PCTEST ENGINEERING LABORATORY, INC.
7185 Oakland Mills Road, Columbia, MD 21046 USA
Tel. 410.290.6652 / Fax 410.290.6654
http://www.pctestlab.com
MEASUREMENT REPORT
FCC Part 15.225 NFC
Applicant Name:
Samsung Electronics Co., Ltd.
129, Samsung-ro,
Yeongtong-gu, Suwon-si
Gyeonggi-do, 16677, Korea
Date of Testing:
6/3 - 6/30/2016
Test Site/Location:
PCTEST Lab, Columbia, MD, USA
Test Report Serial No.:
1M1703230122-10.A3L
FCC ID:
A3LSMN935KOR
APPLICANT:
Samsung Electronics Co., Ltd.
Certification
SM-N935S, SM-N935K, SM-N935L
Portable Handset
13.56MHz
Low Power Communications Device Transmitter (DXX)
FCC Part 15 Subpart C (15.225)
ANSI C63.10-2013, KDB 648474 D03 v01r04
Application Type:
Model(s):
EUT Type:
Frequency:
FCC Classification:
FCC Rule Part(s):
Test Procedure(s):
The device bearing the FCC Identifier specified above has been shown to comply with the applicable technical standards as indicated in
the measurement report and has been tested in accordance with the measurement procedures specified in ANSI C63.10-2013 (See Test
Report). These measurements were performed with no deviation from the standards. Test results reported herein relate only to the item(s)
tested.
I authorize and attest to the accuracy of data. All measurements reported herein were performed by me or were made under my
supervision and are correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these
measurements and vouch for the qualifications of all persons taking them.
NVLAP accreditation does not constitute any product endorsement by NVLAP or any agency of the United States Government. This
report must not be used by the customer to claim product certification, approval, or endorsement by NVLAP, NIST, or any agency of the
Federal Government.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 1 of 31
V 6.3
03/24/2017
T A B L E
O F
C O N T E N T S
FCC Part 15.225 MEASUREMENT REPORT ............................................................................................. 3
1.0
2.0
3.0
INTRODUCTION .............................................................................................................................. 4
1.1
Scope .................................................................................................................................................... 4
1.2
PCTEST Test Location .......................................................................................................................... 4
PRODUCT INFORMATION.............................................................................................................. 5
2.1
Equipment Description........................................................................................................................... 5
2.2
Device Capabilities ................................................................................................................................ 5
2.3
Test Configuration ................................................................................................................................. 5
2.4
EMI Suppression Device(s)/Modifications ............................................................................................. 5
DESCRIPTION OF TEST ................................................................................................................. 6
3.1
Evaluation Procedure ............................................................................................................................ 6
3.2
AC Line Conducted Emissions .............................................................................................................. 6
3.3
Radiated Emissions ............................................................................................................................... 7
3.4
Environmental Conditions ...................................................................................................................... 7
4.0
ANTENNA REQUIREMENTS .......................................................................................................... 8
5.0
MEASUREMENT UNCERTAINTY ................................................................................................... 9
6.0
TEST EQUIPMENT CALIBRATION DATA .................................................................................... 10
7.0
SAMPLE CALCULATIONS ............................................................................................................ 11
8.0
9.0
7.1
Conducted Emission Measurement Sample Calculation ..................................................................... 11
7.2
Radiated Emission Measurement Sample Calculation ........................................................................ 11
TEST DATA .................................................................................................................................... 12
8.1
Summary ............................................................................................................................................. 12
8.2
20dB Bandwidth Measurement ............................................................................................................ 13
8.3
Frequency Stability Test Data .............................................................................................................. 15
8.4
In-Band Radiated Spurious Emission Measurements.......................................................................... 18
8.5
Radiated Spurious Emission Measurements, Out-of-Band .................................................................. 21
8.6
Line Conducted Measurement Data .................................................................................................... 25
CONCLUSION ................................................................................................................................ 31
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 2 of 31
V 6.3
03/24/2017
MEASUREMENT REPORT
FCC Part 15.225
§ 2.1033 General Information
APPLICANT:
Samsung Electronics Co., Ltd.
APPLICANT ADDRESS:
129, Samsung-ro,
Yeongtong-gu, Suwon-si
Gyeonggi-do, 16677, Korea
TEST SITE:
PCTEST ENGINEERING LABORATORY, INC.
TEST SITE ADDRESS:
7185 Oakland Mills Road, Columbia, MD 21046 USA
FCC RULE PART(S):
Part 15 Subpart C (15.225)
BASE MODEL:
SM-N935S
FCC ID:
A3LSMN935KOR
FCC CLASSIFICATION:
Low Power Communications Device Transmitter (DXX)
Test Device Serial No.:
05A93, 0548E
DATE(S) OF TEST:
6/2 - 6/28/2016
TEST REPORT S/N:
1M1703230122-10.A3L
Production
Pre-Production
Engineering
Test Facility / Accreditations
Measurements were performed at PCTEST Engineering Lab located in Columbia, MD 21046, U.S.A.







PCTEST facility is an FCC registered (PCTEST Reg. No. 159966) test facility with the
site description report on file and has met all the requirements specified in Section
2.948 of the FCC Rules and Industry Canada (2451B-1).
PCTEST Lab is accredited to ISO 17025 by U.S. National Institute of Standards and
Technology (NIST) under the National Voluntary Laboratory Accreditation Program
(NVLAP Lab code: 100431-0) in EMC, FCC and Telecommunications.
PCTEST Lab is accredited to ISO 17025-2005 by the American Association for
Laboratory Accreditation (A2LA) in Specific Absorption Rate (SAR) testing, Hearing Aid
Compatibility (HAC) testing, CTIA Test Plans, and wireless testing for FCC and
Industry Canada Rules.
PCTEST Lab is a recognized U.S. Conformity Assessment Body (CAB) in EMC and
R&TTE (n.b. 0982) under the U.S.-EU Mutual Recognition Agreement (MRA).
PCTEST TCB is a Telecommunication Certification Body (TCB) accredited to ISO/IEC
Guide 65 by the American National Standards Institute (ANSI) in all scopes of FCC
Rules and Industry Canada Standards (RSS).
PCTEST facility is an IC registered (2451B-1) test laboratory with the site description
on file at Industry Canada.
PCTEST is a CTIA Authorized Test Laboratory (CATL) for AMPS, CDMA, and EvDO
wireless devices and for Over-the-Air (OTA) Antenna Performance testing for AMPS,
CDMA, GSM, GPRS, EGPRS, UMTS (W-CDMA), CDMA 1xEVDO, and CDMA 1xRTT.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 3 of 31
V 6.3
03/24/2017
1.0
1.1
INTRODUCTION
Scope
Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including
intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal
Communications Commission and the Industry Canada Certification and Engineering Bureau.
1.2
PCTEST Test Location
The map below shows the location of the PCTEST LABORATORY, its proximity to the FCC Laboratory, the
Columbia vicinity, the Baltimore-Washington Internt’l (BWI) airport, the city of Baltimore and the Washington,
DC area. (See Figure 1-1).
These measurement tests were conducted at the PCTEST Engineering Laboratory, Inc. facility located at
7185 Oakland Mills Road, Columbia, MD 21046. The site coordinates are 39o 10’23” N latitude and 76o 49’50”
W longitude. The facility is 0.4 miles North of the FCC laboratory, and the ambient signal and ambient signal
strength are approximately equal to those of the FCC laboratory. The detailed description of the measurement
facility was found to be in compliance with the requirements of § 2.948 according to ANSI C63.4-2014 on
January 22, 2015.
Figure 1-1. Map of the Greater Baltimore and Metropolitan Washington, D.C. area
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 4 of 31
V 6.3
03/24/2017
2.0
2.1
PRODUCT INFORMATION
Equipment Description
The Equipment Under Test (EUT) is the Samsung Portable Handset FCC ID: A3LSMN935KOR. The test
data contained in this report pertains only to the emissions due to the NFC transmitter of the EUT.
2.2
Device Capabilities
This device contains the following capabilities:
1900 GPRS/EDGE, 850/1900 WCDMA/HSPA, Multi-band LTE, 802.11b/g/n WLAN, 802.11a/n/ac UNII,
Bluetooth (1x, EDR, LE), NFC, ANT+
2.3
Test Configuration
The Samsung Portable Handset FCC ID: A3LSMN935KOR was set to continuously transmit at 13.56MHz.
This was performed using manufacturer software loaded on the phone and a passive RFID tag to allow for
continuous transmission. This device was tested in accordance with the guidance of ANSI C63.10-2013. See
Sections 3.2 and 3.3 of this test report for a description of the AC line conducted emissions and radiated
emissions test setups, respectively.
This device supports wireless charging capability and, thus, is subject to the test requirements of KDB 648474
D03 v01r04. Additional radiated spurious emission measurements were performed with the EUT lying flat on a
certified wireless charging pad (WCP) while operating under normal conditions in a simulated call or data
transmission configuration. The worst case radiated emissions data is shown in this report.
2.4
EMI Suppression Device(s)/Modifications
No EMI suppression device(s) were added and no modifications were made during testing.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 5 of 31
V 6.3
03/24/2017
3.0
3.1
DESCRIPTION OF TEST
Evaluation Procedure
The measurement procedure described in the American National Standard of Procedures for Compliance
Testing of Unlicensed Wireless Devices (ANSI C63.10-2013) was used in the measurement of the Samsung
Portable Handset FCC ID: A3LSMN935KOR.
Deviation from measurement procedure…………………………………………….....................................None
3.2
AC Line Conducted Emissions
The line-conducted facility is located inside a 10'x16'x9' shielded enclosure. The shielded enclosure is
manufactured by ETS Lindgren RF Enclosures. The shielding effectiveness of the shielded room is in
accordance with MIL-Std-285 or NSA 65-5. A 1m x 1.5m wooden table 80cm high is placed 40cm away from
the vertical wall and 80cm away from the sidewall of the shielded room. Two 10kHz-30MHz, 50/50H LineImpedance Stabilization Networks (LISNs) are bonded to the shielded room floor. Power to the LISNs is
filtered by external high-current high-insertion loss power line filters. The external power line filter is an ETS
Lindgren Model LPRX-4X30 (100dB Attenuation, 14kHz-18GHz) and the two EMI/RFI filters are ETS Lindgren
Model LRW-2030-S1 (100dB Minimum Insertion Loss, 14kHz – 10GHz). These filters attenuate ambient signal
noise from entering the measurement lines. These filters are also bonded to the shielded enclosure.
The EUT is powered from one LISN and the support equipment is powered from the second LISN. If the EUT
is a DC-powered device, power will be derived from the source power supply it normally will be powered from
and this supply line(s) will be connected to the second LISN. All interconnecting cables more than 1 meter
were shortened to a 1 meter length by non-inductive bundling (serpentine fashion) and draped over the back
edge of the test table. All cables were at least 40cm above the horizontal reference groundplane. Power
cables for support equipment were routed down to the second LISN while ensuring that that cables were not
draped over the second LISN.
Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up
to their normal operating condition. The RF output of the LISN was connected to the spectrum analyzer and
exploratory measurements were made to determine the frequencies producing the maximum emission from
the EUT. The spectrum was scanned from 150kHz to 30MHz with a spectrum analyzer. The detector function
was set to peak mode for exploratory measurements while the bandwidth of the analyzer was set to 10kHz.
The EUT, support equipment, and interconnecting cables were arranged and manipulated to maximize each
emission. Once the worst case emissions have been identified, the one EUT cable configuration/arrangement
and mode of operation that produced these emissions is used for final measurements on the same test site.
The analyzer is set to CISPR quasi-peak and average detectors with a 9kHz resolution bandwidth for final
measurements.
Line conducted emissions test results are shown in Section 8.6. The EMI Receiver mode of the Agilent MXE
was used to perform AC line conducted emissions testing.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 6 of 31
V 6.3
03/24/2017
3.3
Radiated Emissions
The radiated test facilities consisted of an indoor 3 meter semi-anechoic chamber used for final measurements
and exploratory measurements, when necessary. The measurement area is contained within the semianechoic chamber which is shielded from any ambient interference. The test site inside the chamber is a 6m x
5.2m elliptical, obstruction-free area in accordance with Figure 5.7 in Clause 5 of ANSI C63.4-2014. A raised
turntable is used for radiated measurement. It is a continuously rotatable, remote-controlled, metallic turntable
and 2 meters (6.56 ft.) in diameter. The turn table is flush with the raised floor of the chamber in order to
maintain its function as a ground plane. Absorbers are arranged on the floor between the turn table and the
antenna mast in such a way so as to maximize the reduction of reflections for measurements above 1GHz. A
72.4cm high PVC support structure is placed on top of the turntable. A 3” (~7.6cm) sheet of high density
polystyrene is used as the table top and is placed on top of the PVC supports to bring the total height of the
table to 80cm. For measurements above 1GHz, a high density expanded polystyrene block is placed on top of
the test table to bring the total table height to 1.5m.
For all measurements, the spectrum was scanned through all EUT azimuths and from 1 to 4 meter receive
antenna height using a broadband antenna from 30MHz up to the upper frequency shown in 15.33(b)(1)
depending on the highest frequency generated or used in the device or on which the device operates or tunes.
For frequencies above 1GHz, linearly polarized double ridge horn antennas were used. For frequencies below
30MHz, a calibrated loop antenna was used. When exploratory measurements were necessary, they were
performed at 1 meter test distance inside the semi-anechoic chamber using broadband antennas, broadband
amplifiers, and spectrum analyzers to determine the frequencies and modes producing the maximum
emissions. Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them
to warm up to their normal operating condition. The test set-up was placed on top of the 1 x 1.5 meter table.
The EUT, support equipment, and interconnecting cables were arranged and manipulated to maximize each
emission. Appropriate precaution was taken to ensure that all emissions from the EUT were maximized and
investigated. The system configuration, mode of operation, turntable azimuth, and receive antenna height was
noted for each frequency found.
Final measurements were made in the semi-anechoic chamber using calibrated, linearly polarized broadband
and horn antennas. The test setup was configured to the setup that produced the worst case emissions. The
spectrum analyzer was set to investigate all frequencies required for testing to compare the highest radiated
disturbances with respect to the specified limits. The turntable containing the EUT was rotated through 360
degrees and the height of the receive antenna was varied 1 to 4 meters and stopped at the azimuth and height
producing the maximum emission. Each emission was maximized by changing the orientation of the EUT
through three orthogonal planes and changing the polarity of the receive antenna, whichever produced the
worst-case emissions.
3.4
Environmental Conditions
The temperature is controlled within range of 15oC to 35oC. The relative humidity is controlled within range of
10% to 75%. The atmospheric pressure is monitored within the range 86-106kPa (860-1060mbar).
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 7 of 31
V 6.3
03/24/2017
4.0
ANTENNA REQUIREMENTS
Excerpt from §15.203 of the FCC Rules/Regulations:
“An intentional radiator antenna shall be designed to ensure that no antenna other than that furnished by the
responsible party can be used with the device. The use of a permanently attached antenna or of an antenna
that uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the
provisions of this section.”

The antenna of the Samsung Portable Handset are permanently attached.

This unit was tested with its standard battery.
Conclusion:
The Samsung Portable Handset FCC ID: A3LSMN935KOR unit complies with the requirement of §15.203.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 8 of 31
V 6.3
03/24/2017
5.0
MEASUREMENT UNCERTAINTY
The measurement uncertainties shown below were calculated in accordance with the requirements of
ANSI C63.4-2014. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a
95% level of confidence. The measurement data shown herein meets or exceeds the UCISPR measurement
uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly to specified limits to
determine compliance.
Contribution
Expanded Uncertainty (±dB)
Line Conducted Disturbance
3.09
Radiated Disturbance (<1GHz)
4.98
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 9 of 31
V 6.3
03/24/2017
6.0
TEST EQUIPMENT CALIBRATION DATA
Test Equipment Calibration is traceable to the National Institute of Standards and Technology (NIST).
Manufacturer
Model
‐
‐
Agilent
Agilent
Agilent
Emco
Espec
ETS‐Lindgren
Pasternack
Rohde & Schwarz
Rohde & Schwarz
Sunol
RE1
WL25‐1
8447D
N9020A
N9038A
6502
ESX‐2CA
3816/2NM
NMLC‐1
ESR26
ESU40
JB5
Description
Cal Date
Radiated Emissions Cable Set (UHF/EHF) 11/18/2015
Conducted Cable Set (25GHz)
10/8/2015
Broadband Amplifier
6/12/2015
MXA Signal Analyzer
11/5/2015
MXE EMI Receiver
4/21/2016
Active Loop Antenna (10k ‐ 30 MHz)
6/24/2014
Environmental Chamber
3/4/2016
Line Impedance Stabilization Network 11/11/2014
Line Conducted Emissions Cable (NM)
4/28/2015
EMI Test Receiver
3/2/2016
EMI Test Receiver (40GHz)
7/17/2015
Bi‐Log Antenna (30M ‐ 5GHz)
3/14/2016
Cal Interval
Biennial
Annual
Annual
Annual
Annual
Biennial
Annual
Biennial
Biennial
Annual
Annual
Biennial
Cal Due
Serial Number
9/4/2016
RE1
10/8/2016
WL25‐1
6/12/2016 2443A01900
11/5/2016 US46470561
4/21/2017 MY51210133
6/24/2016
267
3/4/2017
17620
11/11/2016
114451
4/28/2017
NMLC‐1
3/2/2017
101328
7/17/2016
100348
3/14/2018
A051107
Table 6-1. Annual Test Equipment Calibration Schedule
Note:
For equipment listed above that has a calibration date or calibration due date that falls within the test date
range, care was taken to ensure that this equipment was used after the calibration date and before the
calibration due date.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 10 of 31
V 6.3
03/24/2017
7.0
7.1
SAMPLE CALCULATIONS
Conducted Emission Measurement Sample Calculation
@ 20.3 MHz
Class B limit
= 60.0 dBV (Quasi-peak limit)
Reading
= - 57.8 dBm (calibrated quasi-peak level)
Convert to dbV
= - 57.8 + 107 = 49.2 dBV
Margin
= 49.2 - 60.0 = - 10.8 dB
= 10.8 dB below limit
7.2
Radiated Emission Measurement Sample Calculation
@ 66.7 MHz
Class B limit
= 100 V/m = 40.0 dBV/m
Reading
= - 76.0 dBm (calibrated level)
Convert to dbV
= - 76.0 + 107 = 31.0 dBV
Antenna Factor + Cable Loss
= 5.8 dB/m
Total
Margin
= 36.8 dBV/m
= 36.8 - 40.0 = - 3.2 dB
= 3.2 dB below limit
Note:
Level [dBV] = 20 log 10 (Level [V/m])
Level [dBV] = Level [dBm] + 107
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 11 of 31
V 6.3
03/24/2017
8.0
TEST DATA
8.1
Summary
Company Name:
Samsung Electronics Co., Ltd.
FCC ID:
A3LSMN935KOR
FCC Classification:
Low Power Communications Device Transmitter (DXX)
Frequencies Examined:
13.56MHz
FCC Part
Section(s)
Test Description
Test Limit
Test
Condition
Test
Result
Reference
PASS
Section 8.2
PASS
Section 8.4
PASS
Section 8.5
Temperature
Chamber
PASS
Section 8.3
LINE
CONDUCTED
PASS
Section 8.6
TRANSMITTER MODE (Tx)
2.1049
20 dB Bandwidth
N/A
15,848µV/m @ 30m
13.553 – 13.567 MHz
15.225
(a)(b)(c)
334µV/m @ 30m
13.410 – 13.553 MHz
13.567 – 13.710 MHz
In-Band Emissions
RADIATED
106µV/m @ 30m
13.110 – 13.410 MHz
13.710 – 14.010 MHz
15.225 (d)
15.209
Out-of-Band Emissions
Emissions outside of the specified
band (13.110 – 14.010 MHz) must
meet the radiated limits detailed in
15.209
15.225 (e)
Frequency Stability
Tolerance
± 0.01% of Operating Frequency
15.207
AC Conducted
Emissions 150kHz –
30MHz
< FCC 15.207 limits
Table 8-1. Summary of Test Results
Note:
This unit was tested with its standard battery.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 12 of 31
V 6.3
03/24/2017
8.2
20dB Bandwidth Measurement
§2.1049
Test Overview and Limit
The bandwidth at 20dB down from the highest in-band spectral density is measured with a spectrum analyzer
connected to the receive antenna while the EUT is operating in transmission mode at the appropriate
frequency.
Test Procedure Used
ANSI C63.10-2013 – Section 6.9.2
Test Settings
1. Spectrum analyzer frequency is set to the nominal EUT channel center frequency.
2. RBW = 1 – 5% OBW
3. VBW ≥ 3 x RBW
4. Reference level set to keep signal from exceeding maximum input mixer level for linear operation.
5. Detector = Peak
6. Trace mode = max hold
7. Sweep = auto couple
8. The trace was allowed to stabilize
9. Using the marker-delta function, determine the “-20dB down amplitude” using [(highest in band
spectral density) – 20dB].
10. Set a marker at the lowest frequency of the envelope of the spectral density, such that the marker is at
or slightly below the “-20dB down amplitude” determined in Step 9.
11. Reset marker-delta function and move the marker to other side of the emission until the delta marker
amplitude is the same level as reference level amplitude. The marker delta frequency reading at this
point is the specified emission bandwidth.
Test Notes
None.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 13 of 31
V 6.3
03/24/2017
Agilent MXA
Spectrum Analyzer
EUT
Figure 8-1. Test Instrument & Measurement Setup
Frequency
20dB Bandwidth
13.56MHz
427kHz
Table 8-2. 20dB Bandwidth Measurement
Figure 8-2. 20dB Bandwidth Plot
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 14 of 31
V 6.3
03/24/2017
8.3
Frequency Stability Test Data
§15.225
Test Overview and Limit
Frequency stability testing is performed in accordance with the guidelines of ANSI C63.10-2013. The
frequency stability of the transmitter is measured by:
a.)
Temperature: The temperature is varied from -20°C to +50°C in 10°C increments using an
environmental chamber.
b.)
Primary Supply Voltage: The primary supply voltage is varied from 85% to 115% of the nominal value
for non hand-carried battery and AC powered equipment. For hand-carried, battery-powered equipment,
primary supply voltage is reduced to the battery operating end point which shall be specified by the
manufacturer.
For Part 15.225, the frequency stability of the transmitter shall be maintained within ±0.01% of the
center frequency.
Test Procedure Used
ANSI C63.10-2013 – Section 6.8
Test Settings
1. The carrier frequency of the transmitter is measured at room temperature (20°C to provide a
reference).
2. The equipment is turned on in a “standby” condition for fifteen minutes before applying power to the
transmitter. Measurement of the carrier frequency of the transmitter is made within one minute after
applying power to the transmitter.
3. Frequency measurements are made at 10°C intervals ranging from -20°C to +50°C. A period of at
least one half-hour is provided to allow stabilization of the equipment at each temperature level.
Test Setup
The EUT was connected via an RF cable to a spectrum analyzer with the EUT placed inside an environmental
chamber.
Test Notes
None.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 15 of 31
V 6.3
03/24/2017
Frequency Stability Test Data
§15.225
OPERATING FREQUENCY:
13,560,000
3.80
REFERENCE VOLTAGE:
DEVIATION LIMIT:
Hz
VDC
± 0.01 % = 1356Hz
VOLTAGE
(%)
POWER
(VDC)
TEMP
(o C)
FREQUENCY
(Hz)
Freq. Dev.
(Hz)
Deviation
(%)
100 %
3.80
+ 20 (Ref)
13,559,778
-222
-0.0016372
100 %
- 30
13,560,295
295
0.0021755
100 %
- 20
13,559,951
-49
-0.0003614
100 %
- 10
13,560,091
91
0.0006711
100 %
13,559,852
-148
-0.0010914
100 %
+ 10
13,560,073
73
0.0005383
100 %
+ 20
13,560,306
306
0.0022566
100 %
+ 30
13,559,765
-235
-0.0017330
100 %
+ 40
13,560,142
142
0.0010472
100 %
+ 50
13,559,988
-12
-0.0000885
+ 20
13,559,965
-35
-0.0002581
BATT. ENDPOINT
3.40
Table 8-3. Frequency Stability Test Data
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 16 of 31
V 6.3
03/24/2017
Frequency Stability Test Data
§15.225
Frequency Stability
0.03
0.02
Deviation (ppm)
0.01
0.00
-0.01
-0.02
-0.03
Tem perature (°C)
Figure 8-3. Frequency Stability Plot
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 17 of 31
V 6.3
03/24/2017
8.4
In-Band Radiated Spurious Emission Measurements
§15.225(a)(b)(c)
Test Overview and Limit
The EUT was tested from 13.110 – 14.010 MHz. All in-band radiated spurious emissions are measured with a
spectrum analyzer connected to a loop antenna while the EUT is operating at appropriate frequencies. Only
the radiated emissions of the configuration that produced the worst case emissions are reported in this
section.
All in-band emissions appearing in a restricted band as specified in Section 15.225 of the Title 47 CFR
must not exceed the limits shown in Table 8-4.
Field Strength
[V/m]
Measured Distance
[Meters]
13.553-13.567 MHz
15,848
30
13.410-13.553 MHz and
13.567-13.710 MHz
334
30
13.110-13.410 MHz
106
30
Frequency
[MHz]
Table 8-4. Radiated Limits
Test Procedures Used
ANSI C63.10-2013 – Section 6.4.7
Test Settings
1. RBW = 9kHz
2. VBW ≥ 3 x RBW
3. Detector = peak
4. Sweep time = auto couple
5. Trace mode = max hold
6. Trace was allowed to stabilize
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 18 of 31
V 6.3
03/24/2017
Test Setup
The EUT and measurement equipment were set up as shown in the diagram below.
Figure 8-4. Radiated Test Setup
Test Notes:
1. All emissions lying in restricted bands specified in §15.225 are below the limit shown in Table 8-4.
2. All measurements were performed using a loop antenna. The antenna was positioned in three orthogonal
positions (X front, Y side, Z top) and the position with the highest emission level was recorded.
3. The EUT was positioned in three orthogonal planes to determine the orientation resulting in the worst case
emissions.
4. Measurements were performed at 3m and the data was extrapolated to the specified measurement
distance of 30m using the square of an inverse linear distance extrapolation factor (40 dB/decade) as
specified in §15.31(f)(2). Extrapolation Factor = 20 log10(30/3)2 = 40dB.
5. The spectrum was investigated from 9kHz up to 30MHz using the loop antenna. Only the emissions
shown in the table below were found to be significant.
6. All measurements were recorded using a spectrum analyzer employing a quasi-peak detector.
7. The "-" shown in the following RSE tables are used to denote a noise floor measurement.
Sample Calculation
Field Strength Level [dBV/m] = Analyzer Level [dBm] + 107 + AFCL [dB/m]
AFCL [dB/m] = Antenna Factor [dB/m] + Cable Loss [dB]
Margin [dB] = Field Strength Level [dBV/m] – Limit [dBV/m]
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 19 of 31
V 6.3
03/24/2017
In-Band Radiated Spurious Emission Measurements
§15.225(a)(b)(c)
Frequency:
13.56MHz
Measurement Distance:
3 Meters
Ante
Antenna Turntable
Frequency nna
Height
Azimuth
[MHz]
Posi
[cm]
[degree]
tion
Level
[dBm]
AFCL
[dB/m]
30m
3m Field
Field
Strength
Strength
[dBµV/m]
[dBµV/m]
Limit
[µV/m]
Margin
Limit
[dB]
[dBµV/m]
13.260
100
123
-87.07
29.18
49.11
9.11
106.00
40.51
-31.40
13.340
100
123
-81.41
29.17
54.76
14.76
106.00
40.51
-25.74
13.450
100
123
-78.20
29.16
57.96
17.96
334.00
50.47
-32.51
13.650
100
123
-64.45
29.14
71.69
31.69
334.00
50.47
-18.79
13.660
100
123
-79.32
29.14
56.82
16.82
334.00
50.47
-33.66
13.760
100
123
-82.33
29.13
53.80
13.80
106.00
40.51
-26.71
13.870
100
123
-87.40
29.12
48.72
8.72
106.00
40.51
-31.79
Table 8-5. In-Band Radiated Measurements
Ante
Antenna Turntable
Frequency nna
Height
Azimuth
[MHz]
Posi
[cm]
[degree]
tion
Level
[dBm]
AFCL
[dB/m]
30m
3m Field
Field
Strength
Strength
[dBµV/m]
[dBµV/m]
Limit
[µV/m]
Margin
Limit
[dB]
[dBµV/m]
13.240
-91.66
14.94
30.28
-9.72
106.00
40.51
-50.22
13.350
100
-85.70
14.94
36.24
-3.76
106.00
40.51
-44.27
13.450
100
-83.80
14.94
38.14
-1.86
334.00
50.47
-52.34
13.650
100
-69.54
14.93
52.39
12.39
334.00
50.47
-38.09
13.660
100
-83.48
14.93
38.45
-1.55
334.00
50.47
-52.03
13.770
100
-85.67
14.93
36.26
-3.74
106.00
40.51
-44.25
13.930
-92.14
14.92
29.78
-10.22
106.00
40.51
-50.73
Table 8-6. In-Band Radiated Measurements with WCP
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 20 of 31
V 6.3
03/24/2017
8.5
Radiated Spurious Emission Measurements, Out-of-Band
§15.209 §15.225(d)
Test Overview and Limit
The EUT was tested from 9kHz up to the 1GHz excluding the band 13.110 – 14.010 MHz. All measurements
up to 960MHz were recorded with a spectrum analyzer employing a quasi-peak detector.
All out-of-band emissions appearing in a restricted band as specified in Section 15.225 of the Title 47
CFR must not exceed the limits shown in Table 8-7 per Section 15.209.
Frequency
Field Strength
[V/m]
Measured Distance
[Meters]
0.009 – 0.490 MHz
0.490 – 1.705 MHz
1.705 – 30.00 MHz
30.00 – 88.00 MHz
88.00 – 216.0 MHz
216.0 – 960.0 MHz
Above 960.0 MHz
2400/F (kHz)
24000/F (kHz)
30
100
150
200
500
300
30
30
Table 8-7. Radiated Limits – Out of band
Test Procedures Used
ANSI C63.10-2013 – Section 6.5.4
Test Settings
1. Analyzer center frequency was set to the frequency of the radiated spurious emission of interest
2. RBW = 9kHz for emissions below 30MHz and 100kHz for emissions between 30MHz and 1GHz
3. VBW ≥ 3 x RBW
4. Detector = peak
5. Sweep time = auto couple
6. Trace mode = max hold
7. Trace was allowed to stabilize
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 21 of 31
V 6.3
03/24/2017
Test Setup
The EUT and measurement equipment were set up as shown in the diagram below.
Figure 8-5. Radiated Test Setup < 30MHz
Figure 8-6. Radiated Test Setup > 30MHz
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 22 of 31
V 6.3
03/24/2017
Test Notes:
1. All measurements were recorded using a spectrum analyzer employing a quasi-peak detector for
emissions below 960MHz.
2. A loop antenna was used to investigate emissions below 30MHz.
3. Both Vertical and Horizontal polarities of the receive antenna were evaluated with the worst case
emissions being reported. Below 30MHz the loop antenna was positioned in 3 orthogonal planes (X
front, Y side, Z top) to determine the orientation resulting in the worst case emissions.
4. The EUT was positioned in three orthogonal planes to determine the orientation resulting in the worst
case emissions.
5. The spectrum is measured from 9kHz to the 10th harmonic and the worst-case emissions are reported.
6. No spurious emissions levels were found to be greater than the level of the fundamental.
7. The "-" shown in the following RSE tables are used to denote a noise floor measurement.
Sample Calculation
Field Strength Level [dBV/m] = Analyzer Level [dBm] + 107 + AFCL [dB/m]
AFCL [dB/m] = Antenna Factor [dB/m] + Cable Loss [dB]
Margin [dB] = Field Strength Level [dBV/m] – Limit [dBV/m]
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 23 of 31
V 6.3
03/24/2017
Radiated Spurious Emission Measurements, Out-of-Band
§15.209 §15.225(d)
Tx Frequency
13.56MHz
Measurement Distance:
3 Meters
Ant. Antenna Turntable
Frequency
Pol. Height
Azimuth
[MHz]
[H/V]
[cm]
[degree]
Level
[dBm]
AFCL
[dB/m]
3m Field
Limit
Margin
Strength
[dBµV/m]
[dB]
[dBµV/m]
27.12
-91.39
13.41
29.02
69.54
-40.53
40.68
100
-106.36
19.30
19.94
40.00
-20.06
54.24
100
-107.38
14.12
13.74
40.00
-26.26
67.80
100
-105.90
14.48
15.57
40.00
-24.43
81.36
100
-103.96
14.45
17.49
40.00
-22.51
94.92
-107.90
16.05
15.16
43.52
-28.37
108.48
-108.39
18.86
17.48
43.52
-26.05
Table 8-8. Radiated Measurements
Ant. Antenna Turntable
Frequency
Pol. Height
Azimuth
[MHz]
[H/V]
[cm]
[degree]
Level
[dBm]
AFCL
[dB/m]
3m Field
Limit
Margin
Strength
[dBµV/m]
[dB]
[dBµV/m]
27.12
-91.78
13.41
28.63
69.54
-40.92
40.68
100
-105.94
19.30
20.36
40.00
-19.64
54.24
100
-106.13
14.12
14.99
40.00
-25.01
67.80
100
-103.97
14.48
17.50
40.00
-22.50
81.36
100
-103.07
14.45
18.38
40.00
-21.62
94.92
-108.00
16.05
15.06
43.52
-28.47
108.48
-108.01
18.86
17.86
43.52
-25.67
Table 8-9. Radiated Measurements with WCP
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 24 of 31
V 6.3
03/24/2017
8.6
Line Conducted Measurement Data
§15.207
Test Overview and Limit
All AC line conducted spurious emissions are measured with a receiver connected to a grounded LISN while
the EUT is operating at its maximum duty cycle, at maximum power, and at the appropriate frequencies. All
data rates and modes were investigated for conducted spurious emissions. Only the conducted emissions of
the configuration that produced the worst case emissions are reported in this section.
All conducted emissions must not exceed the limits shown in the table below, per 15.207.
Frequency of emission
(MHz)
Conducted Limit (dBV)
Quasi-peak
66 to 56*
56
60
0.15 – 0.5
0.5 – 5
5 – 30
Average
56 to 46*
46
50
Table 8-10. Conducted Limits
*Decreases with the logarithm of the frequency.
Test Procedures Used
ANSI C63.10-2013, Section 6.2
Test Settings
Quasi-Peak Field Strength Measurements
1. Analyzer center frequency was set to the frequency of the spurious emission of interest
2. RBW = 9kHz (for emissions from 150kHz – 30MHz)
3. Detector = quasi-peak
4. Sweep time = auto couple
5. Trace mode = max hold
6. Trace was allowed to stabilize
Average Field Strength Measurements
1. Analyzer center frequency was set to the frequency of the spurious emission of interest
2. RBW = 9kHz (for emissions from 150kHz – 30MHz)
3. Detector = RMS
4. Sweep time = auto couple
5. Trace mode = max hold
6. Trace was allowed to stabilize
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 25 of 31
V 6.3
03/24/2017
Test Setup
The EUT and measurement equipment were set up as shown in the diagram below.
Figure 8-7. Test Instrument & Measurement Setup
Test Notes
1.
All modes of operation were investigated and the worst-case emissions are reported using mid channel.
The emissions found were not affected by the choice of channel used during testing.
2.
The limit for an intentional radiator from 150kHz to 30MHz are specified in RSS-Gen (8.8).
3.
Corr. (dB) = Cable loss (dB) + LISN insertion factor (dB)
4.
QP/AV Level (dBV) = QP/AV Analyzer/Receiver Level (dBV) + Corr. (dB)
5.
Margin (dB) = QP/AV Limit (dBV) - QP/AV Level (dBV)
6.
Traces shown in plot are made using a peak detector.
7.
Deviations to the Specifications: None.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 26 of 31
V 6.3
03/24/2017
Line-Conducted Test Data
§15.207
Plot 8-1. Line-Conducted Test Plot (L1)
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 27 of 31
V 6.3
03/24/2017
Line Conducted Measurement Data
§15.207
Plot 8-2. Line-Conducted Test Plot (N)
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 28 of 31
V 6.3
03/24/2017
Line-Conducted Test Data, RFID Antenna Terminated in 50Ohms
§15.207
Plot 8-3. Line-Conducted Test Plot (L1)
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 29 of 31
V 6.3
03/24/2017
Line Conducted Measurement Data, RFID Antenna Terminated in 50Ohms
§15.207
Plot 8-4. Line-Conducted Test Plot (N)
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 30 of 31
V 6.3
03/24/2017
9.0
CONCLUSION
The data collected relate only to the item(s) tested and show that the Samsung Portable Handset
FCC ID: A3LSMN935KOR has been tested to show compliance with the requirements specified in §15.225
of the FCC Rules.
FCC Pt. 15.225 MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMN935KOR
Test Report S/N:
Test Date(s):
EUT Type:
1M1703230122-10.A3L
6/3 - 6/30/2016
Portable Handset
© 2017 PCTEST Engineering Laboratory, Inc.
Reviewed by:
Quality Manager
Page 31 of 31
V 6.3
03/24/2017
Download: SMN935KOR Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN, RFID and ANT+ Test Report NFC Samsung Electronics Co Ltd
Mirror Download [FCC.gov]SMN935KOR Multi-band GSM/EDGE/UMTS/LTE Phone with Bluetooth, WLAN, RFID and ANT+ Test Report NFC Samsung Electronics Co Ltd
Document ID3370912
Application IDm9wFPb1/4Fgz3blYtJe5SA==
Document DescriptionNFC Test Report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize79.74kB (996726 bits)
Date Submitted2017-04-25 00:00:00
Date Available2017-05-04 00:00:00
Creation Date2017-04-20 18:29:32
Producing SoftwareAcrobat Distiller 10.1.16 (Windows)
Document Lastmod2017-04-25 16:43:53
Document TitleNFC Test Report
Document CreatorPScript5.dll Version 5.2.2

Source Exif Data:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          :
Create Date                     : 2017:04:20 18:29:32-04:00
Modify Date                     : 2017:04:25 16:43:53-04:00
XMP Toolkit                     : Adobe XMP Core 5.2-c001 63.139439, 2010/09/27-13:37:26
Creator Tool                    : PScript5.dll Version 5.2.2
Metadata Date                   : 2017:04:25 16:43:53-04:00
Producer                        : Acrobat Distiller 10.1.16 (Windows)
Format                          : application/pdf
Creator                         :
Title                           :
Document ID                     : uuid:b84b235a-4ac4-44c1-825d-0c0325f790ef
Instance ID                     : uuid:7c811bb3-c50b-41ab-8337-5e48ececbad3
Page Count                      : 31

Facebook Twitter Google+ RSS © FCCID.io 2017
