TT2400 802.11b/g wLAN AP Test Setup Photos - FCC ID MFMTT-2400

FCC ID MFMTT-2400

Test Setup Photos

802.11b/g wLAN AP

by Teletronics International Inc

Document preview loads when visible.

Document Details

FCC IDMFMTT-2400
Document ID668315
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title60509208-RP1
ApplicantTeletronics International Inc
Equipment Class802.11b/g wLAN AP
Product CodeTT2400
Application IDWYFIsjDAybe3uj776cT13g==
Application PurposeOriginal Equipment
Application Date2006-06-06
Frequency Range2412-2462 MHz
FRN0007415805
Test FirmCompliance Certification Services Inc.
Certified ByAntony Yao
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2006-06-13
Available2006-06-06
Created2006-06-02
Modified2006-06-02
Pages3
File TypeAdobe Acrobat PDF
File Size408537
File SHA-25687c76f42dbdc97e4433d3bef989abceee8e9167bb7f00d31bd25e9bb92ff5d63
PDF Metadata Authorgina_lo
PDF Metadata ProducerPScript5.dll Version 5.2 Acrobat Distiller 5.0 (Windows)
FCC.gov SourcesFCC.gov 668315
