RBTBHR2W Wireless LAN Card Label Diagram - FCC ID QXO-RBTBHR2W

FCC ID QXO-RBTBHR2W

Label Placement

Wireless LAN Card

by Extreme Networks, Inc.

Document preview loads when visible.

Document Details

FCC IDQXO-RBTBHR2W
Document ID473918
Document TypeID Label/Location Info
DescriptionLabel Placement
Document TitleQXO-RBTBHR2W - Label Placement
ApplicantExtreme Networks, Inc.
Equipment ClassWireless LAN Card
Product CodeRBTBHR2W
Application IDxn1Yro3OCrEDTGwyJlgt9Q==
Application PurposeOriginal Equipment
Application Date2004-09-27
Frequency Range2400-2483.5 MHz
FRN0019588359
Test FirmBUREAU VERITAS CONSUMER PRODUCTS SERVICES, INC.
Certified ByMichael Buchholz
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceYes
Composite PartNo
Submitted2004-09-28
Available2004-09-27
Created2004-09-14
Modified2004-09-14
Pages1
File TypeAdobe Acrobat PDF
File Size95544
File SHA-256b747e3edf1e2e8e56469417eeea4e2494fa596fab96525037ec2e90d774f8d4f
PDF Metadata AuthorDebby Wallace
PDF Metadata ProducerAcrobat Distiller 6.0.1 (Windows) Debby Wallace
FCC.gov SourcesFCC.gov 473918, FCC.gov 473856
