CM2XXNF IEEE 802.11 a/b/g/n/ac Wireless LAN... - FCC ID TLZ-CM2XXNF

FCC ID TLZ-CM2XXNF

Label Location

IEEE 802.11 a/b/g/n/ac Wireless LAN and Bluetooth M.2 Combo Module

by AzureWave Technologies, Inc.

Document preview loads when visible.

Document Details

FCC IDTLZ-CM2XXNF
Document ID2585205
Document TypeID Label/Location Info
DescriptionLabel Location
ApplicantAzureWave Technologies, Inc.
Equipment ClassIEEE 802.11 a/b/g/n/ac Wireless LAN and Bluetooth M.2 Combo Module
Product CodeCM2XXNF
Application IDCFPsyy/Y6jwSlPBpwp1F+Q==
Application PurposeClass II Permissive Change
Application Date2015-04-16
Frequency Range2402-2480 MHz
FRN0013946611
Test FirmSporton International Inc.
Certified ByJONES TSAI DIRECTOR
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Short-Term Confidentiality Date10/12/2015
Grant DeferralNo
Modular EquipmentLimited Single Modular Approval
Composite DeviceYes
Composite PartNo
Submitted2015-04-15
Available2015-04-16
Created2015-04-08
Modified2015-04-08
Pages1
File TypeAdobe Acrobat PDF
File Size44806
File SHA-2562fe857c526f210e01bcbe6b573bb414eee44ca55df2a4f76ccfe0355a2826e05
PDF Metadata ProducerAcrobat Distiller 9.0.0 (Windows)
FCC.gov SourcesFCC.gov 2585205, FCC.gov 2585197, FCC.gov 2585166
