FCC ID XYOLM61

LTE Cat1 module

by Asiatelco Technologies Co.

Grantee Code: XYO   Product Code: LM61
Latest application date: 2016-06-13

Device Images

FCC ID XYOLM61 ID Label Location Info
ID Label Location Info

FCC ID Device Details

FCC IDXYOLM61
Mirrorsfcc.id | gov | fccid.ai
Grantee CodeXYO
Product CodeLM61
Applicant BusinessAsiatelco Technologies Co. 🇨🇳
Related Domains asiatelco.com
Equipment ClassLTE Cat1 module
Test FirmSGS Taiwan Ltd.

Operating Frequencies

Frequency RangeApplication PurposeFinal Action Date
779.5-784.5 MHzOriginal Equipment2016-06-13

Exhibits

DocumentTypeAvailableFile
User manualUsers Manual2016-07-28PDF 273.5 KB
Int photoInternal Photos2016-07-28PDF 133.3 KB
Ext photoExternal Photos2016-07-28PDF 220.9 KB
ID labelID Label/Location Info2016-06-13PDF 30.9 KB
Test setup photoTest Setup Photos2016-07-28PDF 493.6 KB
Test reportTest Report2016-06-13PDF 3.2 MB
Confidential request letterCover Letter(s)2016-06-13PDF 53.1 KB
Modular specificationsCover Letter(s)2016-06-13PDF 61.7 KB
POACover Letter(s)2016-06-13PDF 93.1 KB
MPERF Exposure Info2016-06-13PDF 161 KB
Block diagram Metadata onlyBlock DiagramPDF 48 KB
SCH Metadata onlySchematicsPDF 246.5 KB
Max allowable gain (OpDes) Metadata onlyOperational DescriptionPDF 150.9 KB
OpDes Metadata onlyOperational DescriptionPDF 135.8 KB
Part list Metadata onlyParts List/Tune Up InfoPDF 89.6 KB
Tune up procedure Metadata onlyParts List/Tune Up InfoPDF 59.7 KB

Application Information

Application IDn4yI0J/uaiamLxaZv+3b0Q==
Final Action Date2016-06-13
Application PurposeOriginal Equipment
Applicant FRN0019360338
ModelLM61
Frequency Range779.5-784.5 MHz
Equipment ClassTNB - Licensed Non-Broadcast Station Transmitter
Device DescriptionLTE Cat1 module
Responsible PartyRanran Zhou, Project Manager, certification@asiatelco.com , +86-21-51688806
Test FirmRyan Wang, SGS Taiwan Ltd., Ryan-ec.wang@sgs.com , +886-2-2299-3279
TCB EmailTCB@siemic.com
TCB ScopeB1: Commercial mobile radio services equipment in the following 47 CFR Parts 20, 22 (cellular), 24,25 (below 3 GHz) & 27
Short-Term ConfidentialityYes
Short-Term Confidentiality Date07/28/2016
Long-Term ConfidentialityYes
Grant DeferralNo
Modular EquipmentSingle Modular Approval
Composite DeviceNo
Composite PartNo
Cognitive RadioNo
Authorization WaiverNo
Authorization Waiver ApprovedNo
Section 5301 CertificationYes
Related OET Knowledge DataBase InquiryNo
Grant CommentsListed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance. Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Antenna gain of LTE band 4 must not exceed 1.34dBi and LTE band 13 not exceed 20.75dBi.

Applications

Application IDDatePurpose
n4yI0J/uaiamLxaZv+3b0Q==2016-06-13Original Equipment

Equipment Authorization

FrequencyOutputToleranceEmissionRules
779.5-784.5 MHz0.22399Hz4M49D7W27
779.5-784.5 MHz0.29389Hz4M51G7D27
782 MHz0.28449Hz9M00G7D27
782 MHz0.20469Hz9M00D7W27
1712.5-1752.5 MHz0.189714Hz4M49D7W27
1715-1750 MHz0.26314Hz9M00G7D27
1715-1750 MHz0.203214Hz9M00D7W27
1717.5-1747.5 MHz0.277314Hz13M5G7D27
1717.5-1747.5 MHz0.192314Hz13M5D7W27
1720-1745 MHz0.268514Hz18M0G7D27
1720-1745 MHz0.19114Hz18M0D7W27

Grants

TCB Grant - Application n4yI0J/uaiamLxaZv+3b0Q==

TCB GRANT OF EQUIPMENT
AUTHORIZATION		 TCB
Certification
Issued Under the Authority of the
Federal Communications Commission
By:

  Bureau Veritas Consumer Products Services, Inc.
775 Montague Expressway
Milpitas, CA 95035
 Date of Grant: 06/13/2016

Application Dated: 06/07/2016
Asiatelco Technologies Co.
289 Bisheng Road, Building 8, 3F,
Zhangjiang Hi-Tech Park, Pudong
Shanghai, 201204
China

Attention: Ranran Zhou , Project Manager

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  XYOLM61
Name of Grantee:  Asiatelco Technologies Co.
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: LTE Cat1 module
Modular Type: Single Modular
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
27 1712.5  -  1752.5 0.2661 14.0  Hz 4M51G7D
27 1712.5  -  1752.5 0.1897 14.0  Hz 4M49D7W
27 1715.0  -  1750.0 0.263 14.0  Hz 9M00G7D
27 1715.0  -  1750.0 0.2032 14.0  Hz 9M00D7W
27 1717.5  -  1747.5 0.2773 14.0  Hz 13M5G7D
27 1717.5  -  1747.5 0.1923 14.0  Hz 13M5D7W
27 1720.0  -  1745.0 0.2685 14.0  Hz 18M0G7D
27 1720.0  -  1745.0 0.191 14.0  Hz 18M0D7W
27 779.5  -  784.5 0.2938 9.0  Hz 4M51G7D
27 779.5  -  784.5 0.2239 9.0  Hz 4M49D7W
27 782.0  -  782.0 0.2844 9.0  Hz 9M00G7D
27 782.0  -  782.0 0.2046 9.0  Hz 9M00D7W

Listed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance.

Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Antenna gain of LTE band 4 must not exceed 1.34dBi and LTE band 13 not exceed 20.75dBi.


EAS Grant - Application n4yI0J/uaiamLxaZv+3b0Q==

COPY FEDERAL COMMUNICATIONS
COMMISSION
WASHINGTON, D.C. 20554

GRANT OF EQUIPMENT
AUTHORIZATION		 COPY
Certification

Asiatelco Technologies Co.
289 Bisheng Road, Building 8, 3F, Zhangjiang Hi-Tech Park, Pudong
Shanghai, 201204
China 		  Date of Grant: 06/13/2016

Application Dated: 06/07/2016

Attention: Ranran Zhou , Project Manager

NOT TRANSFERABLE
EQUIPMENT AUTHORIZATION is hereby issued to the named GRANTEE, and is VALID ONLY for the equipment identified hereon for use under the Commission's Rules and Regulations listed below.

FCC IDENTIFIER:  XYOLM61
Name of Grantee:  Asiatelco Technologies Co.
Equipment Class: Licensed Non-Broadcast Station Transmitter
Notes: LTE Cat1 module
Modular Type: Single Modular
Grant Notes  FCC Rule Parts Frequency
Range (MHZ) 		Output
Watts 		Frequency
Tolerance 		Emission
Designator
27 1712.5  -  1752.5 0.2661 14.0  Hz 4M51G7D
27 1712.5  -  1752.5 0.1897 14.0  Hz 4M49D7W
27 1715.0  -  1750.0 0.263 14.0  Hz 9M00G7D
27 1715.0  -  1750.0 0.2032 14.0  Hz 9M00D7W
27 1717.5  -  1747.5 0.2773 14.0  Hz 13M5G7D
27 1717.5  -  1747.5 0.1923 14.0  Hz 13M5D7W
27 1720.0  -  1745.0 0.2685 14.0  Hz 18M0G7D
27 1720.0  -  1745.0 0.191 14.0  Hz 18M0D7W
27 779.5  -  784.5 0.2938 9.0  Hz 4M51G7D
27 779.5  -  784.5 0.2239 9.0  Hz 4M49D7W
27 782.0  -  782.0 0.2844 9.0  Hz 9M00G7D
27 782.0  -  782.0 0.2046 9.0  Hz 9M00D7W

Listed Power is maximum conducted RF output power. The antenna(s) used for this transmitter must be installed to provide a separation distance of at least 20 cm from all persons and must not be co-located or operating in conjunction with any other antenna or transmitter. OEM integrators must be provided with antenna installation instructions and operation conditions for satisfying RF exposure compliance.

Only those antenna(s) tested with the device or similar antenna(s) with equal or lesser gain may be used with this transmitter. Antenna gain of LTE band 4 must not exceed 1.34dBi and LTE band 13 not exceed 20.75dBi.
