HUB100BSM02 2.4 GHz WiFi Module Test... - FCC ID X4K-HUB100BSM02

FCC ID X4K-HUB100BSM02

Test Setup Photo

2.4 GHz WiFi Module

by Automatic Technology (Australia) Pty. Ltd.

Document preview loads when visible.

Document Details

FCC IDX4K-HUB100BSM02
Document ID4126074
Document TypeTest Setup Photos
DescriptionTest Setup Photo
ApplicantAutomatic Technology (Australia) Pty. Ltd.
Equipment Class2.4 GHz WiFi Module
Product CodeHUB100BSM02
Application IDu2u5yH9oNWg14eFdslRBIA==
Application PurposeOriginal Equipment
Application Date2019-01-02
Frequency Range2412-2462 MHz
FRN0019477462
Test FirmShenzhen UnionTrust Quality and Technology Co., Lt
Certified ByBilly Li Deputy General Manager
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2019-01-02
Available2019-01-02
Created2018-12-21
Modified2018-12-21
Pages2
File TypeAdobe Acrobat PDF
File Size530430
File SHA-256691d12154d7359bfb29f57705da59cc37d9f57cecd50b3148fd80c93cb9f7e72
PDF Metadata Authorkevin.liang
PDF Metadata Producerkevin.liang Microsoft® Word 2013
FCC.gov SourcesFCC.gov 4126074
