DNR8416A5R TYCO TM TERRA CLIMBER TM... - FCC ID PIYDNR84-16A5R

FCC ID PIYDNR84-16A5R

Test Setup Photos

TYCO TM TERRA CLIMBER TM RADIO CONTROL VEHICLE

by Mattel Asia Pacific Sourcing Ltd.

Document preview loads when visible.

Document Details

FCC IDPIYDNR84-16A5R
Document ID2939221
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document TitlePhotos
ApplicantMattel Asia Pacific Sourcing Ltd.
Equipment ClassTYCO TM TERRA CLIMBER TM RADIO CONTROL VEHICLE
Product CodeDNR8416A5R
Application IDY1qqr8VOXxN7m4jVyYnwXw==
Application PurposeOriginal Equipment
Application Date2016-03-23
Frequency Range2407-2471 MHz
FRN0009479130
Test FirmSGS-CSTC Standards Technical Services Co., Ltd
Certified ByJerry Chan
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-03-23
Available2016-03-23
Created2016-03-17
Modified2016-03-17
Pages1
File TypeAdobe Acrobat PDF
File Size157688
File SHA-25648779b8af8aabe649aaa0db6771816ffec553dd24170034c2c8a0dbe2d412b0e
PDF Metadata AuthorJune-YJ_Chen
PDF Metadata ProducerAcrobat Distiller 11.0 (Windows) June-YJ_Chen
FCC.gov SourcesFCC.gov 2939221
