Page 25 of 48
Report No.: 180709006RFC-2
5.6 NUMBER OF HOPPING CHANNEL
Test Requirement:
Test Method:
Limit:
Test Procedure:
FCC 47 CFR Part 15 Subpart C Section 15.247(b)(1)
ANSI C63.10-2013 Section 7.8.3
Frequency hopping systems in the 2400 – 2483.5 MHz band shall use at least 15 nonoverlapping channels.
Remove the antenna from the EUT and then connect a low loss RF cable from the
antenna port to the spectrum analyzer.
Use the following spectrum analyzer settings:
a)
b)
c)
d)
e)
f)
g)
Test Setup:
Instruments Used:
Test Mode:
Test Results:
Test Data:
Span: The frequency band of operation. Depending on the number of channels the
device supports, it may be necessary to divide the frequency range of operation
across multiple spans, to allow the individual channels to be clearly seen.
RBW < 30% of the channel spacing or the 20 dB bandwidth, whichever is smaller.
VBW ≥ RBW.
Sweep: Auto.
Detector function: Peak.
Trace: Max hold.
Allow the trace to stabilize.
Note: The cable loss and attenuator loss were offset into measure device as an
amplitude offset.
Refer to section 4.5.3 for details.
Refer to section 3 for details
Hopping Frequencies Transmitter mode
Pass
Type of Modulation
Number of Hopping Channel
GFSK
79
79
79
π/4 DQPSK
8DPSK
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 26 of 48
Report No.: 180709006RFC-2
The test plot as follows:
GFSK_Low End Spectrum Channel Hopping Plot
GFSK_High End Spectrum Channel Hopping Plot
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 27 of 48
Report No.: 180709006RFC-2
π/4 DQPSK_Low End Spectrum Channel Hopping Plot
π/4 DQPSK_High End Spectrum Channel Hopping Plot
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 28 of 48
Report No.: 180709006RFC-2
8DPSK_Low End Spectrum Channel Hopping Plot
8DPSK_High End Spectrum Channel Hopping Plot
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 29 of 48
Report No.: 180709006RFC-2
5.7 DWELL TIME
Test Requirement:
Test Method:
Limit:
Test Procedure:
FCC 47 CFR Part 15 Subpart C Section 15.247(a)(1)
ANSI C63.10-2013 Section 7.8.4
Frequency hopping systems in the 2400-2483.5 MHz band shall use at least 15
channels. The average time of occupancy on any channel shall not be greater than 0.4
seconds within a period of 0.4 seconds multiplied by the number of hopping channels
employed.
Remove the antenna from the EUT and then connect a low loss RF cable from the
antenna port to the spectrum analyzer.
Use the following spectrum analyzer settings:
a)
b)
c)
d)
e)
f)
Test Setup:
Instruments Used:
Test Mode:
Test Results:
Test Data:
Span = zero span, centered on a hopping channel
RBW shall be ≤ channel spacing and where possible RBW should be set >> 1 / T,
where T is the expected dwell time per channel.
Sweep = As necessary to capture the entire dwell time per hopping channel; where
possible use a video trigger and trigger delay so that the transmitted signal starts a
little to the right of the start of the plot. The trigger level might need slight adjustment
to prevent triggering when the system hops on an adjacent channel; a second plot
might be needed with a longer sweep time to show two successive hops on a
channel.
Detector function = peak
Trace = max hold
Use the marker-delta function to determine the dwell time
Note: The cable loss and attenuator loss were offset into measure device as an
amplitude offset.
Refer to section 4.5.3 for details.
Refer to section 3 for details
Hopping Frequencies Transmitter mode
Pass
Type of
Modulation
Test
Frequency
GFSK
2441MHz
π/4 DQPSK
2441MHz
8DPSK
2441MHz
Packet
1-DH1
1-DH3
1-DH5
2-DH1
2-DH3
2-DH5
3-DH1
3-DH3
3-DH5
Pulse Width
ms
0.370
1.632
2.881
0.379
1.632
2.877
0.381
1.631
2.883
Number of
Pulses in 3.16
seconds
189.000
102.000
60.000
195.000
86.000
65.000
200.000
93.000
61.000
Dwell Time
Limit
ms
ms
69.93
166.46
172.86
73.91
140.35
187.01
76.20
151.68
175.86
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
400
400
400
400
400
400
400
400
400
Page 30 of 48
Report No.: 180709006RFC-2
The test plot as follows:
Pulse Width
Number of Pulses in 3.16 Seconds
GFSK_1-DH1
GFSK_1-DH3
GFSK_1-DH5
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 31 of 48
Pulse Width
Report No.: 180709006RFC-2
Number of Pulses in 3.16 Seconds
π/4DQPSK_2-DH1
π/4DQPSK_2-DH3
π/4DQPSK_2-DH5
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 32 of 48
Pulse Width
Report No.: 180709006RFC-2
Number of Pulses in 3.16 Seconds
8DPSK_3-DH1
8DPSK_3-DH3
8DPSK_3-DH5
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 33 of 48
Report No.: 180709006RFC-2
5.8 CONDUCTED OUT OF BAND EMISSION
Test Requirement:
Test Method:
Limit:
Test Procedure:
FCC 47 CFR Part 15 Subpart C Section 15.247(d)
ANSI C63.10-2013 Section 6.10.4
In any 100kHz bandwidth outside the frequency bands in which the spread spectrum
intentional radiator in operating, the radio frequency power that is produced by the
intentional radiator shall be at least 20dB below that in the 100kHz bandwidth within the
band that contains the highest level of the desired power.
Remove the antenna from the EUT and then connect a low loss RF cable from the
antenna port to the spectrum analyzer.
Use the following spectrum analyzer settings:
Step 1:Measurement Procedure REF
a) Set instrument center frequency to 2400 MHz or 2483.5 MHz.
b) Wide enough to capture the peak level of the emission operating on the channel
closest to the band edge, as well as any modulation products that fall outside of the
authorized band of operation.
c) Set the RBW = 100 kHz.
d) Set the VBW ≥ 3 x RBW.
e) Detector = peak.
f) Sweep time = auto couple.
g) Sweep points ≥ 2 x Span/RBW
h) Trace mode = max hold.
i)
Allow the trace to stabilize.
j)
Set the marker on the emission at the band edge, or on the highest modulation
product outside of the band, if this level is greater than that at the band edge.
Enable the marker-delta function, and then use the marker-to-peak function to
move the marker to the peak of the in-band emission.
Step 2:Measurement Procedure OOBE
a) Set RBW = 100 kHz.
b) Set VBW ≥ 300 kHz.
c) Detector = peak.
d) Sweep = auto couple.
e) Trace Mode = max hold.
f) Allow trace to fully stabilize.
g) Use the peak marker function to determine the maximum amplitude level.
Test Setup:
Instruments Used:
Test Mode:
Test Results:
Test Data:
Note: The cable loss and attenuator loss were offset into measure device as an
amplitude offset.
Refer to section 4.5.3 for details.
Refer to section 3 for details
Hopping Frequencies Transmitter mode
Pass
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 34 of 48
Report No.: 180709006RFC-2
The test plot as follows:
GFSK
In-Band Reference Level
Out of Band Emission
Lowest Channel
Middle Channel
Highest Channel
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 35 of 48
Report No.: 180709006RFC-2
π/4DQPSK
In-Band Reference Level
Out of Band Emission
Lowest Channel
Middle Channel
Highest Channel
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 36 of 48
Report No.: 180709006RFC-2
8DPSK
In-Band Reference Level
Out of Band Emission
Lowest Channel
Middle Channel
Highest Channel
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 37 of 48
Hopping Lowest Channel
Report No.: 180709006RFC-2
Hopping Highest Channel
GFSK
π/4DQPSK
8DPSK
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 38 of 48
Report No.: 180709006RFC-2
5.9 RADIATED SPURIOUS EMISSIONS
FCC 47 CFR Part 15 Subpart C Section 15.205/15.209
ANSI C63.10-2013 Section 6.6.4.3
Test Requirement:
Test Method:
Receiver Setup:
Frequency
RBW
0.009 MHz-0.150 MHz
200/300 kHz
0.150 MHz -30 MHz
30 MHz-1 GHz
Above 1 GHz
9/10 kHz
100/120 kHz
1 MHz
Limits:
Spurious Emissions
0.009 MHz-0.490 MHz
Field strength
(microvolt/meter)
2400/F(kHz)
0.490 MHz-1.705 MHz
1.705 MHz-30 MHz
30 MHz-88 MHz
88 MHz-216 MHz
216 MHz-960 MHz
960MHz-1GHz
24000/F(kHz)
30
100
150
200
500
--40.0
43.5
46.0
54.0
--Quasi-peak
Quasi-peak
Quasi-peak
Quasi-peak
30
30
Above 1 GHz
500
54.0
Average
Frequency
Limit (dBµV/m )
Remark
--
--
Measurement
distance (m)
300
Remark:
1. The lower limit shall apply at the transition frequencies.
2. Emission level (dBuV/m) = 20 log Emission level (uV/m).
3. For frequencies above 1000 MHz, the field strength limits are based on average detector, however, the
peak field strength of any emission shall not exceed the maximum permitted average limits, specified
above by more than 20 dB under any condition of modulation.
Test Setup:
Refer to section 4.5.1 for details.
Test Procedures:
1. From 30 MHz to 1GHz test procedure as below:
1) The EUT was placed on the top of a rotating table 0.8 meters above the ground at a 3 meter semi-anechoic
camber. The table was rotated 360 degrees to determine the position of the highest radiation.
2) The EUT was set 3 meters away from the interference-receiving antenna, which was mounted on the top
of a variable-height antenna tower.
3) The antenna height is varied from one meter to four meters above the ground to determine the maximum
value of the field strength. Both horizontal and vertical polarizations of the antenna are set to make the
measurement.
4) For each suspected emission, the EUT was arranged to its worst case and then the antenna was tuned
to heights from 1 meter to 4 meters (for the test frequency of below 30MHz, the antenna was tuned to
heights 1 meter) and the rota table table was turned from 0 degrees to 360 degrees to find the maximum
reading.
5) The test-receiver system was set to Peak Detect Function and Specified Bandwidth with Maximum Hold
Mode.
6) If the emission level of the EUT in peak mode was 10dB lower than the limit specified, then testing could
be stopped and the peak values of the EUT would be reported. Otherwise the emissions that did not have
10dB margin would be re-tested one by one using peak, quasi-peak or average method as specified and
then reported in a data sheet.
2. Above 1GHz test procedure as below:
1) Different between above is the test site, change from Semi- Anechoic Chamber to fully Anechoic Chamber
and change form table 0.8 meter to 1.5 meter( Above 18GHz the distance is 1 meter and table is 1.5
meter).
2) Test the EUT in the lowest channel ,middle channel, the Highest channel
3) The radiation measurements are performed in X, Y, Z axis positioning for Transmitting mode, and found
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 39 of 48
Report No.: 180709006RFC-2
the Y axis positioning which it is worse case.
4) Repeat above procedures until all frequencies measured was complete.
Equipment Used:
Refer to section 3 for details.
Test Result:
Pass
The measurement data as follows:
Radiated Emission Test Data (9 KHz ~ 30 MHz):
The amplitude of spurious emissions attenuated more than 20 dB below the permissible value is not required
to be report.
Radiated Emission Test Data (30 MHz ~ 1 GHz):
Worst-Case Configuration
Horizontal
No.
Frequency
(MHz)
Reading
(dBuV)
48.378
107.031
153.163
191.784
36.19
46.22
45.74
39.37
Correction
factor
(dB/m )
-19.56
-17.42
-16.62
-15.44
228.617
341.244
35.69
36.96
-13.57
-9.84
Result
(dBuV/m)
Limit
(dBuV/m)
Margin
(dB)
Remark
16.63
28.80
29.12
23.93
40.00
43.50
43.50
43.50
-23.37
-14.70
-14.38
-19.57
QP
QP
QP
QP
22.12
27.12
46.00
46.00
-23.88
-18.88
QP
QP
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 40 of 48
Report No.: 180709006RFC-2
Vertical
No.
Frequency
(MHz)
Reading
(dBuV)
39.182
75.321
45.87
39.79
Correction
factor
(dB/m )
-16.12
-19.41
102.612
182.578
250.486
318.088
47.11
46.18
30.83
29.23
-17.41
-15.43
-12.37
-10.53
Result
(dBuV/m)
Limit
(dBuV/m)
Margin
(dB)
Remark
29.75
20.38
40.00
40.00
-10.25
-19.62
QP
QP
29.70
30.75
18.46
18.70
43.50
43.50
46.00
46.00
-13.80
-12.75
-27.54
-27.30
QP
QP
QP
QP
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 41 of 48
Report No.: 180709006RFC-2
Radiated Emission Test Data (Above 1GHz):
Lowest Channel:
No.
Frequency
(MHz)
4804.00
7206.00
4804.00
7206.00
Result
(dBuV/m)
44.90
48.72
43.54
47.41
Limit (dBuV/m)
Margin (dB)
Detector
74.00
74.00
74.00
74.00
-29.10
-25.28
-30.46
-26.59
Peak
Peak
Peak
Peak
Limit (dBuV/m)
Margin (dB)
Detector
74.00
74.00
74.00
74.00
-30.48
-25.69
-30.19
-25.84
Peak
Peak
Peak
Peak
Limit (dBuV/m)
Margin (dB)
Detector
Antenna
Polaxis
Horizontal
Horizontal
Vertical
Vertical
Middle Channel:
No.
Frequency
(MHz)
4882.00
7323.00
4882.00
7323.00
Result
(dBuV/m)
43.52
48.31
43.81
48.16
Antenna
Polaxis
Horizontal
Horizontal
Vertical
Vertical
Highest Channel:
No.
Frequency
(MHz)
4960.00
7440.00
4960.00
7440.00
Result
(dBuV/m)
42.29
46.86
42.14
47.08
Antenna
Polaxis
Horizontal
Horizontal
Vertical
Vertical
74.00
-31.71
Peak
74.00
-27.14
Peak
74.00
-31.86
Peak
74.00
-26.92
Peak
Remark:
1. As shown in this section, for frequencies above 1GHz, the field strength limits are based on average limits.
However, the peak field strength of any emission shall not exceed the maximum permitted average limits
specified above by more than 20 dB under any condition of modulation. So, only the peak measurements were
shown in the report.
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 42 of 48
5.10
Report No.: 180709006RFC-2
BAND EDGE MEASUREMENTS (RADIATED)
Test Requirement: FCC 47 CFR Part 15 Subpart C Section 15.205/15.209
Test Method:
ANSI C63.10-2013 Section 6.6.4.3
Limits:
Radiated emissions which fall in the restricted bands, as defined in section 15.205(a), must also comply with
the radiated emission limits specified in section 15.209(a).
Frequency
Limit (dBµV/m @3m)
Remark
30 MHz-88 MHz
88 MHz-216 MHz
216 MHz-960 MHz
40.0
43.5
46.0
Quasi-peak Value
Quasi-peak Value
Quasi-peak Value
960 MHz-1 GHz
54.0
54.0
74.0
Quasi-peak Value
Average Value
Peak Value
Above 1 GHz
Test Setup:
Refer to section 4.5.1 for details.
Test Procedures:
Radiated band edge measurements at 2390 MHz and 2483.5 MHz were made with the unit transmitting in the
low end of the channel range and the high end closest to the restricted bands respectively. The emissions
were made on the 966 Semi-Chamber. Use (resolution bandwidth (RBW) = 1 MHz, video bandwidth (VBW) =
3 MHz for peak levels and RBW = 1 MHz and VBW = 10 Hz or 1/T for average levels).
1. Use radiated spurious emission test procedure described in clause 5.10. The transmitter output (antenna
port) was connected to the test receiver.
2. Set the PK and AV limit line.
3. Record the fundamental emission and emissions out of the band-edge.
4. Determine band-edge compliance as required.
Equipment Used:
Refer to section 3 for details.
Test Result:
Pass
The measurement data as follows:
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 43 of 48
Test Channel:
Frequency
(MHz)
2390.00
Lowest Channel
Peak level
(dBuv/m)
43.40
Test Channel:
Frequency
(MHz)
2390.00
Peak Limit
(dBuv/m)
74.00
Lowest Channel
Peak level
(dBuv/m)
48.49
Peak Limit
(dBuv/m)
74.00
Report No.: 180709006RFC-2
Ant. Polar. :
AV level
(dBuv/m)
34.16
Horizontal
AV Limit
(dBuv/m)
54.00
Ant. Polar. :
AV level
(dBuv/m)
34.11
Conclusion
Pass
Vertical
AV Limit
(dBuv/m)
54.00
Conclusion
Pass
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 44 of 48
Test Channel:
Frequency
(MHz)
2483.50
Test Channel:
Frequency
(MHz)
2483.50
Highest Channel
Peak level
(dBuv/m)
52.38
Peak Limit
(dBuv/m)
74.00
Highest Channel
Peak level
(dBuv/m)
50.44
Peak Limit
(dBuv/m)
74.00
Report No.: 180709006RFC-2
Ant. Polar. :
AV level
(dBuv/m)
44.69
Horizontal
AV Limit
(dBuv/m)
54.00
Ant. Polar. :
AV level
(dBuv/m)
42.23
Conclusion
Pass
Vertical
AV Limit
(dBuv/m)
54.00
Conclusion
Pass
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 45 of 48
5.11
Report No.: 180709006RFC-2
CONDUCTED EMISSION
Test Requirement:
Test Method:
Limits:
47 CFR Part 15C Section 15.207
ANSI C63.10-2013 Section 6.2
Limits (dB(μV)
Frequency range
(MHz)
Quasi-peak
Average
0,15 to 0,50
0,50 to 5
5 to 30
66 to 56
56
60
56 to 46
46
50
Remark:
1. The lower limit shall apply at the transition frequencies.
2. The limit decreases linearly with the logarithm of the frequency in the range 0.15 to 0.50 MHz.
Test Setup:
Refer to section 4.5.2 for details.
Test Procedures:
Test frequency range :150KHz-30MHz
1) The mains terminal disturbance voltage test was conducted in a shielded room.
2) The EUT was connected to AC power source through a LISN 1 (Line Impedance Stabilization Network)
which provides a 50Ω/50µH + 5Ω linear impedance. The power cables of all other units of the EUT were
connected to a second LISN 2, which was bonded to the ground reference plane in the same way as the
LISN 1 for the unit being measured. A multiple socket outlet strip was used to connect multiple power
cables to a single LISN provided the rating of the LISN was not exceeded.
3) The tabletop EUT was placed upon a non-metallic table 0.8m above the ground reference plane. And for
floor-standing arrangement, the EUT was placed on the horizontal ground reference plane,
4) The test was performed with a vertical ground reference plane. The rear of the EUT shall be 0.4 m from
the vertical ground reference plane. The vertical ground reference plane was bonded to the horizontal
ground reference plane. The LISN 1 was placed 0.8 m from the boundary of the unit under test and bonded
to a ground reference plane for LISNs mounted on top of the ground reference plane. This distance was
between the closest points of the LISN 1 and the EUT. All other units of the EUT and associated equipment
was at least 0.8 m from the LISN 2.
5) In order to find the maximum emission, the relative positions of equipment and all of the interface cables
must be changed according to ANSI C63.10 on conducted measurement.
Equipment Used:
Refer to section 3 for details.
Test Result:
Pass
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 46 of 48
Report No.: 180709006RFC-2
The measurement data as follows:
Quasi Peak and Average:
Mode: BT Link
Live Line
No.
Frequency
(MHz)
Reading
(dBuV)
0.168
0.168
1.356
1.356
23.20
39.30
19.79
35.69
Correction
factor
(dB )
10.18
10.18
10.28
10.28
3.796
17.00
3.796
27.60
Result
(dBuV)
Limit
(dBuV)
Margin
(dB)
Remark
33.38
49.48
30.07
45.97
55.08
65.08
46.00
56.00
-21.70
-15.60
-15.93
-10.03
Average
QP
Average
QP
10.41
27.41
46.00
-18.59
Average
10.41
38.01
56.00
-17.99
QP
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 47 of 48
Report No.: 180709006RFC-2
Neutral Line
No.
Frequency
(MHz)
Reading
(dBuV)
0.167
0.167
1.298
1.298
20.60
38.20
22.09
35.29
Correction
factor
(dB )
10.22
10.22
10.43
10.43
3.899
16.01
3.899
28.01
Result
(dBuV)
Limit
(dBuV)
Margin
(dB)
Remark
30.82
48.42
32.52
45.72
55.08
65.08
46.00
56.00
-24.26
-16.66
-13.48
-10.28
Average
QP
Average
QP
10.58
26.59
46.00
-19.41
Average
10.58
38.59
56.00
-17.41
QP
Remark:
1. An initial pre-scan was performed on the Phase and neutral lines with peak detector. Quasi-Peak and
Average measurement were performed at the frequencies with maximized peak emission were detected.
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Page 48 of 48
Report No.: 180709006RFC-2
APPENDIX 1 PHOTOS OF TEST SETUP
See test photos attached in Appendix 1 for the actual connections between Product and support equipment.
APPENDIX 2 PHOTOS OF EUT CONSTRUCTIONAL DETAILS
Refer to Appendix 2 for EUT external and internal photos.
*** End of Report ***
The test report is effective only with both signature and specialized stamp. The result(s) shown in this report refer
only to the sample(s) tested. Without written approval of UnionTrust, this report can’t be reproduced except in full.
Shenzhen UnionTrust Quality and Technology Co., Ltd.
Address: 16/F, Block A, Building 6, Baoneng Science and Technology Park, Qingxiang Road No.1, Longhua New District, Shenzhen, China
Tel: +86-755-28230888
Fax: +86-755-28230886
E-mail: info@uttlab.com
Http://www.uttlab.com
Download: X565 Mobile Phone Test Report FCC_Part_15.247EDR_Report_Part_2_Rev.1 SMT TELECOMM HK LIMITED
Mirror Download [FCC.gov]X565 Mobile Phone Test Report FCC_Part_15.247EDR_Report_Part_2_Rev.1 SMT TELECOMM HK LIMITED
Document ID3952449
Application ID4gTtMk22g4y7UnPPJoAvbA==
Document DescriptionFCC_Part_15.247EDR_Report_Part_2_Rev.1
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize364.89kB (4561125 bits)
Date Submitted2018-08-06 00:00:00
Date Available2018-08-06 00:00:00
Creation Date2018-08-03 16:44:36
Producing SoftwareMicrosoft® Word 2013
Document Lastmod2018-08-03 16:45:46
Document TitleFCC_Part_15.247EDR_Report_Part_2_Rev.1
Document CreatorMicrosoft® Word 2013
Document Author: kevin.liang

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Author                          : kevin.liang
Create Date                     : 2018:08:03 16:44:36+08:00
Modify Date                     : 2018:08:03 16:45:46+08:00
Tagged PDF                      : Yes
XMP Toolkit                     : Adobe XMP Core 5.4-c005 78.147326, 2012/08/23-13:03:03
Metadata Date                   : 2018:08:03 16:45:46+08:00
Creator Tool                    : Microsoft® Word 2013
Format                          : application/pdf
Creator                         : kevin.liang
Document ID                     : uuid:743f143b-94fc-4294-8fc7-2301d00f2a3a
Instance ID                     : uuid:1a34e1e9-885b-43dc-b45b-37cd1bcd66ee
Producer                        : Microsoft® Word 2013
Page Count                      : 24
