FCC Test Report
FCC ID
: I88WSQ50
Equipment
: Multy X AC3000 Tri-Band WiFi System
Model No.
: WSQ50
Brand Name
: ZYXEL
Applicant
: Zyxel Communications Corporation
Address
: No.2, Industry East Road IX, Hsinchu Science
Park, Hsinchu, 30075, Taiwan, R.O.C.
Standard
: 47 CFR FCC Part 15.407
Received Date
: May 26, 2017
Tested Date
: May 31 ~ Aug. 22, 2017
We, International Certification Corp., would like to declare that the tested sample has been
evaluated and in compliance with the requirement of the above standards. The test results
contained in this report refer exclusively to the product. It may be duplicated completely for
legal use with the approval of the applicant. It shall not be reproduced except in full without
the written approval of our laboratory.
Reviewed by:
Approved by:
Along Chen / Assistant Manager
Gary Chang / Manager
Report No.: FR760801AN
Report Version: Rev. 01
Page : 1 of 96
Table of Contents
GENERAL DESCRIPTION .................................................................................................................... 5
1.1
Information.............................................................................................................................................. 5
1.2
Local Support Equipment List ..............................................................................................................12
1.3
Test Setup Chart ..................................................................................................................................12
1.4
The Equipment List ..............................................................................................................................14
1.5
Testing Applied Standards ...................................................................................................................15
1.6
Measurement Uncertainty ....................................................................................................................15
TEST CONFIGURATION .....................................................................................................................16
2.1
Testing Condition .................................................................................................................................16
2.2
The Worst Test Modes and Channel Details .......................................................................................16
TRANSMITTER TEST RESULTS........................................................................................................18
3.1
Conducted Emissions ...........................................................................................................................18
3.2
Emission Bandwidth .............................................................................................................................25
3.3
RF Output Power ..................................................................................................................................29
3.4
Peak Power Spectral Density ...............................................................................................................32
3.5
Transmitter Radiated and Band Edge Emissions ................................................................................37
3.6
Frequency Stability ...............................................................................................................................94
TEST LABORATORY INFORMATION ...............................................................................................96
Report No.: FR760801AN
Report Version: Rev. 01
Page : 2 of 96
Release Record
Report No.
Version
FR760801AN
Rev. 01
Report No.: FR760801AN
Report Version: Rev. 01
Description
Initial issue
Issued Date
Sep. 04, 2017
Page : 3 of 96
Summary of Test Results
FCC Rules
Test Items
Measured
Result
Conducted Emissions
[dBuV]: 0.476MHz
30.50 (Margin -15.91dB) - AV
Pass
Radiated Emissions
[dBuV/m at 3m]: 5150.00MHz
53.63 (Margin -0.37dB) - AV
Pass
15.407(a)
Emission Bandwidth
Meet the requirement of limit
Pass
15.407(e)
6dB bandwidth
Meet the requirement of limit
Pass
15.407(a)
RF Output Power
Max Power [dBm]:
Non-beamforming mode
5150-5250MHz: 27.63
5725-5850MHz: 29.81
Beamforming mode
5725-5850MHz: 28.92
Pass
15.407(a)
Peak Power Spectral Density
Meet the requirement of limit
Pass
15.407(g)
Frequency Stability
Meet the requirement of limit
Pass
Antenna Requirement
Meet the requirement of limit
Pass
15.207
15.407(b)
15.209
15.203
Report No.: FR760801AN
Report Version: Rev. 01
Page : 4 of 96
1
General Description
1.1
Information
1.1.1
Specification of the Equipment under Test (EUT)
RF General Information
Frequency
Range (MHz)
IEEE Std.
802.11
Ch. Freq. (MHz)
Channel
Number
Transmit
Chains (NTX)
Data Rate /
MCS
5150-5250
5180-5240
36-48 [4]
6-54 Mbps
5150-5250
n (HT20)
5180-5240
36-48 [4]
MCS 0-15
5150-5250
n (HT40)
5190-5230
38-46 [2]
MCS 0-15
5150-5250
ac (VHT20)
5180-5240
36-48 [4]
MCS 0-9
5150-5250
ac (VHT40)
5190-5230
38-46 [2]
MCS 0-9
5150-5250
ac (VHT80)
5210
42 [1]
MCS 0-9
Note 1: RF output power specifies that Maximum Conducted Output Power.
Note 2: 802.11a/n/ac uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM, 256QAM modulation
Note 3: 802.11ac does not support beamforming function..
RF General Information
Frequency
Range (MHz)
IEEE Std.
802.11
Ch. Freq. (MHz)
Channel
Number
Transmit
Chains (NTX)
Data Rate /
MCS
5725-5850
5745-5825
149-165 [5]
6-54 Mbps
5725-5850
n (HT20)
5745-5825
149-165 [5]
MCS 0-31
5725-5850
n (HT40)
5755-5795
151-159 [2]
MCS 0-31
5725-5850
ac (VHT20)
5745-5825
149-165 [5]
MCS 0-9
5725-5850
ac (VHT40)
5755-5795
151-159 [2]
MCS 0-9
5725-5850
ac (VHT80)
5775
155 [1]
MCS 0-9
Note 1: RF output power specifies that Maximum Conducted Output Power.
Note 2: 802.11a/n/ac uses a combination of OFDM-BPSK, QPSK, 16QAM, 64QAM, 256QAM modulation.
Note 3: 802.11ac supports beamforming function.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 5 of 96
1.1.2
Main Chipset / RF Chipset
Function
Model No.
Main Chipset
IPQ4019
2.4G
IPQ4019
5G 2T2R
IPQ4019
5G 4T4R
QCA9984
Bluetooth LE
CSR8811
1.1.3
Antenna Details
Ant.
No.
Model
Type
Connector
ALX17M-126XX3-A
PIFA
UFL
1.1.4
2400~2483.5
5150~5250
5725~5850
0.43
Power Supply Type of Equipment under Test (EUT)
Power Supply Type
1.1.5
Operating Frequency (MHz) / Gain (dBi)
12Vdc from adapter
Accessories
Accessories
No.
Equipment
Adapter
Report No.: FR760801AN
Report Version: Rev. 01
Description
Brand Name: APD
Model Name: WA-36A12FU
I/P: 100-240Vac, 50-60Hz 0.9 Max
O/P: 12Vdc, 3A
Power line: 1.75m non-shielded without core
Page : 6 of 96
1.1.6
Channel List
For Frequency band 5150-5250 MHz
802.11 a / HT20 / VHT20
HT40 / VHT40
Channel
Frequency(MHz)
Channel
Frequency(MHz)
36
5180
38
5190
40
5200
46
5230
44
5220
48
5240
VHT80
42
5210
For Frequency band 5725~5850 MHz
802.11 a / HT20 / VHT20
HT40 / VHT40
Channel
Frequency(MHz)
Channel
Frequency(MHz)
149
5745
151
5755
153
5765
159
5795
157
5785
161
5805
155
5775
165
5825
---
---
Report No.: FR760801AN
Report Version: Rev. 01
VHT80
Page : 7 of 96
1.1.7
Test Tool and Duty Cycle
For Frequency band 5150-5250 MHz
QRCT, Version: 3.0.144.0
Test Tool
Duty Cycle and Duty Factor
Report No.: FR760801AN
Report Version: Rev. 01
Mode
Duty cycle (%)
Duty factor (dB)
11a
98.34%
0.07
VHT20
98.97%
0.05
VHT40
98.14%
0.08
VHT80
92.99%
0.32
11a
VHT20
VHT40
VHT80
Page : 8 of 96
For Frequency band 5725~5850 MHz
Non-Beamforming: QRCT, Version: 3.0.144.0
Beamforming: Telnet
Test Tool
Non-beamforming
Beamforming
Mode
Duty Cycle and Duty Factor
Duty cycle (%)
Duty factor (dB)
Duty cycle (%)
Duty factor (dB)
11a
98.33%
0.07
---
---
VHT20
99.20%
0.04
92.10%
0.36
VHT40
98.14%
0.08
91.83%
0.37
VHT80
95.71%
0.19
92.81%
0.32
Non-beamforming mode
Report No.: FR760801AN
Report Version: Rev. 01
11a
VHT20
VHT40
VHT80
Page : 9 of 96
Beamforming mode
11a
VHT20
---
VHT40
Report No.: FR760801AN
Report Version: Rev. 01
VHT80
Page : 10 of 96
1.1.8
Power Setting
For Frequency band 5150-5250 MHz
Modulation Mode
Test Frequency (MHz)
Power Set
11a
5180
23.50
11a
5200
26.00
11a
5240
26.00
HT20
5180
22.00
HT20
5200
26.00
HT20
5240
26.00
HT40
5190
19.00
HT40
5230
26.00
VHT20
5180
22.00
VHT20
5200
26.00
VHT20
5240
26.00
VHT40
5190
19.00
VHT40
5230
26.00
VHT80
5210
18.50
For Frequency band 5725~5850 MHz
Modulation Mode
Power Set
Test Frequency (MHz)
Non-Beamforming
Beamforming
11a
5745
23.50
---
11a
5785
23.50
---
11a
5825
23.50
---
HT20
5745
23.50
29.00
HT20
5785
23.50
29.00
HT20
5825
23.50
29.00
HT40
5755
23.50
29.00
HT40
5795
23.50
29.00
VHT20
5745
23.50
29.00
VHT20
5785
23.50
29.00
VHT20
5825
23.50
29.00
VHT40
5755
23.50
29.00
VHT40
5795
23.50
29.00
VHT80
5775
20.00
26.00
Report No.: FR760801AN
Report Version: Rev. 01
Page : 11 of 96
1.2
Local Support Equipment List
Non-beamforming mode
Support Equipment List
No.
Equipment
Brand
Model
FCC ID
Signal cable / Length (m)
Notebook
DELL
Latitude E6430
DoC
RJ45, 10m non-shielded.
Notebook
DELL
Latitude E5420
DoC
RJ45, 10m non-shielded.
USB Flash
Kingston
DTSE9
---
---
Beamforming mode
Support Equipment List
No.
Equipment
Brand
Model
FCC ID
Signal cable / Length (m)
Notebook
DELL
Latitude E6430
DoC
RJ45, 10m non-shielded.
Notebook
DELL
Latitude E5420
DoC
RJ45, 10m non-shielded.
USB Flash
Kingston
DTSE9
---
---
Notebook
DELL
Latitude E6430
---
RJ45, 1m non-shielded.
Multy X AC3000
Tri-Band WiFi
System
ZYXEL
WSQ50
---
---
Note: No.5 was supplied by applicant.
1.3
Test Setup Chart
Non-beamforming mode
Test Setup Diagram
Report No.: FR760801AN
Report Version: Rev. 01
Page : 12 of 96
Beamforming mode
Test Setup Diagram
Report No.: FR760801AN
Report Version: Rev. 01
Page : 13 of 96
1.4
The Equipment List
Test Item
Conducted Emission
Test Site
Conduction room 1 / (CO01-WS)
Instrument
Manufacturer
Model No.
Serial No.
Calibration Date
Calibration Until
Receiver
R&S
ESR3
101657
Dec. 21, 2016
Dec. 20, 2017
LISN
R&S
ENV216
101579
Jan. 19, 2017
Jan. 18, 2018
RF Cable-CON
EMC
EMCCFD300-BM-B
M-6000
50821
Dec. 20, 2016
Dec. 19, 2017
Measurement
Software
AUDIX
e3
6.120210k
NA
NA
Note: Calibration Interval of instruments listed above is one year.
Test Item
Radiated Emission
Test Site
966 chamber1 / (03CH01-WS)
Instrument
Manufacturer
Model No.
Serial No.
Calibration Date
Calibration Until
Spectrum Analyzer
R&S
FSV40
101498
Nov. 25, 2016
Nov. 24, 2017
Receiver
R&S
ESR3
101658
Nov. 24, 2016
Nov. 23, 2017
Bilog Antenna
SCHWARZBECK
VULB9168
VULB9168-524
Oct. 13, 2016
Oct. 12, 2017
Horn Antenna
1G-18G
SCHWARZBECK
BBHA 9120 D
BBHA 9120 D 1096
Dec. 21, 2016
Dec. 20, 2017
Horn Antenna
18G-40G
SCHWARZBECK
BBHA 9170
BBHA 9170517
Oct. 25, 2016
Oct. 24, 2017
Loop Antenna
R&S
HFH2-Z2
100330
Nov. 10, 2016
Nov. 09, 2017
Loop Antenna Cable
KOAX KABEL
101354-BW
101354-BW
Dec. 09, 2016
Dec. 08, 2017
Preamplifier
EMC
EMC02325
980146
Oct. 08, 2016
Oct. 07, 2017
Preamplifier
Agilent
83017A
MY39501308
Oct. 06, 2016
Oct. 05, 2017
Preamplifier
EMC
EMC184045B
980192
Aug. 24, 2016
Aug. 23, 2017
RF Cable
HUBER+SUHNER
SUCOFLEX104
MY16014/4
Dec. 09, 2016
Dec. 08, 2017
RF Cable
HUBER+SUHNER
SUCOFLEX104
MY16019/4
Dec. 09, 2016
Dec. 08, 2017
RF Cable
HUBER+SUHNER
SUCOFLEX104
MY16139/4
Dec. 09, 2016
Dec. 08, 2017
LF cable 1M
EMC
EMCCFD400-NM-N
M-1000
16052
Dec. 09, 2016
Dec. 08, 2017
LF cable 3M
Woken
CFD400NL-LW
CFD400NL-001
Dec. 09, 2016
Dec. 08, 2017
LF cable 10M
Woken
CFD400NL-LW
CFD400NL-002
Dec. 09, 2016
Dec. 08, 2017
Measurement
Software
AUDIX
e3
6.120210g
NA
NA
Note: Calibration Interval of instruments listed above is one year.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 14 of 96
Test Item
RF Conducted
Test Site
(TH01-WS)
Instrument
Manufacturer
Model No.
Serial No.
Calibration Date
Calibration Until
Spectrum Analyzer
R&S
FSV40
101063
Mar. 15, 2017
Mar. 14, 2018
TEMP&HUMIDITY
CHAMBER
GIANT FORCE
GCT-225-40-SP-SD
MAF1212-002
Nov. 21, 2016
Nov. 20, 2017
Power Meter
Anritsu
ML2495A
1241002
Oct. 06, 2016
Oct. 05, 2017
Power Sensor
Anritsu
MA2411B
1207366
Oct. 06, 2016
Oct. 05, 2017
AC POWER
SOURCE
APC
AFC-500W
F312060012
Oct. 28, 2016
Oct. 27, 2017
Measurement
Software
Sporton
Sporton_1
1.3.30
NA
NA
Note: Calibration Interval of instruments listed above is one year.
1.5
Testing Applied Standards
According to the specification of EUT, the EUT must comply with following standards and KDB documents.
47 CFR FCC Part 15.407
ANSI C63.10-2013
FCC KDB 789033 D02 General UNII Test Procedures New Rules v01r04
FCC KDB 644545 D03 Guidance for IEEE 802 11ac New Rules v01
FCC KDB 662911 D01 Multiple Transmitter Output v02r01
FCC KDB 412172 D01 Determining ERP and EIRP v01r01
1.6
Measurement Uncertainty
ISO/IEC 17025 requires that an estimate of the measurement uncertainties associated with the emissions test
results be included in the report. The measurement uncertainties given below are based on a 95% confidence
level (based on a coverage factor (k=2)
Measurement Uncertainty
Parameters
Uncertainty
Bandwidth
±34.134 Hz
Conducted power
±0.808 dB
Frequency error
±34.134 Hz
Power density
±0.463 dB
Conducted emission
±2.670 dB
AC conducted emission
±2.90 dB
Radiated emission ≤ 1GHz
±3.66 dB
Radiated emission > 1GHz
±5.63 dB
Time
±0.1%
Temperature
±0.6 C
Report No.: FR760801AN
Report Version: Rev. 01
Page : 15 of 96
2
Test Configuration
2.1
Testing Condition
Test Item
AC Conduction
Radiated Emissions
RF Conducted
 FCC Designation No.:
Test Site
Ambient Condition
Tested By
CO01-WS
23°C / 57%
Alex Tsai
03CH01-WS
24°C / 62-64%
Vincent Yeh
Kevin Lee
TH01-WS
23°C / 62%
Felix Sung
TW2732
 FCC site registration No.:
181692
 IC site registration No.: 10807A-1
2.2
The Worst Test Modes and Channel Details
Non-beamforming mode
For Frequency band 5150-5250 MHz
Test item
Modulation
Mode
Test Frequency
(MHz)
Data Rate
(Mbps) / MCS
Test
Configuration
Conducted Emissions
11a
5200
6 Mbps
---
Radiated Emissions ≤1GHz
11a
5200
6 Mbps
---
11a
HT20
HT40
VHT20
VHT40
VHT80
5180 / 5200 / 5240
5180 / 5200 / 5240
5190 / 5230
5180 / 5200 / 5240
5190 / 5230
5210
6 Mbps
MCS 0
MCS 0
MCS 0
MCS 0
MCS 0
---
11a
VHT20
VHT40
VHT80
5180 / 5200 / 5240
5180 / 5200 / 5240
5190 / 5230
5210
6 Mbps
MCS 0
MCS 0
MCS 0
---
---
---
RF Output Power
Radiated Emissions >1GHz
Emission Bandwidth
Peak Power Spectral Density
Frequency Stability
Report No.: FR760801AN
Report Version: Rev. 01
Un-modulation 5200
Page : 16 of 96
For Frequency band 5725-5850 MHz
Test item
Modulation
Mode
Test Frequency
(MHz)
Data Rate
(Mbps) / MCS
Test
Configuration
Conducted Emissions
11a
5785
6 Mbps
---
Radiated Emissions ≤1GHz
11a
5785
6 Mbps
---
11a
HT20
HT40
VHT20
VHT40
VHT80
5745 / 5785 / 5825
5745 / 5785 / 5825
5755 / 5795
5745 / 5785 / 5825
5755 / 5795
5775
6 Mbps
MCS 0
MCS 0
MCS 0
MCS 0
MCS 0
---
11a
VHT20
VHT40
VHT80
5745 / 5785 / 5825
5745 / 5785 / 5825
5755 / 5795
5775
6 Mbps
MCS 0
MCS 0
MCS 0
---
---
---
Data Rate
(Mbps) / MCS
Test
Configuration
RF Output Power
Radiated Emissions >1GHz
Emission Bandwidth
6dB bandwidth
Peak Power Spectral Density
Frequency Stability
Un-modulation 5785
Beamforming mode
For Frequency band 5725-5850 MHz
Test item
Modulation
Mode
Test Frequency
(MHz)
Conducted Emissions
VHT40
5795
MCS 0
---
Radiated Emissions ≤1GHz
VHT40
5795
MCS 0
---
RF Output Power
HT20
HT40
VHT20
VHT40
VHT80
5745 / 5785 / 5825
5755 / 5795
5745 / 5785 / 5825
5755 / 5795
5775
MCS 0
MCS 0
MCS 0
MCS 0
MCS 0
---
VHT20
VHT40
VHT80
5745 / 5785 / 5825
5755 / 5795
5775
MCS 0
MCS 0
MCS 0
---
Radiated Emissions >1GHz
Emission Bandwidth
6dB bandwidth
Peak Power Spectral Density
Report No.: FR760801AN
Report Version: Rev. 01
Page : 17 of 96
3
Transmitter Test Results
3.1
Conducted Emissions
3.1.1
Limit of Conducted Emissions
Conducted Emissions Limit
Frequency Emission (MHz)
Quasi-Peak
Average
0.15-0.5
66 - 56 *
56 - 46 *
0.5-5
56
46
5-30
60
50
Note 1: * Decreases with the logarithm of the frequency.
3.1.2
Test Procedures
1.
The device is placed on a test table, raised 80 cm above the reference ground plane. The vertical
conducting plane is located 40 cm to the rear of the device.
2.
The device is connected to line impedance stabilization network (LISN) and other accessories are
connected to other LISN. Measured levels of AC power line conducted emission are across the 50 Ω
LISN port.
3.
AC conducted emission measurements is made over frequency range from 150 kHz to 30 MHz.
4.
This measurement was performed with AC 120V / 60Hz.
3.1.3
Test Setup
Report No.: FR760801AN
Report Version: Rev. 01
Page : 18 of 96
3.1.4
Test Result of Conducted Emissions
Non-beamforming mode
Modulation
11a
Power Phase
Line
Test Freq. (MHz)
5200
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 19 of 96
Modulation
11a
Power Phase
Neutral
Test Freq. (MHz)
5200
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 20 of 96
Modulation
11a
Power Phase
Line
Test Freq. (MHz)
5785
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 21 of 96
Modulation
11a
Power Phase
Neutral
Test Freq. (MHz)
5785
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 22 of 96
Beamforming mode
Modulation
VHT40
Power Phase
Line
Test Freq. (MHz)
5795
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 23 of 96
Modulation
VHT40
Power Phase
Neutral
Test Freq. (MHz)
5795
Note 1: Level (dBuV) = Read Level (dBuV) + LISN Factor (dB) + Cable Loss (dB).
2: Over Limit (dB) = Level (dBuV) – Limit Line (dBuV).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 24 of 96
3.2
Emission Bandwidth
3.2.1
Limit of Emission bandwidth
Within the 5.725-5.85 GHz band, the minimum 6 dB bandwidth of U-NII devices shall be at least 500 kHz.
3.2.2
Test Procedures
26dB Bandwidth
1.
Set
c RBW = approximately 1% of the emission bandwidth.
2.
Set the VBW > RBW, Detector = Peak.
3.
Trace mode = max hold.
4.
Measure the maximum width of the emission that is 26 dB down from the peak of the emission.
Occupied Bandwidth
1.
Set RBW = 1 % to 5 % of the OBW
2.
Set VBW ≥ 3 RBW
3.
Sample detection and single sweep mode shall be used
4.
Use the 99 % power bandwidth function of the instrument
6dB Bandwidth
1.
Set RBW = 100kHz, VBW = 300kHz
2.
Detector = Peak,Trace mode = max hold.
3.
Allow the trace to stabilize.
4.
Measure the maximum width of the emission that is constrained by the frequencies associated with the
two outermost amplitude points (upper and lower frequencies) that are attenuated by 6 dB relative to the
maximum level measured in the fundamental emission
3.2.3
Test Setup
Report No.: FR760801AN
Report Version: Rev. 01
Page : 25 of 96
3.2.4
Test Result of Emission Bandwidth
Non-beamforming mode
For Frequency band 5150-5250 MHz
Emission Bandwidth
Mode
NTX
26dB Bandwidth (MHz)
99% Bandwidth (MHz)
Freq.
(MHz)
Chain 0
Chain 1
Chain 2
Chain 3
Chain 0
Chain 1
Chain 2
Chain 3
11a
5180
24.93
20.75
---
---
16.47
16.57
---
---
11a
5200
41.74
38.41
---
---
16.94
18.86
---
---
11a
5240
38.91
37.54
---
---
17.16
16.79
---
---
VHT20
5180
20.52
20.35
---
---
17.62
17.63
---
---
VHT20
5200
42.83
45.07
---
---
18.02
18.80
---
---
VHT20
5240
43.19
39.93
---
---
18.10
17.88
---
---
VHT40
5190
40.46
40.46
---
---
35.98
35.98
---
---
VHT40
5230
84.49
82.61
---
---
37.60
36.90
---
---
VHT80
5210
85.48
83.25
---
---
75.88
75.72
---
---
Worst Plot of 26dB Bandwidth
Report No.: FR760801AN
Report Version: Rev. 01
Worst Plot of 99% Bandwidth
Page : 26 of 96
For Frequency band 5725-5850 MHz
Emission Bandwidth
OBW Bandwidth (MHz)
Mode
NTX
Freq.
(MHz)
6dB Bandwidth (MHz)
Chain 0 Chain 1 Chain 2 Chain 3 Chain 0 Chain 1 Chain 2 Chain 3
6dB BW
Limit
(MHz)
11a
5745
16.57
16.53
16.43
16.50
15.94
16.35
14.43
16.35
0.5
11a
5785
16.58
16.55
16.40
16.51
15.94
16.35
15.01
16.29
0.5
11a
5825
16.56
16.48
16.37
16.52
16.35
15.94
15.07
15.94
0.5
VHT20
5745
17.65
17.67
17.59
17.68
17.16
17.57
15.30
16.93
0.5
VHT20
5785
17.69
17.67
17.57
17.69
17.16
16.81
15.71
16.93
0.5
VHT20
5825
17.70
17.66
17.53
17.66
17.57
17.57
13.91
16.29
0.5
VHT40
5755
36.02
35.92
36.08
36.12
35.13
35.13
35.13
33.86
0.5
VHT40
5795
36.00
35.90
36.14
35.94
35.13
35.13
35.13
33.86
0.5
VHT80
5775
75.92
75.60
76.16
75.76
75.36
75.13
76.29
75.13
0.5
Worst Plot of 99% Bandwidth
Report No.: FR760801AN
Report Version: Rev. 01
Worst Plot of 6dB Bandwidth
Page : 27 of 96
Beamforming mode
For Frequency band 5725-5850 MHz
Emission Bandwidth
OBW Bandwidth (MHz)
Mode
NTX
Freq.
(MHz)
6dB Bandwidth (MHz)
Chain 0 Chain 1 Chain 2 Chain 3 Chain 0 Chain 1 Chain 2 Chain 3
6dB BW
Limit
(MHz)
VHT20
5745
17.65
17.72
17.63
17.71
17.33
17.28
15.13
16.99
0.5
VHT20
5785
17.68
17.74
17.61
17.71
17.39
17.39
15.65
16.70
0.5
VHT20
5825
17.69
17.68
17.62
17.71
16.58
17.28
16.99
17.39
0.5
VHT40
5755
36.18
36.24
36.02
36.06
34.55
35.13
33.28
35.71
0.5
VHT40
5795
36.30
36.16
36.08
36.34
35.71
35.36
35.13
35.71
0.5
VHT80
5775
76.36
76.40
76.20
76.40
75.13
75.83
75.83
74.20
0.5
Worst Plot of 99% Bandwidth
Report No.: FR760801AN
Report Version: Rev. 01
Worst Plot of 6dB Bandwidth
Page : 28 of 96
3.3
RF Output Power
3.3.1
Limit of RF Output Power
Frequency band 5150-5250 MHz
Operating Mode
Limit
Outdoor access point
Conducted Power: 1 W
The maximum e.i.r.p. at any elevation angle above 30 degrees
as measured from the horizon must not exceed 125 mW (21
dBm)
Indoor access point
Conducted Power: 1 W
Fixed point-to-point access points
Conducted Power: 1 W
Client devices
Conducted Power: 250 mW
Frequency Band (MHz)
Limit
5250 ~ 5350
250mW or 11dBm+10 log B
5470 ~ 5725
250mW or 11dBm+10 log B
5725 ~ 5850
1W
Note: “B” is the 26dB emission bandwidth in MHz.
3.3.2
Test Procedures
Method PM-G ( Measurement using a gated RF average power meter )
Measurements is performed using a wideband gated RF power meter provided that the gate
parameters are adjusted such that the power is measured only when the EUT is transmitting at its
maximum power control level. Since the measurement is made only during the ON time of the
transmitter, no duty cycle correction factor is required.
3.3.3
Test Setup
Report No.: FR760801AN
Report Version: Rev. 01
Page : 29 of 96
3.3.4
Test Result of Maximum Conducted Output Power
Non-beamforming mode
For Frequency band 5150-5250 MHz
Conducted Power (dBm)
Chain 0
Chain 1
Chain 2
Chain 3
Total
Power
(mW)
5180
22.42
22.02
---
---
333.803
25.23
30.00
5200
24.72
24.52
---
---
579.622
27.63
30.00
11a
5240
24.49
24.23
---
---
546.040
27.37
30.00
HT20
5180
21.06
20.49
---
---
239.588
23.79
30.00
HT20
5200
24.34
24.42
---
---
548.338
27.39
30.00
HT20
5240
24.44
24.03
---
---
530.901
27.25
30.00
HT40
5190
18.39
17.87
---
---
130.259
21.15
30.00
HT40
5230
24.21
23.98
---
---
513.668
27.11
30.00
VHT20
5180
21.11
20.58
---
---
243.410
23.86
30.00
VHT20
5200
24.52
24.50
---
---
564.977
27.52
30.00
VHT20
5240
24.51
24.12
---
---
540.714
27.33
30.00
VHT40
5190
18.48
17.92
---
---
132.413
21.22
30.00
VHT40
5230
24.36
24.12
---
---
531.124
27.25
30.00
VHT80
5210
17.47
16.47
---
---
100.208
20.01
30.00
Total
Power
(dBm)
Limit
(dBm)
Mode
NTX
Freq. (MHz)
11a
11a
Total
Power
(dBm)
Limit
(dBm)
For Frequency band 5725-5850 MHz
Conducted Power (dBm)
Chain 0
Chain 1
Chain 2
Chain 3
Total
Power
(mW)
5745
24.28
23.48
23.09
23.86
937.685
29.72
30.00
5785
24.32
23.46
23.36
23.94
956.728
29.81
30.00
11a
5825
24.12
23.23
23.26
23.62
910.584
29.59
30.00
HT20
5745
23.88
23.02
22.95
23.31
856.322
29.33
30.00
HT20
5785
24.16
23.18
23.09
23.71
907.253
29.58
30.00
HT20
5825
23.77
22.85
22.94
23.37
845.043
29.27
30.00
HT40
5755
24.03
23.15
22.94
23.84
898.359
29.53
30.00
HT40
5795
24.11
23.19
23.06
23.87
912.164
29.60
30.00
VHT20
5745
23.91
23.06
22.98
23.41
866.229
29.38
30.00
VHT20
5785
24.21
23.34
23.14
23.83
927.017
29.67
30.00
VHT20
5825
23.88
22.91
23.07
23.42
862.331
29.36
30.00
VHT40
5755
24.09
23.28
23.02
23.91
915.746
29.62
30.00
VHT40
5795
24.16
23.23
23.18
23.96
927.849
29.67
30.00
VHT80
5775
20.67
20.06
19.76
20.52
425.416
26.29
30.00
Mode
NTX
Freq. (MHz)
11a
11a
Report No.: FR760801AN
Report Version: Rev. 01
Page : 30 of 96
Beamforming mode
For Frequency band 5725-5850 MHz
Conducted Power (dBm)
Chain 0
Chain 1
Chain 2
Chain 3
Total
Power
(mW)
5745
22.06
22.19
22.39
23.72
735.156
28.66
29.55
5785
22.35
22.41
22.59
23.77
765.755
28.84
29.55
HT20
5825
22.06
22.35
22.07
23.71
728.513
28.62
29.55
HT40
5755
22.35
22.32
22.24
23.84
751.996
28.76
29.55
HT40
5795
22.43
22.16
22.75
23.74
764.379
28.83
29.55
VHT20
5745
22.19
22.28
22.56
23.85
757.584
28.79
29.55
VHT20
5785
22.43
22.53
22.68
23.82
780.389
28.92
29.55
VHT20
5825
22.18
22.42
22.18
23.88
749.318
28.75
29.55
VHT40
5755
22.43
22.38
22.31
23.89
763.088
28.83
29.55
VHT40
5795
22.45
22.25
22.81
23.81
775.094
28.89
29.55
VHT80
5775
19.84
19.40
19.46
21.11
400.909
26.03
29.55
Mode
NTX
Freq. (MHz)
HT20
HT20
Total
Power
(dBm)
Limit
(dBm)
Note:
1. Directional gain = 0.43+10* log(4/1) = 6.45 dBi > 6 dBi.
Limit shall be reduced to 30 dBm – (6.45 dBi – 6 dBi) = 29.55 dBm.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 31 of 96
3.4
Peak Power Spectral Density
3.4.1
Limit of Peak Power Spectral Density
Frequency band 5150-5250 MHz
Operating Mode
Limit
Outdoor access point
17 dBm / MHz
Indoor access point
17 dBm / MHz
Fixed point-to-point access points
17 dBm / MHz
Client devices
11 dBm / MHz
Frequency Band (MHz)
Limit
5250 ~ 5350
11 dBm / MHz
5470 ~ 5725
11 dBm / MHz
5725 ~ 5850
30 dBm /500 kHz
Report No.: FR760801AN
Report Version: Rev. 01
Page : 32 of 96
3.4.2
Test Procedures
For 5150 ~ 5250 MHz
Method SA-1 (Non- Beamforming: 802.11a/VHT20/VHT40 )
1.
Set RBW = 1 MHz, VBW = 3 MHz, Sweep time = auto, Detector = RMS.
2.
Trace average 100 traces.
3.
Use the peak marker function to determine the maximum amplitude level.
Method SA-2 Alternative (Non- Beamforming: VHT80)
1.
Set RBW = 1 MHz, VBW = 3 MHz, Detector = RMS.
2.
Set sweep time ≥ 10 * (number of points in sweep) * (total on/off period of the transmitted signal).
3.
Perform a single sweep.
4.
Use the peak marker function to determine the maximum amplitude level.
5.
Add 10 log(1/x), where x is the duty cycle.
For 5725 ~ 5850 MHz
Method SA-1 (Non- Beamforming: 802.11a/VHT20/VHT40)
1.
Set RBW = 500 kHz, VBW = 2 MHz, Sweep time = auto, Detector = RMS.
2.
Trace average 100 traces.
3.
Use the peak marker function to determine the maximum amplitude level.
Method SA-2 Alternative
(Non- Beamforming: VHT80 / Beamforming: all modes)
1.
Set RBW = 500 kHz, VBW = 2 MHz, Detector = RMS.
2.
Set sweep time ≥ 10 * (number of points in sweep) * (total on/off period of the transmitted signal).
3.
Perform a single sweep.
4.
Use the peak marker function to determine the maximum amplitude level.
5.
Add 10 log(1/x), where x is the duty cycle.
3.4.3
Test Setup
Report No.: FR760801AN
Report Version: Rev. 01
Page : 33 of 96
3.4.4
Test Result of Peak Power Spectral Density
Non-beamforming mode
For Frequency band 5150-5250 MHz
Condition
Peak Power Spectral Density (dBm/MHz)
Modulation
Mode
NTX
Freq.
(MHz)
PPSD
w/o D.F
(dBm/MHz)
Duty Factor
(dB)
PPSD
with D.F
(dBm/MHz)
PPSD Limit
(dBm/MHz)
11a
5180
11.80
0.00
11.80
17
11a
5200
14.67
0.00
14.67
17
11a
5240
13.65
0.00
13.65
17
VHT20
5180
10.32
0.00
10.32
17
VHT20
5200
13.69
0.00
13.69
17
VHT20
5240
13.47
0.00
13.47
17
VHT40
5190
4.77
0.00
4.77
17
VHT40
5230
11.07
0.00
11.07
17
VHT80
5210
0.23
0.32
0.55
17
Note:
1. D.F is duty factor.
2. Test result is bin-by-bin summing measured value of each TX port.
Worst Plot
Report No.: FR760801AN
Report Version: Rev. 01
Page : 34 of 96
For Frequency band 5725-5850 MHz
Condition
Peak Power Spectral Density (dBm/500kHz)
Modulation
Mode
NTX
Freq.
(MHz)
PPSD
w/o D.F
(dBm/500kHz)
Duty Factor
(dB)
PPSD
with D.F
(dBm/500kHz)
PPSD Limit
(dBm/500kHz)
11a
5745
14.79
0.00
14.79
29.55
11a
5785
15.19
0.00
15.19
29.55
11a
5825
14.78
0.00
14.78
29.55
VHT20
5745
14.39
0.00
14.39
29.55
VHT20
5785
14.83
0.00
14.83
29.55
VHT20
5825
14.49
0.00
14.49
29.55
VHT40
5755
12.18
0.00
12.18
29.55
VHT40
5795
12.42
0.00
12.42
29.55
VHT80
5775
5.13
0.19
5.32
29.55
Note:
1. D.F is duty factor.
2. Test result is bin-by-bin summing measured value of each TX port.
3. Directional gain = 0.43+10* log(4/1) = 6.45 dBi
Limit shall be reduced to 30 dBm – (6.45 dBi – 6 dBi) = 29.55 dBm.
Worst Plot
Report No.: FR760801AN
Report Version: Rev. 01
Page : 35 of 96
Beamforming mode
For Frequency band 5725-5850 MHz
Condition
Peak Power Spectral Density (dBm/500kHz)
Modulation
Mode
NTX
Freq.
(MHz)
PPSD
w/o D.F
(dBm/500kHz)
Duty Factor
(dB)
PPSD
with D.F
(dBm/500kHz)
PPSD Limit
(dBm/500kHz)
VHT20
5745
13.28
0.36
13.64
29.55
VHT20
5785
13.41
0.36
13.77
29.55
VHT20
5825
13.03
0.36
13.39
29.55
VHT40
5755
10.27
0.37
10.64
29.55
VHT40
5795
10.39
0.37
10.76
29.55
VHT80
5775
5.13
0.32
5.45
29.55
Note:
1. D.F is duty factor.
2. Test result is bin-by-bin summing measured value of each TX port.
3. Directional gain = 0.43+10* log(4/1) = 6.45 dBi
Limit shall be reduced to 30 dBm – (6.45 dBi – 6 dBi) = 29.55 dBm.
Worst Plot
Note: The plot without duty factor.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 36 of 96
3.5
Transmitter Radiated and Band Edge Emissions
3.5.1
Limit of Transmitter Radiated and Band Edge Emissions
Restricted Band Emissions Limit
Frequency Range (MHz)
Field Strength (uV/m)
Field Strength (dBuV/m)
Measure Distance (m)
0.009~0.490
2400/F(kHz)
48.5 - 13.8
300
0.490~1.705
24000/F(kHz)
33.8 - 23
30
1.705~30.0
30
29
30
30~88
100
40
88~216
150
43.5
216~960
200
46
Above 960
500
54
Note 1:
Qusai-Peak value is measured for frequency below 1GHz except for 9–90 kHz, 110–490 kHz frequency band. Peak and
average value are measured for frequency above 1GHz. The limit on average radio frequency emission is as above
table. The limit on peak radio frequency emissions is 20 dB above the maximum permitted average emission limit
Note 2:
Measurements may be performed at a distance other than what is specified provided. When performing measurements
at a distance other than that specified, the results shall be extrapolated to the specified distance using an extrapolation
factor as below, Frequency at or above 30 MHz: 20 dB/decade Frequency below 30 MHz: 40 dB/decade.
Un-restricted band emissions above 1GHz Limit
Operating Band
Limit
5.15 - 5.25 GHz
e.i.r.p. -27 dBm [68.2 dBuV/[email protected]]
5.725 - 5.850 GHz
15.407(b)(4)(i)
All emissions shall be limited to a level of −27 dBm/MHz at 75 MHz or more
above or below the band edge increasing linearly to 10 dBm/MHz at 25 MHz
above or below the band edge, and from 25 MHz above or below the band
edge increasing linearly to a level of 15.6 dBm/MHz at 5 MHz above or
below the band edge, and from 5 MHz above or below the band edge
increasing linearly to a level of 27 dBm/MHz at the band edge.
15.407(b)(4)(ii) ,compliance with the emission limits in § 15.247(d)
Shall be at least 30dB below that in the 100 kHz bandwidth within the band
that contains the highest level of the desired power,. Attenuation below the
general limits specified in §15.209(a) is not required. In addition,radiated
emissions which fall in the restricted bands, as defined in §15.205(a), must
also comply with the radiated emission limits specified in §15.209(a) (see §
15.205(c))
Note 1: Measurements may be performed at a distance other than the limit distance provided they are not
performed in the near field and the emissions to be measured can be detected by the measurement
equipment. When performing measurements at a distance other than that specified, the results shall
be extrapolated to the specified distance using an extrapolation factor of 20 dB/decade (inverse of
linear distance for field-strength measurements, inverse of linear distance-squared for power-density
measurements).
Report No.: FR760801AN
Report Version: Rev. 01
Page : 37 of 96
3.5.2
Test Procedures
1.
Measurement is made at a semi-anechoic chamber that incorporates a turntable allowing a EUT
rotation of 360°. A continuously-rotating, remotely-controlled turntable is installed at the test site to
support the EUT and facilitate determination of the direction of maximum radiation for each EUT
emission frequency. The EUT is placed at test table. For emissions testing at or below 1 GHz, the table
height is 80 cm above the reference ground plane. For emission measurements above 1 GHz, the table
height is 1.5 m
2.
Measurement is made with the antenna positioned in both the horizontal and vertical planes of
polarization. The measurement antenna is varied in height (1m ~ 4m) above the reference ground plane
to obtain the maximum signal strength. Distance between EUT and antenna is 3 m.
3.
This investigation is performed with the EUT rotated 360°, the antenna height scanned between 1 m
and 4 m, and the antenna rotated to repeat the measurements for both the horizontal and vertical
antenna polarizations.
Note:
1.
120kHz measurement bandwidth of test receiver and Quasi-peak detector is for radiated emission below 1GHz.
2.
RBW=1MHz, VBW=3MHz and Peak detector is for peak measured value of radiated emission above 1GHz.
3.
RBW=1MHz, VBW=1/T and Peak detector is for average measured value of radiated emission above 1GHz.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 38 of 96
3.5.3
Test Setup
Radiated Emissions below 1 GHz
Radiated Emissions above 1 GHz
Report No.: FR760801AN
Report Version: Rev. 01
Page : 39 of 96
Non- beamforming mode
3.5.4
Transmitter Radiated Unwanted Emissions (Below 1GHz)
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 40 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 41 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 42 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 43 of 96
3.5.5
Transmitter Radiated Unwanted Emissions (Above 1GHz) for 11a
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5180
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 44 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5180
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 45 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 46 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 47 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5240
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 48 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5240
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 49 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 50 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 51 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 52 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 53 of 96
Modulation
11a
Polarization
Horizontal
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 54 of 96
Modulation
11a
Polarization
Vertical
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 55 of 96
3.5.6
Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT20
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5180
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 56 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5180
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 57 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 58 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5200
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 59 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5240
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 60 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5240
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 61 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 62 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 63 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 64 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 65 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 66 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 67 of 96
3.5.7
Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT40
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5190
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 68 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5190
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 69 of 96
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5230
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 70 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5230
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 71 of 96
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5755
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 72 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5755
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 73 of 96
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 74 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 75 of 96
3.5.8
Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT80
Modulation
VHT80
Polarization
Horizontal
Test Freq. (MHz)
5210
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 76 of 96
Modulation
VHT80
Polarization
Vertical
Test Freq. (MHz)
5210
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 77 of 96
Modulation
VHT80
Polarization
Horizontal
Test Freq. (MHz)
5775
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 78 of 96
Modulation
VHT80
Polarization
Vertical
Test Freq. (MHz)
5775
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 79 of 96
Beamforming mode
3.5.9
Transmitter Radiated Unwanted Emissions (Below 1GHz)
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 80 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3: All spurious emissions below 30MHz are more than 20 dB below the limit.
Report No.: FR760801AN
Report Version: Rev. 01
Page : 81 of 96
3.5.10 Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT20
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 82 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5745
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 83 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 84 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5785
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 85 of 96
Modulation
VHT20
Polarization
Horizontal
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 86 of 96
Modulation
VHT20
Polarization
Vertical
Test Freq. (MHz)
5825
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 87 of 96
3.5.11 Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT40
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5755
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 88 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5755
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 89 of 96
Modulation
VHT40
Polarization
Horizontal
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 90 of 96
Modulation
VHT40
Polarization
Vertical
Test Freq. (MHz)
5795
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 91 of 96
3.5.12 Transmitter Radiated Unwanted Emissions (Above 1GHz) for VHT80
Modulation
VHT80
Polarization
Horizontal
Test Freq. (MHz)
5775
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 92 of 96
Modulation
VHT80
Polarization
Vertical
Test Freq. (MHz)
5775
Note 1: Emission Level (dBuV/m) = SA Reading (dBuV/m) + Factor* (dB)
*Factor includes antenna factor , cable loss and amplifier gain
Note 2: Margin (dB) = Emission level (dBuV/m) – Limit (dBuV/m).
Note 3:”*” is Peak / Average value of fundamental frequency
Report No.: FR760801AN
Report Version: Rev. 01
Page : 93 of 96
3.6
Frequency Stability
3.6.1
Limit of Frequency Stability
Manufacturers of U-NII devices are responsible for ensuring frequency stability such that an emission is
maintained within the band of operation under all conditions of normal operation as specified in the user’s
manual.
3.6.2
Test Procedures
1.
The EUT is installed in an environment test chamber with external power source.
2.
Set the chamber to operate at 50 centigrade and external power source to output at nominal voltage of
EUT.
3.
A sufficient stabilization period at each temperature is used prior to each frequency measurement.
4.
When temperature is stabled, measure the frequency stability.
5.
The test shall be performed under -30 to 50 centigrade and 85 to 115 percent of the nominal voltage.
Change setting of chamber and external power source to complete all conditions.
3.6.3
Test Setup
Report No.: FR760801AN
Report Version: Rev. 01
Page : 94 of 96
3.6.4
Test Result of Frequency Stability
Frequency:
5200 MHz
Frequency Drift (ppm)
Temperature ( C)
0 minute
2 minutes
5 minutes
10 minutes
T20°CVmax
5.76
5.91
5.55
5.39
T20°CVmin
5.29
5.37
5.65
6.05
T50°CVnom
5.32
6.27
5.31
5.69
T40°CVnom
5.70
5.96
5.73
6.26
T30°CVnom
5.96
6.03
6.07
5.94
T20°CVnom
6.08
5.59
5.43
5.96
T10°CVnom
5.48
5.43
6.28
5.47
T0°CVnom
6.16
5.88
6.03
5.62
T-10°CVnom
6.11
5.46
5.42
5.82
T-20°CVnom
5.49
6.40
6.32
5.73
T-30°CVnom
5.85
6.04
5.69
5.17
Vnom [Vac]: 120
Vmax [Vac]: 138
Vmin [Vac]: 102
Tnom [°C]: 20
Tmax [°C]: 50
Tmin [°C]: -30
Frequency:
5785 MHz
Frequency Drift (ppm)
Temperature ( C)
0 minute
2 minutes
5 minutes
10 minutes
T20°CVmax
5.54
5.53
4.84
4.84
T20°CVmin
5.29
4.74
5.46
5.04
T50°CVnom
5.12
4.86
4.95
5.41
T40°CVnom
4.78
5.62
5.45
5.24
T30°CVnom
5.17
4.67
4.92
4.98
T20°CVnom
4.93
5.16
4.96
5.03
T10°CVnom
5.25
4.80
5.09
5.48
T0°CVnom
5.08
4.96
5.04
5.07
T-10°CVnom
5.03
5.49
5.07
5.32
T-20°CVnom
5.71
5.48
4.52
5.30
T-30°CVnom
5.42
5.36
5.14
4.72
Vnom [Vac]: 120
Vmax [Vac]: 138
Vmin [Vac]: 102
Tnom [°C]: 20
Tmax [°C]: 50
Tmin [°C]: -30
Report No.: FR760801AN
Report Version: Rev. 01
Page : 95 of 96
4
Test laboratory information
Established in 2012, ICC provides foremost EMC & RF Testing and advisory consultation services by our
skilled engineers and technicians. Our services employ a wide variety of advanced edge test equipment and
one of the widest certification extents in the business.
International Certification Corp (EMC and Wireless Communication Laboratory), it is our definitive objective is
to institute long term, trust-based associations with our clients. The expectation we set up with our clients is
based on outstanding service, practical expertise and devotion to a certified value structure. Our passion is to
grant our clients with best EMC / RF services by oriented knowledgeable and accommodating staff.
Our Test sites are located at Linkou District and Kwei Shan District. Location map can be found on our
website http://www.icertifi.com.tw.
Linkou
Kwei Shan
Kwei Shan Site II
Tel: 886-2-2601-1640
Tel: 886-3-271-8666
Tel: 886-3-271-8640
No. 30-2, Ding Fwu Tsuen, Lin
Kou District, New Taipei City,
Taiwan, R.O.C.
No. 3-1, Lane 6, Wen San 3rd St.,
Kwei Shan District, Tao Yuan City
333, Taiwan, R.O.C.
No. 14-1, Lane 19, Wen San 3rd
St., Kwei Shan District, Tao Yuan
City 333, Taiwan, R.O.C.
If you have any suggestion, please feel free to contact us as below information.
Tel: 886-3-271-8666
Fax: 886-3-318-0155
Email: [email protected]
══END══
Report No.: FR760801AN
Report Version: Rev. 01
Page : 96 of 96
Download: WSQ50 Multy X AC3000 Tri-Band WiFi System Test Report _NII ZyXEL Communications Corporation
Mirror Download [FCC.gov]WSQ50 Multy X AC3000 Tri-Band WiFi System Test Report _NII ZyXEL Communications Corporation
Document ID3554894
Application ID5qh/uOxtbtfJd8U73j9m8Q==
Document DescriptionTest Report_NII
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize228.1kB (2851264 bits)
Date Submitted2017-09-11 00:00:00
Date Available2017-09-12 00:00:00
Creation Date2017-09-04 18:21:18
Producing SoftwareMicrosoft® Word 2010
Document Lastmod2017-09-04 18:23:14
Document TitleTest Report_NII
Document CreatorMicrosoft® Word 2010
Document Author: Bunny

Source Exif Data:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : Bunny
Create Date                     : 2017:09:04 18:21:18+08:00
Modify Date                     : 2017:09:04 18:23:14+08:00
Language                        : zh-TW
Tagged PDF                      : Yes
XMP Toolkit                     : Adobe XMP Core 5.4-c005 78.147326, 2012/08/23-13:03:03
Format                          : application/pdf
Creator                         : Bunny
Creator Tool                    : Microsoft® Word 2010
Metadata Date                   : 2017:09:04 18:23:14+08:00
Producer                        : Microsoft® Word 2010
Document ID                     : uuid:865ceb2c-10f7-4535-a615-de94ac8074a6
Instance ID                     : uuid:1379fe0f-7a9b-4885-af3f-c7d424aa32f5
Page Count                      : 96

Facebook Twitter Google+ RSS © FCCID.io 2017
