PCTEST ENGINEERING LABORATORY, INC.
7185 Oakland Mills Road, Columbia, MD 21046 USA
Tel. 410.290.6652 / Fax 410.290.6654
http://www.pctest.com
MEASUREMENT REPORT
FCC PART 15.407 / ISED RSS-247 UNII 802.11ax OFDMA
Applicant Name:
Samsung Electronics Co., Ltd.
129, Samsung-ro,
Yeongtong-gu, Suwon-si
Gyeonggi-do, 16677, Korea
Date of Testing:
10/31/2018-1/09/2019
Test Site/Location:
PCTEST Lab. Columbia, MD, USA
Test Report Serial No.:
1M1810250197-06.A3L
FCC ID:
A3LSMG975U
IC:
649E-SMG975U
APPLICANT:
Samsung Electronics Co., Ltd.
Application Type:
Model:
Additional Model(s):
HVIN:
EUT Type:
Frequency Range:
FCC Classification:
FCC Rule Part(s):
ISED Specification:
Test Procedure(s):
Certification
SM-G975U
SM-G975U1, SM-G975W, SM-G975XU
SM-G975W
Portable Handset
5180 – 5825MHz
Unlicensed National Information Infrastructure (UNII)
Part 15 Subpart E (15.407)
RSS-247 Issue 2
ANSI C63.10-2013, KDB 789033 D02 v02r01,
KDB 648474 D03 v01r04, KDB 662911 D01 v02r01
This equipment has been shown to be capable of compliance with the applicable technical standards as indicated in the measurement
report and was tested in accordance with the measurement procedures specified in ANSI C63.10-2013 and KDB 789033 D02 v02r01. Test
results reported herein relate only to the item(s) tested.
I attest to the accuracy of data. All measurements reported herein were performed by me or were made under my supervision and are
correct to the best of my knowledge and belief. I assume full responsibility for the completeness of these measurements and vouch for the
qualifications of all persons taking them.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 1 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
T A B L E
O F
C O N T E N T S
INTRODUCTION........................................................................................................................................................................................ 4
1.1
Scope ........................................................................................................................................................................................... 4
1.2
PCTEST Test Location ................................................................................................................................................................ 4
1.3
Test Facility / Accreditations ........................................................................................................................................................ 4
PRODUCT INFORMATION ....................................................................................................................................................................... 5
2.1
Equipment Description ................................................................................................................................................................. 5
2.2
Device Capabilities....................................................................................................................................................................... 5
2.3
Test Configuration ........................................................................................................................................................................ 8
2.4
EMI Suppression Device(s)/Modifications ................................................................................................................................... 8
DESCRIPTION OF TESTS ........................................................................................................................................................................ 9
3.1
Evaluation Procedure ................................................................................................................................................................... 9
3.2
AC Line Conducted Emissions .................................................................................................................................................... 9
3.3
Radiated Emissions ................................................................................................................................................................... 10
3.4
Environmental Conditions .......................................................................................................................................................... 10
ANTENNA REQUIREMENTS .................................................................................................................................................................. 11
MEASUREMENT UNCERTAINTY........................................................................................................................................................... 12
TEST EQUIPMENT CALIBRATION DATA .............................................................................................................................................. 13
TEST RESULTS ...................................................................................................................................................................................... 14
7.1
Summary .................................................................................................................................................................................... 14
7.2
26dB Bandwidth Measurement – 802.11ax OFDMA ................................................................................................................. 15
7.3
6dB Bandwidth Measurement – 802.11ax OFDMA ................................................................................................................... 64
7.4
UNII Output Power Measurement – 802.11ax OFDMA ............................................................................................................. 83
7.5
Maximum Power Spectral Density – 802.11ax OFDMA .......................................................................................................... 103
7.6
Radiated Spurious Emission Measurements – Above 1GHz ................................................................................................... 396
7.6.1
SISO Antenna-1 Radiated Spurious Emission Measurements .................................................................................... 399
7.6.2
SISO Antenna-2 Radiated Spurious Emission Measurements .................................................................................... 421
7.6.3
MIMO Radiated Spurious Emission Measurements .................................................................................................... 443
7.6.4
SISO Antenna-1 Radiated Band Edge Measurements (20MHz BW) .......................................................................... 465
7.6.5
SISO Antenna-1 Radiated Band Edge Measurements (40MHz BW) .......................................................................... 470
7.6.6
SISO Antenna-1 Radiated Band Edge Measurements (80MHz BW) .......................................................................... 475
7.6.7
SISO Antenna-2 Radiated Band Edge Measurements (20MHz BW) .......................................................................... 480
7.6.8
SISO Antenna-2 Radiated Band Edge Measurements (40MHz BW) .......................................................................... 485
7.6.9
SISO Antenna-2 Radiated Band Edge Measurements (80MHz BW) .......................................................................... 490
7.6.10
MIMO Radiated Band Edge Measurements (20MHz BW) ......................................................................................... 495
7.6.11
MIMO Radiated Band Edge Measurements (40MHz BW) ......................................................................................... 500
7.6.12
MIMO Radiated Band Edge Measurements (80MHz BW) ......................................................................................... 505
7.7
Radiated Spurious Emissions Measurements – Below 1GHz ................................................................................................. 510
C O N C L U S I O N .............................................................................................................................................................................. 516
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 2 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
MEASUREMENT REPORT
UNII Band
Channel
Bandwidth
(MHz)
2A
2C
2A
2C
2A
2C
20
40
80
ANT1
Tx Frequency
(MHz)
5180 - 5240
5260 - 5320
5500 - 5720
5745 - 5825
5190 - 5230
5270 - 5310
5510 - 5710
5755 - 5795
5210
5290
5530 - 5690
5775
Max.
Power
(mW)
MIMO
Max.
Power
(dBm)
Max.
Power
(mW)
Max.
Power
(dBm)
Max.
Power
(mW)
Max.
Power
(dBm)
36.392
15.61
39.174
15.93
38.107
15.81
37.411
15.73
24.491
13.89
24.889
13.96
24.717
13.93
24.946
13.97
19.724
12.95
19.679
12.94
19.861
12.98
19.143
12.82
EUT Overview
39.264
38.994
39.355
38.107
24.155
24.660
24.660
24.831
19.770
18.836
19.770
19.409
15.94
15.91
15.95
15.81
13.83
13.92
13.92
13.95
12.96
12.75
12.96
12.88
75.683
78.163
74.302
74.817
47.315
48.529
49.091
49.774
38.905
37.931
39.355
38.019
18.79
18.93
18.71
18.74
16.75
16.86
16.91
16.97
15.90
15.79
15.95
15.80
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
ANT2
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 3 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
INTRODUCTION
1.1
Scope
Measurement and determination of electromagnetic emissions (EMC) of radio frequency devices including
intentional and/or unintentional radiators for compliance with the technical rules and regulations of the Federal
Communications Commission and the Innovation, Science and Economic Development Canada.
1.2
PCTEST Test Location
These measurement tests were conducted at the PCTEST Engineering Laboratory, Inc. facility located at 7185
Oakland Mills Road, Columbia, MD 21046. The measurement facility is compliant with the test site requirements
specified in ANSI C63.4-2014.
1.3
Test Facility / Accreditations
Measurements were performed at PCTEST Engineering Lab located in Columbia, MD 21046, U.S.A.
•
PCTEST is an ISO 17025-2005 accredited test facility under the American Association for Laboratory
Accreditation (A2LA) with Certificate number 2041.01 for Specific Absorption Rate (SAR), Hearing Aid
Compatibility (HAC) testing, where applicable, and Electromagnetic Compatibility (EMC) testing for FCC and
Innovation, Science, and Economic Development Canada rules.
•
PCTEST TCB is a Telecommunication Certification Body (TCB) accredited to ISO/IEC 17065-2012 by A2LA
(Certificate number 2041.03) in all scopes of FCC Rules and ISED Standards (RSS).
•
PCTEST facility is a registered (2451B) test laboratory with the site description on file with ISED.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 4 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
PRODUCT INFORMATION
2.1
Equipment Description
The Equipment Under Test (EUT) is the Samsung Portable Handset FCC ID: A3LSMG975U. The test data
contained in this report pertains only to the emissions due to the EUT’s UNII transmitter.
Test Device Serial No.: 0505M, 0218M, 0193M, 0181M, 0543M
2.2
Device Capabilities
This device contains the following capabilities:
800/850/1900 CDMA/EvDO Rev0/A, 1x Advanced (BC0, BC1, BC10), 850/1900 GSM/GPRS/EDGE,
850/1700/1900 WCDMA/HSPA, Multi-band LTE, 802.11b/g/n/ax WLAN, 802.11a/n/ac/ax UNII, Bluetooth (1x, EDR,
LE), NFC, ANT+
Band 1
Band 2A
Ch.
Band 2C
Ch.
Frequency (MHz)
36
42
48
5180
52
5260
100
5500
149
5745
5210
56
5280
120
5600
157
5785
5240
64
5320
144
5720
165
5825
Table 2-1. 802.11a / 802.11n / 802.11ac / 802.11ax (20MHz) Frequency / Channel Operations
Frequency (MHz)
Ch.
Band 3
Frequency (MHz)
Ch.
Frequency (MHz)
Band 1
Band 2A
Band 2C
Band 3
Ch.
Frequency
(MHz)
Ch.
Frequency
(MHz)
Frequency
(MHz)
Frequency
(MHz)
38
46
5190
5230
54
62
5270
5310
Ch.
Ch.
102
5510
151
5755
118
5590
159
5795
142
5710
Table 2-2. 802.11n / 802.11ac / 802.11ax (40MHz BW) Frequency / Channel Operations
Band 1
Band 2A
Ch.
Frequency (MHz)
Ch.
Frequency (MHz)
42
5210
58
5290
Band 2C
Ch.
Frequency (MHz)
Band 3
Ch.
Frequency (MHz)
106
5530
155
138
5690
Table 2-3. 802.11ac / 802.11ax (80MHz BW) Frequency / Channel Operations
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
5775
Approved by:
Quality Manager
Page 5 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Notes:
1. 5GHz NII operation is possible in 20MHz, and 40MHz, and 80MHz channel bandwidths. The maximum
achievable duty cycles for all modes were determined based on measurements performed on a spectrum
analyzer in zero-span mode with RBW = 8MHz, VBW = 50MHz, and detector = peak per the guidance of Section
B)2)b) of ANSI C63.10-2013 and KDB 789033 D02 v02r01. The RBW and VBW were both greater than 50/T,
where T is the minimum transmission duration, and the number of sweep points across T was greater than 100.
The duty cycles are as follows:
Maximum Achievable Duty Cycles
Duty Cycle [%]
802.11 Mode/Band
5GHz
ANT1
ANT2
MIMO
98.8
98.9
98.7
n (HT20)
98.7
98.7
98.7
ac (HT20)
98.8
98.7
97.5
n (HT40)
97.4
97.3
98.1
ac (HT40)
97.1
97.3
98.1
ac (HT80)
94.4
94.5
98.0
ax (HE80)
99.2
99.9
99.5
Table 2-4. Measured Duty Cycles
2. The device employs MIMO technology. Below are the possible configurations.
SISO
SDM
ANT1
ANT2
ANT1
ANT2




11a




11n (20/40MHz)




11ac (20/40/80MHz)




11ax (20/40/80MHz)
Table 2-5. Frequency / Channel Operations
WiFi Configurations
5GHz
CDD
ANT1




ANT2




= Support ;  = NOT Support
SISO = Single Input Single Output
SDM = Spatial Diversity Multiplexing – MIMO function
CDD = Cyclic Delay Diversity - 2Tx Function
3. This device supports simultaneous transmission operation, which allows for two SISO channels to operate
independent of one another in the 2.4GHz (WLAN & BT) and 5GHz bands simultaneously on each antenna.
The following tables show the worst case configurations determined during testing. The data for these
configurations is contained in this test report. The BT + 5GHz case is not considered as worst case since the
BT power is lower than the 2.4GHz WLAN power.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 6 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Configuration 1: ANT1 transmitting in 2.4GHz mode and ANT2 in 5GHz mode
Description
2.4 GHz Emission
5 GHz Emission
2437
1Mbps
802.11b
165
5825
MCS0
802.11ac
Antenna
Channel
Operating Frequency (MHz)
Data Rate (Mbps)
Mode
Table 2-6. Config-1 (ANT1 2.4GHz & ANT2 5GHz)
Configuration 2: ANT1 transmitting in 5GHz mode and ANT2 in 2.4GHz mode
Description
2.4 GHz Emission
5 GHz Emission
2437
1Mbps
802.11b
144
5720
MCS0
802.11ac
Antenna
Channel
Operating Frequency (MHz)
Data Rate (Mbps)
Mode
Table 2-7. Config-2 (ANT1 5GHz & ANT2 2.4GHz)
Configuration 3: ANT1 and ANT2 both transmitting in 2.4GHz and 5GHz modes simultaneously
Description
2.4 GHz Emission
5 GHz Emission
1, 2
2412
MCS0
802.11n
1, 2
144
5720
MCS8
802.11ac
Antenna
Channel
Operating Frequency (MHz)
Data Rate (Mbps)
Mode
Table 2-8. Config-3 (ANT1 MIMO & ANT2 MIMO)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 7 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
2.3
Test Configuration
The EUT was tested per the guidance of KDB 789033 D02 v02r01. ANSI C63.10-2013 was used to reference the
appropriate EUT setup for radiated spurious emissions testing and AC line conducted testing. See Sections 7.8 for
AC line conducted emissions test setups, Section 7.6 and 7.7 for radiated emissions test setups, and Section 7.2,
7.3, 7.4, and 7.5 for conducted emissions test setups.
This device supports wireless charging capability and, thus, is subject to the test requirements of KDB 648474 D03
v01r04. Additional radiated spurious emission measurements were performed with the EUT lying on an authorized
wireless charging pad (WCP) FCC ID: EP-N5100 while operating under normal conditions in a simulated call or
data transmission configuration. The worst case radiated emissions data is shown in this report.
2.4
EMI Suppression Device(s)/Modifications
No EMI suppression device(s) were added and/or no modifications were made during testing.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 8 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
DESCRIPTION OF TESTS
3.1
Evaluation Procedure
The measurement procedures described in the American National Standard of Procedures for Compliance Testing
of Unlicensed Wireless Devices (ANSI C63.10-2013) and the guidance provided in KDB 789033 D02 v02r01 were
used in the measurement of the EUT.
Deviation from measurement procedure……………………………………...……………..........................None
3.2
AC Line Conducted Emissions
The line-conducted facility is located inside a 10'x16'x9' shielded enclosure. The shielded enclosure is manufactured
by ETS Lindgren RF Enclosures. The shielding effectiveness of the shielded room is in accordance with MIL-Std285 or NSA 65-5. A 1m x 1.5m wooden table 80cm high is placed 40cm away from the vertical wall and 80cm away
from the sidewall of the shielded room. Two 10kHz-30MHz, 50Ω/50µH Line-Impedance Stabilization Networks
(LISNs) are bonded to the shielded room floor. Power to the LISNs is filtered by external high-current high-insertion
loss power line filters. The external power line filter is an ETS Lindgren Model LPRX-4X30 (100dB Attenuation,
14kHz-18GHz) and the two EMI/RFI filters are ETS Lindgren Model LRW-2030-S1 (100dB Minimum Insertion Loss,
14kHz – 10GHz). These filters attenuate ambient signal noise from entering the measurement lines. These filters
are also bonded to the shielded enclosure.
The EUT is powered from one LISN and the support equipment is powered from the second LISN. If the EUT is a
DC-powered device, power will be derived from the source power supply it normally will be powered from and this
supply line(s) will be connected to the second LISN. All interconnecting cables more than 1 meter were shortened
to a 1 meter length by non-inductive bundling (serpentine fashion) and draped over the back edge of the test table.
All cables were at least 40cm above the horizontal reference groundplane. Power cables for support equipment
were routed down to the second LISN while ensuring that that cables were not draped over the second LISN.
Sufficient time for the EUT, support equipment, and test equipment was allowed in order for them to warm up to
their normal operating condition. The RF output of the LISN was connected to the spectrum analyzer and
exploratory measurements were made to determine the frequencies producing the maximum emission from the
EUT. The spectrum was scanned from 150kHz to 30MHz with a spectrum analyzer. The detector function was set
to peak mode for exploratory measurements while the bandwidth of the analyzer was set to 10kHz. The EUT,
support equipment, and interconnecting cables were arranged and manipulated to maximize each emission. Once
the worst case emissions have been identified, the one EUT cable configuration/arrangement and mode of
operation that produced these emissions is used for final measurements on the same test site. The analyzer is set
to CISPR quasi-peak and average detectors with a 9kHz resolution bandwidth for final measurements.
Line conducted emissions test results are shown in Section 7.8. The EMI Receiver mode of the Agilent MXE was
used to perform AC line conducted emissions testing.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 9 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
3.3
Radiated Emissions
The radiated test facilities consisted of an indoor 3 meter semi-anechoic chamber used for final measurements and
exploratory measurements, when necessary. The measurement area is contained within the semi-anechoic
chamber which is shielded from any ambient interference. The test site inside the chamber is a 6m x 5.2m elliptical,
obstruction-free area in accordance with Figure 5.7 of Clause 5 in ANSI C63.4-2014. Absorbers are arranged on
the floor between the turn table and the antenna mast in such a way so as to maximize the reduction of reflections
for measurements above 1GHz. An 80cm tall test table made of Styrodur is placed on top of the turn table. For
measurements above 1GHz, an additional Styrodur pedestal is placed on top of the test table to bring the total table
height to 1.5m.
For all measurements, the spectrum was scanned through all EUT azimuths and from 1 to 4 meter receive antenna
height using a broadband antenna from 30MHz up to the upper frequency shown in 15.33 depending on the highest
frequency generated or used in the device or on which the device operates or tunes. For frequencies above 1GHz,
linearly polarized double ridge horn antennas were used. For frequencies below 30MHz, a calibrated loop antenna
was used. When exploratory measurements were necessary, they were performed at 1 meter test distance inside
the semi-anechoic chamber using broadband antennas, broadband amplifiers, and spectrum analyzers to
determine the frequencies and modes producing the maximum emissions. Sufficient time for the EUT, support
equipment, and test equipment was allowed in order for them to warm up to their normal operating condition. The
test set-up was placed on top of the 1 x 1.5 meter table. The EUT, support equipment, and interconnecting cables
were arranged and manipulated to maximize each emission. Appropriate precaution was taken to ensure that all
emissions from the EUT were maximized and investigated. The system configuration, mode of operation, turntable
azimuth, and receive antenna height was noted for each frequency found.
Final measurements were made in the semi-anechoic chamber using calibrated, linearly polarized broadband and
horn antennas. The test setup was configured to the setup that produced the worst case emissions. The spectrum
analyzer was set to investigate all frequencies required for testing to compare the highest radiated disturbances
with respect to the specified limits. The turntable containing the EUT was rotated through 360 degrees and the
height of the receive antenna was varied 1 to 4 meters and stopped at the azimuth and height producing the
maximum emission. Each emission was maximized by changing the orientation of the EUT through three orthogonal
planes and changing the polarity of the receive antenna, whichever produced the worst-case emissions.
All radiated measurements are performed in a chamber that meets the site requirements per ANSI C63.4-2014.
Additionally, radiated emissions below 30MHz are also validated on an Open Area Test Site to assert correlation
with the chamber measurements per the requirements of KDB 474788 D01.
3.4
Environmental Conditions
The temperature is controlled within range of 15oC to 35oC. The relative humidity is controlled within range of 10%
to 75%. The atmospheric pressure is monitored within the range 86-106kPa (860-1060mbar).
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 10 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
ANTENNA REQUIREMENTS
Excerpt from §15.203 of the FCC Rules/Regulations:
“An intentional radiator antenna shall be designed to ensure that no antenna other than that furnished by the
responsible party can be used with the device. The use of a permanently attached antenna or of an antenna that
uses a unique coupling to the intentional radiator shall be considered sufficient to comply with the provisions of this
section.”
•
The antennas of the EUT are permanently attached.
•
There are no provisions for connection to an external antenna.
Conclusion:
The EUT complies with the requirement of §15.203.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 11 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
MEASUREMENT UNCERTAINTY
The measurement uncertainties shown below were calculated in accordance with the requirements of
ANSI C63.10-2013. All measurement uncertainty values are shown with a coverage factor of k = 2 to indicate a
95% level of confidence. The measurement uncertainty shown below meets or exceeds the UCISPR measurement
uncertainty values specified in CISPR 16-4-2 and, thus, can be compared directly to specified limits to determine
compliance.
Contribution
Expanded Uncertainty (±dB)
Conducted Bench Top
Measurements
1.13
Line Conducted Disturbance
3.09
Radiated Disturbance (<1GHz)
4.98
Radiated Disturbance (>1GHz)
5.07
Radiated Disturbance (>18GHz)
5.09
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 12 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
TEST EQUIPMENT CALIBRATION DATA
Test Equipment Calibration is traceable to the National Institute of Standards and Technology (NIST).
Measurements antennas used during testing were calibrated in accordance to the requirements of ANSI C63.52017.
Manufacturer
Model
WL25-1
Agilent
N9020A
Agilent
N9030A
Anritsu
MA2411B
Anritsu
ML2495A
Com-Power
AL-130
COM-Power
PAM-103
Emco
3115
Emco
3116
ETS-Lindgren
3816/2NM
Huber + Suhner Sucoflex 102A
Pasternack
NMLC-2
Rohde & Schwarz
ESU26
Rohde & Schwarz
ESU40
Rohde & Schwarz SFUNIT-Rx
Rohde & Schwarz SFUNIT-Rx
Rohde & Schwarz
TS-PR26
Rohde & Schwarz
TS-PR40
Seekonk
NC-100
Sunol
DRH-118
Sunol
JB5
Description
Cal Date
Cal Interval
Conducted Cable Set (25GHz)
MXA Signal Analyzer
PXA Signal Analyzer (44GHz)
Pulse Power Sensor
Power Meter
9kHz - 30MHz Loop Antenna
Pre-Amplifier (1-1000MHz)
Horn Antenna (1-18GHz)
Horn Antenna (18 - 40GHz)
Line Impedance Stabilization Network
40GHz Radiated Cable Set
Line Conducted Emissions Cable (NM)
EMI Test Receiver (26.5GHz)
EMI Test Receiver (40GHz)
Shielded Filter Unit
Shielded Filter Unit
18-26.5 GHz Pre-Amplifier
26.5-40 GHz Pre-Amplifier
Torque Wrench
Horn Antenna (1-18GHz)
Bi-Log Antenna (30M - 5GHz)
1/23/2018
1/24/2018
5/25/2018
10/30/2018
10/21/2018
10/10/2017
9/17/2018
3/28/2018
6/7/2018
12/27/2016
1/23/2018
1/23/2018
5/21/2018
8/9/2018
6/18/2018
6/25/2018
1/24/2018
1/24/2018
12/28/2017
8/11/2017
4/19/2018
Annual
Annual
Annual
Annual
Annual
Biennial
Annual
Biennial
Triennial
Biennial
Annual
Annual
Annual
Annual
Annual
Annual
Annual
Annual
Annual
Biennial
Biennial
Cal Due
Serial Number
1/23/2019
WL25-1
1/24/2019 US46470561
5/25/2019 MY52350166
10/30/2019
846215
10/21/2019
941001
10/10/2019
121034
9/17/2019
441119
3/28/2020
9704-5182
6/7/2021
9203-2178
12/27/2018
114451
1/23/2019
251425001
1/23/2019
NMLC-2
5/21/2019
100342
8/9/2019
100348
6/18/2019
102134
6/25/2019
102133
1/24/2019
100040
1/24/2019
100037
12/28/2018
N/A
8/11/2019
A050307
4/19/2020
A051107
Table 6-1. Annual Test Equipment Calibration Schedule
Note:
For equipment listed above that has a calibration date or calibration due date that falls within the test date range,
care was taken to ensure that this equipment was used after the calibration date and before the calibration due
date.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 13 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
TEST RESULTS
7.1
Summary
Company Name:
FCC ID:
FCC Classification:
FCC Part
Section(s)
Samsung Electronics Co., Ltd.
A3LSMG975U
Unlicensed National Information Infrastructure (UNII)
RSS
Section(s)
Test Description
Test Limit
Test
Condition
Test
Result
Reference
N/A
RSS-Gen [6.6]
26dB Bandwidth
N/A
PASS
Section 7.2
15.407(e)
RSS-Gen [6.6]
6dB Bandwidth
>500kHz(5725-5850MHz)
PASS
Section 7.3
15.407 (a.1.iv),
(a.2), (a.3)
RSS-247 [6.2]
Maximum Conducted
Output Power
PASS
Section 7.4
15.407 (a.1.iv),
(a.2), (a.3)
RSS-247 [6.2]
Maximum Power
Spectral Density
PASS
Section 7.5
15.407(h)
RSS-247 [6.3]
Dynamic Frequency
Selection
See DFS Test Report
PASS
See DFS
Test Report
15.407(b.1), (2),
(3), (4)
RSS-247 [6.2]
Undesirable Emissions
Undesirable emissions must meet the
limits detailed in 15.407(b) (RSS-247
[6.2])
PASS
Section 7.6
PASS
Section 7.6,
7.7
PASS
See UNII
Test Report
15.205,
15.407(b.1), (4),
(5), (6)
RSS-Gen [8.9]
15.407
RSS-Gen [8.8]
Maximum conducted powers must
meet the limits detailed in 15.407 (a)
(RSS-247 [6.2])
Maximum power spectral density must
meet the limits detailed in 15.407 (a)
(RSS-247 [6.2])
General Field Strength
Limits (Restricted Bands
and Radiated Emission
Limits)
AC Conducted
Emissions 150kHz –
30MHz
Emissions in restricted bands must
meet the radiated limits detailed in
15.209 (RSS-Gen [8.9])
< FCC 15.207 (RSS-Gen [8.8]) limits
CONDUCTED
RADIATED
LINE
CONDUCTED
Table 7-1. Summary of Test Results
Notes:
1.)
2.)
3.)
4.)
5.)
6.)
7.)
8.)
All channels, modes, and modulations/data rates were investigated among all UNII bands. The test results shown in the following
sections represent the worst case emissions.
The analyzer plots shown in this section were all taken with a correction table loaded into the analyzer. The correction table was
used to account for the losses of the cables and attenuators used as part of the system to connect the EUT to the analyzer at all
frequencies of interest.
All antenna port conducted emissions testing was performed on a test bench with the antenna port of the EUT connected to the
spectrum analyzer through calibrated cables and attenuators.
For conducted spurious emissions, automated test software was used to measure emissions and capture the corresponding plots
necessary to show compliance. The measurement software utilized is PCTEST “UNII Automation,” Version 4.6.
For radiated band edge, automated test software was used to measure emissions and capture the corresponding plots necessary to
show compliance. The measurement software utilized is PCTEST “Chamber Automation,” Version 0.2.16.
Per RSS-247 Section 6.2.3, transmission on channels which overlap the 5600-5650 MHz is prohibited. This device operates under
these frequencies only under the control of a certified master device and does not support active scanning on these channels. This
device does not transmit any beacons or initiate any transmissions in UNII Bands 2A or 2C.
802.11ax OFDMA testing was performed for all signal tone configurations as specified by the 802.11ax standard. Worst case results
are determined and reported per the guidance provided at the October 2018 TCB Workshop.
Only one RU index could be selected at a time so no contiguous or non-contiguous RU's were considered for testing.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 14 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
7.2
26dB Bandwidth Measurement – 802.11ax OFDMA
RSS-Gen [6.2]
Test Overview and Limit
The bandwidth at 26dB down from the highest in-band spectral density is measured with a spectrum analyzer
connected to the antenna terminal while the EUT is operating at its maximum duty cycle, at its maximum power
control level, as defined in ANSI C63.10-2013 and KDB 789033 D02 v02r01, and at the appropriate frequencies.
The spectrum analyzer’s bandwidth measurement function is configured to measure the 26dB bandwidth.
The 26dB bandwidth is used to determine the conducted power limits.
Test Procedure Used
ANSI C63.10-2013 – Section 12.4
KDB 789033 D02 v02r01 – Section C
Test Settings
1. The signal analyzers’ automatic bandwidth measurement capability was used to perform the 26dB
bandwidth measurement. The “X” dB bandwidth parameter was set to X = 26. The automatic bandwidth
measurement function also has the capability of simultaneously measuring the 99% occupied bandwidth.
The bandwidth measurement was not influenced by any intermediate power nulls in the fundamental
emission.
2. RBW = approximately 1% of the emission bandwidth
3. VBW > 3 x RBW
4. Detector = Peak
5. Trace mode = max hold
Test Setup
The EUT and measurement equipment were set up as shown in the diagram below.
Figure 7-1. Test Instrument & Measurement Setup
Test Notes
The 26dB Bandwidth measurement for each channel was measured with the RU index showing the highest
conducted power.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 15 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-1 26 dB Bandwidth Measurements (26 Tones)
Measured 26dB
Bandwidth
[MHz]
5180
36
ax (20MHz)
26T
MCS0
19.45
5200
40
ax (20MHz)
26T
MCS0
19.55
5240
48
ax (20MHz)
26T
MCS0
19.84
5190
38
ax (40MHz)
26T
MCS0
19.52
5230
46
ax (40MHz)
26T
MCS0
19.50
5210
42
ax (80MHz)
26T
MCS0
19.26
5260
52
ax (20MHz)
26T
MCS0
19.00
5280
56
ax (20MHz)
26T
MCS0
19.54
5320
64
ax (20MHz)
26T
MCS0
20.08
5270
54
ax (40MHz)
26T
MCS0
19.89
5310
62
ax (40MHz)
26T
MCS0
22.06
5290
58
ax (80MHz)
26T
MCS0
21.14
5500
100
ax (20MHz)
26T
MCS0
19.13
5600
120
ax (20MHz)
26T
MCS0
19.80
5720
144
ax (20MHz)
26T
MCS0
20.09
5510
102
ax (40MHz)
26T
MCS0
18.75
5590
118
ax (40MHz)
26T
MCS0
19.28
5710
142
ax (40MHz)
26T
MCS0
19.86
5530
106
ax (80MHz)
26T
MCS0
21.65
5610
122
ax (80MHz)
26T
MCS0
20.53
5690
138
ax (80MHz)
26T
MCS0
19.32
Table 7-2. Conducted Bandwidth Measurements SISO ANT1 (26 Tones)
Band 2C
Band 2A
Band 1
Frequency Channel
802.11 Mode Tones
[MHz]
No.
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Data Rate
[Mbps]
Approved by:
Quality Manager
Page 16 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-1. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 36)
Plot 7-2. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 40)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 17 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-3. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 48)
Plot 7-4. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 38)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 18 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-5. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 46)
Plot 7-6. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 42)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 19 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-7. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 52)
Plot 7-8. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 56)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 20 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-9. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 64)
Plot 7-10. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 54)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 21 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-11. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 62)
Plot 7-12. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 58)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 22 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-13. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 100)
Plot 7-14. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 120)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 23 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-15. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 144)
Plot 7-16. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 102)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 24 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-17. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 118)
Plot 7-18. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 142)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 25 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-19. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 106)
Plot 7-20. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 122)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 26 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-21. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 138)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 27 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-1 26 dB Bandwidth Measurements (242 Tones)
Measured 26dB
Bandwidth
[MHz]
21.72
5180
36
ax (20MHz)
242T
MCS0
5200
40
ax (20MHz)
242T
MCS0
21.56
5240
48
ax (20MHz)
242T
MCS0
21.56
5260
52
ax (20MHz)
242T
MCS0
21.49
5280
56
ax (20MHz)
242T
MCS0
21.76
5320
64
ax (20MHz)
242T
MCS0
21.62
5500
100
ax (20MHz)
242T
MCS0
21.49
5600
120
ax (20MHz)
242T
MCS0
21.45
5720
144
ax (20MHz)
242T
MCS0
21.54
Table 7-3. Conducted Bandwidth Measurements SISO ANT1 (242 Tones)
Band 2C Band 2A Band 1
Frequency Channel
Data Rate
802.11 Mode Tones
[MHz]
No.
[Mbps]
Plot 7-22. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 36)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 28 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-23. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 40)
Plot 7-24. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 48)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 29 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-25. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 52)
Plot 7-26. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 56)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 30 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-27. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 64)
Plot 7-28. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 100)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 31 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-29. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 120)
Plot 7-30. 26dB Bandwidth Plot SISO ANT1 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 144)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 32 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-1 26 dB Bandwidth Measurements (484 Tones)
Measured 26dB
Bandwidth
[MHz]
5190
38
ax (40MHz) 484T
MCS0
40.11
5230
46
ax (40MHz) 484T
MCS0
39.76
5270
54
ax (40MHz) 484T
MCS0
39.68
5310
62
ax (40MHz) 484T
MCS0
40.22
5510
102
ax (40MHz) 484T
MCS0
40.02
5590
118
ax (40MHz) 484T
MCS0
40.35
5710
142
ax (40MHz) 484T
MCS0
40.25
Table 7-4. Conducted Bandwidth Measurements SISO ANT1 (484 Tones)
802.11
Mode
Tones
Data Rate
[Mbps]
Band 2C
Band Band
2A
Frequency Channel
[MHz]
No.
Plot 7-31. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 1) – Ch. 38)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 33 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-32. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 1) – Ch. 46)
Plot 7-33. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 2A) – Ch. 54)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 34 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-34. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 2A) – Ch. 62)
Plot 7-35. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 102)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 35 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-36. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 118)
Plot 7-37. 26dB Bandwidth Plot SISO ANT1 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 142)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 36 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-1 26 dB Bandwidth Measurements (996 Tones)
802.11
Mode
Tones
Data Rate
[Mbps]
Measured 26dB
Bandwidth
[MHz]
5210
42
ac (80MHz)
996T
MCS0
80.76
5290
58
ac (80MHz)
996T
MCS0
80.63
Band 2C
Band Band
2A
Frequency Channel
[MHz]
No.
5530
106
80.74
ac (80MHz) 996T
MCS0
5610
122
ac (80MHz) 996T
MCS0
81.26
5690
138
ac (80MHz) 996T
MCS0
80.83
Table 7-5. Conducted Bandwidth Measurements SISO ANT1 (996 Tones)
Plot 7-38. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 996 Tones (UNII Band 1) – Ch. 42)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 37 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-39. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 996 Tones (UNII Band 2A) – Ch. 58)
Plot 7-40. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 106)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 38 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-41. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 122)
Plot 7-42. 26dB Bandwidth Plot SISO ANT1 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 138)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 39 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-2 26 dB Bandwidth Measurements (26 Tones)
Measured 26dB
Bandwidth
[MHz]
5180
36
ax (20MHz)
26T
MCS0
19.74
5200
40
ax (20MHz)
26T
MCS0
19.68
5240
48
ax (20MHz)
26T
MCS0
19.75
5190
38
ax (40MHz)
26T
MCS0
21.52
5230
46
ax (40MHz)
26T
MCS0
18.76
5210
42
ax (80MHz)
26T
MCS0
19.25
5260
52
ax (20MHz)
26T
MCS0
19.68
5280
56
ax (20MHz)
26T
MCS0
19.73
5320
64
ax (20MHz)
26T
MCS0
19.67
5270
54
ax (40MHz)
26T
MCS0
18.72
5310
62
ax (40MHz)
26T
MCS0
18.82
5290
58
ax (80MHz)
26T
MCS0
19.26
5500
100
ax (20MHz)
26T
MCS0
18.23
5600
120
ax (20MHz)
26T
MCS0
18.04
5720
144
ax (20MHz)
26T
MCS0
18.20
5510
102
ax (40MHz)
26T
MCS0
18.89
5590
118
ax (40MHz)
26T
MCS0
18.92
5710
142
ax (40MHz)
26T
MCS0
18.89
5530
106
ax (80MHz)
26T
MCS0
19.32
5610
122
ax (80MHz)
26T
MCS0
18.84
5690
138
ax (80MHz)
26T
MCS0
19.28
Table 7-6. Conducted Bandwidth Measurements SISO ANT2 (26 Tones)
Band 2C
Band 2A
Band 1
Frequency Channel
802.11 Mode
[MHz]
No.
Tones
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Data Rate
[Mbps]
Approved by:
Quality Manager
Page 40 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-43. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 36)
Plot 7-44. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 40)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 41 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-45. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 48)
Plot 7-46. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 38)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 42 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-47. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 46)
Plot 7-48. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 26 Tones (UNII Band 1) – Ch. 42)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 43 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-49. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 52)
Plot 7-50. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 56)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 44 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-51. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 64)
Plot 7-52. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 54)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 45 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-53. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 62)
Plot 7-54. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 26 Tones (UNII Band 2A) – Ch. 58)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 46 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-55. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 100)
Plot 7-56. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 120)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 47 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-57. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 144)
Plot 7-58. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 102)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 48 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-59. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 118)
Plot 7-60. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 142)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 49 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-61. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 106)
Plot 7-62. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 122)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 50 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-63. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 26 Tones (UNII Band 2C) – Ch. 138)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 51 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-2 26 dB Bandwidth Measurements (242 Tones)
Measured 26dB
Bandwidth
[MHz]
5180
36
ax (20MHz)
242T
MCS0
21.20
5200
40
ax (20MHz)
242T
MCS0
21.18
5240
48
ax (20MHz)
242T
MCS0
20.91
5260
52
ax (20MHz)
242T
MCS0
21.14
5280
56
ax (20MHz)
242T
MCS0
21.17
5320
64
ax (20MHz)
242T
MCS0
21.30
21.11
5500
100
ax (20MHz)
242T
MCS0
5600
120
ax (20MHz)
242T
MCS0
20.89
5720
144
ax (20MHz)
242T
MCS0
21.41
Table 7-7. Conducted Bandwidth Measurements SISO ANT2 (242 Tones)
Band 2C Band 2A Band 1
Frequency Channel
Data Rate
802.11 Mode Tones
[MHz]
No.
[Mbps]
Plot 7-64. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 36)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 52 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-65. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 40)
Plot 7-66. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 1) – Ch. 48)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 53 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-67. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 52)
Plot 7-68. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 56)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 54 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-69. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2A) – Ch. 64)
Plot 7-70. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 100)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 55 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-71. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 120)
Plot 7-72. 26dB Bandwidth Plot SISO ANT2 (20MHz BW 802.11ax – 242 Tones (UNII Band 2C) – Ch. 144)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 56 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-2 26 dB Bandwidth Measurements (484 Tones)
Measured 26dB
Bandwidth
[MHz]
5190
38
40.11
ax (40MHz)
484T
MCS0
39.76
5230
46
ax (40MHz)
484T
MCS0
5270
54
ax (40MHz)
484T
MCS0
39.68
5310
62
ax (40MHz)
484T
MCS0
40.22
5510
102
40.02
ax (40MHz)
484T
MCS0
5590
118
40.35
ax (40MHz)
484T
MCS0
5710
142
40.25
ax (40MHz)
484T
MCS0
Table 7-8. Conducted Bandwidth Measurements SISO ANT2 (484 Tones)
Band 2C
Band Band
2A
Frequency Channel
Data Rate
802.11 Mode Tones
[MHz]
No.
[Mbps]
Plot 7-73. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 1) – Ch. 38)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 57 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-74. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 1) – Ch. 46)
Plot 7-75. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 2A) – Ch. 54)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 58 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-76. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 2A) – Ch. 62)
Plot 7-77. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 102)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 59 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-78. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 118)
Plot 7-79. 26dB Bandwidth Plot SISO ANT2 (40MHz BW 802.11ax – 484 Tones (UNII Band 2C) – Ch. 142)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 60 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
SISO Antenna-2 26 dB Bandwidth Measurements (996 Tones)
Band 2C
Band Band
2A
Frequency Channel
802.11 Mode
[MHz]
No.
Tones
Data Rate
[Mbps]
Measured 26dB
Bandwidth
[MHz]
5210
42
ax (80MHz)
996T
MCS0
80.61
5290
58
ax (80MHz)
996T
MCS0
80.49
5530
106
ax (80MHz)
996T
MCS0
80.98
5610
122
ax (80MHz)
996T
MCS0
80.96
5690
138
ax (80MHz)
996T
MCS0
80.71
Table 7-9. Conducted Bandwidth Measurements SISO ANT2 (996 Tones)
Plot 7-80. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 996 Tones (UNII Band 1) – Ch. 42)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 61 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-81. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 996 Tones (UNII Band 2A) – Ch. 58)
Plot 7-82. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 106)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 62 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Plot 7-83. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 122)
Plot 7-84. 26dB Bandwidth Plot SISO ANT2 (80MHz BW 802.11ax – 996 Tones (UNII Band 2C) – Ch. 138)
MEASUREMENT REPORT
(CERTIFICATION)
FCC ID: A3LSMG975U
Test Report S/N:
Test Dates:
EUT Type:
1M1810250197-06.A3L
10/31/2018-1/09/2019
Portable Handset
Approved by:
Quality Manager
Page 63 of 516
© 2019 PCTEST Engineering Laboratory, Inc.
V 8.8 11/19/2018
All rights reserved. Unless otherwise specified, no part of this report may be reproduced or utilized in any part, form or by any means, electronic or mechanical, including photocopying and
microfilm, without permission in writing from PCTEST Engineering Laboratory, Inc. If you have any questions about this international copyright or have an enquiry about obtaining additional
rights to this report or assembly of contents thereof, please contact INFO@PCTEST.COM.
Download: SMG975U Multi-band GSM/EDGE/CDMA/UMTS/LTE Phone with Bluetooth, WLAN, RFID and ANT+ Test Report UNII OFDMA  1 Samsung Electronics Co Ltd
Mirror Download [FCC.gov]SMG975U Multi-band GSM/EDGE/CDMA/UMTS/LTE Phone with Bluetooth, WLAN, RFID and ANT+ Test Report UNII OFDMA  1 Samsung Electronics Co Ltd
Document ID4156009
Application IDRcF/EvmEMNc4kHPr8aPMmg==
Document DescriptionUNII OFDMA Test Report 1
Short Term ConfidentialNo
Permanent ConfidentialNo
SupercedeNo
Document TypeTest Report
Display FormatAdobe Acrobat PDF - pdf
Filesize444.02kB (5550292 bits)
Date Submitted2019-01-31 00:00:00
Date Available2019-02-01 00:00:00
Creation Date2019-01-31 12:00:54
Producing SoftwareAdobe PDF Library 19.10.96
Document Lastmod2019-01-31 12:04:19
Document TitleUNII OFDMA Test Report 1
Document CreatorAcrobat PDFMaker 19 for Word

Source Exif Data [exif.tools]:
File Type                       : PDF
File Type Extension             : pdf
MIME Type                       : application/pdf
PDF Version                     : 1.6
Linearized                      : No
Create Date                     : 2019:01:31 12:00:54-05:00
Creator                         : Acrobat PDFMaker 19 for Word
Modify Date                     : 2019:01:31 12:04:19-05:00
Has XFA                         : No
Tagged PDF                      : Yes
XMP Toolkit                     : Adobe XMP Core 5.6-c015 84.159810, 2016/09/10-02:41:30
Metadata Date                   : 2019:01:31 12:04:19-05:00
Creator Tool                    : Acrobat PDFMaker 19 for Word
Format                          : application/pdf
Document ID                     : uuid:290fab80-546e-4737-91bc-ca33e9383e92
Instance ID                     : uuid:29eb6edc-a0e7-4d95-bddd-42bd2ba8c029
Producer                        : Adobe PDF Library 19.10.96
Page Count                      : 63
