60348A Inductive Toys Block Diagram - FCC ID RS460348A

FCC ID RS460348A

Block Diagram

Inductive Toys

by Hasbro Far East Ltd.

Document preview loads when visible.

Document Details

FCC IDRS460348A
Document ID451748
Document TypeBlock Diagram
DescriptionBlock Diagram
ApplicantHasbro Far East Ltd.
Equipment ClassInductive Toys
Product Code60348A
Application ID+12ZsPNYGLjanmngQ/+1sg==
Application PurposeOriginal Equipment
Application Date2004-07-21
Frequency Range13.56 MHz
FRN0016626152
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-07-21
Available2004-07-21
Created2004-06-11
Modified2004-06-11
Pages1
File TypeAdobe Acrobat PDF
File Size32509
File SHA-2562af3b242a2c3d9da2bf2b549e685448fab49687a7d5fc6e8d4d062fa4a00670f
PDF Metadata AuthorITS ELECTRIC TOY
PDF Metadata ProducerHP 9100C Digital Sender
FCC.gov SourcesFCC.gov 451748
