FCC ID XYN503A
BLE2IR Dongle
by ruwido austria GmbH
Grantee Code: XYN Product Code: 503A
Latest application date: 2016-07-13
Device Images
FCC ID Device Details
| FCC ID | XYN503A |
|---|---|
| Mirrors | fcc.id | gov | fccid.ai |
| Grantee Code | XYN |
| Product Code | 503A |
| Applicant Business | ruwido austria GmbH 🇦🇹 |
| Related Domains |  ruwido.com |
| Equipment Class | BLE2IR Dongle |
| Test Firm | CSA Group Bayern GmbH |
Operating Frequencies
| Frequency Range | Application Purpose | Final Action Date |
|---|---|---|
| 2402-2480 MHz | Original Equipment | 2016-07-13 |
Exhibits
| Document | Type | Available | File |
|---|---|---|---|
| User Manual | Users Manual | 2016-07-13 | PDF 202.4 KB |
| Internal Photos | Internal Photos | 2016-07-13 | PDF 417.2 KB |
| External Photos | External Photos | 2016-07-13 | PDF 374.4 KB |
| Label | ID Label/Location Info | 2016-07-13 | PDF 207.7 KB |
| Test Photos | Test Setup Photos | 2016-07-13 | PDF 581.5 KB |
| Test Report | Test Report | 2016-07-13 | PDF 1.9 MB |
| Agent Authorization | Cover Letter(s) | 2016-07-13 | PDF 72.6 KB |
| Confidentiality Request | Cover Letter(s) | 2016-07-13 | PDF 96.7 KB |
| RF Exposure | RF Exposure Info | 2016-07-13 | PDF 847.3 KB |
| Block Diagram Metadata only | Block Diagram | PDF 96.7 KB | |
| Schematics Metadata only | Schematics | PDF 573.9 KB | |
| Operation Description Metadata only | Operational Description | PDF 103 KB | |
| Parts List Metadata only | Parts List/Tune Up Info | PDF 25.5 KB |
Application Information
| Application ID | uphliBWB/mTktyXYvVN4Ng== |
|---|---|
| Final Action Date | 2016-07-13 |
| Application Purpose | Original Equipment |
| Applicant FRN | 0019360239 |
| Model | 503A |
| Frequency Range | 2402-2480 MHz |
| Equipment Class | DXX - Part 15 Low Power Communication Device Transmitter |
| Device Description | BLE2IR Dongle |
| Responsible Party | Rafael Jaburek, Project Manager, rafael.jaburek@ruwido.com , +0043-6216-4571-86 |
| Agent | CSA Bayern GmbH, bettina.stangl@csagroup.org  |
| Test Firm | Frank Scharnowski, CSA Group Bayern GmbH, frank.scharnowski@csagroup.org , 49-9424-9481-140 |
| TCB Email | hotline@acbcert.com  |
| TCB Scope | A2: Low Power Transmitters (except Spread Spectrum) and radar detectors operating above 1 GHz |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | Yes |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | No |
| Composite Part | No |
| Cognitive Radio | No |
| Authorization Waiver | No |
| Authorization Waiver Approved | No |
| Section 5301 Certification | Yes |
| Related OET Knowledge DataBase Inquiry | No |
Applications
| Application ID | Date | Purpose |
|---|---|---|
| uphliBWB/mTktyXYvVN4Ng== | 2016-07-13 | Original Equipment |
Equipment Authorization
| Frequency | Rules |
|---|---|
| 2402-2480 MHz | 15C |
Grants
TCB Grant - Application uphliBWB/mTktyXYvVN4Ng==
| TCB | GRANT OF EQUIPMENT AUTHORIZATION |
TCB |
| Certification | ||
| Issued Under the Authority of the | ||
| Federal Communications Commission | ||
| By: |
|
ACB, Inc. 6731 Whittier Avenue Suite C110 McLean, VA 22101 |
Date of Grant: 07/13/2016 Application Dated: 07/13/2016 |
| ruwido austria GmbH |
| Koestendorfer Strasse 8 |
| Neumarkt, 5202 Austria |
| Attention: Rafael Jaburek , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYN503A |
| Name of Grantee: | ruwido austria GmbH |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | BLE2IR Dongle |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
EAS Grant - Application uphliBWB/mTktyXYvVN4Ng==
| COPY |
FEDERAL COMMUNICATIONS COMMISSION WASHINGTON, D.C. 20554 GRANT OF EQUIPMENT AUTHORIZATION |
COPY |
| Certification |
|
ruwido austria GmbH Koestendorfer Strasse 8 P.O. Box , Neumarkt, 5202 Austria |
Date of Grant: 07/13/2016 Application Dated: 07/13/2016 |
| Attention: Rafael Jaburek , Project Manager |
| NOT TRANSFERABLE |
| EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below. |
| FCC IDENTIFIER: | XYN503A |
| Name of Grantee: | ruwido austria GmbH |
| Equipment Class: | Part 15 Low Power Communication Device Transmitter |
| Notes: | BLE2IR Dongle |
| Modular Type: | Does not apply |
| Grant Notes | FCC Rule Parts | Frequency Range (MHZ) | Output Watts | Frequency Tolerance | Emission Designator |
| 15C | 2402.0 - 2480.0 |
| Mail To: |
