-2710190
Taiwan Accreditation Foundation accreditation number: 1330
Note: This report shall not be reproduced except in full, without the written approval of A Test Lab Techno
Corp. This document may be altered or revised by A Test Lab Techno Corp. personnel only, and shall be
noted in the revision section of the document. The client should not use it to claim product endorsement
by TAF, or any government agencies. The test results in the report only apply to the tested sample.
1 of 7
Report Number: 1708FS18
Revision History
Rev.
Issue Date
00
Aug. 21, 2017
Revisions
Initial Issue
Revised By
Linda Huang
2 of 7
Report Number: 1708FS18
Contents
1.
Description of Equipment under Test (EUT) ......................................................................... 4
2.
Reference Testing Standards ............................................................................................... 4
3.
SAR Test Exclusion .............................................................................................................. 5
3.1
Conducted Power ................................................................................................................. 6
3.2
Antenna Location ................................................................................................................. 7
3.3
Evaluation Results................................................................................................................ 7
3 of 7
Report Number: 1708FS18
1.
Description of Equipment under Test (EUT)
Applicant
Manufacturer
Nuheara Limited
Unit 5, 28 John St Northbridge, 6003, Australia
Flextronics, Zhuhai
Xin Qing Science & Technology Industrial Park, Jing An, Doumen, Zhuhai, P.R.
China
Product Type
IQbuds
Trade Name
NUHEARA
Model Number
NU317
FCC ID
2AKMG00000NU317
Class II Permissive Change
Adding new type antenna and Max. Gain
Frequency Range
(MHz)
Modulation
Type
Data Rate
(Mbps)
Number of Channels
Bluetooth BR
2402 ~ 2480
GFSK
79
Bluetooth EDR
2402 ~ 2480
π/4-DQPSK
79
8DPSK
79
GFSK
40
Operate Freq. Band
Bluetooth LE
Antenna information
2402 ~ 2480
Type
Max. Gain
(dBi)
Planar Antenna
(Fluid conductive silver)
-3.68
The above equipment was tested by A Test Lab Techno Corp. For compliance with the requirements set forth in 47
CFR § 2.1093. The results of testing in this report apply only to the product/system, which was tested. Other similar
equipment will not necessarily produce the same results due to production tolerance and measurement uncertainties.
2.
Reference Testing Standards
Standard
Description
Version
ANSI/IEEE C95.1
American National Standard safety levels with respect to human
exposure to radio frequency electromagnetic fields, 300 KHz to 100
GHz, New York.
1992
IEEE 1528
IEEE Recommended Practice for Determining the Peak
Spatial-Average Specific Absorption Rate (SAR) in the Human Head
From Wireless Communications Devices: Measurement Techniques.
2013
FCC 47 CFR Part 2.1093
Radiofrequency radiation exposure evaluation: portable devices.
FCC KDB 865664 D01
SAR measurement 100 MHz to 6 GHz - describes SAR
measurement procedures for devices operating between 100 MHz to
6 GHz
v01r04
FCC KDB 865664 D02
RF Exposure Reporting - provides general reporting requirements as
well as certain specific information required to support MPE and SAR
compliance.
v01r02
FCC KDB 447498 D01
General RF Exposure Guidance - provides guidance pertaining to
RF exposure requirements for mobile and portable device equipment
authorizations.
v06
4 of 7
---
Report Number: 1708FS18
3.
SAR Test Exclusion
As RF exposure evaluation of portable device, SAR test is not required when the evaluation results. According to
KDB 447498 4.3.1, unless excluded by specific FCC test procedures, portable devices shall include SAR data for
equipment approval. SAR test necessity will be based on the exclusion result.
The test exclusion refers KDB 447498 as below:
≤50mm:
[(max. power of channel, including tune-up tolerance, mW)/(min. test separation distance, mm)] · [√f(GHz)] ≤ 3.0 for
1-g SAR and ≤ 7.5 for 10-g extremity SAR
>50mm and <200mm:
a) [Power allowed at numeric threshold for 50 mm in step 1) + (test separation distance - 50 mm)·( f(MHz)/150)]
mW, at 100 MHz to 1500 MHz
b) [Power allowed at numeric threshold for 50 mm in step 1) + (test separation distance - 50 mm)·10] mW at > 1500
MHz and ≤ 6 GHz
5 of 7
Report Number: 1708FS18
3.1 Conducted Power
The conducted power turn-up tolerance, please reference manufacturer specification.
Operate Band
Modulation Type
Data Rate
(Mbps)
Frequency
(MHz)
2402
Bluetooth BR
GFSK
2441
2480
2402
π/4-DQPSK
2441
2480
Bluetooth EDR
2402
8DPSK
2441
2480
Operate Band
Bluetooth LE
Modulation Type
GFSK
Data Rate
(Mbps)
6 of 7
Packet Type
Average Power
(dBm)
DH1
4.04
DH3
4.07
DH5
4.11
DH1
6.14
DH3
6.20
DH5
6.24
DH1
5.26
DH3
5.30
DH5
5.39
2DH1
-0.77
2DH3
-0.73
2DH5
-0.67
2DH1
1.09
2DH3
1.20
2DH5
1.27
2DH1
1.14
2DH3
1.20
2DH5
1.22
3DH1
-0.73
3DH3
-0.66
3DH5
-0.64
3DH1
1.37
3DH3
1.41
3DH5
1.55
3DH1
1.16
3DH3
1.21
3DH5
1.23
Frequency
(MHz)
2402
Average Power
(dBm)
2440
6.01
2480
5.92
5.83
Report Number: 1708FS18
3.2 Antenna Location
Transmitter and antenna implementation
Operate Band
Bluetooth Antenna
Bluetooth BR/EDR
Bluetooth LE
Antenna to user distance
(mm)
Ant. Used
Side 1
Side 2
Side 3
Side 4
Side 5
Side 6
Bluetooth Antenna
3.3 Evaluation Results
The evaluation of SAR test reduction according to KDB447498
SAR test is not required when the results showed “EXEMPT”.
Body SAR test reduction
Power
Calculated threshold value
Ant. Used
Operate Band
Frequency
(GHz)
(dBm)
(mW)
Bluetooth Antenna
Bluetooth BR
(GFSK)
2.48
6.4
Bluetooth Antenna
Bluetooth LE
(GFSK)
2.48
6.4
Side 1
Side 2
Side 3
Side 4
Side 5
Side 6
1.3
1.3
1.3
1.3
1.3
1.3
EXEMPT EXEMPT EXEMPT EXEMPT EXEMPT EXEMPT
1.3
1.3
1.3
1.3
1.3
1.3
EXEMPT EXEMPT EXEMPT EXEMPT EXEMPT EXEMPT
Exclusion Considerations: Body SAR is not required
Note: 1. Calculated Value include string "mW",that is mean through compare output power with threshold, if the
output power more than threshold value the SAR test should be perform. Otherwise, the SAR test could
be exempt. (> 50mm)
2. Calculated Value only include number format, that is mean through compare output power with threshold,
if the Calculated value more than 3, the SAR test should be perform. Otherwise, the SAR test could be
exempt. (<50mm)
3. When an antenna qualifies for the standalone SAR test exclusion of KDB 447498 section 4.3.1 and also
transmits simultaneously with other antennas, the standalone SAR value must be estimated according to
KDB 447498 section "4.3.2. Simultaneous transmission SAR test exclusion considerations b) ".
4. We used highest frequency and power,that result should be evaluated the worst case.
5. Power and distance are rounded to the nearest mW and mm before calculation.
6. The result is rounded to one decimal place for comparison.
7. We use a minimum distance of 5mm for bluetooth function.
7 of 7
