LB2AB UWB+BLE Combo Module plus 1055 ANT... - FCC ID VPYLB2AB
FCC ID VPYLB2AB
Internal photo
UWB+BLE Combo Module plus 1055 ANT
Document preview loads when visible.
Document Details
| FCC ID | VPYLB2AB |
|---|---|
| Document ID | 6773976 |
| Document Type | Internal Photos |
| Description | Internal photo |
| Document Title | HD 271 S1 |
| Applicant | Murata Manufacturing Co., Ltd. |
| Equipment Class | UWB+BLE Combo Module plus 1055 ANT |
| Product Code | LB2AB |
| Application ID | WJ7+wauy+wlAGJLku74kuA== |
| Application Purpose | Class II Permissive Change |
| Application Date | 2023-09-01 |
| Frequency Range | 6489.6-7987.2 MHz |
| FRN | 0017033432 |
| Test Firm | SGS-CSTC Standards Technical Services Co., Ltd. |
| Certified By | Parlam Zhan Manager |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2023-09-01 |
| Available | 2023-09-01 |
| Created | 2023-08-30 |
| Modified | 2023-08-30 |
| Pages | 3 |
| File Type | Adobe Acrobat PDF |
| File Size | 342161 |
| File SHA-256 | 90254186b4e9abd3f520c39bfe0bfd8ed23f2c970a4b967e0c2d5ab667619ddf |
| PDF Metadata Author | LAB02 |
| PDF Metadata Producer | Microsoft® Word for Microsoft 365 LAB02 |
| FCC.gov Sources | FCC.gov 6773976, FCC.gov 6773952 |
