FCC ID XMR201605EC25A
LTE Module
by Quectel Wireless Solutions Company Limited
Grantee Code: XMR Product Code: 201605EC25A
Latest application date: 2019-07-12
Device Images
FCC ID Device Details
| FCC ID | XMR201605EC25A |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XMR |
| Product Code | 201605EC25A |
| Applicant Business | Quectel Wireless Solutions Company Limited 🇨🇳 |
| Related Domains |  quectel.com |
| Equipment Class | LTE Module |
| Test Firm | Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 699.7-715.3 MHz | Class II permissive change or modification of presently authorized equipment | 2019-07-12 |
| 699.7-715.3 MHz | Class II permissive change or modification of presently authorized equipment | 2019-04-19 |
| 699.7-715.3 MHz | Class II permissive change or modification of presently authorized equipment | 2018-09-27 |
| 699.7-715.3 MHz | Class II permissive change or modification of presently authorized equipment | 2018-06-13 |
| 699.7-715.3 MHz | Class II permissive change or modification of presently authorized equipment | 2017-03-15 |
| 699.7-715.3 MHz | Original Equipment | 2016-07-18 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2020-01-09 | PDF 256.4 KB |
| User Manual-Statement | Users Manual | 2020-01-09 | PDF 181.6 KB |
| Users Manual | Users Manual | 2019-04-19 | PDF 1.9 MB |
| Users Manual | Users Manual | 2018-09-27 | PDF 1.9 MB |
| Users Manual | Users Manual | 2018-06-13 | PDF 5 MB |
| Users Manual | Users Manual | 2016-07-18 | PDF 1.3 MB |
| Internal photos | Internal Photos | 2020-01-09 | PDF 2.1 MB |
| Internal Photos | Internal Photos | 2018-06-13 | PDF 860.9 KB |
| Int Photos | Internal Photos | 2017-03-15 | PDF 351 KB |
| Internal Photos | Internal Photos | 2016-07-18 | PDF 45.2 KB |
| External photo | External Photos | 2020-01-09 | PDF 723.2 KB |
| External Photos | External Photos | 2018-06-13 | PDF 549.5 KB |
| Ext Photos | External Photos | 2017-03-15 | PDF 289.9 KB |
| External Photos | External Photos | 2016-07-18 | PDF 49.3 KB |
| Label | ID Label/Location Info | 2019-07-12 | PDF 130.4 KB |
| Label Location | ID Label/Location Info | 2019-07-12 | PDF 78.7 KB |
| FCC ID Label | ID Label/Location Info | 2017-03-15 | PDF 402.2 KB |
| FCC ID Label | ID Label/Location Info | 2016-07-18 | PDF 87.7 KB |
| RF Test set-up photo | Test Setup Photos | 2020-01-09 | PDF 586.8 KB |
| Test Setup Photos | Test Setup Photos | 2018-06-13 | PDF 2.7 MB |
| Test Setup Photos | Test Setup Photos | 2016-07-18 | PDF 53.2 KB |
| RF Test Report-(co-located) | Test Report | 2019-07-12 | PDF 242.7 KB |
| RF Test Report-22 | Test Report | 2019-07-12 | PDF 426.8 KB |
| RF Test Report-24 | Test Report | 2019-07-12 | PDF 792.4 KB |
| RF Test Report-27 | Test Report | 2019-07-12 | PDF 1.1 MB |
| Test Report_Part 22 | Test Report | 2019-04-19 | PDF 643 KB |
| Test Report_Part 24 | Test Report | 2019-04-19 | PDF 618.5 KB |
| Test Report_Part 27 | Test Report | 2019-04-19 | PDF 1 MB |
| Test Report_ Part22 | Test Report | 2018-09-27 | PDF 569.9 KB |
| Test Report_ Part24 | Test Report | 2018-09-27 | PDF 555.5 KB |
| Test Report_ Part27 | Test Report | 2018-09-27 | PDF 728.4 KB |
| Test Report_Part 22 | Test Report | 2018-06-13 | PDF 1.1 MB |
| Test Report_Part 24 | Test Report | 2018-06-13 | PDF 1.1 MB |
| Test Report_Part 27 | Test Report | 2018-06-13 | PDF 1.3 MB |
| Test Report | Test Report | 2017-03-15 | PDF 524.5 KB |
| Test Report | Test Report | 2016-07-18 | PDF 2.3 MB |
| Authorization Letter | Cover Letter(s) | 2019-07-12 | PDF 100.8 KB |
| Class II Permissive Change Request Letter | Cover Letter(s) | 2019-07-12 | PDF 77.2 KB |
| POA | Cover Letter(s) | 2019-07-12 | PDF 94.3 KB |
| STC Letter | Cover Letter(s) | 2019-07-12 | PDF 81.3 KB |
| FCC class II permissive change application letter | Cover Letter(s) | 2019-04-19 | PDF 85.9 KB |
| Modular Approval Checklist | Cover Letter(s) | 2019-04-19 | PDF 103.7 KB |
| POA | Cover Letter(s) | 2019-04-19 | PDF 59.6 KB |
| Request letter | Cover Letter(s) | 2019-04-19 | PDF 22.8 KB |
| Antenna Spec | Cover Letter(s) | 2018-09-27 | PDF 198.2 KB |
| FCC class II permissive change application letter | Cover Letter(s) | 2018-09-27 | PDF 88.7 KB |
| Modular Approval Checklist | Cover Letter(s) | 2018-09-27 | PDF 104.2 KB |
| POA | Cover Letter(s) | 2018-09-27 | PDF 54.7 KB |
| Request letter | Cover Letter(s) | 2018-09-27 | PDF 22.8 KB |
| FCC class II permissive change application letter | Cover Letter(s) | 2018-06-13 | PDF 344.9 KB |
| POA | Cover Letter(s) | 2018-06-13 | PDF 61 KB |
| confidentiality | Cover Letter(s) | 2018-06-13 | PDF 108.4 KB |
| CIIPC Letter | Cover Letter(s) | 2017-03-15 | PDF 84.3 KB |
| POA | Cover Letter(s) | 2017-03-15 | PDF 20.9 KB |
| Product Similarity Declaration | Cover Letter(s) | 2017-03-15 | PDF 61.6 KB |
| Confidential Request Letters | Cover Letter(s) | 2016-07-18 | PDF 69.9 KB |
| Modular Approval Request Letters | Cover Letter(s) | 2016-07-18 | PDF 74.2 KB |
| RF Exposure report | RF Exposure Info | 2019-07-12 | PDF 64.1 KB |
| MPE Report | RF Exposure Info | 2019-04-19 | PDF 666.5 KB |
| MPE Report | RF Exposure Info | 2018-09-27 | PDF 246.1 KB |
| MPE Report | RF Exposure Info | 2018-06-13 | PDF 209.8 KB |
| RF Exposure | RF Exposure Info | 2017-03-15 | PDF 140 KB |
| MPE Calculation | RF Exposure Info | 2016-07-18 | PDF 79.1 KB |
| RF exposure Information | RF Exposure Info | 2016-07-18 | PDF 77 KB |
| Schematics Metadata only | Schematics | PDF 190.2 KB | |
| Schematics Metadata only | Schematics | PDF 206.4 KB | |
| Operational Description Metadata only | Operational Description | PDF 221.9 KB | |
| BOM Metadata only | Parts List/Tune Up Info | PDF 68.4 KB | |
| Part List Metadata only | Parts List/Tune Up Info | PDF 71.6 KB | |
| Tune Up Information Metadata only | Parts List/Tune Up Info | PDF 161.2 KB |
Application Information
| Application ID | OnIqvzsuldhnREU3oIwEkA== |
|---|---|
| Final Action Date | 2019-07-12 |
| Application Purpose | Class II permissive change or modification of presently authorized equipment |
| Applicant FRN | 0018988279 |
| Model | 201605EC25A |
| Frequency Range | 699.7-715.3 MHz |
| Equipment Class | PCB - PCS Licensed Transmitter |
| Device Description | LTE Module |
| Responsible Party | Jean Hu, jean.hu@quectel.com , +8602150086326 |
| Test Firm | Eric Lin, Bureau Veritas CPS(H.K.) Ltd., Taoyuan Branch, eric-wp.lin@tw.bureauveritas.com  , +886-3-2641570 |
| TCB Email | tcb@siemic.com  |
| TCB Scope | B1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27 |
| Short-Term Confidentiality | Yes |
| Short-Term Confidentiality Date | 01/09/2020 |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Class II Permissive Change to add a host (VeeaHub, Model: VHE09). The certified module which is co-located with a host FCC ID: 2ARXKVHE09. CIIPC: Add a new antenna. CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| OnIqvzsuldhnREU3oIwEkA== | 2019-07-12 | Class II permissive change or modification of presently authorized equipment |
| 1coRiczuvvVktn6nKznIkw== | 2019-04-19 | Class II permissive change or modification of presently authorized equipment |
| LXMiavIjhS/z3tR0SKQOdA== | 2018-09-27 | Class II permissive change or modification of presently authorized equipment |
| dzSkO6jPKPaH70vUomWK5A== | 2018-06-13 | Class II permissive change or modification of presently authorized equipment |
| bmGxpqriz6LL7cT1xE6OUw== | 2017-03-15 | Class II permissive change or modification of presently authorized equipment |
| 4d8dYCOeG2ykZMm7v5rlnA== | 2016-07-18 | Original Equipment |
Equipment Authorization
| Frequency | Output | Tolerance | Emission | Rules |
|---|---|---|---|---|
| 699.7-715.3 MHz | 0.225 | 2.5ppm | 1M11G7D | 27 |
| 699.7-715.3 MHz | 0.192 | 2.5ppm | 1M10W7D | 27 |
| 700.5-714.5 MHz | 0.238 | 2.5ppm | 2M75G7D | 27 |
| 700.5-714.5 MHz | 0.199 | 2.5ppm | 2M76W7D | 27 |
| 701.5-713.5 MHz | 0.237 | 2.5ppm | 4M54G7D | 27 |
| 701.5-713.5 MHz | 0.201 | 2.5ppm | 4M54W7D | 27 |
| 704-711 MHz | 0.242 | 2.5ppm | 9M12G7D | 27 |
| 704-711 MHz | 0.206 | 2.5ppm | 9M12W7D | 27 |
| 1710.7-1754.3 MHz | 0.24 | 2.5ppm | 1M10G7D | 27 |
| 1710.7-1754.3 MHz | 0.209 | 2.5ppm | 1M11W7D | 27 |
| 1711.5-1753.5 MHz | 0.202 | 2.5ppm | 2M75G7D | 27 |
| 1711.5-1753.5 MHz | 0.202 | 2.5ppm | 2M76W7D | 27 |
| 1712.5-1752.5 MHz | 0.237 | 2.5ppm | 4M52G7D | 27 |
| 1712.5-1752.5 MHz | 0.201 | 2.5ppm | 4M52W7D | 27 |
| 1715-1750 MHz | 0.236 | 2.5ppm | 9M08G7D | 27 |
| 1715-1750 MHz | 0.198 | 2.5ppm | 9M08W7D | 27 |
| 1717.5-1747.5 MHz | 0.235 | 2.5ppm | 13M5G7D | 27 |
| 1717.5-1747.5 MHz | 0.192 | 2.5ppm | 13M5W7D | 27 |
| 1717.5-1747.5 MHz | 0.236 | 2.5ppm | 13M5G7D | 27 |
Grants
TCB Grant - Application OnIqvzsuldhnREU3oIwEkA==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bureau Veritas Consumer Products Services, Inc. 775 Montague Expressway Milpitas, CA 95035 |
Date of Grant: 07/12/2019 Application Dated: 07/12/2019 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II Permissive Change to add a host (VeeaHub, Model: VHE09). The certified module which is co-located with a host FCC ID: 2ARXKVHE09. CIIPC: Add a new antenna. CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
EAS Grant - Application OnIqvzsuldhnREU3oIwEkA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 07/12/2019 Application Dated: 07/12/2019 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II Permissive Change to add a host (VeeaHub, Model: VHE09). The certified module which is co-located with a host FCC ID: 2ARXKVHE09. CIIPC: Add a new antenna. CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 09/27/2018 Application Dated: 09/18/2018 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II permissive change : This change is to add an antenna with higher maximum gain value, 4.5 dBi for Band 2/4/5/12. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
EAS Grant - Application LXMiavIjhS/z3tR0SKQOdA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 09/27/2018 Application Dated: 09/18/2018 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II permissive change : This change is to add an antenna with higher maximum gain value, 4.5 dBi for Band 2/4/5/12. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 06/13/2018 Application Dated: 06/12/2018 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II change: The minor circuitry for non-transmitter portions is changed Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
EAS Grant - Application dzSkO6jPKPaH70vUomWK5A==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 06/13/2018 Application Dated: 06/12/2018 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Class II change: The minor circuitry for non-transmitter portions is changed Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bay Area Compliance Laboratory Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 |
Date of Grant: 03/15/2017 Application Dated: 03/15/2017 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
EAS Grant - Application bmGxpqriz6LL7cT1xE6OUw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 03/15/2017 Application Dated: 03/15/2017 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.236 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Bay Area Compliance Laboratory Corp. 1274 Anvilwood Avenue Sunnyvale, CA 94089 |
Date of Grant: 07/18/2016 Application Dated: 07/18/2016 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Single Modular Approval. Output power is conducted. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716MHz, 6 dBi of frequency band 1710-1755MHz, 9 dBi of frequency band 1850-1910MHz, 10.91 dBi of frequency band 824-849MHz,for the purpose of satisfying the requirements of 2.1043 and 2.1091. They operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or they operate at frequencies above 1.5 GHz and their ERP is 3watts or more. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter not described under this FCC ID. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
EAS Grant - Application 4d8dYCOeG2ykZMm7v5rlnA==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 07/18/2016 Application Dated: 07/18/2016 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| Single Modular Approval. Output power is conducted. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716MHz, 6 dBi of frequency band 1710-1755MHz, 9 dBi of frequency band 1850-1910MHz, 10.91 dBi of frequency band 824-849MHz,for the purpose of satisfying the requirements of 2.1043 and 2.1091. They operate at frequencies of 1.5 GHz or below and their effective radiated power (ERP) is 1.5 watts or more, or they operate at frequencies above 1.5 GHz and their ERP is 3watts or more. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter not described under this FCC ID. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. |
| Mail To: | |||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||||
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
Telefication B.V. Wilmersdorf 50 Apeldoorn, NL-7300 AC Netherlands |
Date of Grant: 04/19/2019 Application Dated: 04/15/2019 |
| Quectel Wireless Solutions Company Limited |
| Building 5, Shanghai Business Park PhaseIII |
| (Area B),No.1016 Tianlin Road, Minhang District |
| Shanghai, 200233 China |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| CIIPC: Add a new antenna. CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
EAS Grant - Application 1coRiczuvvVktn6nKznIkw==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
Quectel Wireless Solutions Company Limited Building 5, Shanghai Business Park PhaseIII (Area B),No.1016 Tianlin Road, Minhang District Shanghai, 200233 China |
Date of Grant: 04/19/2019 Application Dated: 04/15/2019 |
| Attention: Jean Hu |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XMR201605EC25A |
| Name of Grantee: | Quectel Wireless Solutions Company Limited |
| Equipment Class: | PCS Licensed Transmitter |
| Notes: | LTE Module |
| Modular Type: | Single Modular |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 22H | 826.4 - 846.6 | 0.205 | 2.5 PM | 4M15F9W | |
| 24E | 1852.4 - 1907.6 | 0.209 | 2.5 PM | 4M15F9W | |
| 27 | 1712.4 - 1752.6 | 0.182 | 2.5 PM | 4M15F9W | |
| 27 | 699.7 - 715.3 | 0.225 | 2.5 PM | 1M11G7D | |
| 27 | 699.7 - 715.3 | 0.192 | 2.5 PM | 1M10W7D | |
| 27 | 700.5 - 714.5 | 0.238 | 2.5 PM | 2M75G7D | |
| 27 | 700.5 - 714.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 27 | 701.5 - 713.5 | 0.237 | 2.5 PM | 4M54G7D | |
| 27 | 701.5 - 713.5 | 0.201 | 2.5 PM | 4M54W7D | |
| 27 | 704.0 - 711.0 | 0.242 | 2.5 PM | 9M12G7D | |
| 27 | 704.0 - 711.0 | 0.206 | 2.5 PM | 9M12W7D | |
| 24E | 1850.7 - 1909.3 | 0.242 | 2.5 PM | 1M10G7D | |
| 24E | 1850.7 - 1909.3 | 0.2 | 2.5 PM | 1M10W7D | |
| 24E | 1851.5 - 1908.5 | 0.244 | 2.5 PM | 2M76G7D | |
| 24E | 1851.5 - 1908.5 | 0.199 | 2.5 PM | 2M76W7D | |
| 24E | 1852.5 - 1907.5 | 0.24 | 2.5 PM | 4M54G7D | |
| 24E | 1852.5 - 1907.5 | 0.191 | 2.5 PM | 4M54W7D | |
| 24E | 1855.0 - 1905.0 | 0.244 | 2.5 PM | 9M12G7D | |
| 24E | 1855.0 - 1905.0 | 0.192 | 2.5 PM | 9M12W7D | |
| 24E | 1857.5 - 1902.5 | 0.235 | 2.5 PM | 13M6G7D | |
| 24E | 1857.5 - 1902.5 | 0.19 | 2.5 PM | 13M6W7D | |
| 24E | 1860.0 - 1900.0 | 0.234 | 2.5 PM | 18M6G7D | |
| 24E | 1860.0 - 1900.0 | 0.193 | 2.5 PM | 18M6W7D | |
| 27 | 1710.7 - 1754.3 | 0.24 | 2.5 PM | 1M10G7D | |
| 27 | 1710.7 - 1754.3 | 0.209 | 2.5 PM | 1M11W7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M75G7D | |
| 27 | 1711.5 - 1753.5 | 0.202 | 2.5 PM | 2M76W7D | |
| 27 | 1712.5 - 1752.5 | 0.237 | 2.5 PM | 4M52G7D | |
| 27 | 1712.5 - 1752.5 | 0.201 | 2.5 PM | 4M52W7D | |
| 27 | 1715.0 - 1750.0 | 0.236 | 2.5 PM | 9M08G7D | |
| 27 | 1715.0 - 1750.0 | 0.198 | 2.5 PM | 9M08W7D | |
| 27 | 1717.5 - 1747.5 | 0.235 | 2.5 PM | 13M5G7D | |
| 27 | 1717.5 - 1747.5 | 0.192 | 2.5 PM | 13M5W7D | |
| 27 | 1720.0 - 1745.0 | 0.224 | 2.5 PM | 18M5G7D | |
| 27 | 1720.0 - 1745.0 | 0.2 | 2.5 PM | 18M5W7D |
| CIIPC: Add a new antenna. CIIPC of adding WCDMA on AWS Band. Single Modular Approval. Output power is conducted. LTE supports 1.4/3/5/10/15/20 MHz BW modes in Band 2 and Band 4, 1.4/3/5/10 MHz BW modes in Band 12. This device is to be used in mobile or fixed applications only. Antenna gain including cable loss must not exceed 9.6 dBi of frequency band 699-716 MHz, 6 dBi of frequency band 1710-1755 MHz, 9 dBi of frequency band 1850-1910 MHz, 10.92 dBi of frequency band 824-849 MHz, for the purpose of satisfying the requirements of CFR 47 §2.1043 and §2.1091. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operated in conjunction with any antenna or transmitter. The final product operating with this transmitter must include operating instructions and antenna installation instructions, for end-users and installers to satisfy RF exposure compliance requirements. Compliance of this device in all final product configurations is the responsibility of the Grantee. Installation of this device into specific final products may require the submission of a Class II permissive change application containing data pertinent to RF Exposure, spurious emissions, ERP/EIRP, and host/module authentication, or new application if appropriate. This device contains functions that are not operational in U.S Territories. This filing is only applicable for US operations. |
| Mail To: |
