DVRSVHF MOBEXCOM DVRS Vehicular Repeater... - FCC ID LO6-DVRSVHF

FCC ID LO6-DVRSVHF

System Configuration

MOBEXCOM DVRS Vehicular Repeater

by Futurecom Systems Group ULC.

Document preview loads when visible.

Document Details

FCC IDLO6-DVRSVHF
Document ID3441295
Document TypeExternal Photos
DescriptionSystem Configuration
ApplicantFuturecom Systems Group ULC.
Equipment ClassMOBEXCOM DVRS Vehicular Repeater
Product CodeDVRSVHF
Application ID9fo789mz7ZyZTOeh6datZw==
Application PurposeClass II Permissive Change
Application Date2018-04-03
Frequency Range136-174 MHz
FRN0009192436
Test FirmUltraTech Engineering Labs Inc
Certified ByDan Huynh Authorized Agent
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2017-06-27
Available2018-04-03
Created2017-05-04
Modified2017-06-22
Pages1
File TypeAdobe Acrobat PDF
File Size106411
File SHA-2567833bfe0a5ab41e6bb9666f40ee1f02ed456eb93f879394fc7bde97cc00a6a96
PDF Metadata Authorfr Motorola
PDF Metadata Producerfr Adobe PDF Library 10.0
FCC.gov SourcesFCC.gov 3441295
