FCC ID QISY560-L01
Smart Phone
by Huawei Technologies Co.,Ltd
Grantee Code: QIS Product Code: Y560L01
Latest application date: 2015-10-21
Device Images
FCC ID Device Details
| FCC ID | QISY560-L01 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | QIS |
| Product Code | Y560L01 |
| Applicant Business | Huawei Technologies Co.,Ltd 🇨🇳 |
| Related Domains |  huawei.com |
| Equipment Class | Smart Phone |
| Test Firm | Huawei Technologies Co., LTD |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2015-10-21 |
| 824.2-848.8 MHz | Original Equipment | 2015-10-21 |
| 2402-2480 MHz | Original Equipment | 2015-10-21 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2015-10-21 | PDF 1,016.5 KB |
| user manual | Users Manual | 2015-10-21 | PDF 1,016.5 KB |
| Internal Photos | Internal Photos | 2015-10-21 | PDF 381.9 KB |
| external photos | External Photos | 2015-10-21 | PDF 171.7 KB |
| Label | ID Label/Location Info | 2015-10-21 | PDF 99.4 KB |
| label | ID Label/Location Info | 2015-10-21 | PDF 99.4 KB |
| photos test setup | Test Setup Photos | 2015-10-21 | PDF 245.7 KB |
| photos test setup | Test Setup Photos | 2015-10-21 | PDF 363.7 KB |
| test setup photos | Test Setup Photos | 2015-10-21 | PDF 305.4 KB |
| test setup photos BT-LE | Test Setup Photos | 2015-10-21 | PDF 363.8 KB |
| test setup photos WLAN | Test Setup Photos | 2015-10-21 | PDF 172.4 KB |
| Test report | Test Report | 2015-10-21 | PDF 447.3 KB |
| test report | Test Report | 2015-10-21 | PDF 3.7 MB |
| test report | Test Report | 2015-10-21 | PDF 372.3 KB |
| test report BTLE | Test Report | 2015-10-21 | PDF 1.6 MB |
| test report WLAN | Test Report | 2015-10-21 | PDF 5.1 MB |
| test report appendix_1 | Test Report | 2015-10-21 | PDF 5 MB |
| test report appendix_2 | Test Report | 2015-10-21 | PDF 3.3 MB |
| test report appendix_3 | Test Report | 2015-10-21 | PDF 3.4 MB |
| Confidentiality Request | Cover Letter(s) | 2015-10-21 | PDF 99.5 KB |
| Confidentiality Request Letter | Cover Letter(s) | 2015-10-21 | PDF 99.5 KB |
| cover letter Labelling | Cover Letter(s) | 2015-10-21 | PDF 69 KB |
| RFExposure_part1 | RF Exposure Info | 2015-10-21 | PDF 1,016.6 KB |
| RFExposure_part10 | RF Exposure Info | 2015-10-21 | PDF 701.4 KB |
| RFExposure_part2 | RF Exposure Info | 2015-10-21 | PDF 1.4 MB |
| RFExposure_part3 | RF Exposure Info | 2015-10-21 | PDF 523.3 KB |
| RFExposure_part4 | RF Exposure Info | 2015-10-21 | PDF 4.3 MB |
| RFExposure_part5 | RF Exposure Info | 2015-10-21 | PDF 977 KB |
| RFExposure_part5 | RF Exposure Info | 2015-10-21 | PDF 956.9 KB |
| RFExposure_part6 | RF Exposure Info | 2015-10-21 | PDF 956.9 KB |
| RFExposure_part6 | RF Exposure Info | 2015-10-21 | PDF 977 KB |
| RFExposure_part7 | RF Exposure Info | 2015-10-21 | PDF 907.9 KB |
| RFExposure_part8 | RF Exposure Info | 2015-10-21 | PDF 849.5 KB |
| RFExposure_part9 | RF Exposure Info | 2015-10-21 | PDF 2.8 MB |
| Block Diagram Metadata only | Block Diagram | PDF 28 KB | |
| Block Diagram Metadata only | Block Diagram | PDF 28 KB | |
| block diagram Metadata only | Block Diagram | PDF 72.3 KB | |
| schematics Metadata only | Schematics | PDF 478.7 KB | |
| Operational Description Metadata only | Operational Description | PDF 90.4 KB | |
| Operational_Technical_Description Metadata only | Operational Description | PDF 90.4 KB | |
| Tune up info Metadata only | Parts List/Tune Up Info | PDF 127.5 KB | |
| part list Metadata only | Parts List/Tune Up Info | PDF 202.4 KB | |
| tune up info Metadata only | Parts List/Tune Up Info | PDF 127.5 KB |
Application Information
| Application ID | zBAqQ4wK0P7pHlIEwPR/ZA== |
|---|---|
| Final Action Date | 2015-10-21 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0007419963 |
| Model | Y560-L01 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | Smart Phone |
| Responsible Party | Zhang Xinghai, zhangxinghai@huawei.com , +86-755-2897-0299 |
| Test Firm | Zhou Fengyum, Huawei Technologies Co., LTD, zhoufengyun@huawei.com , 86-755-28782917 |
| TCB Email | wilfried.latz@cetecom.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Output power listed is peak conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 15 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR for head, body-worn, wireless router and simultaneous transmission use conditions are 0.97 W/kg, 0.12 W/kg, 0.23 W/Kg and 1.59 W/Kg, respectively. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| zBAqQ4wK0P7pHlIEwPR/ZA== | 2015-10-21 | Original Equipment |
| pI3RCPpZzy28ISxbwGYwKA== | 2015-10-21 | Original Equipment |
| MR5tUqtEJWswTyM8QSJCEg== | 2015-10-21 | Original Equipment |
| Fc55lHp+A0zxx50OLZT7xg== | 2015-10-21 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules | Grant Notes |
|---|---|---|---|---|---|
| 15B | CC | ||||
| 824.2-848.8 MHz | 0.412 | 0.176ppm | 245KGXW | 22H | |
| 824.2-848.8 MHz | 0.11 | 0.019ppm | 246KG7W | 22H | |
| 1850.2-1909.8 MHz | 0.418 | 0.018ppm | 247KGXW | 24E | |
| 1850.2-1909.8 MHz | 0.161 | 0.016ppm | 244KG7W | 24E | |
| 2402-2480 MHz | 0.0080000 | 15C | CC | ||
| 2402-2480 MHz | 0.00082 | 15C | CC | ||
| 2412-2462 MHz | 0.053 | 15C | CC | ||
| 2500-2570 MHz | 0.076 | 0.016ppm | 13M5G7D | 27 | |
| 2500-2570 MHz | 0.072 | 0.015ppm | 17M9G7D | 27 | |
| 2500-2570 MHz | 0.065 | 0.048ppm | 18M0W7D | 27 |
Grants
TCB Grant - Application zBAqQ4wK0P7pHlIEwPR/ZA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
CTC advanced GmbH Untertuerkheimer Strasse 6-10 66117 Saarbruecken, Germany |
Date of Grant: 10/21/2015 Application Dated: 10/21/2015 |
| Huawei Technologies Co.,Ltd |
| Administration Building, Headquarters of Huawei |
| Technologies Co., Ltd., Bantian, Longgang District |
| Shenzhen, China |
| Attention: Zhang Xinghai |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | QISY560-L01 |
| Name of Grantee: | Huawei Technologies Co.,Ltd |
| Equipment Class: | Digital Transmission System |
| Notes: | Smart Phone |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| CC | 15C | 2412.0 - 2462.0 | 0.053 | ||
| CC | 15C | 2402.0 - 2480.0 | 0.00082 |
| Output power listed is peak conducted. This device supports 802.11b, 802.11g and 802.11n with a 20 MHz and 40 MHz bandwidth mode. For body worn operation, this phone has been tested and meets FCC RF exposure guidelines when used with an accessory that contains no metal and that positions the handset a minimum of 15 mm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. End users must be informed of the body worn requirements for satisfying RF Exposure compliance. The highest reported SAR for head, body-worn, wireless router and simultaneous transmission use conditions are 0.97 W/kg, 0.12 W/kg, 0.23 W/Kg and 1.59 W/Kg, respectively. |
| CC: | This device is certified pursuant to two different Part 15 rules sections. |
