IR868LC1 Wireless AC1750 Dual Band Gigabit... - FCC ID KA2IR868LC1

FCC ID KA2IR868LC1

Test Setup Photo.pdf

Wireless AC1750 Dual Band Gigabit Cloud Router USB 3.0

by D-Link Corporation

Document preview loads when visible.

Document Details

FCC IDKA2IR868LC1
Document ID2624483
Document TypeTest Setup Photos
DescriptionTest Setup Photo.pdf
Document Title1
ApplicantD-Link Corporation
Equipment ClassWireless AC1750 Dual Band Gigabit Cloud Router USB 3.0
Product CodeIR868LC1
Application ID1Gztwi6T9bZEAErbSe+SNg==
Application PurposeOriginal Equipment
Application Date2015-05-26
Frequency Range2412-2462 MHz
FRN0007371172
Test FirmBureau Veritas CPS (H.K.) Ltd., Taoyuan Branch
Certified ByMichael Boschma
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2015-05-26
Available2015-05-26
Created2015-05-14
Modified2015-05-14
Pages6
File TypeAdobe Acrobat PDF
File Size664358
File SHA-256b26a0e3518b8d4eab394e07d5cd37b4e65891cfae0b2e9fb3255658c316d33bd
PDF Metadata AuthorJim
PDF Metadata ProducerJim Microsoft® Office Word 2007
FCC.gov SourcesFCC.gov 2624483, FCC.gov 2624544
