Document Details
| FCC ID | Z9G-EDF32 |
|---|---|
| Document ID | 3143085 |
| Document Type | Internal Photos |
| Description | Internal Photos |
| Applicant | Edifier International Limited |
| Equipment Class | Active Monitor Speaker |
| Product Code | EDF32 |
| Application ID | 9TJZ/mqKTzH8dPJYUkQ+fQ== |
| Application Purpose | Original Equipment |
| Application Date | 2016-09-22 |
| Frequency Range | 2402-2480 MHz |
| FRN | 0021277140 |
| Test Firm | Accurate Technology Co., Ltd. |
| Certified By | Dingkun Shen |
| Short-Term Confidentiality | No |
| Long-Term Confidentiality | No |
| Grant Deferral | No |
| Modular Equipment | Does not apply |
| Composite Device | Yes |
| Composite Part | No |
| Submitted | 2016-09-22 |
| Available | 2016-09-22 |
| Created | 2016-09-21 |
| Modified | 2016-09-21 |
| Pages | 9 |
| File Type | Adobe Acrobat PDF |
| File Size | 2029588 |
| File SHA-256 | bc1f7acb424b9f3878bad5a6c81decd33a4ba097771903b52b4ddbd8d263e49b |
| PDF Metadata Author | fengt |
| PDF Metadata Producer | Microsoft® Word 2010 Microsoft® Word 2010 |
| FCC.gov Sources | FCC.gov 3143085, FCC.gov 3143072 |
