60348A Inductive Toys Schematics - FCC ID RS460348A

FCC ID RS460348A

Circuit Diagram

Inductive Toys

by Hasbro Far East Ltd.

Document preview loads when visible.

Document Details

FCC IDRS460348A
Document ID451749
Document TypeSchematics
DescriptionCircuit Diagram
ApplicantHasbro Far East Ltd.
Equipment ClassInductive Toys
Product Code60348A
Application ID+12ZsPNYGLjanmngQ/+1sg==
Application PurposeOriginal Equipment
Application Date2004-07-21
Frequency Range13.56 MHz
FRN0016626152
Test FirmIntertek Testing Services Hong Kong
Certified ByWilbur Ng Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2004-07-21
Available2004-07-21
Created2004-06-11
Modified2004-07-19
Pages2
File TypeAdobe Acrobat PDF
File Size117529
File SHA-25632cf58b38ac868458e488c5eb9bfd67409e75ae061480d4b7d8fd56e0131fd6c
PDF Metadata AuthorITS ELECTRIC TOY
PDF Metadata ProducerHP 9100C Digital Sender
FCC.gov SourcesFCC.gov 451749
