WLM200NX WIRELESS-N NETWORK MINI PCI... - FCC ID TK4WLM200NX
FCC ID TK4WLM200NX
1608RSU01102-FCC-UNII Test Report (WiFi) Part2
WIRELESS-N NETWORK MINI PCI ADAPTER
Document preview loads when visible.
Document Details
| FCC ID | TK4WLM200NX |
|---|---|
| Document ID | 3125246 |
| Document Type | Test Report |
| Description | 1608RSU01102-FCC-UNII Test Report (WiFi) Part2 |
| Document Title | Untitled |
| Applicant | Compex Systems Pte Ltd |
| Equipment Class | WIRELESS-N NETWORK MINI PCI ADAPTER |
| Product Code | WLM200NX |
| Application ID | 7Y7bfRdYPjESxMVaOo4sRw== |
| Application Purpose | Original Equipment |
| Application Date | 2016-09-07 |
| Frequency Range | 5745-5825 MHz |
| FRN | 0013908165 |
| Test Firm | MRT Technology (Suzhou) Co., Ltd |
| Certified By | Robin Wu Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-09-07 |
| Available | 2016-09-07 |
| Created | 2017-12-14 |
| Modified | 2017-12-14 |
| Pages | 71 |
| File Type | Adobe Acrobat PDF |
| File Size | 2801921 |
| File SHA-256 | d8ccfa2804de11708bd3b4c739a6a7c784e48677fde8d2f1e016eb2f2034fef7 |
| PDF Metadata Author | Test |
| PDF Metadata Producer | GPL Ghostscript 9.18 Test |
| FCC.gov Sources | FCC.gov 3125246 |
