Report No.: SZEM180200132102
Page:
1 of 15
+86 (0) 755 2601 2053
+86 (0) 755 2671 0594
ee.shenzhen@sgs.com
TEST REPORT
Application No.:
Applicant:
Address of Applicant:
Manufacturer:
SZEM1802001321CR
SCOSCHE Industries Inc.
1550 Pacific Avenue, Oxnard, California, 93033, United States
SCOSCHE Industries Inc.
Address of Manufacturer:
Factory:
Address of Factory:
1550 Pacific Avenue, Oxnard, California, 93033, United States
SCOSCHE Industries Inc.
1550 Pacific Avenue, Oxnard, California, 93033, United States
Equipment Under Test (EUT):
EUT Name:
QI 5W Charging Dock 5000mah
Model No.:
♣
PBQ5DK, PBQ5DKSG-SP, PBQ5DKWT-SP ♣
Please refer to section 2 of this report which indicates which model was
actually tested and which were electrically identical.
FCC ID:
Trade mark:
IKQPBQ5DK
SCOSCHE
Standard(s) :
47 CFR Part 18
Date of Receipt:
2018-02-09
Date of Test:
2018-02-27 to 2018-03-02
Date of Issue:
2018-03-06
Test Result:
Pass*
* In the configuration tested, the EUT complied with the standards specified above.
Keny Xu
EMC Laboratory Manager
The manufacturer should ensure that all products in series production are in conformity with the product sample detailed in this report.
If the product in this report is used in any configuration other than that detailed in the report, the manufacturer must ensure the new
system complies with all relevant standards. Any mention of SGS International Electrical Approvals or testing done by SGS International
Electrical Approvals in connection with, distribution or use of the product described in this report must be approved by SGS International
Electrical Approvals in writing.
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
2 of 15
Revision Record
Version
Chapter
01
Date
2018-03-06
Modifier
Remark
Original
Authorized for issue by:
Peter Geng /Project Engineer
Eric Fu /Reviewer
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
3 of 15
Test Summary
Radio Spectrum Matter Part
Item
Standard
Conducted
disturbance
Radiated emission
Method
Requirement
Result
47 CFR Part 18
FCC MP-5
Part 18.307
Pass
47 CFR Part 18
FCC MP-5
Part 18.305
Pass
Remark:
Model No.: PBQ5DK, PBQ5DKSG-SP, PBQ5DKWT-SP
Only the model PBQ5DK was tested, since the electrical circuit design, layout, components used,
internal wiring and functions were identical for all the above models, with only difference on housing
color.
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
4 of 15
Contents
Page
COVER PAGE ..................................................................................................................................... 1
TEST SUMMARY ................................................................................................................................. 3
CONTENTS ......................................................................................................................................... 4
GENERAL INFORMATION .................................................................................................................. 5
4.1
4.2
4.3
4.4
4.5
4.6
4.7
DETAILS OF E.U.T. ......................................................................................................................... 5
DESCRIPTION OF SUPPORT UNITS .................................................................................................... 5
MEASUREMENT UNCERTAINTY ......................................................................................................... 5
TEST LOCATION ............................................................................................................................. 6
TEST FACILITY ............................................................................................................................... 6
DEVIATION FROM STANDARDS ......................................................................................................... 6
ABNORMALITIES FROM STANDARD CONDITIONS ................................................................................. 6
EQUIPMENT LIST ............................................................................................................................... 7
RADIO SPECTRUM MATTER TEST RESULTS .................................................................................. 8
6.1
CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ) ....................................................... 8
6.1.1 E.U.T. Operation ...................................................................................................................... 8
6.1.2 Test Setup Diagram ................................................................................................................. 8
6.1.3 Measurement Data................................................................................................................... 8
6.2
RADIATED EMISSIONS (MAGNETIC FIELD STRENGTH) (9KHZ-30MHZ) .................................................11
6.2.1 Measurement Data..................................................................................................................11
6.2.2 E.U.T. Operation .....................................................................................................................11
6.2.3 Test Setup Diagram ................................................................................................................11
6.2.4 Measurement Procedure and Data .........................................................................................11
PHOTOGRAPHS ................................................................................................................................15
7.1
7.2
CONDUCTED EMISSIONS AT MAINS TERMINALS (150KHZ-30MHZ) TEST SETUP ...................................15
RADIATED EMISSION TEST SETUP....................................................................................................15
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
5 of 15
General Information
4.1 Details of E.U.T.
Power supply:
Cable:
Operation frequency:
Antenna type:
Modulation type:
Remark:
Input: DC 5V/2A; DC 9V/1.67A from TYPE C port or docking station
Wireless output: 5W, 10W;
USB output: DC 5V, 2.4A
Power supply information,
MODEL: DBS15Q
INPUT: AC 100-240V, 50/60Hz
OUTPUT: DC 5V/2A; DC 9V/2A; DC 12V/1.5A
USB line attached in Docking station: 100cm, unshielded
TYPE C USB charging line: 100cm, unshielded
111.2-183.3kHz
Inductive Loop Coil Antenna
Load modulation
Tests were conducted in both loads and the worst case (DC 9V/1.1A) is
reported only.
4.2 Description of Support Units
Description
Manufacturer
Model No.
Serial No.
mobile phone
Samsung
Galaxy S6 Edge+
N/A
Cement resistor
Supplied by SGS
REF. No.SEA0600
REF. No.SEA0600
4.3 Measurement Uncertainty
No.
Item
Radio Frequency
Duty cycle
Occupied Bandwidth
Measurement Uncertainty
7.25 x 10-8
0.37%
3%
RF conducted power
RF power density
0.75dB
2.84dB
Conducted Spurious emissions
RF Radiated power
Radiated Spurious emission test
10
11
Temperature test
Humidity test
Supply voltages
0.75dB
4.5dB (below 1GHz)
4.8dB (above 1GHz)
4.5dB (Below 1GHz)
4.8dB (Above 1GHz)
1°C
3%
1.5%
12
Time
3%
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
6 of 15
4.4 Test Location
All tests were performed at:
SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen Branch
No. 1 Workshop, M-10, Middle Section, Science & Technology Park, Shenzhen, Guangdong, China.
518057.
Tel: +86 755 2601 2053
Fax: +86 755 2671 0594
No tests were sub-contracted.
4.5 Test Facility
The test facility is recognized, certified, or accredited by the following organizations:
• CNAS (No. CNAS L2929)
CNAS has accredited SGS-CSTC Standards Technical Services Co., Ltd. Shenzhen Branch EMC
Lab to ISO/IEC 17025:2005 General Requirements for the Competence of Testing and Calibration
Laboratories (CNAS-CL01 Accreditation Criteria for the Competence of Testing and Calibration
Laboratories) for the competence in the field of testing.
• A2LA (Certificate No. 3816.01)
SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory is accredited by the
American Association for Laboratory Accreditation(A2LA). Certificate No. 3816.01.
• VCCI
The 3m Fully-anechoic chamber for above 1GHz, 10m Semi-anechoic chamber for below 1GHz,
Shielded Room for Mains Port Conducted Interference Measurement and Telecommunication Port
Conducted Interference Measurement of SGS-CSTC Standards Technical Services Co., Ltd. have
been registered in accordance with the Regulations for Voluntary Control Measures with Registration
No.: G-20026, R-14188, C-12383 and T-11153 respectively.
• FCC –Designation Number: CN1178
SGS-CSTC Standards Technical Services Co., Ltd., Shenzhen EMC Laboratory has been recognized
as an accredited testing laboratory.
Designation Number: CN1178. Test Firm Registration Number: 406779.
• Industry Canada (IC)
Two 3m Semi-anechoic chambers and the 10m Semi-anechoic chamber of SGS-CSTC Standards
Technical Services Co., Ltd. Shenzhen Branch EMC Lab have been registered by Certification and
Engineering Bureau of Industry Canada for radio equipment testing with Registration No.: 4620C-1,
4620C-2, 4620C-3.
4.6 Deviation from Standards
None
4.7 Abnormalities from Standard Conditions
None
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
7 of 15
Equipment List
RE in Chamber
Test Equipment
Manufacturer
Model No.
Inventory No.
Cal. Date (yyyymm-dd)
Cal. Due date
(yyyy-mm-dd)
SEM001-03
2017-05-10
2018-05-09
SEM004-03
2017-04-14
2018-04-13
SEM003-18
2016-06-29
2019-06-28
SEM005-04
2017-06-05
2018-06-04
SEM003-08
2017-08-22
2020-08-21
N/A
N/A
2017-07-13
2018-07-12
10m Semi-Anechoic
FSAC1018
SAEMC
Chamber
EMI Test Receiver
ESR
Rohde & Schwarz
(9k-7GHz)
Trilog-Broadband
Antenna
VULB9168
Schwarzbeck
(30M-1GHz)
Pre-amplifier
Sonoma Instrument
310N
Co
(9kHz-1GHz)
Loop Antenna
6502
ETS-Lindgren
(9kHz-30MHz)
Measurement
e3 V8.2014-6AUDIX
Software
27
Coaxial Cable
SGS
N/A
N/A
SEM029-01
General used equipment
Equipment
Manufacturer
Model No
Inventory No
Cal Date
Cal Due Date
Humidity/ Temperature
Indicator
Shanghai
Meteorological
Industry Factory
ZJ1-2B
SEM002-03
2017-09-29
2018-09-28
Humidity/ Temperature
Indicator
Shanghai
Meteorological
Industry Factory
ZJ1-2B
SEM002-04
2017-09-29
2018-09-28
Humidity/ Temperature
Indicator
Mingle
N/A
SEM002-08
2017-09-29
2018-09-28
Barometer
Changchun
Meteorological
Industry Factory
DYM3
SEM002-01
2017-04-18
2018-04-17
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
8 of 15
Radio Spectrum Matter Test Results
6.1 Conducted Emissions at Mains Terminals (150kHz-30MHz)
Test Requirement:
47 CFR Part 18
Test Method:
FCC OST/MP-5:1986
Frequency Range:
150kHz to 30MHz
6.1.1 E.U.T. Operation
Operating Environment:
Temperature:
17.9 °C
Humidity: 46.6 % RH
Test mode
a:Charge mode_Keep the EUT charging
Atmospheric Pressure: 1015
mbar
6.1.2 Test Setup Diagram
6.1.3 Measurement Data
An initial pre-scan was performed with peak detector.Quasi-Peak or Average measurement were
performed at the frequencies with maximized peak emission were detected.
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
9 of 15
Mode:a; Line:Live Line
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
10 of 15
Mode:a; Line:Neutral Line
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
11 of 15
6.2 Radiated Emissions (Magnetic field Strength) (9kHz-30MHz)
Test Requirement:
47 CFR Part 18
Test Method:
FCC OST/MP-5:1986
Frequency Range:
9kHz to 30MHz
Measurement Distance: 10m
6.2.1 Measurement Data
An initial pre-scan was performed in the chamber using the spectrum analyser in peak detection
mode. Quasi-peak measurements were conducted based on the peak sweep graph. The EUT was
measured by BiConiLog antenna with 2 orthogonal polarities.
6.2.2 E.U.T. Operation
Operating Environment:
Temperature:
23 °C
Humidity: 54 % RH
Test mode
a:Charge mode_Keep the EUT charging
Atmospheric Pressure: 1015
mbar
6.2.3 Test Setup Diagram
6.2.4 Measurement Procedure and Data
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
12 of 15
Model:a
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
13 of 15
Model:a
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
14 of 15
The test was performed at a 10m test site. According to below formulate and the test data at 10m test
distance,
L300 / L10 = D10 / D300
Note:
L300: Level @ 300m distance. Unit: uV/m;
L10: Level @ 10m distance. Unit: uV/m;
D300: 300m distance. Unit: m
D10: 10m distance. Unit: m
The level at 300m test distance is below:
Frequency
(MHz)
0.01
0.02
0.03
0.06
0.09
0.12
0.19
0.52
1.43
3.24
10.40
19.53
Level @
10m
(dBuV/m)
31.52
32.25
33.83
34.07
34.83
36.58
25.11
28.51
20.19
15.97
13.62
13.94
Level @
10m (uV/m)
37.67
40.97
49.15
50.52
55.14
67.45
18.01
26.64
10.22
6.29
4.80
4.98
Level @
300m
(uV/m)
1.26
1.37
1.64
1.68
1.84
2.25
0.60
0.89
0.34
0.21
0.16
0.17
Level @
300m
(dBuV/m)
1.98
2.71
4.29
4.53
5.29
7.04
-4.43
-1.03
-9.35
-13.57
-15.92
-15.60
Limit @
300m
(dBuV/m)
23.52
23.52
23.52
23.52
23.52
23.52
23.52
23.52
23.52
23.52
23.52
23.52
Margin (dB)
-21.54
-20.81
-19.23
-18.99
-18.23
-16.48
-27.95
-24.55
-32.87
-37.09
-39.44
-39.12
This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
SGS-CSTC Standards Technical Services Co., Ltd.
Shenzhen Branch
Report No.: SZEM180200132102
Page:
15 of 15
Photographs
7.1 Conducted Emissions at Mains Terminals (150kHz-30MHz) Test Setup
7.2 Radiated emission Test Setup
- End of the Report This document is issued by the Company subject to its General Conditions of Service printed overleaf, available on request or accessible at http://www.sgs.com/en/Terms-and-Conditions.aspx and, for
electronic format documents, subject to Terms and Conditions for Electronic Documents at http://www.sgs.com/en/Terms-and-Conditions/Terms-e-Document.aspx. Attention is drawn to the limitation of
liability, indemnification and jurisdiction issues defined therein. Any holder of this document is advised that information contained hereon reflects the Company’s findings at the time of its intervention
only and within the limits of Client’s instructions, if any. The Company’s sole responsibility is to its Client and this document does not exonerate parties to a transaction from exercising all their rights and
obligations under the transaction documents. This document cannot be reproduced except in full, without prior written approval of the Company. Any unauthorized alteration, forgery or falsification of the
content or appearance of this document is unlawful and offenders may be prosecuted to the fullest extent of the law. Unless otherwise stated the results shown in this test report refer only to the sample(s)
tested and such sample(s) are retained for 30 days only.
Download: PBQ5DK QI 5W Charging Dock 5000mah Test Report SZEM180200132102  RPT Scosche Industries Inc
Mirror Download [FCC.gov]PBQ5DK QI 5W Charging Dock 5000mah Test Report SZEM180200132102  RPT Scosche Industries Inc
Document ID3843827
Application IDxrHHEHg/umGDpCaBmAMrOQ==
Document DescriptionTest Report
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize100.77kB (1259601 bits)
Date Submitted2018-05-08 00:00:00
Date Available2018-05-08 00:00:00
Creation Date2018-04-12 15:47:42
Producing SoftwareGPL Ghostscript 8.64
Document Lastmod2018-04-12 07:47:44
Document TitleSZEM180200132102 RPT
Document CreatorPScript5.dll Version 5.2.2
Document Author: kate_bian

Source Exif Data:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.3
Linearized                      : No
Encryption                      : Standard V2.3 (128-bit)
User Access                     : Print, Print high-res
Page Count                      : 15
Create Date                     : 2018:04:12 15:47:42+08:00
Title                           : Microsoft Word - SZEM180200132102  RPT.doc
Producer                        : GPL Ghostscript 8.64
Author                          : kate_bian
Creator                         : PScript5.dll Version 5.2.2
Modify Date                     : 2018:04:12 07:47:44Z
EXIF Metadata provided by EXIF.tools

Facebook Twitter Google+ RSS © FCCID.io 2018
