R80 Pulsar Model R80 Label Diagram - FCC ID LPN-R80

FCC ID LPN-R80

R80 ID Label and Location

Pulsar Model R80

by AMETEK Magnetrol USA, LLC

Document preview loads when visible.

Document Details

FCC IDLPN-R80
Document ID5630699
Document TypeID Label/Location Info
DescriptionR80 ID Label and Location
ApplicantAMETEK Magnetrol USA, LLC
Equipment ClassPulsar Model R80
Product CodeR80
Application IDI+N+Yt3BglyFfkTBkq1ZJA==
Application PurposeOriginal Equipment
Application Date2022-01-12
Frequency Range79000 MHz
FRN0007112394
Test FirmRhein Tech Laboratories, Inc.
Certified ByKathy Grzovic EMC Regulatory Assistant
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date07/11/2022
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2022-01-12
Available2022-01-12
Created2021-10-04
Modified2021-10-04
Pages1
File TypeAdobe Acrobat PDF
File Size142342
File SHA-256e9ff23e87f77b80a87f2c8fb62816258b4f0c67588510fac7b6b2f47bfbceceb
PDF Metadata AuthorKathy Grzovic RTL
PDF Metadata ProducerKathy Grzovic Adobe PDF Library 21.7.127
FCC.gov SourcesFCC.gov 5630699
