GMZM4 Wireless Dongle Test Setup Photos - FCC ID FSUGMZM4

FCC ID FSUGMZM4

Test Setup Photos

Wireless Dongle

by KYE SYSTEMS CORP.

Document preview loads when visible.

Document Details

FCC IDFSUGMZM4
Document ID5812739
Document TypeTest Setup Photos
DescriptionTest Setup Photos
ApplicantKYE SYSTEMS CORP.
Equipment ClassWireless Dongle
Product CodeGMZM4
Application IDg1HWDkljaPd8bOglQ3dRQg==
Application PurposeOriginal Equipment
Application Date2022-04-11
Frequency Range2405-2475 MHz
FRN0005897442
Test FirmShenzhen Toby Technology Co., Ltd.
Certified ByRicky Chen Section Supervisor
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-04-11
Available2022-04-11
Created2022-04-07
Modified2022-04-07
Pages2
File TypeAdobe Acrobat PDF
File Size709766
File SHA-25689abfa8a16281a5ef98846ea778fb2da17353e55deebbaecb0498089b8a2ef52
PDF Metadata AuthorTOBY 808
PDF Metadata ProducerMicrosoft® Word 2016 TOBY 808
FCC.gov SourcesFCC.gov 5812739
