FCC RF Exposure Report
FCC ID
: I88WSQ50
Equipment
: Multy X AC3000 Tri-Band WiFi System
Model No.
: WSQ50
Brand Name
: ZYXEL
Applicant
: Zyxel Communications Corporation
Address
: No.2, Industry East Road IX, Hsinchu Science
Park, Hsinchu, 30075, Taiwan, R.O.C.
Standard
: 47 CFR FCC Part 2.1091
Received Date
: May 26, 2017
Tested Date
: May 26 ~ Aug. 22, 2017
We, International Certification Corp., would like to declare that the tested sample has been
evaluated and in compliance with the requirement of the above standards. The test results
contained in this report refer exclusively to the product. It may be duplicated completely for
legal use with the approval of the applicant. It shall not be reproduced except in full without
the written approval of our laboratory.
Reviewed by:
Approved by:
Along Chen / Assistant Manager
Gary Chang / Manager
Report No.: FA760801
Report Version: Rev. 01
Page : 1 of 6
Table of Contents
MPE EVALUATION OF MOBILE DEVICES ......................................................................................... 4
1.1
LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE............................................. 4
1.2
MPE EVALUATION FORMULA ............................................................................................................. 4
1.3
MPE EVALUATION RESULTS .............................................................................................................. 5
TEST LABORATORY INFORMATION ................................................................................................. 6
Report No.: FA760801
Report Version: Rev. 01
Page : 2 of 6
Release Record
Report No.
Version
FA760801
Rev. 01
Report No.: FA760801
Report Version: Rev. 01
Description
Initial issue
Issued Date
Sep. 04, 2017
Page : 3 of 6
1
MPE EVALUATION OF MOBILE DEVICES
Human exposure to RF emissions from mobile devices (47 CFR §2.1091) may be evaluated based on the
MPE limits adopted by the FCC for electric and magnetic field strength and/or power density, as appropriate,
since exposures are assumed to occur at distances of 20 cm or more from persons.
1.1
LIMITS FOR GENERAL POPULATION/UNCONTROLLED EXPOSURE
Frequency Range (MHz)
Power Density (mW /cm )
Averaging Time (minutes)
300~1500
F/1500
30
1500~100000
1.0
30
1.2
MPE EVALUATION FORMULA
Pd =
Pt
4 * Pi * R 2
Where
Pd=
Pt=
Pi=
R=
Power density in mW/cm
EIRP in mW
3.1416
Measurement distance
Report No.: FA760801
Report Version: Rev. 01
Page : 4 of 6
1.3
MPE EVALUATION RESULTS
Non-beamforming mode
Maximum
Conducted
Power (dBm)
Antenna Gain
(dBi)
Distance
(cm)
2412~2462
29.52
20
0.178
5180~5240
27.63
20
0.115
5745~5825
29.81
0.43
20
0.210
3.57
4.94
20
0.001
Maximum
Conducted
Power (dBm)
Antenna Gain
(dBi)
Distance
(cm)
28.92
6.45
20
Frequency
Range (MHz)
Power Density
Limit (mW/cm )
(mW/cm )
For WLAN
For BT
2402~2480 LE
Beamforming mode
Frequency
Range (MHz)
Power Density
Limit (mW/cm )
(mW/cm )
For WLAN
5745~5825
0.685
Note:
For 5745~5850 MHz band
Directional gain = 0.43+10* log(4/1) = 6.45 dBi
MPE Evaluation of Simultaneous Transmission
The device supports simultaneous transmission as below configurations
Wi-Fi 2.4GHz + BT + Wi-Fi 5 GHz UNII Band 1+ Wi-Fi 5GHz UNII Band 3
MPE evaluation is as below formula
PD1 / Limit1 + PD2 / Limit 2 + ….. < 1, PD = Power density
MPE Evaluation = 0.178 / 1 + 0.001 / 1 + 0.115 / 1 + 0.685 / 1 = 0.98 < 1
Conclusion
MPE evaluations of single and simultaneous transmission meet the requirement of standard.
Report No.: FA760801
Report Version: Rev. 01
Page : 5 of 6
2
Test laboratory information
Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our
skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and
one of the widest certification extents in the business.
International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is
to institute long term, trust-based associations with our clients. The expectation we set up with our clients is
based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to
grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff.
Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our
website http://www.icertifi.com.tw.
Linkou
Kwei Shan
Kwei Shan Site II
Tel: 886-2-2601-1640
Tel: 886-3-271-8666
Tel: 886-3-271-8640
No. 30-2, Ding Fwu Tsuen, Lin
Kou District, New Taipei City,
Taiwan, R.O.C.
No. 3-1, Lane 6, Wen San 3rd St.,
Kwei Shan District, Tao Yuan City
333, Taiwan, R.O.C.
No. 14-1, Lane 19, Wen San 3rd
St., Kwei Shan District, Tao Yuan
City 333, Taiwan, R.O.C.
If you have any suggestion, please feel free to contact us as below information.
Tel: 886-3-271-8666
Fax: 886-3-318-0155
Email: [email protected]
══END══
Report No.: FA760801
Report Version: Rev. 01
Page : 6 of 6
