GMZM4 Wireless Dongle Teardown Internal Photos - FCC ID FSUGMZM4

FCC ID FSUGMZM4

Internal Photos

Wireless Dongle

by KYE SYSTEMS CORP.

Document preview loads when visible.

Document Details

FCC IDFSUGMZM4
Document ID5812725
Document TypeInternal Photos
DescriptionInternal Photos
ApplicantKYE SYSTEMS CORP.
Equipment ClassWireless Dongle
Product CodeGMZM4
Application IDg1HWDkljaPd8bOglQ3dRQg==
Application PurposeOriginal Equipment
Application Date2022-04-11
Frequency Range2405-2475 MHz
FRN0005897442
Test FirmShenzhen Toby Technology Co., Ltd.
Certified ByRicky Chen Section Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-04-11
Available2022-04-11
Created2022-04-07
Modified2022-04-07
Pages1
File TypeAdobe Acrobat PDF
File Size695337
File SHA-25602862835ced61ea37efb56641e11ea45b52dfabdff35feb1b04ff89a495a48dd
PDF Metadata AuthorTOBY 808
PDF Metadata ProducerMicrosoft® Word 2016 TOBY 808
FCC.gov SourcesFCC.gov 5812725
