UMNZ1A2 5G Communication Module Test Setup... - FCC ID CWTUMNZ1A2

FCC ID CWTUMNZ1A2

STC_P_Setup Photo_s1.pdf

5G Communication Module

by ALPS ALPINE CO., LTD.

Document preview loads when visible.

Document Details

FCC IDCWTUMNZ1A2
Document ID7716324
Document TypeTest Setup Photos
DescriptionSTC_P_Setup Photo_s1.pdf
ApplicantALPS ALPINE CO., LTD.
Equipment Class5G Communication Module
Product CodeUMNZ1A2
Application IDNjDG5d7iJzmH1SkBiOtNrQ==
Application PurposeOriginal Equipment
Application Date2024-10-07
Frequency Range1712.4-1752.6 MHz
FRN0034613570
Test FirmSGS Taiwan Ltd. Central RF Lab
Certified ByJim Chang RF Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date04/05/2025
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2024-10-06
Available2025-04-05
Created2024-09-13
Modified2024-09-13
Pages4
File TypeAdobe Acrobat PDF
File Size851870
File SHA-2560f9cf07d02a2678ebfb85d60eb066d3ca1f8def46459fb70156f39c376269562
PDF Metadata Producer適用於 Microsoft 365 的 Microsoft® Word; modified using iTextSharp™ 5.5.13.4 ©2000-2024 iText Group NV (AGPL-version) 適用於 Microsoft 365 的 Microsoft® Word
FCC.gov SourcesFCC.gov 7716324
