BC840M Bluetooth 5.0 Module Test Setup Photos - FCC ID X8WBC840M

FCC ID X8WBC840M

Test Setup Photos

Bluetooth 5.0 Module

by Fanstel Corporation, Taipei

Document preview loads when visible.

Document Details

FCC IDX8WBC840M
Document ID4193134
Document TypeTest Setup Photos
DescriptionTest Setup Photos
Document Title18LR474FC (Part15 247+RSS247) BT5.0
ApplicantFanstel Corporation, Taipei
Equipment ClassBluetooth 5.0 Module
Product CodeBC840M
Application IDNEDuxCJNhxpSATUr88465A==
Application PurposeOriginal Equipment
Application Date2019-03-11
Frequency Range2402-2480 MHz
FRN0019658053
Test FirmInternational Standards Laboratory Corp.
Certified ByPaudy Tung Engineer
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Submitted2019-03-07
Available2019-03-11
Created2019-03-06
Modified2019-03-06
Pages6
File TypeAdobe Acrobat PDF
File Size649670
File SHA-2564b9df6ae6a2e9d78b7e9aa801f8dbb8d60be902919bb6565708567d833ec2bc6
PDF Metadata Author10108060
PDF Metadata Producer10108060 Acrobat Distiller 10.1.16 (Windows)
FCC.gov SourcesFCC.gov 4193134
