503A BLE2IR Dongle Test Setup Photos - FCC ID XYN503A

FCC ID XYN503A

Test Photos

BLE2IR Dongle

by ruwido austria GmbH

Document preview loads when visible.

Document Details

FCC IDXYN503A
Document ID3060472
Document TypeTest Setup Photos
DescriptionTest Photos
Document TitleAllgemeiner Prüfbericht englisch
Applicantruwido austria GmbH
Equipment ClassBLE2IR Dongle
Product Code503A
Application IDuphliBWB/mTktyXYvVN4Ng==
Application PurposeOriginal Equipment
Application Date2016-07-13
Frequency Range2402-2480 MHz
FRN0019360239
Test FirmCSA Group Bayern GmbH
Certified ByBettina Stangl Team Lead GMA
Short-Term ConfidentialityNo
Long-Term ConfidentialityNo
Grant DeferralNo
Modular EquipmentDoes not apply
Composite DeviceNo
Composite PartNo
Submitted2016-07-13
Available2016-07-13
Created2016-06-29
Modified2016-06-29
Pages4
File TypeAdobe Acrobat PDF
File Size595451
File SHA-256ec59b0772d7ce1a3f0d7b84bcfadc2f99c6e4f4d6ae403a7df72f5760b6e49f0
PDF Metadata Authortkammerer
PDF Metadata Producertkammerer Microsoft® Word 2013
FCC.gov SourcesFCC.gov 3060472
