Calibration Laboratory of
Schmid & Partner
Schweizerischer Kalibrierdienst
Service suisse d'etalonnage
Servizio svizzero di taratura
Zeughausstrasse 43, 8004 Zurich, Switzerland
Accredited by the Swiss Accreditation Service (SAS)
Accreditation No.:
Engineering AG
Swiss Calibration Service
SCS 0108
The Swiss Accreditation Service is one of the signatories to the EA
Multilateral Agreement for the recognition of calibration certificates
Client
Sporton (Auden)
Certificate No:
EX3-3976_Jan18
CALIBRATION CERTIFICATE
Object
EX3DV4 - SN:3976
Calibration procedure(s)
QA CAL-01 .v9, QA CAL-14.v4, QA CAL-23.vS, QA CAL-25.v6
Calibration procedure for dosimetric E-field probes
Calibration date:
January 23, 2018
This calibration certificate documents the traceability to national standards, which realize the physical units of measurements (S I).
The measurements and the uncertainties with confidence probability are given on the following pages and are part of the certificate.
All calibrations have been conducted in the closed laboratory facility: environment temperature (22 ± 3)°C and humidity< 70%.
Calibration Equipment used (M&TE critical for calibration)
Primary Standards
ID
Cal Date (Certificate No.)
Power meter NRP
SN: 104778
04-Apr-17 (No. 217-02521/ 02522)
Scheduled Calibration
Apr-18
Power sensor NRP-Z91
SN : 103244
04-Apr-17 (No. 217-02521)
Apr-18
Power sensor NRP-Z91
SN: 103245
04-Apr-17 (No. 217-02525)
Apr-18
Reference 20 dB Attenuator
SN : S5277 (20x)
07-Apr-17 (No. 217-02528)
Apr-18
Reference Probe ES3DV2
SN : 3013
30-Dec-17 (No. ES3-3013 Dec17)
Dec-18
DAE4
SN : 660
21-Dec-17 (No. DAE4-660 Dec17)
Dec-18
Secondary Standards
ID
Check Date (in house)
Scheduled Check
Power meter E44198
SN: GB41293874
06-Apr-16 (in house check Jun-16)
In house check: Jun-18
PowersensorE4412A
SN : MY41498087
06-Apr-16 (in house check Jun-16)
In house check: Jun-18
PowersensorE4412A
SN : 000110210
06-Apr-16 (in house check Jun- 16)
In house check: Jun-18
RF generator HP 8648C
SN: US3642U01 700
04-Aug-99 (in house check Jun-16)
In house check: Jun-18
Network Analyzer HP 8753E
SN: US37390585
18-0ct-01 (in house check Oct-17)
In house check: Oct-18
Name
Function
Calibrated by:
Michael Weber
Laboratory Technician
Approved by:
Katja Pokovic
Technical Manager
___Ji!cs:____
-~~~~Issued: January 25, 2018
This calibration certificate shall not be reproduced except in full without written approval of the laboratory.
Certificate No: EX3-3976_Jan18
Page 1 of 11
Calibration Laboratory of
Schmid & Partner
Engineering AG
Zeughausstrasse 43, 8004 Zurich, Switzerland
Accredited by the Swiss Accreditation Service (SAS)
The Swiss Accreditation Service is one of the signatories to the EA
Schweizerischer Kalibrierdienst
Service suisse d'etalonnage
Servizio svizzero di taratura
Swiss Calibration Service
Accreditation No.:
SCS 0108
Multilateral Agreement for the recognition of calibration certificates
Glossary:
TSL
NORMx,y,z
ConvF
DCP
CF
A,B,C, D
Polarization cp
Polarization S
Connector Angle
tissue simulating liquid
sensitivity in free space
sensitivity in TSL / NORMx,y,z
diode compression point
crest factor (1/duty_cycle) of the RF signal
modulation dependent linearization parameters
cp rotation around probe axis
S rotation around an axis that is in the plane normal to probe axis (at measurement center),
i.e., S = 0 is normal to probe axis
information used in DASY system to align probe sensor X to the robot coordinate system
Calibration is Performed According to the Following Standards:
a)
IEEE Std 1528-2013, "IEEE Recommended Practice for Determining the Peak Spatial-Averaged Specific
Absorption Rate (SAR) in the Human Head from Wireless Communications Devices: Measurement
Techniques", June 2013
b) IEC 62209-1 , ", "Measurement procedure for the assessment of Specific Absorption Rate (SAR) from handheld and body-mounted devices used next to the ear (frequency range of 300 MHz to 6 GHz)", July 2016
c) IEC 62209-2, "Procedure to determine the Specific Absorption Rate (SAR) for wireless communication devices
used in close proximity to the human body (frequency range of 30 MHz to 6 GHz)", March 2010
d) KDB 865664, "SAR Measurement Requirements for 100 MHz to 6 GHz"
Methods Applied and Interpretation of Parameters:
•
•
•
•
•
•
•
•
•
NORMx,y,z: Assessed for E-field polarization S = 0 (f ~ 900 MHz in TEM-cell; f > 1800 MHz: R22 waveguide).
NORMx,y,z are only intermediate values, i.e. , the uncertainties of NORMx,y,z does not affect the E2-field
uncertainty inside TSL (see below ConvF).
NORM(f)x,y,z = NORMx,y,z * frequency_response (see Frequency Response Chart). This linearization is
implemented in DASY4 software versions later than 4.2. The uncertainty of the frequency response is included
in the stated uncertainty of ConvF.
DCPx,y,z: DCP are numerical linearization parameters assessed based on the data of power sweep with CW
signal (no uncertainty required). DCP does not depend on frequency nor media.
PAR: PAR is the Peak to Average Ratio that is not calibrated but determined based on the signal
characteristics
Ax,y,z; Bx,y,z; Cx,y,z; Dx,y,z; VRx,y,z: A, B, C, Dare numerical linearization parameters assessed based on
the data of power sweep for specific modulation signal. The parameters do not depend on frequency nor
media. VR is the maximum calibration range expressed in RMS voltage across the diode.
ConvF and Boundary Effect Parameters: Assessed in flat phantom using E-field (or Temperature Transfer
Standard for f ~ 800 MHz) and inside waveguide using analytical field distributions based on power
measurements for f > 800 MHz. The same setups are used for assessment of the parameters applied for
boundary compensation (alpha, depth) of which typical uncertainty values are given. These parameters are
used in DASY4 software to improve probe accuracy close to the boundary. The sensitivity in TSL corresponds
to NORMx,y,z * ConvF whereby the uncertainty corresponds to that given for ConvF. A frequency dependent
ConvF is used in DASY version 4 .4 and higher which allows extending the validity from ± 50 MHz to± 100
MHz.
Spherical isotropy (30 deviation from isotropy): in a field of low gradients realized using a flat phantom
exposed by a patch antenna.
Sensor Offset: The sensor offset corresponds to the offset of virtual measurement center from the probe tip
(on probe axis). No tolerance required.
Connector Angle: The angle is assessed using the information gained by determining the NORMx (no
uncertainty required).
Certificate No: EX3-3976_Jan18
Page 2 of 11
EX3DV4 - SN:3976
January 23, 2018
Probe EX3DV4
SN:3976
Manufactured:
Calibrated:
November 5, 2013
January 23, 2018
Calibrated for DASY/EASY Systems
(Note: non-compatible with DASY2 system!)
Certificate No: EX3-3976_Jan18
Page 3 of 11
EX3DV4- SN:3976
January 23, 2018
DASY/EASY - Parameters of Probe: EX3DV4 - SN:3976
Basic Calibration Parameters
Norm (uV/(V/m)T
DCP (mvi-
SensorX
SensorY
SensorZ
Unc (k=2)
0.48
101.2
0.50
99.0
0.54
102.1
+ 10.1 %
Modulation Calibration Parameters
UID
Communication System Name
cw
dB
dByµV
0.0
0.0
0.0
0.0
0.0
0.0
1.0
1.0
1.0
dB
0.00
VR
mV
Uncc
(k=2)
148.0
139.7
159.8
±3.0 %
The reported uncertainty of measurement is stated as the standard uncertainty of measurement
multiplied by the coverage factor k=2, which for a normal distribution corresponds to a coverage
probability of approximately 95%.
The uncertainties of Norm X,Y,Z do not affect the E 2-fie!d uncertainty inside TSL (see Pages 5 and 6).
Numerical linearization parameter: uncertainty not required.
E Uncertainty is determined using the max. deviation from linear response_applying rectangular distribution and is expressed for the square of the
field value.
Certificate No: EX3-3976_Jan18
Page 4 of 11
EX3DV4- SN:3976
January 23, 2018
DASY/EASY - Parameters of Probe: EX3DV4 - SN:3976
Calibration Parameter Determined in Head Tissue Simulating Media
f CMHz\ c
Relative
Permittivitv F
Conductivity
CS/ml F
ConvF X
ConvF Y
ConvF Z
AlphaG
Depth"
Cmml
Unc
(k=2)
750
41.9
0.89
10.74
10.74
10.74
0.40
0.85
+ 12.0 %
835
41.5
0.90
10.19
10.19
10.19
0.44
0.80
+ 12.0 %
900
41.5
0.97
10.03
10.03
10.03
0.51
0.80
+ 12.0 %
1750
40.1
1.37
8.99
8.99
8.99
0.39
0.86
+ 12.0 %
1900
40.0
1.40
8.71
8.71
8.71
0.37
0.84
+ 12.0 %
2000
40.0
1.40
8.59
8.59
8.59
0.39
0.80
+ 12.0 %
2450
39.2
1.80
7.75
7.75
7.75
0.34
0.89
+ 12.0 %
2600
39.0
1.96
7.54
7.54
7.54
0.33
0.89
± 12.0 %
3700
37.7
3.12
7.66
7.66
7.66
0.25
1.25
± 13.1 %
5250
35.9
4.71
5.56
5.56
5.56
0.35
1.80
+ 13.1 %
5600
35.5
5.07
4.97
4.97
4.97
0.40
1.80
± 13.1 %
5750
35.4
5.22
5.04
5.04
5.04
0.40
1.80
+ 13.1 %
c Frequency validity above 300 MHz of± 100 MHz only applies for DASYv4.4 and higher (see Page 2), else it is restricted to± 50 MHz. The
uncertainty is the RSS of the ConvF uncertainty at calibration frequency and the uncertainty for the indicated frequency band. Frequency validity
below 300 MHz is± 10, 25, 40, 50 and 70 MHz for ConvF assessments at 30, 64, 128, 150 and 220 MHz respectively. Above 5 GHz frequency
validity can be extended to± 110 MHz.
F At frequencies below 3 GHz, the validity of tissue parameters (r. and er) can be relaxed to± 10% if liquid compensation formula is applied to
measured SAR values. At frequencies above 3 GHz, the validity of tissue parameters (e and u) is restricted to± 5%. The uncertainty is the RSS of
the ConvF uncertainty for indicated target tissue parameters.
G Alpha/Depth are determined during calibration. SPEAG warrants that the remaining deviation due to the boundary effect after compensation is
always less than± 1% for frequencies below 3 GHz and below± 2% for frequencies between 3~6 GHz at any distance larger than half the probe tip
diameter from the boundary,
Certificate No: EX3-3976_Jan18
Page 5 of 11
EX3DV4- SN:3976
January 23, 2018
DASY/EASY - Parameters of Probe: EX3DV4 - SN:3976
Calibration Parameter Determined in Body Tissue Simulating Media
Relative
Permittivitv F
Conductivity
f/MHzlc
IS/ml•
ConvF X
ConvFY
ConvF Z
Alpha"
Depth"
lmml
Unc
(k=2)
750
55.5
0.96
10.37
10.37
10.37
0.38
0.92
+ 12.0 %
835
55.2
0.97
10.08
10.08
10.08
0.50
0.80
± 12.0 %
1750
53.4
1.49
8.36
8.36
8.36
0.44
0.80
+ 12.0 %
1900
53.3
1.52
8.09
8.09
8.09
0.37
0.84
+ 12.0 %
2450
52.7
1.95
7.80
7.80
7.80
0.35
0.88
+ 12.0 %
2600
52.5
2.16
7.37
7.37
7.37
0.32
1.01
+ 12.0 %
3700
51.0
3.55
6.80
6.80
6.80
0.25
1.20
± 13.1 %
5250
48.9
5.36
4.92
4.92
4.92
0.35
1.90
+ 13.1 %
5600
48.5
5.77
4.28
4.28
4.28
0.40
1.90
+ 13.1 %
5750
48.3
5.94
4.46
4.46
4.46
0.40
1.90
+ 13.1 %
c Frequency validity above 300 MHz of± 100 MHz only applies for DASY v4.4 and higher (see Page 2), else it is restricted to± 50 MHz. The
uncertainty is the RSS of the ConvF uncertainty at calibration frequency and the uncertainty for the indicated frequency band. Frequency validity
below 300 MHz is± 10, 25, 40, 50 and 70 MHz for ConvF assessments at 30, 64, 128, 150 and 220 MHz respectively. Above 5 GHz frequency
validity can be extended to ± 110 MHz.
F At frequencies below 3 GHz, the validity of tissue parameters (e and cr) can be relaxed to± 10% If liquid compensation fonnula is applied to
measured SAR values. At frequencies above 3 GHz, the validity of tissue parameters (c and cr) is restricted to± 5%. The uncertainty is the RSS of
the ConvF uncertainty for indicated target tissue parameters.
G Alpha/Depth are determined during calibration. SPEAG warrants that the remaining deviation due to the boundary effect after compensation is
always less than± 1% for frequencies below 3 GHz and below± 2% for frequencies between 3~6 GHz at any distance larger than half the probe tip
diameter from the boundary.
Certificate No: EX3-3976_Jan18
Page6of11
EX3DV4- SN:3976
January 23, 2018
Frequency Response of E-Field
(TEM-Cell:ifi110 EXX, Waveguide: R22)
1.5
-·.
... .
.. --- ... ---- . -- ...... --........
...
...
..
-............
--~
......................
.............................
--...
---......
-~
.......
---..
----............
-.
-----.....
........
,......_ 1.3
. .
-0
(I)
.'
.'
..
-~ 1.2 ... .. ...........................................................................
... ............ ... ............ .... ..... .... ................ ......... .....
J
I JG
4G
. .. .
, ~r
·J~.
04
OG
00
...,. .
·o~
•, .. .
1RC
o,
or,
08
•
:"s
315
•X
Tot
0.5
Jj
•y
•X
Tot
~:o
•z
•y
...
''
..
-0 .5 - -- . -. ---- .. ..+---- . - . ---- . - . -- - ---~-.. - -- -.. -- --. - . ----. - -~.' - -- . -.... ---.... - -- . ~..' -- -- . -.. --- . - . -- --
.'
---~--r.-: ~~~. .~~-,·~~r*=.~. .
0.0
•z
3 15
---·------·-i------------------·-1-- ----·-----------·-·r·--·-·-·-·--·-·----·1·------·---- --·---- -·r--------------------~ ------------------ --1------·----.'
:?"'.)
225
''
~ -'!::
:~*'
.'
......·--- .. . -- -- . -. ----. -....----.. ----- ....... -. ~.'-...........
''
''
''
-1 50
- 100
•
100 MHz
. 0
50
100
[!]
...!J
600 MHz
1800 MHz
Uncertainty of Axial Isotropy Assessment: ± 0.5% (k=2)
Certificate No: EX3-3976_Jan18
150
RoD [j
Page 8 of 11
...!J
2500 MHz
EX3DV4- SN:3976
January 23, 201 8
Dynamic Range f(SARhead)
(TEM cell,
feva1=
1900 MHz)
:~-..... :... ' .... '.: ·:·~: ..... ··:·. ··:.. ·:· ·:·:·: :·:·:·.... ··:·.. ·:·· :·:·:·:::
... ... ... . .. :. :·.·:·.::....... .. ·: . ·:··: ·:· :·:·:·:·. - --- ·:· - -~- ··:··:· ·:·: :
- --.. i···i ··t·i· t -:· H i····· + •+•~•H+ l·>~· -• •••:••••:• +.:•·M ~H-• .. ••t•··•·-t·H-HH······~---i.--:--t-:-H-:-}-- --:---~-- ~-..:-HH
..••. ; . .•; .. ; .;.; .;.;. ; ; •..•.. ; ...; .. ;.. ;. .; .; .;.;.;. ..... ...-...:--~--:-;-H.;;...... ; ... , .• ;.;.;-;..;.;; . ....•;. . .. ;. ••;.. ;.;.;.;y;. . . . . ; ... . ; .• .; • ..;.;.;;;
!·~ !~
·---·· 1-··I--~·I·t)t~----··f···t··i-- I-1-~1t··-··- (·1·· 1-~- 1--····1·--~- ·t· 1-~ ( \!·· ··--:----~- -i--~~-t(\ -·---~---~--1--1-1?1
: : : ; ; :::: ; : : ; : :::: ; : ; : : :::: : ; : : : :::: : : : : ' ; ::: . : : : : : :::
I : : :: ::j: : , . : i ::i i : , i:::: : . ' , ,1:t: , : i :: ::i
; ; : :: ::
: : :::::: : : ' ::: ::: : : : :::::: : : ;.::: :: : : : :::::
•• ·
~- · l · l ·t ·:·t: \· · · t · · · ~· ·1"· t ·~ : -:·~~····· -:- -· -:- --1- .-:- ! · l ~H -·--·· : -· · l ··! · H 7~ !l · •· · ·-~ · t ·-' -~·:·: -17} · ·· · · ~- ·- ~-- :·--:· : ·~ ::
uuu :--<.. :-:-:-:-:::--····:...:--:-:·: :~·:'.-····: ·- :·· ·..: :< :::-····<··-:··:- :-r :-: ::·•u•:.. -: -:--:-:·!:::.....:---:--:--:<<::
: I
10 5
:····· ;
·· ; ··;. ;
·; ;
· ;
• • • · · ·;
- · ·;
· ·~- · ; ; ; ; ; :·
·- •
• • ;· ·
·
;·· ;· ;· ;·; ; ;
;·· •••• ;
•• ·
;·.;.; · ;
· ;
; ~ --
· - ' :· · · ·;
~ - ·; ;· ;
; ; · ~- - . h . ; · · . ; · · ;
·
;·; · ;;;
104
: :,
C.
C:
103
• -•• • {· • •~ -• t • ~ •! -:-11I····· -1• • -~• -:- - t ·i- t -:·H·· • •• - -:- · • -,· --:- -:- -:- ~ ~ H · · • · • · { ··· I • • l • 1· l -:- ~ t I·····-:- ···} ·-:-- ~-:- 1H -( • • - · · ~-• · {· · (· -:· i · }ii
:~;~ ~ i~~ i~ : ~ i~lJ'.lii:~~~::[: ~: : :.::~: ::::~::~;]::~1:;J:j:J:l11r~~~:~ : ~~;~ ; ~ :~••-• ••~~:J_~:~;~ •1.
t.
: : : : : :: ::
: : : :: : :
: :
1·111\\I l
10
: : :: :::
: : : : :::
lj 1lllll1
..... j_. _j .. L~.:l~ i~ --.... L
: : : : :: ::
: : : : :::
.t. :.J. .......
':
: :::: : :
. ... ....
·1:!Hl
r: :. 1.. 1.
1..
t. .t
: :::::
1/lfll
:. .-~.;-~ : ~-~~ ..... l. .l..i. l l.i1 i~-.----~-.. ;.. ;. ~-~ .:- ~;~ ......:. ... ;-~-- ~ .!. i~ll.-... ~-..~-. j.J.Ui1
··-··r·:··:rn:·--·--:~-rnrm:-····-r+nn:;r-···rr:-:-:r::····-·:···-:--nr1r-··-r·-rrr::
-----1---1- 1-r-~ r--·· --r---~ -·r-1-r 1-Hr ---- --i----:--1·-1-1-r111" --- --1---~--t -1-r-i-r tt ------r ---r--;--r-i- r1-;-r-----1- -- 1--1--i- ~ -~ 11
·t·
····· .··· . ··.·,-,•,•,,,••••• •,• ••,••, •,•,, :
10-3
10-2
.. ····· .···.·· .·-:- ,•, ,,,······.···.··.·.·.....······.···,·-.·.-.,, ,, ·····.-·· .··.·.-.-...
10-1
100
SAR [mW/cm3]
102
101
103
[I]
...!..J
not compensated
compensated
:!:!.
....
...2
UJ
-1
-2
10·3
10-2
10-1
1 oo
SAR [mW/cm3)
101
102
[!]
not compensated
compensated
Uncertainty of Linearity Assessment: ± 0.6% (k=2)
Certificate No: EX3-3976_Jan18
Page 9 of 11
103
EX3DV4- SN :3976
January 23, 2018
Conversion Factor Assessment
f = 835 MHz.WGLS R9 (H_convF)
f = 1900 MHz,WGLS R22 (H_convF)
.!5 .
30
,"
:0
- 0
5·
05
...
00
';
,o
25
z (inmJ
30
0 ..
•o
~')
·o
lfJ
F,
z [ow,:
•
•
measureo
a nat)1.cal
rneasved
Deviation from Isotropy in Liquid
Error(, ~). f = 900 MHz
1.0
0.8
0.6
c:: 0.4
~ 0.2
0.0
o -0.2
·i
·1 .0
· 0.8
-0.6
·0.4
-0.2
0.0
0 .2
0.4
0.6
0.8
1.0
Uncertainty of Spherical Isotropy Assessment: ± 2.6% (k=2)
Certificate No: EX3-3976_Jan18
30
Page 10 of 11
3fJ
40
January 23, 2018
EX3DV4- SN:3976
DASY/EASY - Parameters of Probe: EX3DV4 - SN:3976
Other Probe Parameters
Sensor Arrangement
Triangular
-0.5
Connector Angle (')
Mechanical Surface Detection Mode
enabled
Optical Surface Detection Mode
disabled
Probe Overall Length
337mm
Probe Body Diameter
10 mm
9mm
Tip Length
Tip Diameter
2.5mm
Probe Tip to Sensor X Calibration Point
1 mm
Probe Tip to Sensor Y Calibration Point
1 mm
Probe Tip to Sensor Z Calibration Point
1 mm
Recommended Measurement Distance from Surface
Certificate No: EX3-3976_Jan18
Page 11 of 11
1.4 mm
......-.......
~ ~
In Collaboration with
- TTL s
CALIBRATION LABORATORY
Add: No.S I Xueyuan Road, Haidian District, Beij ing, 100 19 1, China
Tel: +86-1 0-623 04633 -22 18
Fax: +86- 10-62304633-2209
E-mai l: cttl@chinattl.com
Http://www.chinattl.cn
Certificate No: 217-97143
Sporton
Client
CALIBRATION CERTIFICATE
Object
ES3DV3 - SN:3270
Calibration Procedure(s)
FF-211-004-01
Calibration Procedures for Dosimetric E-field Probes
Calibration date:
September 25, 2017
This calibration Certificate documents the traceability to national standards, which realize the physical units of
measurements(SI). The measurements and the uncertainties with confidence probability are given on the following
pages and are part of the certificate.
All calibrations have been conducted in the closed laboratory facility: environment temperature(22±3)"C and
humidity<70%.
Calibration Equipment used (M&TE critical for calibration)
ID#
Primary Standards
Power Meter
NRP2
Cal Date(Calibrated by, Certificate No.)
Scheduled Cal ibration
101919
27-Jun-17 (CTTL, No.J17X05857)
Jun-18
Power sensor NRP-291
101547
Jun-18
Power sensor NRP-291
Reference1 OdBAttenuator
101548
27-Jun-17 (CTTL, No.J17X05857)
27-Jun-17 (CTTL, No.J17X05857)
18N50W-1 OdB
13-Mar-16(CTTL,No.J16X01547)
Mar-18
Jun-18
Reference20d8Attenuator
Reference Probe EX3DV4
18N50W-20d8
13-Mar-16(CTTL, No.J16X01548)
SN 7433
26-Sep-16(SPEAG,No.EX3-7433_Sep16)
Mar-18
Sep-17
DAE4
SN 549
13-Dec-16(SPEAG, No. DAE4-549_Dec16)
Dec -17
Secondary Standards
ID #
Cal Date(Calibrated by, Certificate No.)
SignalGeneratorMG3700A
6201052605
27-Jun-17 (CTTL, No.J17X05858)
Jun-18
Network Analyzer E5071C
MY46110673
13-Jan-17 (CTTL, No.J17X00285)
Jan-18
Name
Calibrated by:
Yu Zongying
Function
Scheduled Calibration
Signature
SAR Test Engineer
Reviewed by:
Zhao Jing
SAR Test Engineer
Approved by:
Qi Dianyuan
SAR Project Leader
l v~
Issued: September 27, 2017 This calibration certificate shall not be reproduced except in full without written approval of the laboratory.
Certificate No: Z 17-97 143
Page I of 11
.......-....... ®
----.....
In Collaboration with
- TTL s p
a g
CALIBRATION LA90RA.TORY
Add: No.5 1 Xueyuan Road, Haidian District, Beijing, 100 191, China
Tel: +86-10-62304633-2218
Fax: +86-10-62304633-2209
E-mai l: cttl@chinattl.com
•1up://www.chinattl.cn
Glossary:
tissue simulating liquid
sensitivity in free space
sensitivity in TSL / NORMx,y,z
diode compression point
crest factor ( 1/duty_cycle) of the RF signal
modulation dependent linearization parameters
 rotation around probe axis
9 rotation around an axis that is in the plane normal to probe axis (at measurement center) , i
9=0 is normal to probe axis
Connector Angle information used in DASY system to align probe sensor X to the robot coordinate system
TSL
NORMx,y,z
ConvF
DCP
CF
A ,B,C,D
Polarization 4>
Polarization 9
Calibration is Performed According to the Following Standards:
a) IEEE Std 1528-2013, "IEEE Recommended Practice for Determining the Peak Spatial-Averaged
Specific Absorption Rate (SAR) in the Human Head from Wireless Communications Devices:
Measurement Techniques" , June 2013
b) lEC 62209-1 , "Measurement procedure for the assessment of Specific Absorption Rate (SAR) from
hand-held and body-mounted devices used next to the ear (frequency range of 300 MHz to 6 GHz)",
July 2016
c) IEC 62209-2, "Procedure to determine the Specific Absorption Rate (SAR) for wireless communication
devices used in close proximity to the human body (frequency range of 30 MHz to 6 GHz)", March
2010
d) KDB 865664, "SAR Measurement Requirements for 100 MHz to 6 GHz"
Methods Applied and Interpretation of Parameters:
•
•
•
•
•
•
•
•
•
NORMx,y,z: Assessed for E-field polarization 9=0 (fS:900MHz in TEM-cell; f > 1800MHz: waveguide).
NORMx,y,z are only intermediate values, i.e., the uncertainties of NORMx,y,z does not effect the
E 2 -field uncertainty inside TSL (see below ConvF).
NORM(f}x,y,z = NORMx,y,z* frequency_response (see Frequency Response Chart). This
linearization is implemented in DASY4 software versions later than 4.2. The uncertainty of the
frequency response is included in the stated uncertainty of ConvF.
DCPx,y, z: DCP are numerical linearization parameters assessed based on the data of power sweep
(no uncertainty required). DCP does not depend on frequency nor media.
PAR: PAR is the Peak to Average Ratio that is not calibrated but determined based on the signal
characteristics.
Ax,y, z; Bx,y,z; Cx,y, z; VRx,y,z:A,B,C are numerical linearization parameters assessed based on the
data of power sweep for specific modulation signal. The parameters do not depend on frequency nor
media. VR is the maximum calibration range expressed in RMS voltage across the diode.
ConvF and Boundary Effect Parameters: Assessed in flat phantom using E-field (or Temperature
Transfer Standard for fS:800MHz) and inside waveguide using analytical field distributions based on
power measurements for f >800MHz. The same setups are used for assessment of the parameters
applied for boundary compensation (alpha , depth) of which typical uncertainty valued are given.
These parameters are used in DASY4 software to improve probe accuracy close to the boundary.
The sensitivity in TSL corresponds to NORMx,y,z* ConvF whereby the uncertainty corresponds to
that given for ConvF. A frequency dependent ConvF is used in DASY version 4.4 and higher which
allows extending the validity from±50MHz to±100MHz.
Spherical isotropy (30 deviation from isotropy): in a field of low gradients realized using a flat
phantom exposed by a patch antenna.
Sensor Offset: The sensor offset corresponds to the offset of virtual measurement center from the
probe tip (on probe axis). No tolerance required.
Connector Angle: The angle is assessed using the information gained by determining the NORMx
(no uncertainty required).
Certificate No: Z 17-97 143
Page 2 of II
.....-......
I !>
------...
In Collaboration with
- TTL s p
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian District, Beijing, 100 191 , China
Tel: + 86-1 0-62304633-22 18
Fax: +86-1 0-62304633-2209
E-mail: cttl@chi nattl. com
Http://www.chinattl.cn
Probe ES3DV3
SN: 3270
Calibrated: September 25, 2017
Calibrated for DASY/EASY Systems
(Note: non-compatible with DASY2 system!)
Certificate No: 2 17-97 143
Page 3 of 11
......-....... ®
- TTL s
~ ~
In Collaboration with
CALIBRATION LABORATORY
Add: No.5 1 Xueyuan Road, Haidian District, Beijing, 100 19 1, China
Tel: +86-10-62304633-2218
Fax: +86- 10-62304633 -2209
E-mail: cttl@chinattl.com
I lttp://www.chinattl.cn
DASY/EASY - Parameters of Probe: ES3DV3 - SN: 3270
Basic Calibration Parameters
Norm(µV/(V/m) 2) A
DCP(mV)
SensorX
SensorY
Sensor Z
Unc (k=2)
1.12
1.22
1.21
±10.0%
101.7
105.3
103.1
Modulation Calibration Parameters
UID
Communication
System Name
dB
0.0
0.0
0.0
cw
dB'-'µV
0.0
0.0
0.0
1.0
1.0
1.0
VR
UncE
dB
0.00
mV
(k=2)
262.1
281.1
275.2
±2.5%
The reported uncertainty of measurement is stated as the standard uncertainty of
Measurement multiplied by the coverage factor k=2, which for a normal distribution
Corresponds to a coverage probability of approximately 95%.
The uncertainties of Norm X, Y, Z do not affect the E -field uncertainty inside TSL (see Page 5 and Page 6) .
Numerical linearization parameter: uncertainty not required .
E Uncertainly is determined using the max. deviation from linear response applying rectangular distribution
and is expressed for the square of the field value.
Certificate No: 217-97143
Page 4 of 11
~
®
In Coffaborstion with
- TTL s
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian District, Beijing, 100191 , China
Tel: +86-10-62304633-2218
Fax: + 86-10-62304633-2209
E-mail: cttl@chinattl.com
I lttp://www.chinattl.cn
DASY/EASY - Parameters of Probe: ES3DV3 - SN: 3270
Calibration Parameter Determined in Head Tissue Simulating Media
f [MHzf
750
835
900
1750
1900
2000
2100
2450
2600
Relative
Permittivity F
Conductivity
(Sim) F
ConvF X
ConvF Y
ConvF Z
AlphaG
41 .9
41 .5
41.5
40.1
40.0
40.0
39.8
39.2
39.0
0.89
0.90
0.97
1.37
1.40
1.40
1.49
1.80
1.96
6.34
6.18
6.21
5.24
5.20
4.93
5.02
4 .75
4.45
6.34
6.18
6.21
5.24
5.20
4.93
5.02
4 .75
4.45
6.34
6.18
6.21
5.24
5.20
4.93
5.02
4 .75
4.45
0.60
0.32
0.39
0.65
0.71
0.67
0.71
0.90
0.90
DepthG
Unct.
(mm)
(k=2)
1.20
1.70
1.59
1.26
1.21
1.26
1.22
1.15
1.18
±12.1%
+12.1%
+12.1%
± 12.1%
±12.1%
±12.1%
±12.1%
+ 12.1%
+12.1%
c Frequency validity above 300 MHz of ±100MHz only applies for DASY v4.4 and higher (Page 2) , else it is restricted to
±50MHz. The uncertainty is the RSS of ConvF uncertainty at calibration frequency and the uncertainty for the indicated
frequency band. Frequency validity below 300 MHz is± 10, 25, 40, 50 and 70 MHz for ConvF assessments at 30, 64, 128,
150 and 220 MHz respectively. Above 5 GHz frequency validity can be extended to± 110 MHz.
At frequency below 3 GHz, the validity of tissue parameters(£ and cr) can be relaxed to ±10% if liquid compensation
formula is applied to measured SAR values. At frequencies above 3 GHz, the validity of tissue parameters(£ and cr) is
restricted to ±5%. The uncertainty is the RSS of the ConvF uncertainty for indicated target tissue parameters.
Alpha/Depth are determined during calibration . SPEAG warrants that the remaining deviation due to the boundary
effect after compensation is always less than ± 1% for frequencies below 3 GHz and below± 2% for the frequencies
between 3-6 GHz at any distance larger than half the probe tip diameter from the boundary.
Certificate No: Z17-97143
Page 5 of 11
......-......
® In
--...
- TTL s
CoOaboration with
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian District, Beijing, 100 191 , China
Fax: +86-10-62304633-2209
Tel: +86-10-62304633-22 18
E-mail: cttl@chinattl.com
1lttp://www.chinattl.cn
DASY/EASY - Parameters of Probe: ES3DV3 - SN: 3270
Calibration Parameter Determined in Body Tissue Simulating Media
f [MHzf
Relative
Permittivity F
Conductivity
(S/m) F
ConvF X
ConvF Y
ConvF Z
AlphaG
DepthG
Unct.
(mm)
(k=2)
750
55.5
0.96
6.31
6.31
6.31
0.50
1.35
± 12.1%
835
1750
1900
2450
55.2
53.4
53.3
52.7
52.5
0.97
6.09
6.09
5.00
4.90
4.39
4.19
5.00
4.90
4.39
0.43
0.66
0.72
0.71
4.19
0.90
1.56
1.29
1.21
1.36
1.15
± 12.1%
1.49
1.52
1.95
2.16
6.09
5.00
4.90
4.39
4.19
2600
±12.1%
± 12.1%
±12.1%
± 12.1%
c Frequency validity above 300 MHz of ±100MHz only applies for DASY v4.4 and higher (Page 2), else it is restricted to
±50MHz. The uncertainty is the RSS of ConvF uncertainty at calibration frequency and the uncertainty for the indicated
frequency band . Frequency validity below 300 MHz is± 10, 25, 40, 50 and 70 MHz for ConvF assessments at 30, 64, 128,
150 and 220 MHz respectively. Above 5 GHz frequency validity can be extended to ± 11 O MHz.
F At
frequency below 3 GHz, the validity of tissue parameters (E and o) can be relaxed to ±10% if liquid compensation
formula is applied to measured SAR values. At frequencies above 3 GHz, the validity of tissue parameters (E and o) is
restricted to ±5%. The uncertainty is the RSS of the ConvF uncertainty for indicated target tissue parameters.
Alpha/Depth are determined during calibration. SPEAG warrants that the remaining deviation due to the boundary
effect after compensation is always less than ± 1% for frequencies below 3 GHz and below± 2% for the frequencies
between 3-6 GHz at any distance larger than half the probe tip diameter from the boundary.
Certificate No: Z I 7-97 143
Page 6 of 11
......-...... ®
In Collaboration with
- TTL s
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian District, Beijing, 100191 , China
Tel: +86-10-62304633-2218
Fax: +86-1 0-62304633-2209
E-mail: cttl@chinattl.com
l1ttp://www.chinattl .cn
Frequency Response of E-Field
(TEM-Cell: ifi110 EXX, Waveguide: R22)
1.5
...
----- -- ' ------__,_------- -,- -- ---- -.... ---- --
"C
(1)
1.4
•• •
• • • • .L. • • •
-- -
1.3
•
•
•
. 1.
- ·- I
-- ---- -
. ... - - I
. .. . I
-- •
-- -
_ , _. - I
'~
......I - -- -
----•- ----- - -
... - - - - - -- ... - I
• • • • • • • •1. • • • • • • • - ' • • • • • • • • J • • • • • • • . J. • • • " " • • • L. • • • • • • • • L. • • • • • • • • L • • • • • • • .1. • • • • • • • J • • • • • • • • -' • " •
•
. .. --- - - -· - -- - - -- - - - - - ----~- -- -
-- - · I
---·'· I
- - -
-- •
- .,_ I
--~- -- - -- I
-- - - -
•
• -
J. I
_ ., _ I
- -
- ·
- -
- -
- - -
... I
.. I
• .to I
- -
- -
- -
- -
- -- -
.. I
- --- -
... I
- - .... I
- . .. - I
- -
.. - · I
-· - - I
-- - -
., _ I
.. - -
- -
.,_ - I
- -
-~- I
•
- -- -
J I
- - -- - - - -~-- - - - - - -:- - - - - - - - -:- - - - - - - · -!· -- - -- - - ~- - - - -- - - ~ - - - -- - - - ~- - - - - - - - ~ - --- - - - -~- - - - - - - -:- -- - - - - - -! - - - - --- - ~ - --
ca
E 1.2 ----- ---:--------:9----- -- -:9-------:---. -·-. :-.... --.:- ..-----: .. ------:---- ----:--------:--------:--------:---
...0
fl)
--------: .-------:9-------·t ·------:--. -----:-- ------: . -------:--------:---- ----:------ --:-- --- -- -:----.---:- -I
1.1
--• -4 ---~ t -------!--------i------J ------~ --------r+-~~--=--· ~ ~---·-- ;
-- - - - - - -: - - - - - - --:- - --- - - - -:- - - - - -- - :- - - - -- - - ~- - - - - - - -1 - -- - - -- -: - - - - - - - -: - -- - - - - -: - - - --- - -:---- - - - - :-- - - - - - - :- -:
(1)
1.0
~--
-:--- -.. --· i· ----- -· i··. ----· t-.-----.~ --------~ ---- ----~ ---.----:----. ---~- -------~---
...-----f. -.. ----:-~•
...
· · · •• · • · Ir · · -- · · • ·,·
· • · · · • • · ,·
•• · •• • • .,I . • • ••· • · ,I - - · - - -- - ,I -- - -- - · · rI • - - - - • · · rI • •• • • •• - I~ • • • - • • • -.• • - · •• • .,. • • • • - · - ,-- I
a.
U) 0.9
--
>i 0.8
•
- - - - - - - - ~ - - - - - - - - •- - - - - - - - _,_ - - - - - - - . . . . - - - - - - '4• • • - - - - - • - - - - - - - - .. - - - - - - - - . . . - - - - - - - ~ - - - - - - - -•- - • • - - - . . . . - - - - - • • '4• • •
0.7
(1)
• • • • • .. . . .... • . . . • - - • . . . . . . • • • • 4 • • • • • • • • + - - • • •
- - - - - - - . . . - - - - - - - . 1.
•
- - - - - _ _ _ ,_ - - - - - - - .,_ - - - • • - - "'- - - - - - - - ... - - - - - - - - .. - - - - - - __ .. - - - - - - - . . . - - - - - - - -· - - - - - - - - .,_ - • - - - · . J - - -
•
500
1000
TEM
1500
f [MHz]
2000
2500
- +R22
Uncertainty of Frequency Response of E-field : ±7.4% (k=2)
Certificate No: Z l7-97143
•
• • • .. • • - - • • • . .. • - - - - • • - ~ - - • • • • • -, - - - - - • • • -4 • • • • - - - • 4 • • •
- - --- - - .... --- - - - .1. -• - -- - - -·- - • - • - --~- -- - -- - - "'- - -- -- - -.. - - - -- -- ... - -- - -- - - .. - --- -- - ... - - - - -- - -·-- - - - - - - .,_ - ---- - -
0.5
-4 •
• • • - - • • . . . • • • • • • • •, .
0.6
• • - • • • • - ~ - • • • • • • • I • • • • • • • ••I• • • • • • • • .. . . • • • • • • C • • • • • • • • + • • • • • • • • .. • • • • • • . . ... • • • • • • ... • • • • • • • • I • • • • • • • • ... • • • • • • •
C"
...
LL
-,-
(.)
:::,
--- - -.,.. . . ------,- ----. --.,. - --. ---., ... --- -. .,. -. --- -. ,. .. -- ---.,. ----. ... ,. ------- . ,.. -- . - - -- ... - - - --- - .,. - - - - - -. .,. - -. -- ---... ---- ----,- --. ----.,. -. --- - - .... - -- -- - .,. - --- - - . ,.. -- -- -- - ,. - - - - -- .. ,.. -- - --- ... - -- - -- - - - --- - - .,.. - - - - -- .,. - -
(I)
(1)
Page 7 of 11
J .
- -
3000
~
®
-----........
In CoUaboration with
• TTL s
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian District, Beijing, I 00 19 1, China
Fax: +86-10-62304633-2209
Tel: +86-10-62304633-22 18
E-mail: cttl@chinattl.com
lHtp://www.chinattl.cn
Receiving Pattern (}, 9=0°
f=600 MHz, TEM
f=1800 MHz, R22
90
270
- ,- 'Tot
-+- X
....z
-+- Y
1.0
0.5
iii'
"C
=e
--- .. -- - . -- - -· -- -- -
~-~l~~lt·--- t--·;···· · 4~~-r~··-t·~,. ~
.r~·. . .t -- ~-=t·r···. . r~·~·
0 .0
.;
;.
--;---·····---; ··········-; .......... ;------····· ;---······--: ·······----:·······---:-----------1___________1___________1__________ :.......... i___________ i__________ ) __
--
··:···········:···········:··········r··········1··········r·········:···········r··········r·········r········r··········:-··········:--·········:···········r··
-0 .5
··;···········r··········-r·········-r·········r········r········-r··········r··········r·········r ·········r··········-:-··········r·········:···········:···
··\···········:···········:..........,........... ,--·········:·········--:.......... ,··········:'········--:···········: .......... f.......... ,--·········,···········: ..
-1 .0
-150
-100
100MHz
-50
Roll
600MHz
50
100
1800MHz
2500MHz
Uncertainty of Axial Isotropy Assessment: ±1.2% (k=2)
Certificate No: 217-97143
Page 8 of 11
150
In Colleboration with
a 9
CALIBRATION LABORATORY
Add: No.SI Xueyuan Road, Haidian District, Beijing, 100191, China
Tel: +86-10-62304633-2218
Fax: +86-10-62304633-2209
E-mail: cttl@chinattl.com
littp://www.chinattl.cn
Dynamic Range f(SARhead)
(TEM cell, f = 900 MHz)
~=
. .
~=
: : : : : : :t: : : ~: : ~=: t :t :t ~ ~=~ : ::::: ~=:: :t:: ! : ::: ::: t ~::!: ::: : : : ! : : : ::: : :t: ::!: ! ::: t ! : : : :: : : t : :: ~: : ::: : !: ! : L
·---- - -""·--·-- ... - - +- +•"""""' _"" _____ _..... . .....
. .............................. . . ~-1- ...... ... .... .£ . . . . . . , .... .. \. .. .J .. .> .. J. ..• .. L .£ ......... .. . t.. ..... .J ...... 1... l .. J. .. \. .J .. 1.. 1
... . .... . . t.. .... .. .J ... .J .. • L • L - '- .J ..J .. t.. .......... J _ .... . L • • J. ..., .. .., .._
L .J ..J .... .... ... .. .1. ..... ..• ... •'- .. .J .. ..J .. J. ..• .. L .1. . . . . .. . . . . . \. .... - .J,. .. . 1... J. .. .1. . I.. J .. ,. 1
• • • .... • • (" • • .. '1 .. • '\ • •
•• •••••: ••• >• :•• :-:-:: :-: •• •- ••:----: --:• •'• I ,-: : :•••••• •:••••:---: • :- :-:-:-: :•••••••: •• • :---:-• :•:•: :-:-:
- .... - ........... - I
.. -
- ..
..... ~ ~- ~ - - - - - -
1 1
- - - -
- - •
.. - •-
~- ~
- - - - - .. - r - - - , - - ... - - ,. - ,. -r, ,-,.. - - - - - - "'\- - - - ,. ..
..
- - - .. - - - + - - - _,_ - -~ I
.. -.- -,· "'\ .. ,., ..... - - - - - .. T .. -
C.
C:
.. -
- -~ -
- - .. . . ~ - -
•
~ - ~ ~ . . .. ... .. -
--• -
- - - .. - - ..... - ~
.. L. .J ..J.L. . . . . . . . . . . .J . . . . . .
•~ •
- :-
- :--:-:-:
•
• - - - - - - - ... - - I
- - -•- - • - + ........ - ·- •
I I
· 1· 1
r,
·1-1
·1· - ,. - ,. -
.. .. . . . . . . -1 -
~. -
.. -
..... -
1,. . . . .
~~-
:- .. ........ •
-: - .. •
..
- 1- -
-~ -
~ ~
11
.. -
-•- -
• -
•
- ~
.. ......
I I
11
..... .
. . . . . _,_ ~ . ~
1.1. .r,. .... .
-~ -
.. ~
.............
-,- -
...............
11
•
1....
-~ ~-·-·
4.t.. .J .1 .. 1
~ ....
t .. •:• -:· ~ .. ~ ~ -:- • • - • • • t • • .. -:• .. •:- • ~ • ~- t •:• ~ ; • • • • • • -~ • • • ~ • • •:• • t .. t -:- ~ -:-:
-,- . , .. "- ,. , '"\- - - - - - - T - - - -,- - .. ,.. - , - , - T -,- ,. T - - - - - -
•
·r - - - , - - -.- - T - T ·r , -,-,
: :-: - ----- :----:--:--:--:- :-: : :---- ---:-- --:---: - :- :-:-:-: :-------: --- :---:--:-:-: :-:-:
• ~ - • .. • .. - ~
4 • • 1. . . ! • .J .. L .J ..J . . . . . . . . . . J. ........I • • • L. • .J • ..J •
11
11
•I
~ ~-~
• • • • • • ... .... • ..
11
-,- -.- .... ,. , -. - - - - - - - T - - - .., .. - .. ,.. - , - , - T - ,- ,. T - - - - - I
r - - - , - - "'\ - - ,. - ,. - r , ..... ,. - .. .. . .. - -.- - - - ,. - .. T -
• • • • • • .. ._ • • • "' •
r - , - -,- ,. -,- r ,. - - - - - - -,- - - - ., - •
_,_ .. ..... -
- r - r, ..... r .. - - - - - ... - - - - ,. .. - T I •
• .... • • • •'- • .. • .J .... . I . • L .. L .. \. .J .> ..
..... ~ · ~ - -
-,- - , -
T .. , .. ,. T - - - - - - - ,.. - - - , - - -.- - T - T ·r,
- • -•-
:::: ~=::: t:: ! : ::: ::: ~= t ~ ~=:: :: :: ! : : : ::: : :t: ~: ~= ! ::: t ! : : : : :: :t: : : ~:: ::: : ! : ! :t ~::::
~-.-...o,.. ::
-...
. . ---~
_,_ ~-- ... ~~- ------•
.. .. .. ---.
.. - - ~- - - --•
-- --1- _, _-•- - - - - - -....
- - - -·- - -~ - - .a. .._,_ -- - - -- -~ --- .J •.. ....
- -·- + ..
_,_,
--- - - - -
•
• • , . - · , · • 1• . , • , . . , -,- - - • • • - T • • - ·.- • -
·r - , - ... -
- -,· •
11
· 1· • 1· . , .. ,. ., . , .. •
- - - - - • ·r - - • , - - ,- - r - r - r, ... -r - • - - - - ..... - - - r • - T - - - - - - - ,.. - - - , - • , .. - r • r • r, .,. .. ,. - • • - • - -.- • • • r • • T •
·,· · 1· .....
·,- - ,- .,. ..
- - - - - • -,- - • - ., - - , • • ,. •,.., r-, ., .. ,.. • - • • • • ...... • • • r • •,. •
• 1•
•
•
•
r , ... - • - - - • r,,-------
•1 • . , .. ,. ,
...... -
•
T •
•
•
•1• .. .. ,.. .. ,
T - - - ·1· - T - - - ·1· - T -
-.- •
•
T- T-
r, -,-,
11
• • + • • I• • I• ~ • . 1 -t• • .. • • • • + • • • • I•••~•~•~ • + •I•~ + • • .. • .. • •
- - • - - - -,- - • - , • • , .. - ,. • r -,- , -,-r-- • • • • ., .. • • • r - - ,. -
-r - - - , - - -,- -
• • •
• • •I•• + • + .. ... -I • I• I
. , .. T •1•,.,. •
•
•
-- •
•r • • - , • • .. , .. •, • T·r-, •1•1
., -
-,.. -
r - , - .,. .. T ·1· r T - - • - - - ·r - - - , - - - ,- - , - T · r, -,- ,
r - , - ... - T -,- r r - - - - - - ·r - - - , - - -,- - 1' - T ·r, -,-,
• ,- -
., -
,. ·1·,. T
., •
- ,- -
· r , -,-,
,.
- - - - - - -~- - - ~ - - ~ - - ~ - ~ -:- { -:-~ - - - - - - -:- .. - - ~ .. - f - -:- -:- -:- ~ { ~- - - - - .... ; .. - .. -:- - -:- - ~ - -:- t -:- ~ t - - - - - - -:- - - - ~ - - -:- - ! - ; -~ ~ -:-:
• • • • • • -~ • •"' "'• • "'• •
•
•
..
-~ • • • • • •
• • • • .. • • + •
-1- - 1-
~- ~ ~
°" • • • • • • • + •
• • -•- • • ._
• - I • ....
+ -•- • + • • • • • • -~ • • • .. • • . ... • + • + -~ -1 - · - ·
10°
10
SAR[mW/cm ]
not compensated
_._ compe nsated
IO+
1 r r:rr1
•
I,
•
•
I,
I .
I.
I<
I<
I•
IO I
O !
I••
I++
' : 1:r:·: : !:n1m ,·,!rnrr
•
•
I'
•
I<
I<
I•
It
I!
· - • .,. - · r· .,. · , ·, · r -,- -- - -- --- . , ..... • ·,·- - - , · • .,. • ,. •,· -~ •,•,• • • • • • · • • • r •• • • . , • • • •, • • . , •• , .. , • .,. , ·r • - • • • • • • • , . •• • • -,-- · · , - · ·r - -,-· r ·r - ,- ,
-1
~•••J~1.·:.]I~
••••••••• :••••• •••i••:••:•:•:•::•••••••••1•••••:•••:••I•1•1ii1·--•••••:••••· ·••~••!••i•J•!f
----------,----- ···r··:··:T:·1r········r-···T···1·T1·r:·:·:··········:·····:···-r··1· '" \ T·-----··:·····r·-~·-r·:··r·r·fI
•••I
•
I+
I,
Io
IO
-2 +---r--r----r--r--r-,r-r,CT---r---r----r-""T"-r-r....,..,-r----,r--""T"-r--,--,-r-n--r---,--,--.--.--r-,-"TT"I
10°
SAR[mW/cm
E---J not compensated
10
- - - compensated
Uncertainty of Linearity Assessment: ±0.9% (k=2)
Certificate No: Z 17-97143
Page 9 of 11
~
®
In Collaboration with
--------.....
- TTL s p
...............
a g
CALIBRATION LABORATORY
Add: No.SI Xueyuan Road, Haidian District, Beijing, 100191 , China
Tel: +86-10-62304633-2218
Fax: +86-1 0-62304633-2209
E-mail: cttl@chinattl. com
Http://www.chinattl.cn
Conversion Factor Assessment
f=835 MHz, WGLS R9(H_convF)
f=1750 MHz, WGLS R22(H_convF)
30.00 r -- - , - - - , - - - - , - - -
3.50 ~- - - -- ·~
·- - + - · - - + -- - - + - - - - ~
2.50
oi 2.00
·--+---l---l-:-_1
1-- ~ --+-
t--i.~ - - - i - -- ; - - - - + - - - i -
15.00
i - - -~
C)
--~
~ 1.50
-1- ~~--+----j
(/)
1.00
0.50
o.oo
20.00
20
40
80
60
10.00
t--- --
· - + - -- t - - -
. . .1. . .=~~•-•.. . ,_J
o.oo L.....J~......1. . . . . .
100
10
20
30
40
analytical
- -measured
Deviation from Isotropy in Liquid
-----··:··---...
1.0
0.8
0.6
50
100
150
...\"A . .
- 1-f"ts
200
350
-1 0
-0.80 -0.60 -0.40 -0.20
0.20
0.40
0.60
0.80
1.0
Uncertainty of Spherical Isotropy Assessment: ±3.2% (K=2)
Certificate No: Zl 7-97 143
50
z{mm)
z[mm)
- -measured
·-+--·,-
--,
L---1--L-=::?~~----l
_j
Page 10 of 11
analytical
60
70
......-....... ®
In Collaboration with
,,,,_,,,.....-- -----..
• TTL s
CALIBRATION LABORATORY
Add: No.51 Xueyuan Road, Haidian Di strict, Beijing, 100191 , China
Tel: +86-10-62304633-2218
Fax: +86-10-62304633-2209
E-mail: cttl@chinattl.com
Http://www.chinattl .cn
DASY/EASY - Parameters of Probe: ES3DV3 - SN: 3270
Other Probe Parameters
Sensor Arrangement
Triangular
Connector Angle (0 )
166.5
Mechanical Surface Detection Mode
enabled
Optical Surface Detection Mode
disable
Probe Overall Length
337mm
Probe Body Diameter
10mm
Tip Length
10mm
Tip Diameter
4mm
Probe Tip to Sensor X Calibration Point
2mm
Probe Tip to Sensor Y Calibration Point
2mm
Probe Tip to Sensor Z Calibration Point
2mm
Recommended Measurement Distance from Surface
3mm
Certificate No: ZI 7-97143
Page II of 11

Download: X00QSA ASUS Phone (Mobile phone) RF Exposure Info RF Exposure Appendix C-2 ASUSTeK Computer Inc
Mirror Download [FCC.gov]X00QSA ASUS Phone (Mobile phone) RF Exposure Info RF Exposure Appendix C-2 ASUSTeK Computer Inc
Document ID3799377
Application ID8Q1vdPQW9g1aQiekAOwG2w==
Document DescriptionRF Exposure Appendix C-2
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeRF Exposure Info
Display FormatAdobe Acrobat PDF - pdf
Filesize341.82kB (4272694 bits)
Date Submitted2018-03-28 00:00:00
Date Available2018-04-09 00:00:00
Creation Date2018-03-20 10:45:19
Producing SoftwareFoxit PhantomPDF - Foxit Software Inc.
Document Lastmod2018-03-22 18:09:18
Document TitleRF Exposure Appendix C-2
Document Author: Wan

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.7
Linearized                      : No
Author                          : Wan
Create Date                     : 2018:03:20 10:45:19Z
Modify Date                     : 2018:03:22 18:09:18+08:00
Has XFA                         : No
XMP Toolkit                     : Adobe XMP Core 5.6-c015 84.159810, 2016/09/10-02:41:30
Format                          : application/pdf
Creator                         : Wan
Metadata Date                   : 2018:03:22 18:09:18+08:00
Producer                        : Foxit PhantomPDF - Foxit Software Inc.
Document ID                     : uuid:904e3d56-3243-488f-a188-8da40fea516b
Instance ID                     : uuid:62a68156-4cfa-4f5b-b4bb-2a4eb5313626
Page Count                      : 54
