FCC ID XQW-FMAPR4400
WIFI+BT Module
by Fender Musical Instruments
Grantee Code: XQW Product Code: FMAPR4400
Latest application date: 2017-03-06
Device Images
FCC ID Device Details
| FCC ID | XQW-FMAPR4400 |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XQW |
| Product Code | FMAPR4400 |
| Applicant Business | Fender Musical Instruments 🇺🇸 |
| Related Domains |  fender.com |
| Equipment Class | WIFI+BT Module |
| Test Firm | Dongguan NTC Co.,Ltd., |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2017-03-06 |
| 2402-2480 MHz | Original Equipment | 2017-03-06 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| 15_F23BUUM13-W2 UserMan, r2 | Users Manual | 2017-03-06 | PDF 308.8 KB |
| 09_F23BUUM13-W2 IntPho | Internal Photos | 2017-03-06 | PDF 851.2 KB |
| 08_F23BUUM13-W2 ExtPho | External Photos | 2017-03-06 | PDF 852.3 KB |
| 06-07_F23BUUM13-W2 LabelSmpl-Loc | ID Label/Location Info | 2017-03-06 | PDF 940.8 KB |
| 17_F23BUUM13-W2 AntSpec,r1 | Operational Description | 2017-03-06 | PDF 79.5 KB |
| 10_F23BUUM13-W2 TSup | Test Setup Photos | 2017-03-06 | PDF 370.3 KB |
| 14_F23BUUM13-W2 TestRpt DSS, r2 | Test Report | 2017-03-06 | PDF 2.3 MB |
| 14_F23BUUM13-W2 TestRpt DTS BLE,r1 | Test Report | 2017-03-06 | PDF 2 MB |
| 14_F23BUUM13-W2 TestRpt DTS WIFI,r1 | Test Report | 2017-03-06 | PDF 2.6 MB |
| 18_F23BUUM13-W2 RFExp | RF Exposure Info | 2017-03-06 | PDF 114.5 KB |
| 12_F23BUUM13-W2 BlkDia Metadata only | Block Diagram | PDF 467 KB | |
| 13_F23BUUM13-W2 Schem Metadata only | Schematics | PDF 76.9 KB | |
| 11_F23BUUM13-W2 OpDes Metadata only | Operational Description | PDF 91.6 KB | |
| 16_F23BUUM13-W2 PartsLst Metadata only | Parts List/Tune Up Info | PDF 70.6 KB |
Application Information
| Application ID | l0euzRDWH+sipwyhdO4MJQ== |
|---|---|
| Final Action Date | 2017-03-06 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0002963429 |
| Model | FMAPR4400 |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DTS - Digital Transmission System |
| Device Description | WIFI+BT Module |
| Responsible Party | Larry Clauss, Principal Engineer - Compliance, lclauss@fender.com , 480-845-5203 |
| Test Firm | sunm lv sunm lv, Dongguan NTC Co.,Ltd.,, sunmlv@21cn.com  , 86-769-22022444 |
| TCB Email | joergkusig@eurofins.com  |
| TCB Scope | A4: UNII devices & low power transmitters using spread spectrum techniques |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Limited Single Modular Approval |
| Composite Device | Yes |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
| Grant Comments | Limited Modular Approval (due to lack of RF shielding). Power listed is conducted. This device supports 20 and 40MHz bandwidth operation. Compliance of this device in all final host configurations is the responsibility of the Grantee. OEM integrators and end-users must be provided with specific operating instructions for satisfying RF exposure compliance. OEM integrators are instructed to ensure that the end user has no manual instructions to remove or install the device. This module is approved for mobile applications only (minimum distance of 20cm to human bodies). |
