DNR8416A5R TYCO TM TERRA CLIMBER TM... - FCC ID PIYDNR84-16A5R

FCC ID PIYDNR84-16A5R

Block Diagram

TYCO TM TERRA CLIMBER TM RADIO CONTROL VEHICLE

by Mattel Asia Pacific Sourcing Ltd.

Document preview loads when visible.

Document Details

FCC IDPIYDNR84-16A5R
Document ID2939214
Document TypeBlock Diagram
DescriptionBlock Diagram
Document Title发射方框图x
ApplicantMattel Asia Pacific Sourcing Ltd.
Equipment ClassTYCO TM TERRA CLIMBER TM RADIO CONTROL VEHICLE
Product CodeDNR8416A5R
Application IDY1qqr8VOXxN7m4jVyYnwXw==
Application PurposeOriginal Equipment
Application Date2016-03-23
Frequency Range2407-2471 MHz
FRN0009479130
Test FirmSGS-CSTC Standards Technical Services Co., Ltd
Certified ByJerry Chan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-03-23
Available2016-03-23
Created2016-03-17
Modified2016-03-17
Pages1
File TypeAdobe Acrobat PDF
File Size10172
File SHA-2561b9687feae6b2e5a0490aeb8571d21d910de86f338f43e94c510c69bb70da770
PDF Metadata AuthorJune-YJ_Chen
PDF Metadata ProducerJune-YJ_Chen Acrobat Distiller 11.0 (Windows)
FCC.gov SourcesFCC.gov 2939214
