AP72598V Label Diagram - FCC ID APIAP72598V

FCC ID APIAP72598V

Label and location_Rev1

AP72598V

by Harman International Industries, Inc

Document preview loads when visible.

Document Details

FCC IDAPIAP72598V
Document ID7141558
Document TypeID Label/Location Info
DescriptionLabel and location_Rev1
ApplicantHarman International Industries, Inc
Equipment ClassAP72598V
Product CodeAP72598V
Application IDFDVowJpzgZrzFc/+1YE1Ow==
Application PurposeOriginal Equipment
Application Date2024-02-28
Frequency Range2402-2480 MHz
FRN0024748147
Test FirmIntertek Testing Services Shanghai
Certified ByErick Liu Certification Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2024-02-28
Available2024-02-28
Created2022-04-28
Modified2022-04-28
Pages1
File TypeAdobe Acrobat PDF
File Size186569
File SHA-256df745ec06cd436ef370dee35fe2c403bc8103ea34d6395898c0a204d4d0ed3f3
PDF Metadata Authoryiny
PDF Metadata ProducerWPS 表格
FCC.gov SourcesFCC.gov 7141558, FCC.gov 5878765, FCC.gov 5878702
