1103022011008... - FCC ID UDV-1103022011008

FCC ID UDV-1103022011008

Block Diagram

GSM/GPRS/EDGE/WCDMA/HSDPA module

by Shanghai Simcom Ltd.

Document preview loads when visible.

Document Details

FCC IDUDV-1103022011008
Document ID1484815
Document TypeBlock Diagram
DescriptionBlock Diagram
Document TitleSIM5320_HD_V1.01.DOC
ApplicantShanghai Simcom Ltd.
Equipment ClassGSM/GPRS/EDGE/WCDMA/HSDPA module
Product Code1103022011008
Application IDcKRVXsIzqFhc4tyCPe1p8w==
Application PurposeOriginal Equipment
Application Date2011-06-17
Frequency Range1850.2-1909.8 MHz
FRN0015216328
Test FirmQuieTek Corporation
Certified ByYongsheng Li
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2011-06-17
Available2011-06-17
Created2011-05-17
Modified2011-05-17
Pages2
File TypeAdobe Acrobat PDF
File Size190766
File SHA-256244a3d7c70c604108344bcc18a2634c44b74a468eb7a93ebbabd15d2fcd53bcd
PDF Metadata Authorchunlin.zhu
PDF Metadata CreatorPScript5.dll Version 5.2
PDF Metadata ProducerAcrobat Distiller 7.0 (Windows)
FCC.gov SourcesFCC.gov 1484815
