MX3FG 2.4G Radio Transmitter Teardown... - FCC ID L73MX-3FG

FCC ID L73MX-3FG

Internal Photos

2.4G Radio Transmitter

by Sanwa Electronic Instrument Co Ltd

Document preview loads when visible.

Document Details

FCC IDL73MX-3FG
Document ID1012295
Document TypeInternal Photos
DescriptionInternal Photos
Document TitleFCC+IC
ApplicantSanwa Electronic Instrument Co Ltd
Equipment Class2.4G Radio Transmitter
Product CodeMX3FG
Application IDzVvO32mubxA+nLc7WwfUbQ==
Application PurposeOriginal Equipment
Application Date2008-10-07
Frequency Range2415-2465 MHz
FRN0009195744
Test FirmShenzhen Huatongwei International Insp. Co., Ltd
Certified ByYoshiki Ito Engineering Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2008-10-07
Available2008-10-07
Created2008-10-07
Modified2008-10-07
Pages2
File TypeAdobe Acrobat PDF
File Size144693
File SHA-2564e5787b8c3aa8099f0df0a15ffcccfa0f2a66eadeb6c5dbdd2f888240dd1d3b2
PDF Metadata Authoradum1
PDF Metadata CreatorPScript5.dll Version 5.2.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1012295
